Barney Dachnaya Tryoshka Programming manual

width 3.0m
height 2.1m
any length multipple to 2m
min 4m
STRONG
honeycomb polycarbonate greenhouse
page 2-6
page7-22
Technical certi cate
Assembling manual
Сертифицировано
Русским Регистром

2
Greenhouse Sizes
Greenhouse length, m
Covered ground area, m2
Quantity of polycarbonate sheets 2100х6000 mm
(pcs)
412 3
618 4
824 5
Completing with packages
Green-
house
length
package number
№1 №2 №3 №4 №5 insert
№1 №2
+++++
+ + + + + + +
+ + + + + ++ ++
Contents of packages
contents dimensions, mm
weight, no
more kg
frame (4 m base length)
1 package - balks, straight elements and manual 106х1075х79 15,2
2 package - arc and end elements 275х1550х65 11,0
3 package - straight end elements, arc reinforcing elements 112х1415х65 25,0
4 package - fi xtures and component parts 80х180х130 3,0
5 package - sealing profi le 1,45
Insert (2 m frame elongation)
1 package - balks, straight elements, fi xtures 90х1405х65 13,7
2 package - arc elements 260х1550х65 5,0
Technical certi cate
Dachnaya Tryoshka greenhouse is designed for creation of microclimate favorable for growing
garden crops on cottage and household plots. Area of covered ground depends on length of the
greenhouse (table 1). Height of installed frame is 2.1 m, width is 3.0 m. The greenhouse may
have various length depending on desire of buyer. Required length of greenhouse is provided by
purchase of packages with extending inserts in addition to 4 m base length (table 2).
Greenhouse is  xed on the ground by digging special frame endings or on fundament using
cleater angles. Complete set includes all that is needed for fastening of coverage. Greenhouse
may be completed with coverage on buyer’s request. Greenhouse has two door openings and two
small windows in opposite ends.
Perform assembling and operation of the greenhouse in strict accordance with
the manual and operating rules stated in the technical certi cate. Please keep
this technical certi cate for further reference.
Description
Table 1
Table 2
Table 3

3
Technical certicate
Dachnaya Tryoshka detailed parts list
marking name quantity (pcs)
1st package (balks and straight elements)
2balk 16
3support 14
5rotator cover plate 4
8bottom end strainer 4
10 door opening strainer 4
11п middle right end strainer 2
11л middle left end strainer 2
12д door vertical 8
13д door horizontal 6
12ф small window vertical 4
13ф small window horizontal 4
14 small door diagonal 4
15 large door diagonal 4
16 small window diagonal 2
hooks 4
2nd package (arc elements)
4н bottom arc 6
4в top arc 3
4вк top end arc 2
4нкп right end bottom arc 2
4нкл left end bottom arc 2
3rd package (straight end elements and arc reinforcing elements)
1stand 10
2в top balk 12
9-1 bottom door opening stand 4
9-2л left top door opening stand 2
9-2п right top door opening stand 2
17 horizontal strainer 3
18 top brace strut 6
19 bottom brace strut 6
20 brace liner 6
21 stiffening boom 6
tubular reinforcing element 4
Table 4

4
Technical certi cate
Vstavka insert detailed parts list
1st package
1stand 4
3support 4
2в top balk 6
2balk 8
17 horizontal strainer 2
18 top brace strut 4
19 bottom brace strut 4
20 brace strut liner 4
21 stiffening boom 4
screw М4х8 164
screw М4х25 8
screw М4х35 12
nut 184
washer 20
2nd package
4н bottom arc 4
4в top arc 2
Table 5
Dachnaya Tryoshka detailed parts list
marking name quantity (pcs)
4th package ( xtures and component parts)
hook angle 8
end angle 8
screw М4х8 492
screw М4х10 50
screw М4х25 100
screw М4х35 76
self-tapping screw 6
nut 718
washer 188
hinge 8
rotator blank part (with two elastic headers) 4
bending tube 1
adhesive tape 1
knob 8
pin 4
special wrench 1
5th package (sealing pro le)
hinge pro le (m) 3,7
3,7 door pro le (m) 10
10 end pro le (m) 12
Table 4 (continuation)

5
Technical certi cate
1. Before use of greenhouse, assemble
and install it in accordance with the
manual.
When installing the greenhouse by
third parties, buyer should supervise
compliance of assembling with the
manual.
Operating rules
Cleaning and washing of polycarbonate sheets
1. Rinse sheet with warm water.
2. To remove dirt, wash it with mild soap solution or domestic detergent using a soft
cloth or sponge.
3. To remove water, rinse the sheet with cold water and wipe with a soft cloth.
Do not use sulphur cartridges for disinfecting greenhouse against fungal
and bacterial agents in order to prevent corrosion (darkening) of frame.
Never use abrasives or high-alkali detergents for cleaning polycarbonate
sheets. Dry wiping damages protective layer of the coverage and shortens its
service life. Never rub surface of polycarbonate sheets with a brush, metalized
fabric or other abrasive materials.
2. In winter, coverage of greenhouse should not be removed provided that snow load is
limited. If greenhouse be unattended all winter period, buyer should either remove the
coverage or estimate possible snow load. Ultimate load for the frame having complete
package with installed drawbars and side braces is 180 kg per 1 m2 corresponding to
rated snow load of IV snow region (according to 2.01.07-85 Loads and Impacts building
norms and rules (SNiP)). In case of correctly installed greenhouse manufacturer
guarantees snow resistance of the greenhouse in Moscow, Sverdlovsk, Novosibirsk and
other oblasts with snow region number not higher than IV. Under purchase clarify snow
region where greenhouse is installed.
Do not install greenhouse close to
buildings and trees from which snow or
ice can fall down. 2 m or more distance
is recommended.

6
Technical certicate
Warranty
1. Manufacturer is responsible for full completing frame elements of
greenhouse.
2. Manufacturer is responsible for assemblability of the greenhouse in
accordance with the manual.
3. Manufacturer is responsible for durability of the greenhouse under specied
values of weather impact.
4. Warranty period – 12 months from date of purchase.
Warranty conditions
The warranty does not cover cases of:
1. Installation of greenhouse with violation of manual’s requirements.
2. Violation of operating rules.
3. Unintended use of greenhouse.
4. Floods, hurricanes, other natural disasters.
Manufacturer: Volya LLC
8 Severnyi Pereulok, Dubna, Moscow Oblast 141983
Manufacturer is responsible for quality of products in accordance with RF Civil Code.
Manufacturer reserves right to change design of greenhouse
Date of manufacture:
Warranty

7
Manual
Dachnaya Tryoshka greenhouse installation manual
General view of frame is represented in Fig. 1. Install details in such a way
to make pro le side shelves facing coverage. Frame is constructed from
numbered elements.
Legend, indices:
К- end (along the length of greenhouse);
Н- bottom;
В- top;
П- right;
Л- left;
Ф- small window;
Д - door;
- arrow indicates installation direction according to manuals’ schemes.
Terminology:
Left side is from the left when standing outside of the greenhouse in front of
the door.
Right Side is from the right when standing outside of the greenhouse in front
of the door.
Connect elements using pro les, screws and nuts. When connecting elements
by pro le-in-pro le method, no matter what the element is on top.
Be careful not to damage elements, because they don’t have enough rigidity
before  nal assembling. Use supports (for example, chairs) on temporary stages
of assembling for uniform lifting of frame assembled. To coincide holes in
complicated joints use a nail of 4 mm diameter or a drift pin with tapered end.
1.
2.
3.
4.
Some elements have
free holes resulted from
elements’ uniformity
free holes resulted from
Introduction
Be careful! Elements have sharp angles. Guard against cutting! Work in safety
gloves.
gloves.
When assembling the frame, connect elements using all available holes.
Simpli ed connection with one or two screws is a violation of assembling
rules and a ground for warranty waiver.

8
General view of Dachnaya Tryoshka greenhouse frame
4ВК
2В
4Н
1
1
1
8
38
1
2
2
2
2
5
11П
11Л
19
20
21
18
11
9-1
9-1
9-2П
9-2Л
2
2
2
2
2В
17
16
14
15
13ф
13д
12д
12ф
Manual
9-1
11Л
9-2Л
3
1
А
Fig. 1
Б
Г
Е
Д
В
А
ГEД
БВ
10
4НКЛ
4НКЛ
4НКЛ
4НКП
4ВК
4ВК
8
8
10
4ВК

9
Manual
General view of Dachnaya Tryoshka greenhouse frame
General view of insert
for Dachnaya Tryoshka
greenhouse.
Fig. 2
Fig. 3
Dachnaya Tryoshka
extended by any
number of inserts.
866
4060
1000100010001000
2988
Greenhouse foundation support
layout plan.
Fig. 4
Each insert extends
greenhouse length by 2 m.
1061
А
Б
60
21
42
15
А
Б
А

10
Set out arcs 4в and 4вк
(Fig. 5).
Connect balks 2в to arcs.
Assembling stages
Fig. 5
Level the frame using  lling or deepening of pits to make longitudinal elements straight,
horizontal and parallel to each other and to make arcs even at side view. If arc planes
require leveling, loosen connections of balks with arcs, complete leveling on the ground and
tight screws again.
Perform assembling close to location of the greenhouse.
Assemble greenhouse in accordance with photographs of assembling stages and units
represented in Fig. 5…12. The  gures show assembling of greenhouse of 4 m length.
Required length is reached using attachment of appropriate number of insert packages.
Use M4x8 screws for connection of elements.
Dig pits on the site selected for greenhouse installation at a depth of shovel blade
according to Fig. 4 Install frame into the pits. Check equality of frame diagonals using a
cord. Total draft of greenhouse into the ground should be so that bottom elements
10 of
door opening and bottom balks
2 touch the ground. Check equality of the diagonals using
a cord again and correct position of the frame angles.
1.
2.
3.
4.
Installation sequence
Fig. 7
Fasten balks 2в on arc 4в
from two sides.
Manual
4в
4вк
4вк
4вк
4в
4в
4в
4в
4в
Fig.6
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
2в
4вк
4в
4в

11
Fig.12
Connect arcs 4н, 4нкп,
4нкл to arcs 4в.
Connect balks 2 to bottom
arcs ( Fig. 9 ). Do it from the
other side in the same way
( Fig. 10 ).
Connect stands
1 to
bottom arcs and then
connect balks 2 to them
( Fig. 11 ).
Install end elements
8, 10, 11-л, 11-п,
9-1, 9-2л, 9-2п (Fig. 12).
Assembling stages
Manual
Fig. 8
А
Б
Г
В
В
4н
4нкп
4нкп
4нкп
4нкп
4нкп
4н
4н
4н
4нкп
4вк
4н
4н
4н
4н
4н
4н
4н
4нкл
4нкл
4нкл
2
2
2
2
2
22
2
221
1
3
33333
1
1
1
1
1
1
11л
11
8
8
8
8
9-1
9-2п
10
10
9-1
9-2
4вк
4в
Fig.9
Fig.11
Fig.10
А
Г
В
Б

12
Fig. 13
А
БВ
Г
Install side braces (elements 18,
19) and strainer (element 17) on
each arc inside of greenhouse
frame. Assemble side brace from
two elements. Connect side brace
liner 20 to the joint of top and
bottom brace struts and to arc 4н
on the other end. Use stiffening
boom 21 to connect strainers with
side braces.
Assembling stages
Manual
19
2
2
4н
Г
А
21
17
4В
4Н
18
Б
4н
20
В
20
19
18
(inside view)

13
Mount angles for end coverage fastening
according to the scheme.
Assembling stages
Manual
tubular
reinforcing
element
tubular
reinforcing
element
Fig.14 2в
2в
2в
9-2П
9-2Л
9-2П
Mount tubular reinforcing elements of door opening in
accordance with Fig. 14
(inside view)
4ВК
4ВК
angle
4НКЛ
- points of end angles fastening

14
Manual
Cutting and fastening of coverage
1. Cut coverage sheet for ends. To
do this, cut a piece of 2095 mm
length from polycarbonate sheet
(see cutting lines on Fig. 15).
To make a stencil of coverage,
put the cut piece to assembled
end of greenhouse and, without
removal of protective  lm from
polycarbonate, make a stencil
marking on the coverage sheet
by elements 4вк, 4нк and 1
with allowance (Fig. 16). When
marking a sheet, align its edge
strictly with edges of elements
9-1, 9-2. Cut a stencil, mark the
rest of sheet using the stencil in
accordance with cutting scheme
(Fig. 15).
CUT POLYCARBONATE
SHEET STRICTLY
IN ACCORDANCE WITH
FIG. 15 AND 16
2100 x 600 mm honeycomb
polycarbonate sheet
Fig. 15
Be careful! In windy
weather, load
polycarbonate
sheet edges with burdens to
prevent damage.
Left end
side
/stencil/
Left end
side
Right end
side
Door
Door
Ridge panel
Right end
side
2095
805
1480
2100
1810
6000
Cutting line
Small
window
Small
window
330
330

15
Manual
Cutting and fastening of coverage
A power jigsaw or  ne tooth arm saw is recommended for cutting.
Mount honeycomb polycarbonate strictly facing sun with a side having
protective layer (by all means, clarify it under purchase or before
mounting). Protective layer usually is on the side with inscriptions on
transport  lm. On the other side of sheet  lm is clear. After marking
the sheet but before its cutting make marks on protective side of each
piece of sheet: After removal of transport  lm sheet sides have no visual
differences. Transport  lm is removed from both sides immediately
before fastening coverage on the frame.
Fig. 16
2095
2100
marking
1
4НК

16
Manual
Раскрой и крепление покрытия торца
Fig. 17
2. Cut coverage pieces of ridge panel located above the
door at the place of installation from remaining pieces.
Mark coverage by elements 4вк with allowance aligning
bottom edge of sheet with bottom edge of element 10
(Fig. 17 ).
marking 4вк
10
Cutting and fastening of coverage
coverage
3. Mount end sides in accordance with Fig. 21. Holding a piece of coverage fasten it
on elements 8, 11, 10 using washers and screws M4x25 (Fig. 18), on elements 9-1,
9-2 using washers and screws M4x35 (Fig. 19), and on angles using washers and
tap screws. Holes for screws are drilled by boring bit of 4 mm diameter from inside
of greenhouse through available holes in frame elements. Mount ridge panel pieces
fastening them on elements 10 (Fig. 18).
Fig.18
Fig.18
coverage
washer
screw М4х25
8,11,10
Fig.19
coverage
washer
screw М4х35
9-1,9-2 elements
4ВК, 4НК
и 1
end sealer
protective layer
Fig.20
4. Even coverage pieces by arcs 4нк, 4вк and stand 1using a knife and mount
sealing pro le in accordance with Fig.20.
end coverage

17
Manual
Cutting and fastening of coverage
Avoid excessive tightening of fastening screws to prevent crumbling of
polycarbonate and destruction of honeycomb.
5. Mount washers and angles for end hook in
accordance with Fig.21.
Fig.21
ground level
- washer fastening points
hook angle
washer

18
Manual
12д
Door
Assembled door and small window
14
13д
15
15
15
14
Б
Fig. 22
А
12д
12д
13д
13д
14
15
15
14
14
14
Small
window
А
Б
13ф 13ф
13ф 12ф
16
16
12ф
12ф 12ф
13ф
13д
14
12д
12д
15
14
13д
13д
15
13д
12д
12д
12д
Assemble door and end small window from elements 12, 13, 14, 15, 16 (Fig.22).
6. Fasten pieces of coverage on door and small window using washers (Fig. 23, 24) making
runoff by one side (Fig. 28) closing combs beforehand (with adhesive tape). Mount sealing
pro les by door contour in accordance with Fig. 25, 26, 27. Mount hinges over polycarbonate.
When mounting hinges on small window, eliminate screw gaps in holes: move top hinge to the
small window and bottom hinge - from the small window. It is necessary for compensating a
hinge play to eliminate small window slack.

19
Cutting and fastening of coverage
Manual
Fig.24
adhesive
tape
handle
handle door sealer
hinge sealer
coverage
15
screw М4х10
coverage
adhesive tape
door sealer
hinge
adhesive tape
door sealer
door sealer
hinge sealer
door sealer
door sealer
coverage
hook angle
hinge
washer
hinge
adhesive tape
adhesive
tape coverage
coverage
Fig.23
pin
washer

Manual
20
Cutting and fastening of coverage
Fig.28
end coverage
20..25мм
(coverage run out of door contour)
Door
washer
element 12д
element 9-1
door
coverage
small
window
coverage
screw М4х25
screw М4х25
element 10
element 4ВК
door sealer
element 13ф
element 10
element 13д
Small window
ridge panel
Fig.25
end coverage
coverage
screw М4х14 screw М4х10
hinge sealer
hinge
washer washer
washer
element 12д
Door
Fig.26
door sealer
door sealer
end sealer
screw М4х25
screw М4х25
door
coverage
door sealer
door sealer
washer
washer
7. Install assembled doors and small windows on ends mounting sealer in accordance
with Fig. 25-28.
When mounting small windows, prevent its further slackening. When tightening the
screws, lift the opposite end of small window to remove screw gaps in holes.
Fig.27
screw М4х25
screw М4х25
screw М4х25 screw М4х35
element 10
screw М4х25
screw М4х35
element 9-1
element 13д
