Baker MM2P User manual

Model MM2P
Max-Min
Thermometer
Instruction Manual
BAKER
INSTRUMENTS
YEAR
WARRANTY
GARANTIE
D’UN AN
YEAR
WARRANTY
GARANTIE
D’UN AN
1
1
1
1
1
1
1
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

2
Features
• Pushbutton reset releases limit markers
• Thermometer registers highest and lowest readings from last setting
• Permacolor mercury-free thermometer
A Max/Min thermometer records highest and lowest temperatures.
A “U” shaped tube holds red spirit. As the temperature increases, the
liquid expands, forcing the red spirit up the maximum scale. When the
temperature falls, the liquid contracts, and the red spirit follows it back up
the minimum scale. Two black markers record changes in temperature.
Specifications
Temperature Range: -40 to 120°F (-40 to 50°C)
Dimensions: 8 x 2.19 x 0.75" (203.2 x 55.6 x 19.1mm)
Instructions
The markers are held in position by a magnet in the back of the case.
The Max/Min temperatures are read at the top point of the markers.
The current temperature can be read at the bottom of each red
spirit column.
Note: The minimum scale is inverted with the lower temperatures above
the high ones. Press the center button to reset the Max/Min readings.
Bubbles in the capillary will disappear if the thermometer is put on
a heater.
Should the red spirit column separate, the thermometer must be shaken
to unite the red spirit. If one of the black Max/Min markers disappear,
press the button during the shaking process, and it will appear again.
Do not mount or place the thermometer in direct sunlight.
For service, repairs or calibration as well as product info on this or any other
Baker product, contact Baker Instruments.
www.calcert.com [e-mail]1.888.610.7664 0
