B&R SDL3 User manual

SDL3 Converter
User's manual
Version: 2.01 (November 2022)
Order no.: MASDL3CON-ENG
Translation of the original documentation

Publishing information
B&R Industrial Automation GmbH
B&R Strasse 1
5142 Eggelsberg
Austria
Telephone: [phone]
Fax: [phone]
[email protected]
Disclaimer
All information in this document is current as of its creation. The contents of this document are subject to change
without notice. B&R Industrial Automation GmbH assumes unlimited liability in particular for technical or editorial
errors in this document only (i) in the event of gross negligence or (ii) for culpably inflicted personal injury. Beyond
that, liability is excluded to the extent permitted by law. Liability in cases in which the law stipulates mandatory
unlimited liability (such as product liability) remains unaffected. Liability for indirect damage, consequential damage,
business interruption, loss of profit or loss of information and data is excluded, in particular for damage that is
directly or indirectly attributable to the delivery, performance and use of this material.
B&R Industrial Automation GmbH notes that the software and hardware designations and brand names of the
respective companies used in this document are subject to general trademark, brand or patent protection.
Hardware and software from third-party suppliers referenced in this document is subject exclusively to the respec-
tive terms of use of these third-party providers. B&R Industrial Automation GmbH assumes no liability in this regard.
Any recommendations made by B&R Industrial Automation GmbH are not contractual content, but merely non-
binding information for which no liability is assumed. When using hardware and software from third-party suppliers,
the relevant user documentation of these third-party suppliers must additionally be consulted and, in particular,
the safety guidelines and technical specifications contained therein must be observed. The compatibility of the
products from B&R Industrial Automation GmbH described in this document with hardware and software from third-
party suppliers is not contractual content unless this has been separately agreed in individual cases; in this respect,
warranty for such compatibility is excluded in any case, and it is the sole responsibility of the customer to verify
this compatibility in advance.
1412217059450-2.01

Table of contents
1 Introduction................................................................................................................5
1.1 Manual history.................................................................................................................................................5
1.2 Information about this document.................................................................................................................... 5
1.2.1 Organization of notices..............................................................................................................................5
1.2.2 Guidelines.................................................................................................................................................. 6
2 General safety guidelines........................................................................................ 7
2.1 Intended use................................................................................................................................................... 7
2.2 Protection against electrostatic discharge...................................................................................................... 7
2.2.1 Packaging.................................................................................................................................................. 7
2.2.2 Regulations for proper ESD handling....................................................................................................... 7
2.3 Regulations and measures............................................................................................................................. 8
2.4 Transport and storage.................................................................................................................................... 8
2.5 Installation....................................................................................................................................................... 8
2.6 Operation.........................................................................................................................................................9
2.6.1 Protection against contact with electrical parts.........................................................................................9
2.6.2 Ambient conditions - Dust, moisture, aggressive gases........................................................................... 9
2.6.3 Programs, viruses and malicious programs..............................................................................................9
2.7 Cybersecurity disclaimer for products...........................................................................................................10
3 System overview..................................................................................................... 11
3.1 Information about this user's manual............................................................................................................11
3.2 SDL3 Converter for Automation PCs........................................................................................................... 11
3.3 Connection options....................................................................................................................................... 12
3.3.1 SDL3 operation........................................................................................................................................12
3.3.1.1 SDL3 operation with SDL3 Converter via SDL................................................................................. 12
3.3.1.2 SDL3 operation with SDL3 Converter via DVI.................................................................................. 14
3.3.2 General limitations/characteristics........................................................................................................... 14
3.4 Design/Configuration..................................................................................................................................... 15
3.5 System data.................................................................................................................................................. 16
3.5.1 5COSD3.1000-00.................................................................................................................................... 16
3.5.1.1 General information............................................................................................................................16
3.5.1.2 Order data.......................................................................................................................................... 16
3.5.1.3 Technical data....................................................................................................................................17
3.5.1.4 Dimensions.........................................................................................................................................18
3.5.2 Device interfaces..................................................................................................................................... 19
3.5.2.1 Device interface overview..................................................................................................................19
3.6 Overview........................................................................................................................................................23
4 Dimensioning...........................................................................................................24
4.1 Spacing for air circulation............................................................................................................................. 24
5 Installation and wiring............................................................................................ 25
5.1 Basic information...........................................................................................................................................25
5.2 Installing the SDL3 Converter.......................................................................................................................27
5.2.1 Procedure................................................................................................................................................ 27
5.3 Installing the cable strain relief clip.............................................................................................................. 28
5.4 Connecting to the power grid....................................................................................................................... 29
5.4.1 Installing the DC power cable.................................................................................................................29
5.4.1.1 Wiring................................................................................................................................................. 29
5.4.2 Connecting the power supply to a B&R device...................................................................................... 30
5.4.3 Grounding concept.................................................................................................................................. 31
5.5 Connecting cables.........................................................................................................................................32
5.6 Removing the SDL3 Converter.....................................................................................................................33
5.6.1 Procedure................................................................................................................................................ 33
SDL3 Converter User's manual V 2.01 3

Table of contents
6 Commissioning........................................................................................................34
6.1 Basic information...........................................................................................................................................34
6.2 Switching on the device for the first time..................................................................................................... 34
6.2.1 General information before switching on the device...............................................................................34
6.2.2 Switching on the SDL3 Converter...........................................................................................................34
7 Software................................................................................................................... 35
7.1 Upgrade information......................................................................................................................................35
7.1.1 Firmware upgrade................................................................................................................................... 35
8 Maintenance.............................................................................................................36
8.1 Repairs/Complaints and replacement parts..................................................................................................36
9 International and national certifications...............................................................37
9.1 Directives and declarations...........................................................................................................................37
9.1.1 CE marking..............................................................................................................................................37
9.1.2 EMC Directive..........................................................................................................................................37
9.2 Certifications..................................................................................................................................................38
9.2.1 UL certification.........................................................................................................................................38
9.2.2 EAC..........................................................................................................................................................38
9.2.3 UKCA....................................................................................................................................................... 38
10 Accessories........................................................................................................... 39
10.1 General accessories................................................................................................................................... 39
10.1.1 Accessories - Order data...................................................................................................................... 39
10.2 Installation accessories............................................................................................................................... 39
10.2.1 Order data............................................................................................................................................. 39
10.3 0TB103.9x................................................................................................................................................... 40
10.3.1 General information............................................................................................................................... 40
10.3.2 Order data............................................................................................................................................. 40
10.3.3 Technical data....................................................................................................................................... 40
10.4 Cable strain relief clip................................................................................................................................. 41
10.4.1 5ACCRHMI.0011-000............................................................................................................................ 41
10.4.1.1 General information..........................................................................................................................41
10.4.1.2 Order data........................................................................................................................................ 41
10.4.1.3 Technical data..................................................................................................................................41
10.5 Cables......................................................................................................................................................... 41
11 Environmentally friendly disposal.......................................................................42
11.1 Separation of materials............................................................................................................................... 42
4 SDL3 Converter User's manual V 2.01

Introduction
1 Introduction
Information:
B&R makes every effort to keep documents as current as possible. The most current versions are
available for download on the B&R website (www.br-automation.com).
1.1 Manual history
Version Date Comment1)
2.01 November 2022 •Updated document.
•Updated "Technical data" on page 17.
•Updated "International and national certifications" on page 37.
•Updated "Grounding concept" on page 31.
•Cables are described in a separate document starting with this version.
2.00 August 2019 •Updated document.
•Updated the following sections:
°"+24 VDC power supply" on page 20
°"Connection options" on page 12
°"International and national certifications" on page 37
•Updated the following products:
°SDL cable 0.8 m and 6 m
°"Cable strain relief clip 5ACCRHMI.0011-000" on page 41
°"General accessories" on page 39
1.00 2015-04-15 •Updated technical data for the 5COSD3.1000-00 SDL3 Converter, see "Technical data" on page 17.
•Updated section "Grounding concept" on page 31.
•Updated figures for the SDL3 Converter.
V0.10
PRELIMI-
NARY
2014-12-17 •First version
1) Editorial corrections are not listed.
1.2 Information about this document
This document is not intended for end customers! The safety guidelines required for end customers
must be incorporated into the operating instructions for end customers in the respective national lan-
guage by the machine manufacturer or system provider.
1.2.1 Organization of notices
Safety notices
Contain only information that warns of dangerous functions or situations.
Signal word Description
Danger! Failure to observe these safety guidelines and notices will result in death, severe injury or substantial damage to property.
Warning! Failure to observe these safety guidelines and notices can result in death, severe injury or substantial damage to property.
Caution! Failure to observe these safety guidelines and notices can result in minor injury or damage to property.
Notice! Failure to observe these safety guidelines and notices can result in damage to property.
General notices
Contain useful information for users and instructions for avoiding malfunctions.
Signal word Description
Information: Useful information, application tips and instructions for avoiding malfunctions.
SDL3 Converter User's manual V 2.01 5

Introduction
1.2.2 Guidelines
European dimension standards apply to all dimension diagrams.
All dimensions in millimeters.
Unless otherwise specified, the following general tolerances apply:
Nominal dimension range General tolerance per
DIN ISO 2768 medium
Up to 6 mm ±0.1 mm
Over 6 to 30 mm ±0.2 mm
Over 30 to 120 mm ±0.3 mm
Over 120 to 400 mm ±0.5 mm
Over 400 to 1000 mm ±0.8 mm
6 SDL3 Converter User's manual V 2.01

General safety guidelines
2 General safety guidelines
2.1 Intended use
In all cases, applicable national and international standards, regulations and safety measures must be taken into
account and observed!
The B&R products described in this manual are intended for use in industry and industrial applications.
The intended use includes control, operation, monitoring, drive and HMI tasks as part of automation processes
in machines and systems.
B&R products are only permitted to be used in their original condition. Modifications and extensions are only per-
mitted if they are described in this manual.
B&R excludes liability for damage of any kind resulting from the use of B&R products in any intended way.
B&R products have not been designed, developed and manufactured for use that involves fatal risks or hazards
that could result in death, injury, serious physical harm or other loss without the assurance of exceptionally stringent
safety precautions.
B&R products are explicitly not intended for use in the following applications:
•Monitoring and control of thermonuclear processes
•Weapon systems control
•Flight and traffic control systems for passenger and freight transport
•Health monitoring and life support systems
2.2 Protection against electrostatic discharge
Electrical assemblies that can be damaged by electrostatic discharge (ESD) must be handled accordingly.
2.2.1 Packaging
•Electrical assemblies with housing:
Do not require special ESD packaging but must be handled properly (see "Electrical assemblies with hous-
ing").
•Electrical assemblies without housing:
Are protected by ESD-suitable packaging.
2.2.2 Regulations for proper ESD handling
Electrical assemblies with housing
•Do not touch the connector contacts of connected cables.
•Do not touch the contact tips on circuit boards.
SDL3 Converter User's manual V 2.01 7

General safety guidelines
Electrical assemblies without housing
The following applies in addition to "Electrical assemblies with housing":
•All persons handling electrical assemblies and devices in which electrical assemblies are installed must
be grounded.
•Assemblies are only permitted to be touched on the narrow sides or front plate.
•Always place assemblies on suitable surfaces (ESD packaging, conductive foam, etc.). Metallic surfaces
are not suitable surfaces!
•Assemblies must not be subjected to electrostatic discharges (e.g. due to charged plastics).
•A minimum distance of 10 cm from monitors or television sets must be maintained.
•Measuring instruments and devices must be grounded.
•Test probes of floating potential measuring instruments must be discharged briefly on suitable grounded
surfaces before measurement.
Individual components
•ESD protective measures for individual components are implemented throughout B&R (conductive floors,
shoes, wrist straps, etc.).
•The increased ESD protective measures for individual components are not required for handling B&R
products at customer locations.
2.3 Regulations and measures
Electronic devices are generally not failsafe. If the programmable logic controller, operating or control device or
uninterruptible power supply fails, the user is responsible for ensuring that connected devices (such as motors)
are brought to a safe state.
When using programmable logic controllers as well as when using operating and monitoring devices as control
systems in conjunction with a Soft PLC (e.g. B&R Automation Runtime or similar product) or Slot PLC (e.g. B&R
LS251 or similar product), the safety measures that apply to industrial controllers (protection by protective equip-
ment such as emergency stops) must be observed in accordance with applicable national and international regu-
lations. This also applies to all other connected devices, such as drives.
All work such as installation, commissioning and servicing are only permitted to be carried out by qualified person-
nel. Qualified personnel are persons who are familiar with the transport, installation, assembly, commissioning and
operation of the product and have the appropriate qualifications for their job (e.g. IEC 60364). National accident
prevention regulations must be observed.
The safety guidelines, information about connection conditions (nameplate and documentation) and limit values
specified in the technical data must be read carefully before installation and commissioning and must be strictly
observed.
2.4 Transport and storage
During transport and storage, devices must be protected against undue stress (mechanical stress, temperature,
humidity, aggressive atmosphere).
2.5 Installation
•The devices are not ready for use and must be installed and wired according to the requirements of this
documentation in order to comply with EMC limit values.
•Installation must be carried out according to the documentation using suitable equipment and tools.
•Devices are only permitted to be installed in a voltage-free state and by qualified personnel. The control
cabinet must first be disconnected from the power supply and secured against being switched on again.
•General safety regulations and national accident prevention regulations must be observed.
•The electrical installation must be carried out in accordance with relevant regulations (e.g. line cross section,
fuse protection, protective ground connection).
8 SDL3 Converter User's manual V 2.01

General safety guidelines
2.6 Operation
2.6.1 Protection against contact with electrical parts
In order to operate programmable logic controllers, operating and monitoring devices and uninterruptible power
supplies, it is necessary for certain components to carry dangerous voltages over 42 VDC. Touching one of these
components can result in a life-threatening electric shock. There is a risk of death, serious injury or damage to
property.
Before switching on programmable logic controllers, operating and monitoring devices and uninterruptible power
supplies, it must be ensured that the housing is properly connected to ground potential (PE rail). Ground connec-
tions must also be made if the operating and monitoring device and uninterruptible power supply are only connect-
ed for testing purposes or only operated for a short time!
Before switching on, live parts must be securely covered. All covers must be kept closed during operation.
2.6.2 Ambient conditions - Dust, moisture, aggressive gases
The use of operating and monitoring devices (e.g. industrial PCs, Power Panels, Mobile Panels) and uninterruptible
power supplies in dusty environments must be avoided. This can otherwise result in dust deposits that affect the
functionality of the device, especially in systems with active cooling (fans), which may no longer ensure sufficient
cooling.
The presence of aggressive gases in the environment can also result in malfunctions. In combination with high
temperature and relative humidity, aggressive gases – for example with sulfur, nitrogen and chlorine components
– trigger chemical processes that can very quickly impair or damage electronic components. Blackened copper
surfaces and cable ends in existing installations are indicators of aggressive gases.
When operated in rooms with dust and condensation that can endanger functionality, operating and monitoring
devices such as Automation Panels or Power Panels are protected on the front against the ingress of dust and
moisture when installed correctly (e.g. cutout installation). The back of all devices must be protected against the
ingress of dust and moisture, however, or the dust deposits must be removed at suitable intervals.
2.6.3 Programs, viruses and malicious programs
Any data exchange or installation of software using data storage media (e.g. floppy disk, CD-ROM, USB flash
drive) or via networks or the Internet poses a potential threat to the system. It is the direct responsibility of the user
to avert these dangers and to take appropriate measures such as virus protection programs and firewalls to protect
against them and to use only software from trustworthy sources.
SDL3 Converter User's manual V 2.01 9

General safety guidelines
2.7 Cybersecurity disclaimer for products
B&R products communicate via a network interface and were developed for secure connection with internal and,
if necessary, other networks such as the Internet.
Information:
In the following, B&R products are referred to as "product" and all types of networks (e.g. internal
networks and the Internet) are referred to as "network".
It is the sole responsibility of the customer to establish and continuously ensure a secure connection between
the product and the network. In addition, appropriate security measures must be implemented and maintained
to protect the product and entire network from any security breaches, unauthorized access, interference, digital
intrusion, data leakage and/or theft of data or information.
B&R Industrial Automation GmbH and its subsidiaries are not liable for damages and/or losses in connection
with security breaches, unauthorized access, interference, digital intrusion, data leakage and/or theft of data or
information.
The aforementioned appropriate security measures include, for example:
•Segmentation of the network (e.g. separation of the IT network from the control network1))
•Use of firewalls
•Use of authentication mechanisms
•Encryption of data
•Use of anti-malware software
Before B&R releases products or updates, they are subjected to appropriate functional testing. Independently of
this, we recommend that our customers develop their own test processes in order to be able to check the effects
of changes in advance. Such changes include, for example:
•Installation of product updates
•Significant system modifications such as configuration changes
•Deployment of updates or patches for third-party software (non-B&R software)
•Hardware replacement
These tests should ensure that implemented security measures remain effective and that systems in the customer's
environment behave as expected.
1) The term "control network" refers to computer networks used to connect control systems. The control network can be divided into zones, and there can be
several separate control networks within a company or site. The term "control systems" refers to all types of B&R products such as controllers (e.g. X20), HMI
systems (e.g. Power Panel T30), process control systems (e.g. APROL) and supporting systems such as engineering workstations with Automation Studio.
10 SDL3 Converter User's manual V 2.01

System overview
3 System overview
3.1 Information about this user's manual
This user's manual contains all necessary information regarding the SDL3 Converter.
For information about SDL3 link modules and SDL3 transmitters, see the Automation Panel and Automation PC
user's manuals.
Information:
All specifications in dimension diagrams and associated tables are in millimeters [mm].
3.2 SDL3 Converter for Automation PCs
Smart Display Link 3 offers even more advantages when used together with
an external converter. For example, SDL3 can be used to connect Automa-
tion Panels to all Automation PC 910, Automation PC 620 and Automation
PC 810 systems as well as to all Panel PCs. Upgrading systems to SDL3
in the course of retrofitting or modifications is extremely easy.
The integrated SDL3 interface makes it possible to connect two Automation
Panels to an Automation PC 910 in dual independent display mode.
SDL3 Converter User's manual V 2.01 11

System overview
3.3 Connection options
3.3.1 SDL3 operation
Smart Display Link 3 (SDL3) technology transfers all communication channels between a B&R industrial PC and
panel up to 100 m over a standard Ethernet cable (min. Cat 6a). An RJ45 connector is used for the device con-
nection, which is ideal for confined spaces in feed-throughs and swing arm systems.
3.3.1.1 SDL3 operation with SDL3 Converter via SDL
When operating SDL3 with an SDL3 Converter (5COSD3.1000-00) via SDL, communication between a B&R in-
dustrial PC and the SDL4 Converter is handled using an SDL cable and an optional USB type A/B cable. The
Automation Panel is connected to the SDL3 Converter using an SDL3 cable; the maximum SDL3 cable length
is 100 m.
In addition to the display data, information from the touch screen, matrix keys, LEDs and service/diagnostic data
is transferred.
If the B&R industrial PC is equipped with an SDL3 transmitter, then an additional SDL3 graphics line can also be
implemented.
The brightness of the display can be set via the B&R ADI Control Center.
Operation with a USB type A/B cable
The Automation Panel can be up to 100 m away from the SDL3 Converter; USB 2.0 is fully integrated in the SDL3
transfer and transferred over this distance. The maximum distance for transferring data between the B&R industrial
PC and SDL3 Converter (5COSD3.1000-00) is 5 m; USB 2.0 is transferred via a USB type A/B cable.
Power supply (SELV/PELV)
Automation Panel
with SDL3 receiver
B&R industrial PC
SDL cable
SDL3 cable
SDL3 Converter
USB type A/B cable
Availability of interfaces on Automation Panels with an SDL3 receiver:
SDL3 interface ✓USB1, USB2 ✓ USB 2.0 Power supply ✓Grounding ✓
Maximum cable length for SDL3: 100 m
Maximum cable length of SDL and USB: 5 m
Requirements
•Automation Panel with SDL3 receiver
•B&R industrial PC with SDL interface
•SDL3 Converter
•SDL cable, USB type A/B cable, SDL3 cable
12 SDL3 Converter User's manual V 2.01

System overview
Operation without a USB type A/B cable
The Automation Panel can be up to 100 m away from the SDL3 Converter; USB 2.0 is fully integrated in the SDL3
transfer and transferred over this distance. The maximum distance for transferring data between the B&R industrial
PC and SDL3 Converter is 10 m; USB 1.1 is fully integrated in the SDL transfer and transferred over this distance.
Automation Panel
with SDL3 receiver
B&R industrial PC
SDL cable
SDL3 cable
SDL3 Converter
Power supply (SELV/PELV)
Availability of interfaces on Automation Panels with an SDL3 receiver:
SDL3 interface ✓USB1, USB2 ✓ USB 1.1 Power supply ✓Grounding ✓
Maximum cable length for SDL3: 100 m
Maximum cable length of SDL: 10 m
Requirements
•Automation Panel with SDL3 receiver
•B&R industrial PC with SDL interface
•SDL3 Converter
•SDL cable, SDL3 cable
SDL3 Converter User's manual V 2.01 13

System overview
3.3.1.2 SDL3 operation with SDL3 Converter via DVI
When operating SDL3 with an SDL3 Converter (5COSD3.1000-00) via DVI, communication between an industrial
PC and the SDL3 Converter is handled using a DVI cable and USB type A/B cable. The Automation Panel is
connected to the SDL3 Converter using an SDL3 cable. The touch screen data from the multi-touch screen is
transferred via the USB type A/B cable.
The Automation Panel can be up to 100 m away from the SDL3 Converter; USB 2.0 is fully integrated in the SDL3
transfer and transferred over this distance. The maximum distance for transferring data between the B&R industrial
PC and SDL3 Converter is 5 m; USB 2.0 is transferred via a USB type A/B cable.
Automation Panel
with SDL3 receiver
Industrial PC
DVI cable
USB type A/B cable
SDL3 cable
SDL3 Converter
Power supply (SELV/PELV)
Availability of interfaces on Automation Panels with an SDL3 receiver:
SDL3 interface ✓USB1, USB2 ✓ USB 2.0 Power supply ✓Grounding ✓
Maximum cable length for SDL3: 100 m
Maximum cable length for DVI and USB: 5 m
Requirements
•Automation Panel with SDL3 receiver
•Industrial PC with DVI interface
•SDL3 Converter
•DVI cable, USB type A/B cable, SDL3 cable
Limitations
•Key and LED data is not transferred.
•Service and diagnostic data is not transferred.
•Resistive touch screens are not supported.
•Firmware updates are not possible.
•Adjusting the display brightness is not possible.
3.3.2 General limitations/characteristics
•USB 2.0 transfer is limited to 30 Mbit/s with SDL3.
•A display is always emulated by the SDL3 Converter using EDID data and hot plug detection on SDL3
Out, so DVI-compatible operation is possible. For this reason, the following behavior may occur during
operation with multiple displays. In the operating system, a connected panel is reported by the video driver
even in the following situations:
°No SDL3/SDL4 cable is connected.
°There is no connection established yet between the SDL3 link module and SDL3 Converter.
This behavior can be avoided by appropriate configuration in BIOS or via the graphics driver.
14 SDL3 Converter User's manual V 2.01

System overview
3.4 Design/Configuration
Configuration
SDL3 Converter Select 1
5COSD3.1000-00
SDL3/SDL4 cables Select 1
5CASD3.0030-00 5CASD3.0050-00 5CASD3.0100-00 5CASD3.0150-00
5CASD3.0200-00 5CASD3.0300-00 5CASD3.0500-00 5CASD3.1000-00
SDL cable Select 11)
SDL cable
5CASDL.0008-00 5CASDL.0018-00 5CASDL.0050-00
5CASDL.0060-00 5CASDL.0100-00
SDL cables with 45° connector
5CASDL.0018-01 5CASDL.0050-01 5CASDL.0100-01
SDL flex cables
5CASDL.0018-03 5CASDL.0050-03 5CASDL.0100-03
DVI cables Select 12)
5CADVI.0018-00 5CADVI.0050-00
USB cables Select 13)
5CAUSB.0018-00 5CAUSB.0050-00
Terminal blocks Select 1
Power supply connector
0TB103.9 0TB103.91
Accessories Optional selection
Cable strain relief clip
5ACCRHMI.0011-000
1) Only required for SDL operation.
2) Only required for DVI operation.
3) Optional for SDL operation, required for DVI operation.
SDL3 Converter User's manual V 2.01 15

System overview
3.5 System data
3.5.1 5COSD3.1000-00
3.5.1.1 General information
The SDL3 Converter makes operation via SDL3 with B&R industrial PCs and Automation Panels possible that
are not equipped with an SDL3 interface or SDL3 slot. Upgrading systems to SDL3 in the course of retrofitting or
modifications is extremely easy. When combined with an SDL3 interface integrated on a B&R industrial PC, two
Automation Panels can be connected in dual-independent display mode.
3.5.1.2 Order data
Order number Short description Figure
Converter
5COSD3.1000-00 SDL/SDL3 Converter
Required accessories
Accessories
0TB103.9 Connector 24 VDC - 3-pin, female - Screw clamp terminal block
3.31 mm²
0TB103.91 Connector 24 VDC - 3-pin, female - Cage clamp terminal block
3.31 mm²
SDL3/SDL4/PoE cables
5CASD3.0030-00 SDL3/SDL4/FT50 cable - 3 m - FT50 including Power over Eth-
ernet
5CASD3.0050-00 SDL3/SDL4/FT50 cable - 5 m - FT50 including Power over Eth-
ernet
5CASD3.0100-00 SDL3/SDL4/FT50 cable - 10 m - FT50 including Power over Eth-
ernet
5CASD3.0150-00 SDL3/SDL4/FT50 cable - 15 m - FT50 including Power over Eth-
ernet
5CASD3.0200-00 SDL3/SDL4/FT50 cable - 20 m - FT50 including Power over Eth-
ernet
5CASD3.0300-00 SDL3/SDL4/FT50 cable - 30 m - FT50 including Power over Eth-
ernet
5CASD3.0500-00 SDL3/SDL4/FT50 cable - 50 m - FT50 including Power over Eth-
ernet
5CASD3.1000-00 SDL3/SDL4/FT50 cable - 100 m - FT50 including Power over
Ethernet
SDL-cables
5CASDL.0008-00 SDL cable - 0.8 m
5CASDL.0018-00 SDL cable - 1.8 m
5CASDL.0050-00 SDL cable - 5 m
5CASDL.0060-00 SDL cable - 6 m
5CASDL.0100-00 SDL cable - 10 m
Optional accessories
Accessories
5ACCRHMI.0011-000 Strain relief USB - For APC2100/APC2200 - For SDL3 Convert-
er/SDL4 Converter
DVI cables
5CADVI.0018-00 DVI-D cable - 1.8 m
5CADVI.0050-00 DVI-D cable - 5 m
Other
5ACCRHMI.0000-000 HMI grounding clip
SDL cables with 45° connector
5CASDL.0018-01 SDL cable - 45-degree connector - 1.8 m
5CASDL.0050-01 SDL cable - 45-degree connector - 5 m
5CASDL.0100-01 SDL cable - 45-degree connector - 10 m
SDL flex cables
5CASDL.0018-03 SDL flex cable - 1.8 m
5CASDL.0050-03 SDL flex cable - 5 m
5CASDL.0100-03 SDL flex cable - 10 m
USB cables
5CAUSB.0018-00 USB 2.0 connection cable - Type A - type B connector - 1.8 m
5CAUSB.0050-00 USB 2.0 connection cable - Type A - type B connector - 5 m
16 SDL3 Converter User's manual V 2.01

System overview
3.5.1.3 Technical data
Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Order number 5COSD3.1000-00
General information
LEDs Status, SDL3
B&R ID code 0xE3C4
Certifications
CE Yes
UKCA Yes
UL cULus E115267
Industrial control equipment
Interfaces
USB
Quantity 1
Type USB 2.0
Variant Type B
Transfer rate Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s)
SDL/DVI-D interface
Variant DVI-I
Type SDL/DVI-D
SDL3 Out
Variant RJ45, shielded
Type SDL3
Electrical properties
Nominal voltage 24 VDC ±25%, SELV 1)
Nominal current Max. 0.2 A
Overvoltage category per EN 61131-2 II
Galvanic isolation Yes
Operating conditions
Pollution degree per EN 61131-2 2
Degree of protection per EN 60529 IP20
Ambient conditions
Temperature
Operation 0 to 55°C 2)
Storage -20 to 60°C
Transport -20 to 60°C
Relative humidity
Operation 5 to 90%, non-condensing
Storage 5 to 95%, non-condensing
Transport 5 to 95%, non-condensing
Vibration 3)
Operation (continuous) 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g peak
Operation (occasional) 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g peak
Storage 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g peak / 200 to 500 Hz: 4 g peak
Transport 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g peak / 200 to 500 Hz: 4 g peak
Shock 3)
Operation 15 g peak, 11 ms
Storage 30 g peak, 6 ms
Transport 30 g peak, 6 ms
Elevation
Operation Max. 3000 m 2)
Mechanical properties
Housing
Material Aluminum
Coating White
Dimensions
Width 40 mm
Height 100 mm
Depth 80 mm
Weight Approx. 500 g
1) EN 60950 requirements must be observed.
2) The temperature specifications correspond to a specification at 500 meters. The max. ambient temperature is typically derated 1°C per 1000 meters starting
at 500 m above sea level.
3) Top-hat rail clamp set X20AC0RF1 can also be used for improved installation / vibration resistance.
Vibration testing is performed per EN 60068-2-6. Shock testing is performed per EN 60068-2-27.
SDL3 Converter User's manual V 2.01 17

System overview
3.5.1.4 Dimensions
Information:
All specifications in dimension diagrams and associated tables are in millimeters [mm].
2D and 3D diagrams (DXF and STEP formats) can be downloaded from the B&R website
(www.br-automation.com).
100
40 80
18 SDL3 Converter User's manual V 2.01

System overview
3.5.2 Device interfaces
3.5.2.1 Device interface overview
Information:
The interfaces available on the device or module are numbered for the purpose of clear differentiation.
The numbering used by the operating system may deviate, however.
View A
View B A B
Legend
1"LED status indicators" on page 22 4"+24 VDC power supply" on page 20
2"SDL/DVI In interface" on page 21 5"Grounding" on page 20
3"USB In interface" on page 22 6"SDL3 Out interface" on page 22
SDL3 Converter User's manual V 2.01 19

System overview
3.5.2.1.1 +24 VDC power supply
Danger!
The device is only permitted to be supplied with a SELV/PELV power supply unit or with safety extra-low
voltage (SELV) per EN 60950.
The necessary 3-pin connector is not included in delivery; for suitable accessories, see "0TB103.9x" on page 40.
The device is protected against overload and reverse polarity by a soldered fuse (10 A, fast-acting). If the fuse
is defective (e.g. due to overload), the device must be sent to B&R for repairs. If the polarity is reversed, it is not
necessary to replace the fuse.
Pin Description Figure
1 +
2 Functional ground
3 -
•Reverse polarity protection
•3-pin
•Male
Electrical properties
Nominal voltage 24 VDC ±25%, SELV1)
Nominal current Max. 0.2 A
Overvoltage category per EN 61131-2 II
Galvanic isolation Yes
1) EN 60950 requirements must be observed.
3.5.2.1.1.1 Grounding
Caution!
The functional ground (power supply pin 2 and ground connection) must be connected to the central
grounding point (e.g. control cabinet or system) via the shortest possible path with the lowest possible
resistance and with the largest possible wire cross section. This type of grounding is mandatory for
proper functionality.
For example, a copper strip must be attached to the ground connection
at a central grounding point of the control cabinet or system in which the
device is installed. The wire cross section should be as large as possible
(at least 2.5 mm²).
20 SDL3 Converter User's manual V 2.01
