B&C Honeycomb User manual

Honeycomb Installation Guide –Inside Fit option
Parts
1. Installation brackets (Same bracket used for inside and face fitting)
2. Installation Screw (2 per bracket, Square head)
Bracket positioning
We will supply you with the correct number of installation brackets and they should be
evenly spaced across the head rail

Figure 1
Step 1
Inside mounting
The brackets should positioned evenly across the window frame as shown in Figure 3
If you want the blind at the front edge of your existing frame position them so that the
front of the bracket is 5mm back from the front of the window frame.
Screw through the bracket either upwards as shown in Figure 3. You will be supplied 2
screws per bracket.

Figure 3
Step 2
Installing the blind
Once the brackets have been fitted
Lift the blind up and place the front of the bracket under the front lip of the head rail.
The brackets are spring loaded, once the front of the bracket is under the front lip of the
head rail, straighten the blind and push the front of the blind toward the back of the
bracket.
By pushing the blind backwards it will allow you lift the back of the blind past the back
log on the bracket.
Once in position take the pressure off the front of the blind and it will spring forward
slightly locking the blind into position

Figure 4
Removing the Blind
To remove the blind, simply reverse the procedure, push the front of the blind so the
back of the head rail disengages from the rear lug on the bracket. Lower the back of
the blind on an angle and left out

Honeycomb Installation Guide –Face Fit option
Parts
1. Installation brackets (Same bracket used for inside and face fitting)
2. Installation Screw (2 per bracket, Square head)
Bracket positioning
We will supply you with the correct number of installation brackets and they should be
evenly spaced across the head rail
Figure 1

Step 1
Face mounting
The brackets should positioned evenly across the window frame as shown in Figure 3
If you want the blind at the front edge of your existing frame position them so that the
front of the bracket is 5mm back from the front of the window frame.
Screw through the bracket either upwards as shown in Figure 3. You will be supplied 2
screws per bracket.
Figure 3

Step 2
Installing the blind
Once the brackets have been fitted
Lift the blind up and place the front of the bracket under the front lip of the head rail.
The brackets are spring loaded, once the front of the bracket is under the front lip of the
head rail, straighten the blind and push the front of the blind toward the back of the
bracket.
By pushing the blind backwards it will allow you lift the back of the blind past the back
log on the bracket.
Once in position take the pressure off the front of the blind and it will spring forward
slightly locking the blind into position

Figure 4
Removing the Blind
To remove the blind, simply reverse the procedure, push the front of the blind so the
back of the head rail disengages from the rear lug on the bracket. Lower the back of
the blind on an angle and left out
