BAKFlip VP Assembly instructions

RAM BOX
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly. Call 844-779-8986 Mon - Fri
8:30 am - 7 pm EST or email [email protected]
RAM BOX HARDWARE
•
Front cover mounting plate
(left & right)
•Prop rod swiel mounting bracket
•Prop rod to lock cover open
•Prop rod retainer clip
•Cover latching plate
•Track mounting bracket
•Front drain cup (left & right)
•Rear tailgate drain cap
(left & right)
•Adhesive promoter packet
(not shown)
•Bulkhead seal (not shown)
•Rail seals (not shown)
34
Apply provided adhesive
promoter (wipes) to top edge
of the aluminum rail and tape
seal to top inner edge, the
rubber has a bump that goes
to the inside.
1
Remove tie
downs from
rail. Don’t worry
they will be
re-installed later.
Front (cab) Rear (tailgate)
6.5’ bed
5.5’ bed
2
Unclip and
remove plug
from rail.
Install the provided cab/
bulkhead seal (weather strip).
Wipe surface with isopropyl
alcohol and let flash dry
before applying tape.
PARTS INCLUDED IN YOUR KIT
•1 x Hard folding cover assembly
•3 x D Shaped cab bumpers
(taped to cover)
•1 x Bulkhead seal
(¾ x ¾ x truck width)
•2 x Black drain tubes
1 HARDWARE BAG
•2 x Elevator bolt (w-large
flat head)
•4 x Rubber washers
•2 x Large flat washers
•2 x Lock washers
•2 x Star knobs (thumb screws)
•2 x Buckle ends
•4 x Machine screws
•4 x Threaded posts
BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 844-779-8986 • bakindustries.com Part# 318A0030 Rev. A

Insert the large flat bolt with the supplied rubber
washer through the front panel and silver slotted
bracket underneath. Repeat on other side.
5
Slide in
mounting
plates from
the end.
6
Trim
away
excess
flush
with
rail.
7
Mount the slotted cover
mounting plate in the
front as far forward as
possible.The top edge
of the plate aligns with
the rubber seal. Then
reinstall tiedown.
8
11
Set the cover in the folded position on the BakFlip
rails towards the front of cab.
10
The small panel
faces forward,
toward the cab and
folds down over the
silver brackets.The
front panel must
sit just inside the
bulkhead rail with
the seal resting on
top of the rail. Fold
the panel down and
align it so it is set-
ting squarely on the
rails and align the
mounting holes with
the silver slotted
brackets on the rails.
9
Before mounting the cover on truck, using a screwdriver
install the two buckle ends into pre-drilled holes on the front
header with the provided machine screws and threaded posts.
DO NOT use a screw gun, securely tighten by hand only.
IMPORTANT
BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 844-779-8986 • bakindustries.com Part# 318A0030 Rev. A

13
14
Mount cover with elevator bolt, rubber washer, flat washer,
lock washer and star knob in order. Center cover in the bed
opening and tighten.
Install prop rod
swivel mount
aprox 17 in. from
bulkhead so rod
swivels into the
slide lock with
some clearance.
The U shape
faces up.
15
16 17
Make sure
the latch
brackets are
in position
where they
will clear the
other hard-
ware like the
slide lock on
the cover.
18
Attached the prop rod retaining clip to the Ram Box rail
where it will meet the prop rod when rotated down.
Attach drain caps and drain hoses at each end. The
larger drain cap goes towards the cab and the smaller
caps installs towards the tailgate.
19
Install remaining
brackets where each
latch meets the rail.
The latch plate should
not touch the bottom
of the cover and should
latch when closed.
Cab bumpers attach on the
very top edge of the panel
facing the cab. The two
outer cab bumpers should
be 3 inches in from the
panel edge to prevent rail
interference when closed.
If your truck has a slider
window, the center
bumper should be cut
in two pieces and go
on each side of the
slider to prevent
direct contact.
The large flat bolt goes down through the front panel
on each side. Underneath the cover, the order of
washers is as follows: rubber washer first, then large
flat stainless washer, then the lock washer, and finally
the 5 star finger knob as shown to the left.
12
BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 844-779-8986 • bakindustries.com Part# 318A0030 Rev. A

STORAGE
POSITION
FOR CLIP
IMPORTANT
BAKFlip safe operation and use
IMPORTANT NOTICE
While driving, cover must be completely at and secure with all latches
in the closed position OR completely folded up (all panels) and secured at
the cab. DO NOT DRIVE with cover partially opened.
Tonneau Cover Positions While Operating Vehicle
Prior to vehicle operation, tonneau cover MUST be properly secured.
CLOSED POSITION
All panels must be closed and FULLY LATCHED to tonneau side rail.
All panels must be flat and latches engaged
FOLDED UP POSITION
To drive with your cover in the folded up position, simply make use of the
tie down straps and buckles provided with your cover. Ensure BOTH buckle
clips are fully inserted into the buckle ends located on the front header panel
of the cover and adjust the straps to ensure the cover is secure during
vehicle operation. The clips should be secured in the storage position,
as shown in Figure 1, when not in use.
FLIPPED UP POSITION
A) Fold the cover open and lift it until its vertical or
past 90 degrees towards your truck cab. Then release
the prop rod that is attached to your rail. Fold the
prop rod over and position it firmly against the
vertical plate on the underside of your cover.
Then slide the prop rod locks downwards
and tighten the knobs to lock into position.
Do this on both sides of the cover.
B) Your cover should be firmly in
position with little to no movement
once the prop rods are locked.
FOLDED UP POSITION
FLIPPED UP: B
FLIPPED UP: A
FIGURE 1
BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 844-779-8986 • bakindustries.com Part# 318A0030 Rev. A

1st
2nd
THEN
Tail Panel Operation
TO CLOSE THE TAILGATE PANEL
zWARNING – to avoid damage, always shut tailgate before
closing cover. DO NOT shut your tailgate when the rear panel
of your cover in closed.
TO RAISE THE TAILGATE PANEL
zOpen the tailgate and reach under the panel for the cable at the
ends of the panel housing.
zPull down on either cable to release both rear latches with one
hand while lifting the panel with the other hand.
EXCEPTION - BAKFlip MX4 offer’s a universal tailgate seal
which allows the tailgate to close with the cover up or down.
DO NOT ATTEMPT TO DRIVE WITH THE TAIL PANEL
IN THE PARTIALLY OPEN POSITION!
Additional Important Operating Tips
zTonneau cover MUST be free of foreign material including snow and ice
before opening panels.
zDo NOT tow your vehicle from the rear with the tonneau on your truck.
zDo NOT operate vehicle with objects on top of cover.
FAILURE TO FOLLOW THESE CAUTIONS MAY RESULT IN
SEVERE DAMAGE AND WILL VOID YOUR WARRANTY!
Remove any snow or foreign
matter before folding cover.
Do NOT tow your vehicle from the
rear with this cover on your truck.
BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 844-779-8986 • bakindustries.com Part# 318A0030 Rev. A
