Barco BM1210 User manual

REV#1
SQUARE TABLE
INSTRUCTIONS
BM1210

C
B
D
2
END SUPPORT FRAME
A
6
1-1/4" X 1/4"
LAG SCREWS
3
1" X 5/16"
HEX HEAD BOLTS
23
5/16" SERRATED
FLANGE NUTS
7
4" X 5/16"
CARRIAGE BOLT
12
3-1/2" X 5/16"
CARRIAGE BOLT
8
PLASTIC BOARDS
2
ANGLE BRACE
E
2
END SUPPORT
10205
A
2
ANGLE BRACE
10202
F
2
OUTRIGGER FRAME
LEFT
10213
C
2
OUTRIGGER FRAME
RIGHT
10212
D
8
PIPE FRAME CLAMP
10204
G
1
CENTER SUPPORT
10215
E
C
N
1
PLASTIC BOARD
WITH UMBRELLA HOLE
B
EXTRA THICK WASHER
X 8
** KEEP ALL HARDWARE THAT IS LOOSENED AND REMOVED **
SQUARE TABLE
INSTRUCTIONS
BM1210
2/7
HARDWARE &
TOOLS REQUIRED
FOR ASSEMBLY

A
K
C
2
1-1/4" X 1/4"
LAG SCREWS
I
12
1" X 5/16"
HEX HEAD BOLTS
K
52
5/16" SERRATED
FLANGE NUTS
J
4
1-3/4" X 1/4"
CARRIAGE BOLT
L
36
3-1/2" X 5/16"
CARRIAGE BOLT
H
4
1/4" SERRATED
FLANGE NUT
M
8
EXTRA THICK WASHER
23" CENTER SUPPORT
X 1
NOTE: IT IS IMPORTANT TO KEEP ALL BOLTS FINGER TIGHT
DURING ASSEMBLY UNTIL ENTIRE TABLE IS ASSEMBLED
REQUIRED TOOLS
(NOT INCLUDED)
1 -1/2" WRENCH
1 - 1/2" SOCKET
1 - 7/16" SOCKET
1/8"- DRILL BIT
DRILL
TUBE SEAT SUPPORTS
X 2
** KEEP ALL HARDWARE THAT IS LOOSENED AND REMOVED **
SQUARE TABLE
INSTRUCTIONS
BM1210
3/7
HARDWARE &
TOOLS REQUIRED
FOR ASSEMBLY

1
AA
B
DETAIL A
SCALE 1 : 15
A
B
HHHHH
N
AP
DETAIL AP
SCALE 1 : 10
JJ
STEP 1: Tabletop Assembly
Lay 4 boards (B) face down on a flat, clean surface •
Place the board with the predrilled umbrella hole (N) in the center •
Insert twenty 3-1/2" x 5/16" carriage bolts (H) thru the face of the boards (B) •
Place end supports (A) over bolts and hand tighten with 5/16" flange nuts (J) •
SQUARE TABLE
INSTRUCTIONS
BM1210
4/7
TABLETOP
ASSEMBLY

CENTER
DETAIL CENTER
SCALE 1 : 5
II
E B
A
FF
View 2
View 3
FF
DETAIL View 2
SCALE 1 : 4
View 2
K
J
A
DETAIL View 3
SCALE 1 : 4
View 3
K
JJ
STEP 2: Mount the Center Support
Position the center support (E) on the bottom side •
of the board (N) with the umbrella hole
Align the holes in the bracket with the intersections •
of the web on the board
Pre-drill a 1/8" hole 3/4" deep at each hole location •
Attach the center bracket (E) with two 1-1/4" x 1/4" •
lag screws (I)
STEP 3: Attach the Angle Braces
Using two 1" x 5/16" hex bolts (K) and two 5/16" flange •
nuts (J), attach the angle support (F) to the center
support (E) and end support (A)
Repeat for the opposite side •
Keep all nuts finger tight until the assembly is complete •
SQUARE TABLE
INSTRUCTIONS
BM1210
5/7
TOP AND END
SUPPORT

View 4
D
C
AA
K
J
DETAIL View 4
SCALE 2 : 15
VIEW 4
A
D
K
J
View 5
G
G
G
C
D
DETAIL View 5
SCALE 1 : 5
VIEW 5
G
L
STEP 4: Attach Outriggers
Carefully turn the table right side up •
The outrigger frames (C & D) are marked left and right •
Attach each outrigger to its appropriate side using a •
1" x 5/16" hex bolt (K) and 5/16" flange nut (J)
STEP 5: Attach Pipe Frame Clamps
At the base of the table, place a pipe frame •
clamp (G) around the end support frame (A)
and the outrigger frame (C&D)
Attach the pipe frame clamp by bolting •
through the center of each clamp and secure
with a 1-3/4" x 1/4" carriage bolt (L) and 1/4"
flange nut (M)
SQUARE TABLE
INSTRUCTIONS
BM1210
6/7
OUTRIGGER
ASSEMBLY

B
BB
J
HH
H
H
JJ
STEP 6: Attach the Seats
Lay the remaining 4 boards (B) over the outrigger frames (C&D) •
Use the 3-1/2" x 5/16" carriage bolts (H) to go through the board (B) and outrigger frames (C&D) •
Fasten using the 5/16" flange nut (J) •
Repeat for each seat •
Square all parts and tighten all hardware •
SQUARE TABLE
INSTRUCTIONS
BM1210
7/7
SEAT
ASSEMBLY

18.19
48.00
17.50
2
75.94
48.00
48.00
9.44
31.93
13.50
9.44
18.50
71.00
2.63
SIDE
TOP
ALL DIMENSIONS ARE SHOWN IN INCHES
SQUARE TABLE
SPECIFICATIONS
BM1210

F
F
2.63
9.44
0.25
STEEL FRAME DETAIL
STEEL FRAME DETAIL
Plastic Boards w/ Steel
Frame Rectangular
Table Picnic
END SUPPORT FRAME 1.5" OD TUBING
SEAT SUPPORT ARM 1.5" OD & 2"X2" ANGLE IRON
TABLE TOP SUPPORT 2"X2" ANGLE IRON
HARDWARE ZINC
FRAME FINISH POWDER COAT BLACK
SQUARE TABLE
SPECIFICATIONS
BM1210
