Baldwin Boxall VIGIL Eclipse5 Installation guide

BVECASE5
19/05/2020
Issue 1
ECR n/a
VIGIL Eclipse5
(BVECASE5)
Installation Details
www.acornfiresecurity.com
www.acornfiresecurity.com

- 2 - Issue 1
VIGIL ECLIPSE5(BVECASE5)
The VIGIL Eclipse5 is a wall mountable, public address and / or voice evacuation system.
The unit houses the required number of input and output modules, one BVMBC battery charger,
Network Interface modules (if required), suitable batteries and a choice of up to four amplifier
mainframes.
If more than two amplifier mainframes are installed then an external Battery Box (BVECASE5BATT) is
supplied that is designed to be floor mounted, with the BVECASE5 installed directly above it.
PRECAUTIONS AND SAFETY INFORMATION
Environmental Conditions
AC Supply Voltage
230V - 15% +10% RMS 50Hz AC
DC Supply Voltage
18V to 33V (Nominal 24V) DC
Temperature (Operating & Storage)
Nominal 25°C, transitory -5°C to +40°C
Humidity Range / IP Rating
0% - 90% Non-Condensing / IP30
This equipment must not be installed in an area that is subject to a corrosive atmosphere, excessive
moisture or may allow water or other liquids to come into contact with the unit or its external
connections.
In the close proximity of some radio frequency transmitting devices, the signal to noise ratio of this
product may be reduced. If this occurs, re-location of the equipment or the signal cables is
recommended.
CA U T I O N
This product must only be disposed of in accordance with the
WEEE directive.
WA R N I N G
The BVECASE5BATT is designed to be floor mounted as the
maximum weight of the BVECASE5BATT can be upto 100Kg.
!
WA R N I N G
Ensure the wall or structure that this product is going to be
attached to is strong enough to support the weight of the unit.
The maximum weight of the BVECASE5 (without an external
battery box) can be upto 60Kg.
!
www.acornfiresecurity.com
www.acornfiresecurity.com

- 3 - Issue 1
General Safety Precautions
CA U T I O N
These Safety Precautions apply to assembled systems, however
they may not all be applicable to every item within that system.
Failure to follow these instructions and guidelines may cause
personal injury and/or damage to the equipment.
WA R N I N G
This equipment is intended for continuous operation and as such
should be permanently connected to the mains supply.
This unit does not contain an external mains switch.
For servicing, an all-pole Switch / Circuit Breaker with a
separation of 3 mm in each pole should be incorporated in the
electrical supply spur feeding the unit, and this must be suitably
marked to prevent inadvertent or accidental usage.
WA R N I N G
Always ensure that this equipment is correctly earthed by
connection to an AC mains supply with a protective earth
connection.
WA R N I N G
Voltages in excess of 35V RMS AC are considered Hazardous
and in certain circumstances can be lethal.
This product contains wiring and terminations that are energised
to 230V RMS AC mains & 100V RMS AC audio signals.
WA R N I N G
If Functional Testing, Maintenance, or Repair is to be completed
with the Mains Power (and/or battery backup) connected then
this should only be undertaken by personnel who are fully aware
of the danger involved and who have taken adequate precautions
and training.
Terminals marked with the "High Voltage" symbol are
considered hazardous and the external wiring connected to
these terminals requires installation by suitably trained
personnel.
!
!
www.acornfiresecurity.com
www.acornfiresecurity.com

- 4 - Issue 1
General Safety Precautions (cont.)
WA R N I N G
Note that this equipment uses battery backup, and if the Mains
Supply is disconnected Hazardous voltages will still be accessible
on the terminals marked with the "High Voltage" symbol.
WA R N I N G
The 24V DC batteries used within this system can deliver
extremely high currents that can cause fire or burns.
Care should be taken to ensure tools or jewellery etc. are
prevented from causing a Short Circuit.
WA R N I N G
Batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
WA R N I N G
If battery isolation / disconnection is required then the 0V cable
to the chassis should be disconnected first.
WA R N I N G
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of battery carefully to avoid environmental damage.
Do not dispose of battery in a fire.
WA R N I N G
Always replace blown fuses with the correct type and rating.
If a fuse continues to blow further investigation is required.
CA U T I O N :EL E C T R O -S T A T I C SE N S I T I V E DE V I C E S
This product contains Electro-static Sensitive Devices.
Observe the relevant precautions for the protection of ESDs if
internal covers are removed.
!
!
!
!
!
www.acornfiresecurity.com
www.acornfiresecurity.com

- 5 - Issue 1
BVECASE5 Mounting Holes and Knockout Positions
Note: The BVECASE5 has been designed to allow cable entry from the top (via knockouts) or via the
removable access plate in the rear panel.
There is no requirement for ventilation or space either side of the installed position as all terminations can
be accessed and maintenance operations can be performed from the front of the unit.
www.acornfiresecurity.com
www.acornfiresecurity.com

- 6 - Issue 1
BVECASE5BATT Mounting Holes
Note: Ensure the internal battery mounting plinth is fitted to the base of the BVECASE5BATT before
installing the batteries.
Note: The Adjustable feet should be set to ensure the BVECASE5BATT is flat and level to allow the
BVECASE5 to be installed directly above it.
Once in position the optional plinth base shroud can be fitted around the bottom edge of the
BVECASE5BATT.
