Programming the
Baofeng Radio

Rev Final 1/9/2104 AD7FO, AE7RJ, KE7RAP
Manually Programing Your BAOFENG UV5RA Dual band Transceiver
by Bob Peterson KE7RAP, Randall Jones AE7RJ and Jack Tiley AD7FO
1. Turn on the radio (knob on the top of the radio).
2. Push Orange V/M button If necessary to enter Frequency (VFO) mode (no channel
number is shown) if voice mode is on the radio will announce ”Frequency mode”.
ENTERING A FREQUENCY IN FREQUENCY (VFO) MODE
3. Press the A/B key so that the 5symbol is to the left of the upper frequency display
4. Press Orange V/M Button to enter the frequency mode If you have the voice on (option
#14) the radio will announce “Frequency Mode”and there will not be a channel number
next to the frequency display. If the radio announced “channel mode”press the
Orange VM Button again.
5. Enter the desired frequency like 147.300 443.400 using the keypad. Note that there is
no decimal point key, it will be entered automatically after your first three input digits. If
the voice mode (Menu # 14) if on the radio will announce each digit entered.
SETTING THE REPEATER OFFSET
6. Press the MENU Key.
7. Use the 65up down arrow keys to get to menu item #25 to set plus, minus or none
offset.
8. Press the MENU again and use the use 65up down arrow keys to select +, - or none.
9. Press MENU again to lock in your selection If you have voice turned on (Menu #14) the
radio announce “confirmed”.
10. Press the EXIT key to leave the menu system.
SETTING THE REPEATER OFFSET FREQUENCY
11. Press the MENU key.
12. Use the 65up down arrow keys to get to menu # 26 to set plus the repeater offset
frequency.
13. Press the MENU again. The radio will announce “offset frequency”if the voice is turned
on (Menu #14) . Use keyboard to enter the desired offset frequency (for 2 meters this
will be 600 KHz and for 70 cm it will be 5 MHz). For 600 KHz enter 00600 and for 5 MHz
enter 05000.
14. Press MENU again to lock in your selection If you have voice turned on (Menu # 14) the
radio announce “confirmed”.
15. Press the EXIT key to leave the menu system.
SETTING TRANSMIT POWER
16. Press the MENU again and use the 65up down arrow keys to get to item #2 Transmit
Power
17. Press the MENU again The radio will respond with ”power”if voice (menu #14) is on
and use the 65up down arrow keys to select the desired power level (HIGH or LOW)

Rev Final 1/9/2104 AD7FO, AE7RJ, KE7RAP
18. Press the MENU again to lock in your selection If you have voice turned on (Menu item
14) the radio announce “confirmed”.
19. Press the EXIT key to leave the menu system.
SETTING THE CTCSS TONE
20. Press the MENU key and use the 65up down arrow keys to get to menu item #13 to
set the CTCSS Tone if used.
21. Press the MENU If you have voice turned on (Menu item 14) the radio will respond with
“TCTCSS”. Use the keypad to select the desired CTCSS tone (i.e. 100, 123, 141, etc.)
22. Press the MENU again to lock in your selection If you have voice turned on (Menu #14)
the radio announce “confirmed”.
23. Press the EXIT key to leave the menu system.
STORING THE FREQUENCY
24. This procedure will store the frequency entered above along with the above settings.
25. Press the MENU and use the 65up down arrow keys to get to menu # 27 MEM-CH
26. Press the MENU the radio will announce “memory channel”. Use the keyboard to enter
an empty channel number location.
27. Press the MENU the radio will announce “receiving memory”
28. Press the EXIT key to leave the menu system.
ENTERING AND STORING THE TRANSMIT FREQUENCY
29. Press the *KEY. The display will show the transmit frequency (previously entered
frequency + or –or the offset set above or (no offset))
30. Press the MENU key
31. Press the MENU key the radio will announce “Channel number”.
32. Press the MENU key again and the radio will announce “Transmitting memory”.
33. Press the EXIT key to leave the menu system.
34. Press the * KEY to exit the “reverse”mode.
If you are entering additional frequencies go back to step 2, skipping steps
that are the same as the previous entry (power, offset, offset frequency, etc.)
Deleting a memory location
35. Press the MENU and use the 65up down arrow keys to get to menu #28 DEL-CH
36. Press the MENU The voice will announce “Delete Memory”. Use the keyboard to enter
the channel number to be deleted.
37. Press the MENU the radio will announce “Confirm”
38. Press the EXIT key to leave the menu system.
======================================================================
Keep in mind that you can program frequencies that are illegal to use with your amateur
radio privileges. This radio does not inhibit transmitting on these frequencies so if you

Rev Final 1/9/2104 AD7FO, AE7RJ, KE7RAP
accidently transmit you will be heard on that frequency (police, weather, taxi, fire, etc.) The
way to avoid this is to use the programing software and enter a transmit frequency of
000.000 MHz). We have not found a way of entering 000.000 in the manual programing
mode.
Additional “Menu“choices that may be of interest
All of these modes are accessed by pressing the MENU key then using the 65up down arrow
keys to get to the menu item then pressing the MENU key and the 65up down arrow keys or
entering data to make choices.
Menu # Function
# 0 SQL Set Squelch threshold (0 is no squelch 9 is max squelch))
# 1 STEP Tuning step size using the 65up down arrow keys
# 2 TXP Set transmit power (High or Low)
# 3 SAVE Battery Save Mode (Off or 1,2,3 or 4 Hours)
# 4 VOX (ON or OFF and sensitivity)
# 5 WN Wide or Narrow Bandwidth (5 KHz or 2½ KHz)
# 6 ABR Display illumination (Off or 1 to 10 Seconds)
# 7 TDR Dual watch (on, A or B)
# 8 BEEP Tone on key stroke (ON or OFF)
# 9 TOT Transmitter On Time, in seconds
# 11 RCTCS Receive CTCSS (set tone or off with the 65up down arrow keys)
# 13 TCTCS Transmit CTCSS (off or select tone with the 65up down arrow keys)
#14 VOICE Select language (English or Chinese)
# 19 PTT-ID (Off, BOT, EOT, BOTH)
# 20 PTT-LT Delay PTT for coding (0 to 50 ms)
# 23 BCL Busy Channel Lockout (on or off)
# 24 AUTOLK Automatic Keyboard Lock (on or Off)
# 25 SFT-D Repeater Offset (+,-, off)
# 26 OFFSET Repeater Offset Frequency
# 27 MEM-CH Memory Channel number entry
# 28 DEL-CH Delete Channel number entry
#33 BAND Band select VHF or UHF (same as BAND button)
# 34 TDR Dual watch (on, A or B)
#39 RODGER places tone at end of transmission (On or Off)
# 40 RESET ALL Restores default settings (use with caution, your stored data will
be lost)
