Barco R591346 User manual

User’s manual
GREEN BCM SOLUTION
R591346

R591346 , Current Version
Title: GREEN BCM SOLUTION – User’s Manual
ID-no.: R591346
Revision: 04
Date: November-2016
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016______________________________________________________________________ ii

Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of
their respective holders. All brand and product names mentioned in this manual serve as comments or examples
and are not to be understood as advertising for the products or their manufacturers.
Copyright © 2015-2016 by Barco
Die Weitergabe sowie die Vervielfältigung aller Unterlagen, die von uns überlassen werden, deren Verwertung
und Mitteilung ihres Inhaltes an Dritte ist nicht gestattet, soweit dies nicht ausdrücklich zugestanden ist.
Urheberrechte, insbesondere auch solche an Software, werden nur insoweit übertragen, als es für die Erreichung
des speziellen Vertragszwecks erforderlich ist. Zuwiderhandlungen können zu Schadensersatz verpflichten. Alle
Rechte aus der Erteilung eines Patents oder der Eintragung eines Gebrauchsmusters verbleiben bei uns.
Copyright © 2015-2016 by Barco
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of BARCO.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016_____________________________________________________________________ iii

Barco standard warranty
In case of any contradiction or inconsistency to the Barco Terms and Conditions of Sale the latter will prevail!
This warranty is granted to end users owning a Barco product.
Barco warrants that its products, when delivered in new condition, in original packaging, sold directly or through
a Barco authorized partner and used in normal conditions, is free from any defects in manufacturing, materials
and workmanship.
The warranty shall apply only to the extent that the products or any parts thereof have been installed and ser-
viced by skilled personnel certified by Barco.
The Warranty shall only apply if the mandatory preventive maintenance actions as described in the technical
documentation have been executed.
Warranty starts on the shipment date of products. If Barco is responsible for onsite acceptance (OSAT), warranty
starts upon sign off of OSAT or when product is taken into use, whatever starts first.
For software, repairs and purchased spare parts 3 months warranty apply, unless specified otherwise.
Any third party product or any part thereof which Barco merely resells with its products or services is subject to
the original manufacturer's warranty unless specified otherwise.
The warranty does not apply to consumables (lamps, liquids, filters, reflectors, fans, pumps, batteries, etc…)
This warranty does not cover defects resulting from improper or unreasonable use or maintenance, failure to
follow operating instructions as mentioned in the technical documentation.
This warranty does not cover defects resulting from accident, unauthorized alteration or modification of the origi-
nal condition, or product being connected to or used in combination with other equipment, products or systems
(hardware and/or software) not compatible with the product or not respecting the installation requirements as
defined in the installation manual (such as high temperatures, humidity, dust, power surges…).
In no event shall Barco be liable for any defects, failures, loss of or damage caused by or resulting from wear and
tear, any external cause or event out of Barco’s control, use or operation of the product prior to acceptance, any
act or negligence of customer or any third party, or any phenomena inherent to the technology used such as
image retention, burn-in, vibrations, etc…
The warranty is void if serial numbers, warning labels or original seals are removed, changed or tampered with.
During the warranty period, Barco will, at its sole discretion, repair (at Barco’s own or at a Barco certified service
center), or replace (using new or refurbished replacement parts) any defect within a reasonable period of time
and free of charge. The replaced product, parts and/or components shall become the property of Barco and shall,
at our request, be returned to Barco, otherwise invoiced.
Upon request of the customer Barco can send a service engineer onsite to repair the product. The travel time and
the travel and living expenses of the service engineer shall be payable by the customer in accordance with Bar-
co’s then applicable rates and procedures.
Barco will not pay shipping, insurance or transportation charges from you to us (Barco’s own or a Barco certified
service center), or pay any import fees, duties and taxes.
To obtain the Standard warranty service, return the product or part using the following procedures:
(i) Contact your Barco partner or Barco help desk in your country/region (visit Barco.com/ support) for
specific return and shipping informations.
(ii) Label and ship the product to the address provided by Barco in your country/region. You shall pack
the products correctly in the original packaging so as to protect them from transport damage.
(iii) Place the necessary return material authorization number (RMA number) prominently on the outside
of the box. Shipments not bearing a RMA number will be refused.
Please ensure that a backup of any customized data or configurations is made prior to returning the product for
repair/replacement. During the repair or replacement process products are reset to their factory configurations
and all customized data and configurations will be lost.
The remedies specified in this warranty document shall constitute customer's sole and exclusive remedy and
Barco's sole and exclusive liability for Barco’s breach of the warranty hereunder.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016_____________________________________________________________________ iv

Revision sheet
To:
•BARCO Control Rooms GmbH
Greschbachstr. 5a, D-76229 Karlsruhe
Phone: [phone], Fax: [phone]
E-mail: [email protected], Web: www.barcocontrolrooms.com
From:
Date:
Please correct the following points in this documentation (R591346 ):
page
wrong
correct
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016______________________________________________________________________ v

Contents
1 Introduction........................................................................................................................................... 9
1.1 Styles and Symbols ......................................................................................................................................10
1.2 Safety Instructions........................................................................................................................................11
1.2.1 Standards .............................................................................................................................................11
1.2.2 Precautions ..........................................................................................................................................12
1.2.3 Intended use........................................................................................................................................14
1.2.4 Storage and transportation .................................................................................................................14
1.2.5 Unpacking of Devices ..........................................................................................................................14
1.2.6 Importers contact information ............................................................................................................14
1.2.7 Certifications (Green BCM Box)...........................................................................................................14
1.2.8 Servicing...............................................................................................................................................14
1.2.1 Environmental information: disposal information .............................................................................15
2 Summary ............................................................................................................................................. 17
3 Components of the Green BCM Solution............................................................................................ 19
3.1 Green BCM Box.............................................................................................................................................19
3.1.1 Position and function of the control elements on the front..............................................................20
3.2 Green Power Switch..................................................................................................................................... 21
3.2.1 Position and function of the control elements on the front..............................................................21
3.3 Complete solution ........................................................................................................................................22
3.4 Power Module 19inch ..................................................................................................................................23
3.4.1 Position and function of controls ........................................................................................................24
3.5 Green ONOFF Button ....................................................................................................................................25
4 Installation .......................................................................................................................................... 27
4.1 Installing Green BCM Box and the Green Power Switches (AC power supply).........................................27
4.1.1 Control cabling .....................................................................................................................................28
4.1.2 Power cabling ......................................................................................................................................29
4.1.3 Switching on ........................................................................................................................................29
4.2 Installing Green BCM Box and Power Module 19inch ................................................................................30
4.2.1 Control cabling .....................................................................................................................................32
4.2.2 Power cabling ......................................................................................................................................33
4.2.3 Cabling within the responsibility of a qualified electrician ...............................................................34
4.2.4 Disconnection and reconnection of a DC power cable / hard display reboot..................................36
5 Network setup .................................................................................................................................... 37
5.1 Test Green BCM Box .....................................................................................................................................39
5.2 Switching off Green BCM Box, Stand-by Mode...........................................................................................39
6 Maintenance ....................................................................................................................................... 41
6.1 Replacing the SMPS power unit...................................................................................................................42
6.2 Upgrading Firmware of Green BCM Box...................................................................................................... 43
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016_____________________________________________________________________ vi

7 Technical specifications ...................................................................................................................... 45
7.1 Green BCM BOX ............................................................................................................................................45
7.2 Green Power Switch..................................................................................................................................... 45
7.3 Power Module 19inch ..................................................................................................................................45
7.3.1 SMPS Power Unit 800W....................................................................................................................... 45
7.3.2 SMPS Power Unit 1200W.....................................................................................................................46
7.3.3 Mechanics ............................................................................................................................................46
7.4 Environmental Conditions ............................................................................................................................46
7.5 Interfaces ......................................................................................................................................................46
7.5.1 HDMI Type A ........................................................................................................................................46
7.5.2 USB connector...................................................................................................................................... 47
7.5.3 RJ25 connector.....................................................................................................................................47
7.5.4 RJ45 connector.....................................................................................................................................48
7.5.5 10.00mm Pitch Mini-fit ™ Header ......................................................................................................48
7.6 Module configurations .................................................................................................................................49
7.6.1 Distribution of power bricks / displays per power module ..............................................................50
8 Contact ................................................................................................................................................ 51
9 Certification......................................................................................................................................... 53
10 RoHS of Chinese Mainland................................................................................................................ 55
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ vii

1. Introduction
1Introduction
This chapter explains the structure of the manual itself and the used typographic styles and symbols. Safety in-
formation is provided concerning the operation of devices from Barco.
This manual explains the devices and function of the Green BCM Solution. The Green BCM Solution comprises the
following functional components:
Green BCM Box (mandatory)
Green Power Switch (optional, requires displays with AC power module)
Green On/Off button (mandatory with Power Module 19inch, else optional)
Power Module 19inch (optional, requires displays with DC power module)
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016______________________________________________________________________ 9

1. Introduction
1.1 Styles and Symbols
The typographic styles and the symbols used in this document have the following meaning:
Bold Labels, menus and buttons are printed in Bold font.
Condensed Links to both other chapters of this manual and to sites in the Internet are printed
condensed. In the on-line version of this manual all hyperlinks appear teal.
Courier
Names of files and parts from programs are printed in the
Courier
font.
Courier bold
Inputs you are supposed to do from the keyboard are printed in
Courier bold
font.
If you do not heed instructions indicated
by this symbol there is a risk of damage
to the equipment!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque de
dommage de l'équipement ! �
If you do not heed instructions indicated
by this symbol there is a risk of electrical
shock and danger to personal health!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque de
décharge électrique et sera source de danger
pour la santé du personnel ! �
If you do not heed instructions indicated
by this symbol there is a risk of damage
to parts, which are sensitive towared
electrostatic charge!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque de
dommage de pièces sensibles à la charge
électrostatique ! �
If you do not heed instructions indicated
by this symbol there is a risk to get
harmed by sharp objects!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque de
blessure dû à des objets tranchants !
If you do not heed instructions indicated
by this symbol there is a risk that parts
may explode!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque
d'explosion de pièces ! �
If you do not heed instructions indicated
by this symbol there is a risk that hot
parts impact persons or objects!
Le non-respect des instructions symbolisées par
ce pictogramme entraînera un risque de contact
de personnes ou d'objets avec des pièces
chaudes !
The sheet icon indicates additional notes. Cette icône représentant une feuille indique
des remarques supplémentaires.
Next to this icon you find further
information.
Cette icône est suivie d'informations plus
détaillées. �
This hand marks tips. Cette icône attire l'attention sur des conseils.
Next to this icon you find important
notes.
Cette icône est suivie de remarques
importantes.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 10

1. Introduction
1.2 Safety Instructions
This section describes safety precautions, which must be observed when installing and operating a product from
BARCO.
1.2.1 Standards
The devices are built in accordance with the requirements of the international safety standards EN 60950-1 and
IEC 60950-1. The device conforms to UL std. UL 60950-1 and is certified to CSA std. C22.2 No. 60950-1. The Power Module
19inch is also certified to China Compulsory Certifcation CCC. All these safety standards are the information technology
equipment standards, including electrical business equipment.
These safety standards impose important requirements on the use of safety critical components, materials and
isolation, in order to protect the user or operator against the risk of electric shock and energy hazard, and having
access to live parts.
Safety standards also impose requirements to the internal and external temperature variations, radiation levels,
mechanical stability and strength, enclosure construction and protection against risk of fire.
Simulated single fault condition testing ensures the safety of the equipment to the user even when the equip-
ment's normal operation fails.
Electromagnetic Interference
Green BCM Solution complies with the following EMC standards:
Electromagnetic compatibility -
emission:
EN 55022 (2010)/AC :2011
EN 61000-3-2 (2006) + A1 (2009) + A2 (2009)
EN 61000-3-3 (2008)
Electromagnetic compatibility -
immunity:
EN 55024 (2010)
Make sure to use cables with shielding of
type S-FTP or S-STP when connecting the
display to the network!
Assurez vous d'utiliser des câbles avec un
blindage de type S-FTP ou S-STP lors de la
connexion de l’écran au réseau!
EN55022/CISPR22 Class A ITE (Information Technology Equipment)
All the products within the Green BCM solution are products of class A ITE. ITE means Information Technology
Equipment. ITE is subdivided into two categories denoted class B ITE (products intended primarily for use in do-
mestic environment) and class A ITE (all other ITE which satisfies the class A ITE limits but not the class B ITE lim-
its).
This is a class A product. In a domestic envi-
ronment this product may cause radio inter-
ference in which case the user may be re-
quired to take adequate measures.
Ce est un produit de classe A. Dans un envi-
ronnement domestique, ce produit peut
causer la radio inter-conférence auquel cas
l'utilisateur peut être tenu de prendre les
mesures adéquates.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 11

1. Introduction
FCC Compliance statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
1.2.2 Precautions
For your own protection, observe the
following safety precautions when
installing, operating and servicing your
device!
Pour votre propre sécurité, respectez les
consignes de sécurité suivantes lors de
l'installation, l'exploitation et l'entretien de
votre appareil!
•Before operating the units please read this manual thoroughly and retain it for future reference!
•Observe all warnings and instructions printed on the devices!
•Servicing not explicitly mentioned in this manual should never be carried out by unauthorized personnel!
Never open the case of the unit without first disconnecting the power supply cord!
•To prevent fire or electrical shock hazard, do not expose this unit to rain or moisture!
•The Green BCM Box and the Green Power Switch should be operated from an AC power source!
•Check that the voltage and frequency of your power supply match those printed on the device label with the
rated electrical values!
•If you are not sure of the type of AC power available, consult your dealer or local power company!
•The Green BCM Box and the Green Power Switch are equipped with a 3-wire grounding plug, a plug having a
third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not
defeat the purpose of the grounding-type plug!
•Green BCM Box and the Green Power Switch must be grounded (earthen) via the supplied 3 conductor AC
power cable. (If the supplied power cable is not the correct on, consult your dealer.)
Mains lead (AC Power cord) with CEE 7 plug:
The wires of the mains lead are colored in accordance with the following code:
yellow + green
Earth (Ground)
blue
Neutral
brown
Line (Live)
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 12

1. Introduction
Power cord with NEMA 5-15 plug:
The wires of the power cord are colored in accordance with the following code.
Green or Green/Yellow: Earth (Ground)
White or Blue: Neutral
Black or Brown: Line ( Live)
•The cord set must be UL-approved and CSA-certified.
•The minimum specification for the flexible cord is No. 18 AWG Type SVT or SJT, 3-conductor.
•The cord set must have a rated current capacity of at least 10A.
•The attachment plug must be an Earth-grounding type with a NEMA 5-15P (10 A, 125 V) configuration.
Power cord with GB 2099 plug:
The wires of the power cord are colored in accordance with the following code.
yellow + green
Earth (Ground)
blue
Neutral
brown
Line ( Live)
•Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the
cord. To disconnect the cord, pull it out by the plug. Never pull the cord itself.
•If an extension cord is used with this product, make sure that the total of the ampere ratings on the products
plugged into the extension cord does not exceed the extension cord ampere rating.
•Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a risk of fire or electrical shock.
•Never spill liquid of any kind on the product. Should any liquid or solid object fall into the cabinet, unplug the
set and have it checked by qualified service personnel before resuming operations.
The Power Box 19inch comes with connection terminals for field wiring. The terminal block has 3 connections
(green-yellow, neutral, live; connection method: screw connection). The customer is responsible for providing the
correct connecting cables based on local power net and the electric specification on the product ID label.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 13

1. Introduction
1.2.3 Intended use
The Green BCM solution is intended for professional use only in Barco Control Room applications.
The Green BCM solution is not for household use!
1.2.4 Storage and transportation
All components of the Green BCM Solution have to be stored and transported in the original packaging in accord-
ance with the non-operating conditions,7.4 Environmental Conditions
1.2.5 Unpacking of Devices
Note advises on the packaging for unpacking!
Only unpack for immediate installation!
1.2.6 Importers contact information
To find your local importer, contact Barco directly or one of Barco’s regional offices. Use the contact information
given on the official Barco web site http://www.barco.com.
1.2.6.1 Made in information
•For the country the product has been manufactured in, please check the product ID label on the product itself
1.2.6.2 Production date
•For month and year of production, please check the product ID label on the product itself
1.2.7 Certifications (Green BCM Box)
See the product label for additional approval marks.
1.2.8 Servicing
Mechanical or electrical modifications others than described in this manual must not be made to the devices.
Barco is not liable for damages resulting from modified devices.
Only authorized personnel should carry out
other maintenance work not explicitly
mentioned in this manual!
Never open the case of any component
without disconnecting all power supply
cords! Measurements and tests with the
opened device may be carried out only in
the factory or by specially trained personnel,
due to the dangers of electrical shock.
Seul le personnel autorisé devrait effectuer
d'autres travaux d'entretien ne sont pas
explicitement mentionné dans ce manuel!
Ne ouvrez jamais le cas de tout composant
sans débrancher tous les cordons
d'alimentation! Mesures et essais avec le
dispositif ouvert peuvent être effectués que
dans l'usine ou par un personnel
spécialement formé, en raison des dangers
de choc électrique.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 14

1. Introduction
The Power Module 19inch is a multiple
power source! Always disconnect all power
sources before servicing! Servicing is
restricted to qualified personal!
High leakage current! Grounding is
mandatory prior connecting the displays!
The surface might be very hot!
Le 19 pouces Power Module est une source
d'alimentation multiples! Toujours
débrancher toutes les sources
d'alimentation avant l'entretien!
L'entretien est limité à un personnel
compétent!
Courant de fuite élevé! Mise à la terre est
obligatoire avant de connecter les écrans!
La surface peut être très chaud!
Keep the original shipping carton and packing material; they will come in handy if you ever have to ship your
unit. For maximum protection, repack your set as it was originally packed at the factory.
1.2.1 Environmental information: disposal information
This symbol on the product indicates that, under the European Directive 2012/19/EU govern-
ing waste from electrical and electronic equipment, this product must not be disposed of with
other municipal waste. Please dispose of your waste equipment by handing it over to a des-
ignated collection point for the recycling of waste electrical and electronic equipment. To pre-
vent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to pro-
mote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or
your municipal waste disposal service. For details, please visit the Barco website at:
http://www.barco.com/en/AboutBarco/weee
Disposal of batteries
This product contains batteries covered by the European Directive which must be collected and
disposed of separately from municipal waste.
If the battery contains more than the specified values of lead (Pb), mercury (Hg) or cadmium
(Cd), these chemical symbols will appear below the crossed-out wheeled bin symbol.
By participating in separate collection of batteries, you will help to ensure proper disposal and
to prevent potential negative effects on the environment and human health.
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur
[Republic of Turkey: In conformity with the WEEE Regulation]
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 15

2. Summary
2Summary
This manual describes the Green BCM Solution for Barco OVD/KVD/IVD/HVD video walls.
The Green BCM Solution has been introduced to fulfill the EnergyStar 6.0 requirements. To achieve these re-
quirements, all displays of an OVD/KVD/IVD/HVD video wall, all power switches and also the Green BCM Box has
to be switched off in standby. It is only a small controller in the control unit which stays alive and which is able
to power up the entire wall again from standby. The control unit will start up or shut down the complete wall in
a controlled way by controlling each device using the wall internal Ethernet interface.
The Green BCM Solution comprises the following functional components:
•Green BCM Box (mandatory)
•Power Box 19inch (optional) (requires displays with DC power supplies)
•Power switch boxes (optional) (requires displays with AC power supplies)
•Green ONOFF button (mandatory with Power Box 19inch, else optional)
For functional setup of the Green BCM Solution, the mandatory Green BCM Box and one of the optional compo-
nents is required.
Each display needs to be connected to either a power switch box (AC power supply) or an exit of the power
module on the Power Box 19 inch (DC power supply)
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 17

3. Components of the Green BCM Solution
3Components of the Green BCM Solution
3.1 Green BCM Box
The Green BCM Box is the mandatory component of the Green BCM solution.
The Green BCM Box serves as both, as switch controller and as Barco Wall Control Manager.
In its role as switch controller, the Green BCM Box together with one of the optional components (Green Power
Switch Box, Power Module 19inch) provides not only energy efficiency in standby mode but also low inrush cur-
rents:
When switching the entire display wall on, the command is executed with minimal delays on all display: it is
only during the zero crossing that the display is switched on. Thus the inrush current of the entire display wall is
rather low and does not require special safeguarding.
The green power switch is always looking for a zero crossing on the phase of the power net. If no power net is
connected, the Green Power Switch will not switch to on mode.
In standby mode, all displays of an OVD/KVD/IVD/HVD video wall, all power switches and also the BCM control-
ler are switched off. It is only a small controller in the control unit which stays alive and which is able to power
up the entire wall again from standby.
The command to power up is available on the web site of the Green BCM Box. The command can also be trig-
gered via API or the Green ONOFF Button.
In its role as Barco Wall Control Manager, the Green BCM Box manages and controls the displays of an
OVD/KVD/IVD/HVD display wall in terms of color and brightness. Please refer to the user manual of Barco Wall
Control Manager for detailed description.
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 19

3. Components of the Green BCM Solution
3.1.1 Position and function of the control elements on the front
POWER LED
When Green BCM Box is up and running, the green power LED is on.
Interfaces CLIENT, IR IN, PUSH BUTTON CONTROL IN
These interfaces are used by Green BCM Box as switch controller:
Green BCM Box can bring the display wall in ON/STANDBY mode by any of the following controls:
•Command on the Green BCM web page (interface labeled CLIENT)
•IR
•Green ONOFF button (interface labeled PUSH BUTTON CONTROL IN)
Interfaces WALL, CLIENT
These interfaces are used by Green BCM Box as wall router running Barco Wall Control Manager service:
Green BCM Box is operated via LAN and controls the displays also via LAN. Therefore the LAN interfaces Wall and
Client are required for operating Green BCM Box as wall router.
Interfaces USB1, USB2, (HDMI)
The device does not require to be connected to a keyboard and a monitor. It can be configured remotely using a
web browser. Please refer to the user manual of Barco Wall Control Manager Software.
The HDMI interface is for servicing only!
For Firmware upgrade of the Green BCM Box
use the USB2 interface only!!
Pour la mise à niveau du micrologiciel de
la BCM Green Box utiliser l'interface USB2
seulement !!
Interface CONTROL OUT
Used to connect to CONTROL IN of the first Green Power Switch in the chain, cf. 4.1.1 Control cabling
Barco – Green BCM Solution – R591346 – user's manual – Revision 04– November-2016____________________________________________________________________ 20
