Barco SP4K-B User manual

ENABLING BRIGHT OUTCOMES
Installation manual
SP4K-B

Registered office: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com
Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com

Changes
Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not
limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make
improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time
without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made
to the information in this publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the
secured Barco web site https://www.barco.com/en/signin.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights
of their respective holders. All brand and product names mentioned in this manual serve as comments or
examples and are not to be understood as advertising for the products or their manufacturers.
Product Security Incident Response
As a global technology leader, Barco is committed to deliver secure solutions and services to our customers,
while protecting Barco’s intellectual property. When product security concerns are received, the product
security incident response process will be triggered immediately. To address specific security concerns or to
report security issues with Barco products, please inform us via contact details mentioned on https://www.
barco. com/psirt. To protect our customers, Barco does not publically disclose or confirm security
vulnerabilities until Barco has conducted an analysis of the product and issued fixes and/or mitigations.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area may cause harmful interference, in which case the user will be responsible for correcting any interference
at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment
FCC responsible: Barco Inc.
3059 Premiere Parkway Suite 400
30097 Duluth GA, United States
Tel: [phone]

5R5912128 /03 SP4K-B
1 Safety...................................................................................................................................................................................................................9
1.1 General considerations ...............................................................................................................................................................10
1.2 Important safety instructions.....................................................................................................................................................12
1.3 Product safety labels.....................................................................................................................................................................16
1.4 High Brightness precautions: Hazard Distance.............................................................................................................18
1.5 HD for fully enclosed projection systems...........................................................................................................................20
1.6 HD in function of modifying optics .........................................................................................................................................21
2 Getting started..........................................................................................................................................................................................23
2.1 Installation requirements ............................................................................................................................................................24
2.2 Unpacking the projector ..............................................................................................................................................................26
2.3 Unpacking the external cooler.................................................................................................................................................30
2.4 Initial inspection ...............................................................................................................................................................................32
2.5 Conventions.......................................................................................................................................................................................33
2.6 Air flow...................................................................................................................................................................................................34
2.7 Web Communicator.......................................................................................................................................................................36
2.8 Web Commander............................................................................................................................................................................37
2.9 Exhaust adapters (optional)......................................................................................................................................................38
3 Installation process..............................................................................................................................................................................39
3.1 Installation process overview...................................................................................................................................................40
4 Physical installation projector....................................................................................................................................................41
4.1 Positioning the SP4K-B...............................................................................................................................................................42
4.2 Accessing the power connections.........................................................................................................................................45
4.3 Power input configuration of the projector ........................................................................................................................46
4.4 Connecting the projector with the power net ...................................................................................................................48
4.5 Connecting a UPS with the projector electronics..........................................................................................................50
4.6 Connecting the external cooler ...............................................................................................................................................52
5 Lenses and Lens holder..................................................................................................................................................................55
5.1 Available lenses...............................................................................................................................................................................56
5.2 Lens selection...................................................................................................................................................................................57
5.3 Installation of a lens.......................................................................................................................................................................58
5.4 Removal of a lens from the lens holder ..............................................................................................................................60
5.5 Lens shift, zoom and focus........................................................................................................................................................62
5.6 Scheimpflug introduction............................................................................................................................................................64
Table of contents

R5912128 /03 SP4K-B6
5.7 Scheimpflug adjustment..............................................................................................................................................................65
6 Input & communication ....................................................................................................................................................................69
6.1 Introduction.........................................................................................................................................................................................70
6.2 Cinema controller of the projector .........................................................................................................................................71
6.3 ICP-D (Integrated Cinema Processor – Direct) .............................................................................................................73
7 ICMP-X............................................................................................................................................................................................................75
7.1 ICMP-X introduction......................................................................................................................................................................77
7.2 ICMP-X HDD .....................................................................................................................................................................................79
7.3 What are the possible HDD swaps ......................................................................................................................................81
7.4 ICMP-X communication and input ports ............................................................................................................................83
7.5 ICMP-X status LEDs .....................................................................................................................................................................85
7.6 ICMP-X HDD status LEDs .........................................................................................................................................................86
7.7 ICMP-X device certificate...........................................................................................................................................................88
7.8 ICMP-X configuration via Web Communicator...............................................................................................................90
7.9 ICMP-X reset.....................................................................................................................................................................................91
7.10 Obtaining the ICMP-X certificate............................................................................................................................................92
7.11 Removing a HDD from the ICMP-X......................................................................................................................................93
7.12 Installing a HDD into the ICMP-X...........................................................................................................................................94
8 Projector Power Cycle......................................................................................................................................................................97
8.1 Explaining the power states......................................................................................................................................................98
8.2 Switching the projector ON..................................................................................................................................................... 100
8.3 Switching the projector OFF ................................................................................................................................................. 102
9 Connectivity ............................................................................................................................................................................................ 105
9.1 Connecting to the projector for the first time................................................................................................................. 106
9.2 Software update............................................................................................................................................................................ 107
10 Convergence .......................................................................................................................................................................................... 111
10.1 Opening the sealed compartment .......................................................................................................................................112
10.2 Closing the sealed compartment .........................................................................................................................................114
10.3 Convergence controls ................................................................................................................................................................116
10.4 Converging the blue pattern onto the red pattern.......................................................................................................118
10.5 Converging the green pattern onto the red pattern....................................................................................................119
11 Color calibration.................................................................................................................................................................................. 121
11.1 Calibration process..................................................................................................................................................................... 122
11.2 White point calibration............................................................................................................................................................... 123
11.3 Color gamut calibration............................................................................................................................................................. 125
12 Projector Covers................................................................................................................................................................................. 127
12.1 Removal of the front cover......................................................................................................................................................128
12.2 Removal of the rear cover....................................................................................................................................................... 129
12.3 Removal of the mains side cover........................................................................................................................................130
12.4 Removal of the operator side cover................................................................................................................................... 131
12.5 Removal of the sealed compartment side cover........................................................................................................ 132
12.6 Removal of the light source side cover............................................................................................................................ 133
12.7 Removal of the small rear cover.......................................................................................................................................... 134
12.8 Removal of the top cover......................................................................................................................................................... 135
12.9 Mounting the top cover ............................................................................................................................................................. 136
12.10 Mounting the light source side cover ................................................................................................................................137
12.11 Mounting the sealed compartment side cover............................................................................................................. 138
12.12 Mounting the operator side cover ....................................................................................................................................... 139

7R5912128 /03 SP4K-B
12.13 Mounting the mains side cover............................................................................................................................................. 141
12.14 Mounting the rear cover ...........................................................................................................................................................142
12.15 Mounting the front cover .......................................................................................................................................................... 143
A Dimensions.............................................................................................................................................................................................. 145
A.1 Dimensions of the projector ...................................................................................................................................................146
A.2 Dimensions of the universal pedestal............................................................................................................................... 147
A.3 Dimensions of the external cooler ......................................................................................................................................148
Glossary ..................................................................................................................................................................................................... 149
List of tools............................................................................................................................................................................................... 151
Index .............................................................................................................................................................................................................. 153

R5912128 /03 SP4K-B8

9R5912128 /03 SP4K-B
About this chapter
Read this chapter attentively. It contains important information to prevent personal injury while installing and
using your SP4K-B projector. Furthermore, it includes several cautions to prevent damage to your SP4K-B
projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings
mentioned in this chapter before installing and using the SP4K-B projector. After this chapter, additional
“warnings” and “cautions” are given depending on the procedure. Read and follow these “warnings” and
“cautions” as well.
Clarification of the term “SP4K-B” used in this document
When referring in this document to the term “SP4K-B” means that the content is applicable for following Barco
products:
• SP4K-27BHC
• SP4K-35B
• SP4K-40B
• SP4K-55B
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms
of guarantee. Observing the specification mentioned in this chapter is critical for projector
performance. Neglecting this can result in loss of warranty.
Safety 1

R5912128 /03 SP4K-B10
1.1 General considerations
General safety instructions
• Before operating this equipment please read this manual thoroughly and retain it for future reference.
• Installation and preliminary adjustments should be performed by qualified Barco personnel or by
authorized Barco service dealers.
• All warnings on the projector and in the documentation manuals should be adhered to.
• All instructions for operating and use of this equipment must be followed precisely.
• All local installation codes should be adhered to.
Notice on safety
This equipment is built in accordance with the requirements of the applicable international safety standards.
These safety standards impose important requirements on the use of safety critical components, materials
and insulation, in order to protect the user or operator against risk of electric shock and energy hazard and
having access to live parts. Safety standards also impose limits to the internal and external temperature rises,
radiation levels, mechanical stability and strength, enclosure construction and protection against the risk of
fire. Simulated single fault condition testing ensures the safety of the equipment to the user even when the
equipment's normal operation fails.
Notice on optical radiation
This projector embeds extremely high brightness (radiance) lasers; this laser light is processed through the
projector's optical path. Native laser light is not accessible by the end user in any use case. The light exiting
the projection lens has been diffused within the optical path, representing a larger source and lower radiance
value than native laser light. Nevertheless the projected light represents a significant risk for the human eye
and skin when exposed directly within the beam. This risk is not specifically related to the characteristics of
laser light but solely to the high thermal induced energy of the light source; which is equivalent with lamp
based systems.
Thermal retinal eye injury is possible when exposed within the Hazard Distance (HD). The HD is defined from
the projection lens surface towards the position of the projected beam where the irradiance equals the
maximum permissible exposure as described in the chapter “Hazard Distance”.
WARNING: No direct exposure to the beam within the hazard distance shall be permitted, RG3
(Risk Group 3) IEC EN 62471-5:2015
CAUTION: Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Restricted access location
This product may only be installed in a restricted access location. The definition of a “restricted access
location" is a location for equipment where both of following applies:
• Access can only be gained by SERVICE PERSONNEL or by OPERATORS who have been instructed
about the reasons for the restriction applied to the location and about the precautions that shall be taken.
• Access is through the use of the tool or lock and key, or other means of security, and is controlled by the
authority responsible for the location.
Why a restricted access location: This is a RG3 product. Based on international requirements, no person is
allowed to enter the projected beam within the zone between the projection lens and the related Hazard
Distance (HD). This shall be physically impossible by creating sufficient separation height or by placing
optional barriers. Within the restricted area operator training is considered sufficient. The applicable
separation heights are discussed in “High Brightness precautions: Hazard Distance”, page 18.
Users definition
Throughout this manual, the terms SERVICE PERSONNEL and TRAINED PROJECTIONIST refers to
persons having appropriate technical training and experience necessary to be knowledgeable of potential
hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and
ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures
Safety
