Balcrank BOBCAT 130 Series Instruction Manual

®
BOBCAT™130 SERIES
1.3:1 Ratio Pump
Multi-Purpose Transfer
Models:
1110-005 General Lube
1110-006 General Lube
1110-008 General Lube (w/bung adapter)
1160-002 Antifreeze
1160-003 Antifreeze (w/bung adapter)
1160-006 Antifreeze
SERVICE BULLETIN SB1078
Revision C 09/10
Thoroughly read and understand this manual before
installing, operating or servicing this equipment.
OPERATION, INSTALLATION,
MAINTENANCE AND REPAIR GUIDE

2
GENERAL SAFETY REQUIREMENTS
NOTE: THOROUGHLY READ AND UNDERSTAND THIS
MANUAL BEFORE INSTALLING, OPERATING OR
SERVICING THIS EQUIPMENT.
PRESSURE RELIEF PROCEDURE:
Follow this procedure whenever you
shut off the pump, when checking or servicing any part
of the system and when installing, cleaning or changing
any part of the system.
1 ) Disconnect the air to the pump.
2) Point dispensing valve away from
yourself and others.
3) Open dispensing valve until
pressure is relieved.
WARNING
!
WARNING
!
DANGER: Not for use with uids
that have a ash point below 100°F
(38°C). Examples: gasoline, alcohol.
Sparking could result in an explosion which could result
in death.
WARNING
!
THIS PUMP CONTAINS
ALUMINUM AND ZINC PARTS. DO
NOT use 1-1-1 Trichloroethane, methylene chloride
or other halogenated hydrocarbon solvents or uids
containing such solvents in this pump. Use of these
solvents/uids may result in a violent chemical reaction,
causing serious bodily injury, property damage or
death. All uids used in this pump must be chemically
compatible with the wetted parts materials shown on
page three (3) of this manual. Consult your chemical
supplier to ensure compatibility.
Because this pump can be
incorporated into pressurized
systems, the following safety
precautions should be observed.
Check equipment regularly and repair or replace worn
and damaged parts.
Never alter or modify any parts of this pump, doing so
may cause damage to pump and/or personal injury.
Under no circumstances should the dispensing valve
be aimed at any person at any time. Personal injury
may result.
Release pressures built up in the system before any
service or repair is begun. See the pressure relief
procedure below.
Do not operate this pump above 150 PSI (10.3 BAR) air
inlet pressure or 300 cycles per minute.
Always read and follow the fluid manufacturer’s
recommendations regarding the use of protective
eyewear, clothing and respirators.
IMPORTANT
!
WARNING
!
Pump develops 195 PSI
(13.3 BAR) maximum working
pressure at 150 PSI (10.3 BAR)
maximum inlet air pressure. Be sure that any components
or accessories used in the system are rated to withstand
this pressure. To determine uid outlet pressure, multiply
the ratio of the pump by the air pressure being used.
EX: 1.3 (1.3:1 ratio) x 100 PSI = 130 PSI
uid pressure.
1.3 (1.3:1 ratio) x 6.8 BAR = 8.84 BAR
uid pressure.
In the presence of explosive vapors, take
action to prevent static sparking. Failure to ground the
pump, piping, valves, containers, or other miscellaneous
equipment can result in re or explosion. A green
grounding lug is provided on the pump.
WARNING
!
If a check valve is installed at the end of the suction tube,
then an external pressure relief valve must be installed
at the outlet of the pump.
WARNING
!

3
TABLE OF CONTENTS
Cover................................................................................1
General Safety Information...............................................2
Technical Data..................................................................3
Dimensional Data .............................................................4
Installation ........................................................................5
Operation..........................................................................6
Troubleshooting................................................................7
Parts Listing............................................................... 8 & 9
Pump Servicing ....................................................... 9 & 10
Accessories ....................................................................11
Warranty .........................................................................12
TECHNICAL DATA
Pressure Ratio............................................................1.3:1
Air Pressure Operating Range ..........................40-150 psi
Maximum Fluid Working Pressure..........................195 psi
Stroke Length .........................................................3.88 in.
Air Inlet Port Size............................................... 1/4” NPTF
Fluid Inlet Port Size ..............................................1” NPTF
Fluid Outlet Port Size.........................................3/4” NPTF
Wetted Parts:
(General Lube) ..........Steel, Al, Acetal, Buna-N,Ultrathane
(Antifreeze).....................300 Series S/Steel, Acetal, Viton
Noise Level (DBA).................................................... 72-82
PERFORMANCE/FLOW CURVES
Note: Test Fluid 10W30 Motor Oil
AIR CONSUMPTION (SCFM)
FLUID PRESSURE (PSI)
FLUID FLOW (GPM)
# 40 PSI (GPM)  40 PSI (SCFM) 100 PSI (GPM)
100 PSI (SCFM) 125 PSI (GPM) 125 PSI (SCFM)
Figure 1
Flow Curves
160
140
120
100
80
60
40
20
0
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
16
12
8
4
0
0 5 10 15 20
160
140
120
100
80
60
40
20
FLUID PRESSURE (PSI)
FLUID FLOW (GPM)
1110-005, 1110-006 & 1110-008 1160-002, 1160-003 & 1160-006

4
1-1/2” nptm
1” nptf
3/4” nptf
1/4” nptf
4.2” OD
8.4
“A”
“B”
“C”
*Includes 4411-009 bung adapter
**Includes 4411-017 bung adapter
PRODUCT DESCRIPTION
The “Bobcat™ 130” pump family replaces the earlier “Trans-Jet
130”, “131A-CB & 131A-CBL”, “121”, “Econo-Jet” ™ (1.5:1)
and P-160/P-161 food pumps. These pumps are suitable for
petroleum products, chemicals, and USDA applications.
Four versions are currently available, two each in stub and
drum lengths. The 1110-005,1110-006 and 1110-008 are
composed of carbon steel parts with Buna-N seals for long
life. The model 1110-008 includes the model 4411-009 bung
adapter.
The 1160-002, 1160-003 and 1160-006 have all “wetted
parts” made from 304 SS or 316 SS and Viton and are USDA
approved. The model 1160-003 includes the model 4411-017
bung adapter.
All pumps contain a pair of 1 inch Delrin®balls which provide
compatibility for many uids and a smooth ow on both pump
strokes. For uids more viscous than 90W gear lube, carbon
steel or 300-series SS balls may be substituted.
All pumps are composed of a 2-piece body with the upper
section beingAluminum and the lower section beingAluminum
or 316 SS, depending on model number.
The lower section’s anged coupling contains a 4-hole bolt
pattern which allows 360° rotation of the inlet and outlet
ports in 90° degree increments. This feature is useful when
installing a pump on a wall bracket that limits orientation of
the hoses.
All pumps contain a pair of internal exhaust mufers which
provide efcient operation with low noise levels conforming
to OSHA regulations. These mufers also act as lters,
inhibiting air line debris from exiting the pump where cleaner
environments are required.
The 1-piece pump air motor is factory-lubricated with a life-
tested, synthetic grease (Balcrank #826733). This grease
coats all internal parts and repels air line moisture to inhibit
corrosion. Steel components exposed to air line moisture are
surface treated to inhibit corrosion.
NOTE: Delrin®is a registered trademark of the
DuPont Company
DIMENSIONS &
MOUNTING DIAGRAM
Figure 2
Pump Dimensions
OVERALL LENGTH
MODEL “A” “B” “C”
(Stub Length)
1110-005 25.1” 9.1” 6.6”
1160-002 26.2” 9.8” 8.2”
(Drum Length)
1110-006 50.4” 34.4” 31.9”
1110-008* 50.4” 34.4” 31.9”
1160-003** 50.4” 34.0” 32.4”
1160-006 50.4” 34.0” 32.4”

5
TYPICAL INSTALLATIONS
INSTALLATION
Remove pump from carton and attach to cover, bung tting
or other mountings.
Blow out any foreign material from the air supply line before
connecting to pump. An air line lter/regulator is recommended
for all applications; wet and dirty air will shorten the life of the
pump.
NOTE: For severe duty applications, an air line lubricator
is recommended for better performance and longer pump
life. Use an SAE 10 oil and set the lubricator for 2 drops per
hour.
Be sure the air supply is OFF before connecting accessories
and/or pump.
NOTE: DO NOT hang Filters/Regulators/Lubricators or other
equipment of this type directly from pump air inlet. The ttings
are not strong enough to support the weight and may cause
one or more to leak and/or break. A bracket should be used
to support the use of these products.
1. Install an air line regulator to control pump speed and air
pressure for the system.
2. Install an air line lter to remove and trap contaminates
that could cause unwanted wear and tear on pump air
motor.
3. Install a quick disconnect coupler to relieve air pressure
between the pump air motor and regulator for servicing
purposes later.
4. Install uid hose, making note of uid and pressure
compatibility of hose.
Figure 3
Drum Installation
Figure 4
Optional Wall Mount
Bracket (4411-008)*
*Hoses sold separately
A Fluid Outlet
B 1.3:1 Ratio Pump
C Air Regulator
D Air Filter/Separator
E Shut Off Valve
F Air Supply
H Pressure Relief Valve
A
BC
D
E
F
H
A
BC
D
E
F
H
CAUTION
If you are not using a low-level cut-off at the pump uid
intake, install a pump runaway valve to shut off the air
to the pump, when the pump accelerates beyond the
pre-adjusted setting. A pump that runs too fast can be
seriously damaged.
!
WARNING: Attach a proper ground wire to the
Bobcat’s grounding lug (item 40) before starting
the pump.
!

6
OPERATION
NOTE: All uids used in this pump must be chemically
compatible with the materials used to manufacture the
“wetted parts”. Consult your chemical supplier to ensure
compatibility.
TO START PUMP:
1. Connect air coupler to pump and turn the air regulator to
the minimum setting.
2. Direct outlet hose into an approved waste oil container.
3. Slowly adjust air regulator until pump is primed and is
running smoothly. Be sure all air has been purged from
system. The pump should only take a few strokes to
prime. However, in a large system, it may take longer.
4. Use the air regulator to control the pump speed and cycle
rate. Always use the lowest pressure needed to obtain
the desired ow rate. This will increase pump and seal
life!
5. Never allow a pump to run dry of the uid being pumped.
A dry pump quickly speeds up and can damage the air
motor. If it speeds up, shut off air supply immediately. Rell
the supply container and prime the pump to eliminate air
in the uid line.
NOTE: To prevent air from being sucked into the pump and
uid lines, if the supply container should run dry, use a low-
level cutoff valve (4411-010) at the pump uid intake.
6. Read and follow the instructions supplied with each
component in your system.
7. If the pump will be unattended for any period of time, or
to shut off the system at the end of the work shift, always
follow the Pressure Relief Procedure.
PRESSURE RELIEF
PROCEDURE:
Follow this procedure
whenever you shut off the pump, when checking or servic-
ing any part of the system and when installing, cleaning
or changing any part of the system.
1 ) Disconnect the air to the pump.
2) Point dispensing valve away from
yourself and others.
3) Open dispensing valve until
pressure is relieved.
WARNING
!
WARNING
!
Pump develops 195 PSI (13.3
BAR) maximum working pressure
at 150 PSI (10.3 BAR) maximum inlet air pressure. NEVER
exceed the maximum working pressure of the lowest rated
equipment of your system.

7
Pump does not operate
Air motor not tripping over
Air leaking from exhaust
Fluid leaking from exhaust
Erratic pump operation
Pump runs “wild”
Fluid output on one stroke only or
continues to operate when dispensing
valve is closed
Pump operates, but output low on both
strokes
Increase air supply; clear (1)
Open; clear (1)
Service/replace air motor
Rell, reprime and/or ush
Service/replace air motor
Service/replace air motor
Replace
Check for loose connections
Rell, reprime or ush
Run pump at lower pressure; run
at lower cycles per minute; clean
mufers
Rell, reprime or ush
Remove pump tube; clean blockage
Replace ball and reseat footvalve
Replace with new seal
Service and replace
Service and replace
Increase air supply; increase delivery
line size
Clear (1)
Rell, reprime or ush
Clear (1)
TROUBLE PROBABLE CAUSES REMEDY
(1) Follow the Pressure Relief Procedure, on page 6 and disconnect the uid line. If the pump starts when the air is turned
on again, the line, etc. is clogged.
TROUBLESHOOTING GUIDE
NOTE: Check all other possible causes before disassembling
the pump.
Inadequate air supply pressure or
restricted air line
Clogged uid lines, hoses, valves, etc.
Damaged air motor
Empty uid supply
Air motor o-rings are worn/damaged
Worn or damaged air motor o-ring and/or
seal, etc.
Seal (30) is worn and/or damaged
Air entering suction line
Fluid level too low
Air motor icing
Empty uid supply
Blockage in pump tube or footvalve
Lower ball (14) is stuck in footvalve
Lower seal (16) on uid piston is worn
or damaged
Retainer (38) is broken (ball oats with
uid)
Upper ball (14) is lodged in piston (15)
Inadequate air supply pressure or
restricted air lines
Closed or clogged solenoid valve, meter,
dispensing valve, etc.
Empty uid supply
Air inlet strainer/lter clogged

8
1
2
9
7
14
14
15
16
10
17
18
18
19
20
21
22
23
24
25
26 27
28
29 30
31
32
33
34
35
36
37
38
11
12
13
40
Pump Schematic Bobcat™130 Series 1:1 Ratio Pump
This assembly used on
Stainless Steel Model Nos.
1160-002, 1160-003 and
1160-006.
This assembly used on Carbon
Steel Model Nos. 1110-005,
1110-006 and 1110-008.
Figure 5
Pump Schematic

9
Repair Kits: There are three kits available to repair the stub
and drum “Bobcat 130” pumps:
* 827711 (air piston parts for all pumps)
 ** 900020 (uid seals for carbon steel pumps)
 *** 828070 (uid seals for stainless steel pumps)
PRESSURE RELIEF
PROCEDURE:
Follow this procedure
whenever you shut off the pump, when checking or servic-
ing any part of the system and when installing, cleaning
or changing any part of the system.
1 ) Disconnect the air to the pump.
2) Point dispensing valve away from
yourself and others.
3) Open dispensing valve until
pressure is relieved.
WARNING
!
# 828359 O-ring used on pumps built before 10/13/08.
Old O-ring (828359) will be tagged in service kit with a twist
tie for identication.
## 826676 O-ring used on pumps built after 10/13/08
Parts List
1110-005 1110-006 1110-008
1160-002 1160-003 1160-006
Item Part# Description
1 827710 Air Valve Assy 1 1 1 1 1 1
2 826658 Upper pump rod 1 1 1 1 1 1
3 805723 Crimp Nut 1 1 1
4806629 Washer 1 1 1
5 826052 Adapter 1 1 1
6 826680 Rod 1 1 1
7 831507 Lower pump rod (316 SS) 1 1 1
827415 Lower pump rod (316 SS) 1 1 1
8827441 O-Ring Viton, -120*** 1 1 1
9 832181 Coupler 1 1 1
10 826248 Wear Band** 1 1 1
11 821570 Screw, 1/4-20 x 1 1/8” 4 4 4
12 813913 Nut, 1/4-20 4 4 4
13 832180 Plate, Upper 1 1 1
14 827168 1” Ball (Delrin)*** 2 2 2
806962 1” Ball (STL) 2 2 2
15 832022 Fluid piston (STL) 1 1 1
828988 Fluid piston (316 SS) 1 1 1
16 831638 O-Ring, Buna-N, -325** 1 1 1
827065 Quad-Ring, Viton, -325** 1 1 1
17 826660 Cap (Alum.) 1 1 1 1 1 1
18 828529 Flat Gasket* 2 2 2 2 2 2
19 826663 Spring* 1 1 1 1 1 1
20 826664 Spring Retainer 1 1 1 1 1 1
21 826665 Screw, 1/4-20 x 1/2” 1 1 1 1 1 1
22 827727 Air Piston Tube (STL) 1 1 1 1 1 1
23 808439 Spring* 1 1 1 1 1 1
24 807342 O-Ring, Buna-N, -222* 1 1 1 1 1 1
25 827780 Upper Body (Alum) 1 1 1 1 1 1
26 827767 Mufer Screen (Brass) 2 2 2 2 2 2
27 827766 Mufer Foam** *** 2 2 2 2 2 2
28 827426 Retaining Spring*** 1 1 1
831544 Retaining Ring** 1 1 1
29 827425 Backup Ring (Brass)*** 1 1 1
831542 Backup Ring (Delrin)** 1 1 1
30 831540 Wiper Seal, Ultrathane** 1 1 1
826072 Wiper Seal, Viton** 1 1 1
31 831663 Lower Body (STL) 1 1 1
828366 Lower Body (316 SS) 1 1 1
32 829002 Lock Washer (STL) 4 4 4
805784 Lock Washer (STL) 4 4 4
Parts List
1110-005 1110-006 1110-008
1160-002 1160-003 1160-006
Item Part# Description
33 829001 Screw, 1/4-20 x 3/4” 4 4 4
805823 Screw, 1/4-20 x 3/4” 4 4 4
34 828359 O-Ring, Buna-N -136**# 1 1 1
826676 O-Ring, Buna-N -033**## 1 1 1
826679 O-Ring, Viton -132*** 1 1 1
35 832560 Pump Tube, (STL), 6.8” 1
831205 Pump Tube, (316SS), 6.8” 1
832561 Pump Tube, (STL), 31” 1 1
831206 Pump Tube, (316SS), 31” 1 1
36 826678 O-Ring, Buna-N, -133** 1 1 1
826679 O-Ring, Viton, -132*** 1 1 1
37 831993 Footvalve, (STL) 1 1 1
829027 Footvalve, (316SS) 1 1 1
38 827427 Retaining Pin (316SS)*** 1 1 1
829769 Retaining Pin (STL)** 1 1 1
39 831489 Grounding Lug (not shown) 1 1 1 1 1 1
40 830108 Lower Plate 1 1 1
41 4411-009 Bung adapter (Alum) 1
42 4411-017 Bung adapter (Nickel plated) 1

10
PUMP SERVICING
NOTE: Air motor is lubricated with a life tested synthetic
grease (Balcrank®P/N 826733) at the factory. This grease
coats all parts and repels air line moisture to inhibit corrosion.
It is imperative that any grease removed during routine
maintenance be replaced. Contact your local Balcrank®
Distributor, using the above part number, for replacement
grease.
NOTE: The following steps and item numbers pertain to the
stub pumps. Except for a few uid section components (pump
tube, pump rod, uid piston, etc.), stub and drum pumps are
alike. When repairing a drum pump, pay close attention to
different parts that may carry the same item number as their
stub counterparts, such as the pump tube (35).
MODEL #1110-005, 1110-006 & 1110-008
Pump Disassembly: This operation must be performed
before continuing to the following sections. See page 11 for
applicable repair kits.
Grip the upper pump body (25) in a padded-jaw or smooth-
jaw vise. Remove screws (11) and nuts (12) with 1/4” wrench.
Remove screws (33) and washers (32) with 1/4” wrench. Set
aside plates (13 & 14). Disconnect uid rod (7) from adapter
(9). Unscrew air piston tube (22), with cap (17) attached, from
the upper body. Grip air motor assembly (1) by hand and pull
out the entire upper assembly (air motor and upper pump rod.
Wrap the pump rod to prevent damaging the surface. Keep
the lower spring (23) with the rod.
Lower Spring and Air Motor Replacement: Replace the
spring (23) by sliding off the old spring and sliding on the
new part. The air motor (1 ) is a 1 -piece, staked assembly
that cannot be disassembled for repair of internal o-rings
or upper seal. Replace the entire assembly using Balcrank
Repair Kit 827711.
Wrap the upper pump rod (2) with protective material or
use wood/plastic blocks to grip it in a vise. Use a wrench to
remove the air motor assembly at the hex adaptor (1) pump
rod (2) joint. Apply thread adhesive to the air motor before
installation.
Upper Spring and Flat Seal Replacement:
Unscrew cap (17) from air piston tube (22). Remove screw
(21), spring retainer (20) and spring (19) and lift out upper
gasket (18). Reassemble in reverse order.
Replacing the Pump Rod Seals: Remove foot valve (37)
from uid tube (35). Remove uid tube (35) from adapter
(31) and slide off. With two spanner wrenches remove uid
piston (15) from uid rod (7). Remove the uid rod (7) from
the adapter (31). Now seals (30, 34, and 16) are accessible.
Inspect balls (14) and change as required. Reassemble in
reverse order. Apply grease (P/N 826733) to seals (30 and
16) to ease assembly.
Footvalve: With a strap wrench attached on the tube (35)
now remove foot valve (37) with a pipe wrench. Remove and
inspect pin (38) for wear, straightness, etc. Replace if required.
Remove footvalve ball (14) and seal (36), inspect, and replace
if required. Reassemble in reverse order.
MODEL #1160-002, 1160-003 & 1160-006
Upper Spring and Flat Seal Replacement:
Unscrew cap (17) from air piston tube (22). Remove screw
(21), spring retainer (20) and spring (19) and lift out upper
gasket (18). Reassemble in reverse order.
Replacing the Pump Rod Seals: Remove foot valve (37)
from uid tube (35). Remove uid tube (35) from adapter
(31) and slide off. With two spanner wrenches remove uid
piston (15) from uid rod (7). Remove the uid rod (7) from
the adapter (31). Now seals (30, 34, and 16) are accessible.
Inspect balls (14) and change as required. Reassemble in
reverse order. Apply grease (P/N 826733) to seals (30 and
16) to ease assembly.
Footvalve: With a strap wrench attached on the tube (35)
now remove foot valve (37) with a pipe wrench. Remove and
inspect pin (38) for wear, straightness, etc. Replace if required.
Remove footvalve ball (14) and seal (36), inspect, and replace
if required. Reassemble in reverse order.
Pump Disassembly: This operation must be performed
before continuing to the following sections. See page 11 for
applicable repair kits.
Grip the upper pump body (25) in a padded-jaw or smooth-jaw
vise. Unscrew air piston tube (22), with cap (17) attached, from
the upper body. Unscrew the pump tube (35), with footvalve
(37) attached, from the lower body (31).
Place a 1/4” diameter rod through hole at the bottom of the
lower pump rod (7). Use an adjustable wrench to unscrew
the uid piston (15) from the pump rod. Remove ball (14) and
set aside. Grip air motor assembly (1) by hand and pull out
the entire assembly (air motor and both pump rods). Wrap
the pump rods to prevent damaging the surfaces. Keep the
lower spring (23) with the rod.
Upper Body O-ring Replacement: O-ring (24) can be
removed by using a curved pick or small-bladed screw driver.
Wipe o-ring groove to remove debris and replace.
Lower Body Seal Replacement: This seal must be replaced
each time the lower rod is pulled through the body.
The wiper seal (30) is replaced by removing screws (33) and
washers (32) and separating the upper (25) and lower (31)
body sections. Use snap ring pliers to remove the retaining
ring (28). Remove the backup ring (29) and seal (30). Apply
Balcrank lubricating grease (p/n 826733) to the seal area and
install a new seal ared side down. Work carefully to avoid
seal tearing around the snap ring groove. Reassemble in
reverse order.
Lower Spring and Air Motor Replacement: Replace the
spring (23) by sliding off the old spring and sliding on the
new part. The air motor (1 ) is a 1 -piece, staked assembly
that cannot be disassembled for repair of internal o-rings
or upper seal. Replace the entire assembly using Balcrank
Repair Kit 827711.

11
Wrap the upper pump rod (2) with protective material or use
wood/plastic blocks to grip it in a vise. Use a wrench to remove
the air motor assembly at the hex adaptor (1) pump rod (2)
joint. Note: If the upper pump rod needs replacement, do so
before the new air motor is installed (refer to Replacing the
Upper Pump Rod). Apply thread adhesive to the air motor
before installation.
Upper Spring and Flat Seal Replacement:
Unscrew cap (17) from air piston tube (22). Remove screw
(21), spring retainer (20) and spring (19) and lift out upper
gasket (18). Reassemble in reverse order.
Replace the lower gasket (18) while the tube is off the body
(25). Be sure the new gasket is at against the body before
assembling the tube
Replacing Parts in the Footvalve: Grip pump tube (35)
and footvalve (37) with separate strap wrenches. Unscrew
the footvalve, drive out retainer pin (38) with a 1/8” diameter
punch, remove lower ball (14) and/or o-ring (36) as necessary.
When reassembling the pump tube to the lower pump body, be
sure to check the upper o-ring (34) for damage and replace as
necessary. Apply grease to the footvalve threads and o-rings
(34,36) and reassemble.
Replacing the Upper Pump Rod: Grip only the upper rod in
a vise. Use a 1/8” spanner wrench to remove the oating joint
adapter (5) and air motor assembly (1) from the upper rod.
Wrap the replacement upper rod in protective material before
placing in the vise. Apply thread adhesive to both internal
threads of the pump rod and reassemble the connecting
parts.
Replacing the Lower Pump Rod: Grip only the lower rod
in a vise. Use a 1/8” spanner wrench to remove the oating
joint adapter (5) from the upper rod (2). Wrap the upper rod
and air motor assembly and set aside.
Use an adjustable wrench to remove lock nut (3). Slide off
washer (4) and adapter (5). Remove connecting rod (6) with
a pipe wrench. Wrap replacement lower rod in protective
material before placing in the vise. Apply thread adhesive to
the connecting rod (6) and reassemble with the short thread
length into the rod. Replace the washer (4), adapter (5) and
nut (3). Tighten nut completely then back off 1/4-tum to allow
free movement of adapter. Apply thread adhesive to the
adapter and reassemble.
Pump Reassembly: Apply grease to the lower pump rod end,
wiper seal (30) and o-ring (24). Slide the lower spring (23) over
the upper pump rod and then slide the entire upper rod/lower
rod/air motor assembly through the pump. Some resistance
will be encountered as the lower rod passes through the wiper
seal (30). Reinstall the upper ball (14) and piston (15). Insert
a 1/4” diameter rod through the pump rod and tighten the
uid piston with a wrench. File off any burrs or raised areas
created during the repair process.
Grease o-rings (16,34) and pump tube (35) threads before
reassembling to the body. Tighten with a strap wrench.
Grease the air motor assembly and inside the tube (22),
reassemble and tighten with a strap wrench.
Universal Bung Adapter Kit
4411-009 (carbon steel pumps)
4411-017 (stainless steel pumps)
Universal bung adapter mounts all Bobcat 130
pumps to 2” npt bung threads and wall mount
brackets
Foot Mount Adapter Kit (Double Tapped Bushing)
4411-018 (carbon steel stub pumps)
 Mounts carbon steel stub pumps to 2” npt bung
threads.
ACCESSORIES
Air Regulators
3260-028 1/4” nptf (mini)
3260-029 1/4” nptf
3260-030 3/8” nptf
Air Filter/ReguIators
3260-033 1/4” nptf (mini)
3260-034 1/4” nptf
3260-035 3/8” nptf
Pump Over-Run Controls
3241-001 1/2” nptf
3241-002 1/4” nptf
In-Line Hand Operated Valves
3230-003 300 psi (air), 1/4” nptf
3230-002 2,000 psi, 1/2” nptf
Spigot & Tube Kit
4410-009
Gooseneck spigot
 1” npt suction tube
 Air hose, 3/8” x 5’
Air coupler and nipple
 Bung Adapter
Telescoping Suction Tube
4412-012
 1”npt (ts 55 gal drum and 250 gal tank)
Hose & Tube Kit
4410-011
 1” npt suction tube
 Air hose, 3/8” x 3’
 Fluid hose, 3/4” npt x 5’
 Air coupler and nipple
 Bung Adapter

Balcrank®Corporation
Weaverville, NC 28787
800-747-5300
800-763-0840 Fax
www.balcrank.com
SERVICE BULLETIN SB1078
Revision C - 09/10
832179
Revision Log:
Rev. A - Added new O-ring and Tube Part Numbers (page
9; #’s 34 & 35)
Rev. C - Added models 1110-008 & 1160-003
Balcrank Lubrication Equipment Warranty Statement
All Balcrank equipment sold by authorized Balcrank distributors is warranted to their original customer to be free from defects in materi-
als and workmanship for a period of one year from the date of sale to that customer. Selected Balcrank equipment carries warranty terms
for a more extended period as dened in the Balcrank Lubrication Equipment & Accessories User Price List, wherein a “lifetime” warranty
represents a warranty period of thirty years. Within the initial one-year warranty period, Balcrank will repair or replace all Balcrank equip-
ment determined by Balcrank to have defective materials or workmanship. For equipment carrying more extended warranties, Balcrank
will repair or replace the product including parts and labor during the rst full year and will provide parts only for the remainder of the war-
ranty period.
This warranty applies only to equipment installed and operated according to applicable Balcrank Service Bulletins and Installation Instruc-
tions.
Any equipment claimed to be defective must be returned, freight prepaid, to an Authorized Balcrank Service Center (ASC). Upon receiv-
ing candidate warranty equipment from a customer, ASC will: 1) diagnose to determine the warrantable condition of the equipment, 2)
submit, prior to repair or replacement, a request to Balcrank for warranty authorization, then 3) in cooperation with Balcrank, proceed with
repair locally or forward the equipment to Balcrank and obtain replacement. If the part(s) or equipment items are found defective upon
inspection by Balcrank, they will be repaired or replaced, and then will be returned to the ASC. If Balcrank nds the claimed part(s) or
equipment not to be defective, the ASC will receive written authorization from the original customer, and then repair them for a reasonable
charge to the customer, which will include all applicable parts, labor, and return transportation costs.
Optionally, the customer may submit certain eligible products directly to Balcrank for warranty return by using Balcrank Lubrication Equip-
ment Direct Service Warranty Procedure. Eligible products are dened in the Balcrank Lubrication Equipment & Accessories User Price
List. Refer to the Balcrank web site www.balcrank.com for a copy.
Any equipment returned to Balcrank must have the Warranty Service Claim number (WSC#) clearly marked on the outside of the carton.
Balcrank’s sole responsibility is for defects in material and workmanship, and Buyer’s sole and exclusive remedy hereunder, shall be
limited to repair or replacement of the defective part or equipment.
This warranty does not cover, nor shall Balcrank be liable for repair or replacement of parts or equipment resulting from general wear and
tear through use, or damage or failure caused by improper installation, abuse, misapplication, abrasion, corrosion, insufcient or improper
maintenance, negligence, accident, alteration, or substitution of non-Balcrank parts.
Furthermore, the Warranty for Lubrication Equipment and Accessories does not cover the following specic conditions:
• Failure or damage to equipment caused by dirt or debris in compressed air lines and uid lines. This includes, but is not
limited to, clogged inlet lters, strainers, or regulators; uid meters; control handles; uid tips; and valves.
• Failure of normal wear parts including but not limited to: o-rings, packings, seals and valves unless originally improperly
installed by the factory.
• Products placed in applications for which their use was not intended. Examples include but are not limited to Lubricant pump
being used to pump solvents, or placing equipment intended strictly for indoor use outdoors
• Damage to equipment resulting from operation above and beyond Balcrank’s recommendations.
• Leaks at air and uid ttings and connections.
• Damage caused by thermal expansion whenever adequate pressure relief was not included in the system.
• Loose suction tubes on pumps.
• Incorrect hose reel spring tension, requiring adjustment.
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FIT-
NESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL BALCRANK BE LIABLE FOR ANY SPECIAL, CONSEQUENTIAL, OR
OTHER DAMAGES OF SIMILAR NATURE, INCLUDING BUT NOT LIMITED TO LOST PROFITS, LOST PRODUCTION, PROPERTY
DAMAGE, PERSONAL INJURY, WHETHER SUFFERED BY BUYER OR ANY THIRD PARTY, IRRESPECTIVE OF WHETHER CLAIMS
OR ACTIONS, LEGAL OR EQUITABLE, FOR SUCH DAMAGES ARE BASED UPON CONTRACTS, WARRANTY, NEGLIGENCE,
STRICT LIABILITY, OR OTHERWISE. ANY CLAIM OR ACTION FOR BREACH OF WARRANTY MUST BE BROUGHT WITHIN TWO (2)
YEARS FROM THE DATE OF SALE TO THE ORIGINAL CUSTOMER.
