Band-it 2550 User manual

2550
Model No: __________________________
Serial No: __________________________
DEALER:
Name: _____________________________
Address: ___________________________
City/State: __________________________
Phone No: __________________________
Delivery Date: _______________________
Engine Make: _______________________
Serial No: __________________________
Clutch Make: ________________________
Model: ___________ S/N _____________
Copyright 4/21
MODEL 2550
OPERATING & PARTS MANUAL
6750 Millbrook Rd. • Remus, MI 49340 • 1-989-561-2270
MANUFACTURED BY BANDIT INDUSTRIES, INC
PHONE: [phone]
PHONE: [phone] IN USA
FAX: [phone] ~ SALES DEPT.
FAX: [phone] ~ PARTS/SERVICE
WEBSITE: www.banditchippers.com
ATTENTION:
Depending on what replacement parts you are ordering, we will need the following information:
STUMP GRINDER COMPONENTS
Serial Number
Model Number of Stump Grinder
ENGINE COMPONENTS
Brand
Engine Serial Number
Engine Model Number

WARNING
!
ADVERTENCIA
!
Breathing diesel engine
exhaust exposes you to
chemicals known to the
State of California to cause
cancer and birth defects or
other reproductive harm.
• Always start and
operate the engine in a
well-ventilated area.
• If in an enclosed area,
vent the exhaust to the
outside.
• Do not modify or tamper
with the exhaust system.
• Do not idle the engine
except as necessary.
For more information go to:
www.P65warnings.ca.gov/diesel
Respirar gases de escape de
motores diesel le expone a
quÍmicos conocidos por el estado
de California como causales de
cáncer y defectos congénitos u
otros daños reproductivos.
Para mayor informaciÓn visite:
www.P65warnings.ca.gov/diesel
• Siempre encienda y opere el
motor en áreas bien ventiladas.
• Si está en un área cerrada,
ventile escape hacia el exterior.
• No modifi que ni altere el
sistema de escape.
• No deje el motor en ralentÍa no
ser que sea necesario.
SPW-46 8/18
SPW-47 8/18
Cancer and
Reproductive
Harm
WARNING
!
ADVERTENCIA
!
Cáncer y daño
reproductivo
www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65

I have inspected this equipment and nd it in correct working condition. To the best of my knowledge, the customer and
his/her personnel are aware of, and agree to the above procedures.
Signed: ________________________________________________________________________ Date: ______________
(Dealer Representative)
The equipment has been thoroughly checked by the above named dealer representative, and I am satised with his/her
instructions. I have also read, understand, and agree to reverse side of page.
Signed: ________________________________________________________________________ Date: ______________
(Customer)
White-Bandit Industries, Inc. copy / Yellow-Dealer copy / Pink-Customer copy
Copyright 2/17 FORM #WV-124
WARRANTY VALIDATION FORM
(STUMP GRINDER)
PURCHASER / OWNER INFORMATION:
Company Name __________________________________________________ Contact Name ______________________________
Mailing/Street Address _____________________________________________________ City _______________________________
State ____________________ Zip Code _________ Country ___________________ Telephone Number ( ___ ) _____________
E-mail _______________________________________ Machine Model No. _____________ Date Put Into Service _____________
Machine Serial No. __________________________________ Machine Work Order No. _____________ Machine Hours _________
Engine Make ______________________________ Engine Serial No. ___________________________ Machine Color _________
DEALER / SELLER INFORMATION:
Dealer/Seller Name ________________________________________________ Contact Name _______________________________
Mailing/Street Address _____________________________________________________ City _______________________________
State ____________________ Zip Code _________ Country ___________________ Telephone Number ( ___ ) _____________
1. _____ The customer has received instruction and fully understands all operational, safety and maintenance requirements of
the equipment.
2. _____ The customer has received instruction and fully understands that everyone within 100 feet of the machine must wear
proper personal safety equipment including hard hat, face shield, safety glass, gloves, ear protection and/or other items
per OSHA and ANSI requirements.
3. _____ The customer has received instruction and fully understands the equipment maintenance schedules and procedures. The
customer understands that it is their responsibility to perform scheduled maintenance that includes periodic relief valve
 adjustments,retighteningallfastenersasneeded,periodiccleaningofowdivider,clutchandbeltadjustments,and
other items.
4. _____ The customer has received instruction and fully understands not to reach near the cutter head with hands or feet or to be
 locatedneardebriseldwithenginerunning.
5. _____ The customer has received instruction and fully understands that the operators must always be located within easy
reach of all control and shut down devices.
6. _____ The customer has received instruction and fully understands to not start grinding a stump without checking for power lines,
water lines, sewer lines, phone lines, etc.
7. _____ The customer has received instruction and fully understands the purpose of and how to operate the shut down/shut-off
devices, and will not attempt to override any safety devices or guards.
8. _____ The customer has received instruction and fully understands that before performing any maintenance on the machine
the ignition key must be removed, the cables must be completely disconnected from the battery, the cutter head must
have come to a complete stop, and the cutter head lock must be installed. The customer understands they must allow
the necessary time for the cutter head to come to a complete stop before opening the cutter head guard or start any
maintenance or service procedures. If applicable the customer has received instruction and fully understands the
purpose of the beltshield inspection hole and that they are never to attempt any maintenance or service procedures
 untilvisuallyconrmingthebeltshavecometoacompletestop.
9. _____ The customer has received instruction and fully understands the machine is not to be operated without the factory
approved cutter head guard in place, the machine is not to be operated with any type of make shift cutter head guard,
and the machine is not to be operated under any circumstances with the cutter guard open or unsecured.
10. _____ The customer has reviewed and fully understands limited warranty, and all written and visual instructions.
11. _____ The customer has received instruction and fully understands that warranty will not apply if the machine is operated with
replacement parts or equipment not manufactured or recommended by Bandit Industries, Inc.
12. _____ The customer has received, been advised, and understands the manuals, and the Safety/Service video supplied with
the grinder. A video is supplied for equipment models as available.
13. _____ All Danger, Warning and Operational decals are properly displayed on equipment and fully understood by customer.
14. _____ The customer has been instructed, understands, and agrees that all potential operators must: See the supplied video,
be instructed on all the Danger, Warning and Operational decals, read the manual and follow the procedures.
IMPORTANT - WARRANTY WILL BE DEEMED NULL AND VOID IF THIS
FORM IS NOT FILLED OUT COMPLETELY AND ACCURATELY AND
RETURNED TO THE CUSTOMER DATA DEPARTMENT WITHIN 10 DAYS
OF EQUIPMENT DELIVERY
Customer Data Department
6750 Millbrook Road
Remus, MI, USA 49340
Phone: [phone] in USA
Phone: [phone]
Fax: [phone]
Website: www.banditchippers.com

All of the employees that build your equipment strive to manufacturer the very best quality product on
the market. We would appreciate your efforts in letting us know how we are doing.
We would like you to operate your machine for thirty (30) days and then ll out this questionnaire and mail it to us.
This will help us to keep producing a good product and improving our products through your recommendations.
DATE PURCHASE: ______________________
MODEL: ________________________________
SERIAL NUMBER: _______________________
DEALER NAME: ________________________
_______________________________________
Copyright 4/17 FORM #Q-112
TO BE RETURNED AFTER THIRTY (30)
DAYS OF OPERATION
Please return to: Customer Data Department
6750 Millbrook Road
Remus, MI 49340
Phone: [phone] in USA
Phone: [phone]
Fax: [phone]
Website:www.banditchippers.com
STUMP GRINDER / FORESTRY MOWER
QUALITY REPORT
1. Did your machine perform to your expectations? _______________________________________
2. Was the machine delivered on schedule? _____________________________________________
3. Was the paint color and nish to your satisfaction? ______________________________________
4. Was machine equipment as ordered? ________________________________________________
5. Did all welds appear to be high quality? ______________________________________________
6. Was the overall machine to your liking? ______________________________________________
7. What problems have you experienced? ______________________________________________
8. Have any components regularly loosened that caused problems? __________________________
9. Does the hydraulic system seem to have adequate power? ______________________________
10. Is the machine manufactured to accommodate service in an adequate manner? If not, please explain:
_______________________________________________________________________________
11. General comments and/or suggestions: ________________________________________________
_______________________________________________________________________________
_______________________________________________________________________________
12. Would you like to be contacted concerning more of our equipment? ________________________
YOUR COMPANY: ________________________________
NAME: __________________________________________
ADDRESS: ______________________________________
CITY: ___________________________________________
STATE & ZIP: _____________________________________
PHONE: ( ____ ) _________________________________
E-MAIL: _________________________________________


Bandit
1
Copyright 4/21
MODELS 2550/2550T TABLE OF CONTENTS
TABLE OF CONTENTS
ANY PART, PORTION, DESIGN, NUMBER, SPECIFICATION, AND/OR DIMENSION IN THIS
MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE BY THE MANUFACTURER.
NOTICE
PAGE
INTRODUCTION & WARRANTY........................................................... 2
SERIAL NUMBER LOCATIONS............................................................ 6
SAFETY PROCEDURES........................................................................ 7
EQUIPMENT SPECIFICATIONS........................................................... 12
DECALS................................................................................................... 13
CONTROLS............................................................................................. 17
MACHINE OPERATION ......................................................................... 33
TRANSPORTATION PROCEDURES.................................................... 36
MAINTENANCE ...................................................................................... 38
HYDRAULICS ......................................................................................... 55
ELECTRICAL .......................................................................................... 64
REPLACEMENT PARTS........................................................................ 65
CUTTER WHEEL ARM COMPONENTS........................................ 66
CUTTER WHEEL COMPONENTS ................................................. 68
FRAME COMPONENTS.................................................................. 72
STEERING COMPONENTS............................................................ 76
TANK COMPONENTS..................................................................... 78
CONTROL BOX COMPONENTS ................................................... 80
SWING OUT COMPONENTS ......................................................... 82
CURTAIN SWING OUT COMPONENTS........................................ 83
GRADING BLADE COMPONENTS ............................................... 84
REMOTE CONTROL COMPONENTS ........................................... 85
HYDRAULIC DIAGRAM.................................................................. 86
SERVICE RECORD ................................................................................ 94

Bandit
2
Copyright 4/21
INTRODUCTION
The purpose of this manual is to provide the user with speci cations and procedures for the
operation, maintenance and repair of this BANDIT product. As with any piece of equipment, safety
should always be a constant thought while the machine is being operated, serviced or stored.
In order to highlight this consideration, the material which addresses safety is proceeded by the
following signal words:
The equipment is designed and manufactured in accordance with the latest product industry
standards. This alone does not prevent injury. It is the operator’s responsibility to use good
judgement and follow the warnings and instructions as indicated in this manual, on the machine
and follow all safety standards per ANSI and OSHA instructions.
Improper use of the product can result in severe personal injury. Personnel using the equipment
must be quali ed, trained and familiar with the operating procedures as de ned in this manual,
prior to operating the product.
It is the responsibility of the owner or employer to ensure that the operator is trained and practices
safe operation while using and servicing the machine. It is also the owner’s responsibility to provide
and follow a regularly scheduled preventative maintenance and repair program on the product,
using only factory approved replacement parts. Any unapproved repairs or modi cations may
not only damage the machine and its performance, but could result in severe personal injury.
Unapproved repairs or modi cations will void warranty and eliminate manufacturer of any liability
claims. Consult the equipment manufacturer with any questions.
Each machine is shipped with a manual, a customer’s check sheet on the product, and any
available parts & service manuals on component parts not produced by this manufacturer.
Additional copies of these manuals and check sheets can be purchased from the manufacturer,
or through the dealer. Engine parts, service and maintenance manuals MUST be purchased
through the engine manufacturer or their dealer.
The producer of this Bandit product reserves the right to make any modi cations or revisions to
the design or speci cations of its machine without advance notice. The producer also reserves
the right to change machine and part prices as needed without advance notice.
NOTICE
WARNING
!
WARNING
!
Signal Word Likelihood of Occurrence Degree of Potential
Injury or Damage
Will occur if warning is ignored
Can occur if warning is ignored
Will or can occur if warning is ignored
Important, but not hazard related
Severe
Minor
Minor to Severe
Severe
CAUTION
!
NOTICE
DANGER
!
WARNING
!
INTRODUCTION & WARRANTY

Bandit
3
Copyright 4/21
BANDIT INDUSTRIES, INC.
EXPLANATION OF LIMITED WARRANTY
The warranty validation form must be completed and submitted to Bandit Industries within 10
business days of the purchase of your Bandit machine. Any and all warranty is NULL AND
VOID if the Warranty Validation Form is not returned within 10 business days of the original
purchase of the machine. If the original owner elects to sell the machine within the warranty
period, the remaining warranty transfers to the new owner. Do not submit a new Warranty Validation
Form upon the sale of the machine within the warranty period. Please contact Bandit Industries
to report the sale.
The quickest and easiest way to solve most problems is to use this manual to identify and
resolve the issue. If you are unable to do this or need additional assistance, please contact the
authorized dealer and/or Bandit Industries directly.
To initiate a warranty claim, complete and submit a Warranty Consideration Form. This form
is available online at www.banditchippers.com, through the authorized dealer or through Bandit
Industries, Inc. While some warranty claims will be covered by the vendor, all claims should be
initiated through and facilitated by Bandit Industries or the authorized dealer.
Regardless of warranty consideration, all parts will be invoiced at the time of shipment. Warranty
credits may be issued only if the claim forms are completed and all defective parts requested to
be returned have been returned to the requested location.
The manufacturer may elect, at its discretion, to reimburse reasonable labor costs to the
customer or dealer for defect repairs. No reimbursement will be considered without prior approval
from the manufacturer. The hours allowed for repair will be determined by Bandit Industries.
Diagnostic labor and travel expenses will not be covered under warranty.
The manufacturer will not reimburse the customer or dealer labor costs incurred for installing
“bolt-on” or “slip-on” items, such as hydraulic pumps and motors, control valves,  ow dividers,
belts, sheaves, etc. The manufacturer will provide replacement parts to the customer for defective
parts during the warranty period. Please keep the defective parts as you may need to return
them for warranty consideration. A Bandit representative will issue a RMA (Return Merchandise
Authorization) and contact the customer if the defective parts need to be returned.
The manufacturer will not reimburse the customer or dealer for shipping or freight charges for
replacement parts or returned defective parts during the warranty period without prior approval.
It is the customer’s responsibility to install any replacement parts unless the authorized dealer
agrees to install them.
The manufacturer will not reimburse travel costs to the servicing dealer without prior approval
from the manufacturer. It is the customer’s responsibility to deliver the machine to dealer’s service
facility unless the authorized dealer agrees to assist with machine transportation.
All warranty consideration is NULL AND VOID If the Warranty Validation Form
has not been submitted. The Warranty Validation Form can be mailed in or e-mailed to
[email protected].
Prior to delivery to  nal owner and during storage, this machine
must
be serviced and lubricated
to avoid damage that will
not be covered under warranty, see “Maintenance” section.
Any damage or equipment failure due to incorrect or incomplete service or maintenance by
the equipment owner will
not be covered under warranty.
All controls, safety devices, guards, and shields must be correctly operational and securely
in place at all times during equipment operation.
NOTICE

Bandit
4
Copyright 4/21
INTRODUCTION & WARRANTY
BANDIT INDUSTRIES INC. LIMITED WARRANTY
[phone]
Bandit Industries Inc., also referred to as “Manufacturer” warrants this new product to be free of
defects in workmanship and material for a period of 1 year or 2000 operating hours, which ever
comes  rst. Any machine used for lease or rental purposes warranty is limited to 90 days or 500
hours from the  rst day of initial service.
This warranty takes e󰀨 ect upon delivery to the original retail purchaser and return of the Warranty
Validation Form to Bandit Industries. The warranty is
NULL AND VOID
if the Warranty Validation
Form is not returned within 10 business days. The manufacturer at its option will replace or repair
at a point designated by the manufacturer, any parts which appear to have been defective in
material or workmanship. The manufacturer is not responsible for labor, consequential damages,
traveling expenses, down time expenses, or shipping and freight charges.
This warranty and any possible liability of Bandit Industries Inc., is expressly in lieu of any
other warranties, expressed or implied, including but not limited to, any implied warranty or
merchantability of  tness for a particular purpose and of any noncontractual liabilities including
product liabilities based upon negligence or strict liability. Bandit Industries Inc., will not be liable
for consequential damages resulting from breach of warranty.
All parties involved agree that the Owner’s Sole and Exclusive Remedy against the Manufacturer,
whether in contract or arising out of this warranty, instructions, representations, or defects
shall only be for the replacement or repair of defective parts as provided herein. In no event or
circumstances shall the Manufacturer’s liability exceed the purchase price of the machine. The
buyer also agrees that no other remedy (including but not limited to consequential or incidental
loss) shall be available to him or her.
It is absolutely necessary to return the Warranty Validation Form, completely and
accurately  lled out to Bandit Industries Inc. or e-mailed to [email protected],
within ten (10) business days from the date of purchase to validate this warranty. All warranty
consideration is NULL AND VOID If the Warranty Validation Form has not been submitted.
This warranty will
not
apply if the Bandit product is not operated with replacement parts or
equipment
not manufactured or recommended by Bandit Industries, Inc.
This warranty will not apply if the Bandit product is not operated in a manner recommended by
the manufacturer. The following examples would void the warranty:
1. The completed Warranty Validation Form has not been submitted.
2. The Bandit product has been abused, or not serviced properly.
3. Repairs or attempted repairs made without prior written authorization.
4. Repairs made due to normal wear are not warrantable.
5. The machine was involved in, or damaged by an accident.
6. The machine was damaged from any type of foreign material.
The owner is responsible for all scheduled maintenance as explained in the Operators Manuals.
Negligence of proper maintenance or any other negligence, accident or  re; nor with failure to
adjust, tighten, or replace wear items included but not limited to items such as knives, anvil, teeth,
belts, lubrication  uids, bearings,  lters, hydraulic components, loose nuts or bolts, etc. may void
warranty.
All components and parts being returned for warranty consideration must be complete and
assembled when delivered. Warranty will not be considered if the failed component has been
disassembled at any point in time. Hydraulic components and parts must be returned assembled
with all  uid ports capped or plugged and free of foreign contamination, or warranty will not be
considered.

Bandit
5
Copyright 4/21
INTRODUCTION & WARRANTY
BANDIT INDUSTRIES, INC. LIMITED WARRANTY
[phone]
Bandit Industries Inc., reserves the right to alter, improve, revise or modify any parts or products.
They also may change design, speci cations, or part prices without advance notice.
Bandit Industries Inc., is
NOT
responsible for updating or upgrading completed machines with
design changes that are made after its production.
Bandit Industries Inc., may require the Customer/Owner to bring their machine to the
Dealer/Manufacturer for warranty repairs. The Manufacturer
DOES NOT
pay Dealers or Customers
for travel time or travel costs. The Manufacturer does not furnish loaner machines or reimburse
for rental machines.
This warranty applies only to new and unused equipment or parts thereof
manufactured by Bandit Industries Inc. and is void if the machine is operated with replacement
parts or equipment not manufactured or recommended by Bandit Industries Inc.
All other components are warranted by their respective manufacturers (i.e. engines, axles,
hydraulic pumps and motors, clutches, tires, batteries, etc.) Even though certain warranties are
not handled through Bandit Industries, the warranty procedure for those components should be
facilitated through Bandit Industries or your nearest dealer.
Any machine used for lease or rental purposes warranty is limited to 90 days or 500 hours from
the  rst day of initial service.
NOTICE
Clutch and engine maintenance (air  lter maintenance, oil changes, oil  lter
maintenance, etc.) are important to your machine. Refer to the clutch or engine manual for
the maintenance schedule. Failure to perform the clutch or engine maintenance will void
the warranty with the respective manufacturer. Bandit Industries Inc. does not warranty
these components.
NOTICE
In order to process any warranty claims, it is the owner’s responsibility to  ll out a warranty
consideration form and send it in with pictures and detailed information within 10 business days
of the failure to the Manufacturer or our authorized dealer. If an RMA is given to return the failed
parts, they must be returned within 10 business days to the respective vendor or Bandit Industries
depending on the instructions given. The new parts must be installed and work be complete within
10 business from receiving the parts to receive credit.
1. Warranty Consideration Form, obtained
from Bandit Industries or its dealers,
completely and accurately  lled out.
2. Dealer from whom purchased.
3. Date of delivery.
4. Serial number of unit.
5. Model number of unit.
6. Engine make and serial number.
7. Length of time in use (hours on
machine).
8. Date of Failure.
9. Nature of Failure.
It is necessary to include the following information on any and all requests for warranty:
EXAMPLES OF COMPONENTS WARRANTIED BY THE COMPONENT MANUFACTURER.
-Engines
-Clutches
-Hydraulic Components
-Electronic Components
-Batteries
-Belts
-Bearings
-Axles
-Tires
-Tracks

Bandit
6
Copyright 4/21
MODELS 2550/2550T
TYPICAL SERIAL NUMBER AND/OR
WORK ORDER NUMBER LOCATIONS
1. Side of control box
2. W/O # on pivot mount plate The engine information is located on the engine
block. The clutch information is located on the
clutch plate (if equipped).
SERIALNUMBERLOCATIONS
NOTICE
2
1
