Bartec Polaris Remote 15" User manual

User Manual - TRANSLATION
POLARIS REMOTE
POLARIS Zero Client 12,1" W 15" 17,3" 19,1" 24"
Typ B7-72V1-….
ATEX
Zone 2 and Zone 22
Document no. B1-72V1-7D0007
Revision 1 / Status: September 2020
Reservation: Technical ata subject to change without notice. Changes, errors an
misprints may not be use as a basis for any claim for amages.
Content Pages
English 1-88
GmbH
Max-Eyth-Straße 16 Phone: [phone] Support: support-polaris@bartec. e
97980 Ba Mergentheim Fax: [phone] Downloa : http://automation.bartec. e
GERMANY Internet: www.bartec. e

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Table of Contents
Technical ata subject to change.
09/2020

Table of Contents POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
Technical ata subject to change.
09/2020
1. Basic safety instructions .................................................................................................................... 1
1.1 Notes on this manual ................................................................................................................ 1
1.1.1 Languages .................................................................................................................... 2
1.1.2 Changes to the ocument ............................................................................................ 2
1.2 Han ling the pro uct ................................................................................................................. 2
1.3 Use in accor ance with the inten e purpose .......................................................................... 2
1.3.1 Exclusive purpose ........................................................................................................ 2
1.3.2 Improper use ................................................................................................................ 3
1.4 Owner’s/Managing operator’s obligations ................................................................................. 3
1.5 Safety instructions ..................................................................................................................... 3
1.5.1 General safety instructions ........................................................................................... 3
1.6 Safety instructions for operation................................................................................................ 3
1.6.1 Upkeep ......................................................................................................................... 3
1.6.2 Maintenance ................................................................................................................. 4
1.6.3 Inspection ..................................................................................................................... 4
1.6.4 Repairs ......................................................................................................................... 4
1.6.5 Commissioning ............................................................................................................. 4
1.7 Ex protection type, certification an stan ar s ......................................................................... 4
1.8 Warranty.................................................................................................................................... 4
2. Product description............................................................................................................................. 6
2.1 Definition ................................................................................................................................... 6
2.2 Schematic esign ...................................................................................................................... 7
3. Explosion protection and approvals ................................................................................................. 8
4. Technical data...................................................................................................................................... 9
4.1 POLARIS Zero Client ................................................................................................................ 9
4.1.1 Characteristics POLARIS Zero Client 12.1" W ........................................................... 10
4.1.2 Characteristics POLARIS Zero Client 15" / POLARIS Zero Client 15 " Sunlight ........ 11
4.1.3 Characteristics POLARIS Zero Client 17.3" ............................................................... 12
4.1.4 Characteristics POLARIS Zero Client 19.1" ............................................................... 13
4.1.5 Characteristics POLARIS Zero Client 24" .................................................................. 14
4.2 Keyboar ................................................................................................................................. 15
4.2.1 Explosion Protection ................................................................................................... 15
4.2.2 General Data .............................................................................................................. 15
4.2.3 Characteristics enclosure for keyboar ...................................................................... 16
4.3 Finger mouse, Trackball, Touchpa an Joystick ................................................................... 16
4.3.1 Explosion protection ................................................................................................... 16
4.3.2 Variants ...................................................................................................................... 17
4.4 USB Smart Device .................................................................................................................. 18
4.4.1 Explosion protection ................................................................................................... 18
4.4.2 Electric ata (USB stan ar ) ...................................................................................... 18
4.4.3 Technical ata (WLAN)............................................................................................... 19
4.5 Pro uct Labelling .................................................................................................................... 20
5. Transport, Storage, Scope and Assembly ...................................................................................... 21
5.1 Transport ................................................................................................................................. 21
5.2 Interme iate Storage............................................................................................................... 21
5.3 Scope of elivery..................................................................................................................... 21
5.3.1 Accessories optional ................................................................................................... 21
5.4 Assembly................................................................................................................................. 22
5.4.1 Installation options ...................................................................................................... 22
6. Installation.......................................................................................................................................... 23
6.1 Requirements .......................................................................................................................... 23
6.2 Mechanical Installation ............................................................................................................ 24
6.2.1 Installation 2G-/3G-enclosure ..................................................................................... 25
6.2.2 Installation as a System Solution in the Stainless Steel Enclosure "Exclusive II" ...... 26
6.2.3 Floor mounting (Stainless steel enclosure "Exklusive II“: ........................................... 27
6.2.4 Wall mounting (Stainless steel enclosure "Exklusive II“: ............................................ 27
6.2.5 Table mounting swivel/tilt (Stainless steel enclosure "Exclusive II") ........................... 28
6.3 Electrical Installation ............................................................................................................... 29

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Table of Contents
Technical ata subject to change.
09/2020
6.3.1 Installation gui elines ................................................................................................. 29
6.4 Terminal compartments .......................................................................................................... 30
6.5 PE con uctor connection ........................................................................................................ 31
6.6 Terminal compartments X1 ..................................................................................................... 32
6.6.1 Cable entries .............................................................................................................. 32
6.6.2 Supply voltage terminal assignment) .......................................................................... 32
6.6.3 Ethernet terminal assignment ..................................................................................... 32
6.6.4 RS422 interface .......................................................................................................... 33
6.6.5 USB interface ............................................................................................................. 34
6.6.6 2 x Ethernet terminal assignment ............................................................................... 35
6.6.7 Universal Power Supply for Scanner Series BCS 36xx IS ......................................... 36
6.6.8 Fibre-Optic Port (optional) .......................................................................................... 37
6.7 Terminal compartment X2 ....................................................................................................... 38
6.7.1 Cable entries .............................................................................................................. 38
6.7.2 Connection of a keyboar to the POLARIS (optional) ................................................ 38
6.7.3 USB socket, 4-pole, Type A ....................................................................................... 39
6.8 EMC (Electromagnetic Compatibility) ..................................................................................... 40
6.8.1 Voltage Supply (AC- an DC-Variants) ...................................................................... 40
6.8.2 Back-up fuse ............................................................................................................... 41
6.8.3 Interference suppression ............................................................................................ 41
6.8.4 Shiel ing ..................................................................................................................... 42
6.8.5 Connection of shiel ing .............................................................................................. 42
6.8.6 Examples of Shiel ing Connections ........................................................................... 42
6.8.7 Ethernet cable ............................................................................................................ 43
7. Commissioning.................................................................................................................................. 44
7.1 Final Inspection ....................................................................................................................... 44
8. Operation............................................................................................................................................ 45
8.1 Operating system .................................................................................................................... 45
8.1.1 General remarks ......................................................................................................... 45
8.1.2 Functions of the ZeroClient Concept .......................................................................... 45
8.1.3 ZeroClient Shel ........................................................................................................... 46
8.1.4 Tile Quick Start Bar .................................................................................................... 47
8.1.5 Info-Center .................................................................................................................. 48
8.1.6 Wi gets ....................................................................................................................... 48
8.1.7 Tile-System menu ....................................................................................................... 50
8.1.8 Application .................................................................................................................. 50
8.1.9 System Functions ....................................................................................................... 50
8.1.10 Switching to A ministrator Mo e ................................................................................ 51
8.2 ZeroClient Control Center ....................................................................................................... 53
8.2.1 "Apps” Tab” ................................................................................................................. 53
8.2.2 Structure of the element list ........................................................................................ 54
8.2.3 Applications ................................................................................................................ 54
8.2.4 Inserting a New Application ........................................................................................ 55
8.2.5 E iting Applications .................................................................................................... 56
8.2.6 Deleting Applications .................................................................................................. 57
8.2.7 System Functions ....................................................................................................... 57
8.2.8 E iting System Functions ........................................................................................... 58
8.2.9 Wi gets ....................................................................................................................... 59
8.2.10 "UWF" Tab .................................................................................................................. 60
8.3 Network setup ......................................................................................................................... 62
8.4 Setting up RDP connections ................................................................................................... 68
8.4.1 Enabling RDP connections in the Zero Client Control Centre .................................... 68
8.4.2 File storage ................................................................................................................. 69
8.4.3 Settings for automatic login ........................................................................................ 70
8.4.4 Checking the UWF status ........................................................................................... 70
8.4.5 RDP settings ............................................................................................................... 71
8.4.6 Checking the UWF status ........................................................................................... 74
9. Recovery ............................................................................................................................................ 75
9.1 Bartec Recovery Solution........................................................................................................ 75
Start of the evice in the Recovery mo e ............................................................................... 75

Table of Contents POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
Technical ata subject to change.
09/2020
Recovery surroun ings ........................................................................................................... 75
Recovery application ............................................................................................................... 76
Restoration in the work state................................................................................................... 77
Finish the recovery .................................................................................................................. 79
9.1.1 Recovery Stick ............................................................................................................ 80
9.1.2 Recovery stick image ................................................................................................. 80
10. Faults and troubleshooting .............................................................................................................. 81
11. Maintenance, inspection, repair ....................................................................................................... 82
11.1 Maintenance intervals ............................................................................................................. 82
11.2 Inspection ................................................................................................................................ 82
11.3 Maintenance an repair work .................................................................................................. 82
11.3.1 Instructions for Repairs ............................................................................................... 83
12. Disposal.............................................................................................................................................. 83
13. Dispatch and packaging instructions .............................................................................................. 83
14. Accessories, spare parts .................................................................................................................. 84
15. Order numbers................................................................................................................................... 85
16. Additional information ...................................................................... Fehler! Textmarke nicht efiniert.
17. Own Notes .......................................................................................................................................... 85
18. Declaration of conformity ................................................................................................................. 87

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Table of Contents
Technical ata subject to change.
09/2020

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
Basic
safety instructions
Technical ata subject to change.
09/2020
EN 1/88
1. Basic safety instructions
1.1 Notes on this manual
Read carefully before putting the devices into operation.
The user manual is a fixe part of the pro uct. It must be kept in the irect vicinity of the
evice an the installation, operating an service staff must have access to it at all times.
The user manual contains important information, safety instructions an test certificates
which are necessary for the perfect function of the evice in operation.
The user manual is irecte at all in ivi uals concerne with the commissioning, han ling
an servicing of the pro uct. The applicable gui elines an stan ar s for areas with gas
an ust atmosphere (2014/34/-EU, EN/IEC 60079-17 an
EN/IEC 60079-19) must be observe when con ucting this work.
Knowle ge of the safety an warning information in this user manual an the strict
compliance with it is essential for safe installation an commissioning. Acci ents, injuries
an material amage can be avoi e by circumspect han ling an systematically
following the instructions.
The examples, tables, an figures provi e in this user manual are for illustration
purposes. Due to the ifferent requirements of the respective application, the BARTEC
company cannot assume responsibility or liability for actual use base on the examples
an figures.
The BARTEC company reserves the right to carry out technical changes at any time.
In no event will BARTEC company be responsible or liable for in irect or consequential
amages resulting from the use or application of this user manual.
Safety instructions an warnings are specially highlighte in these operating instructions
an marke by symbols.
DANGER
DANGER escribes a irectly imminent anger. If not avoi e , eath or severe injury will
be the consequence.
WARNING
WARNING escribes a possibly imminent anger. If not avoi e , eath or severe injury
may be the consequence.
CAUTION
CAUTION escribes a possibly imminent anger. If not avoi e , mil or slight injury may
be the consequence.

Basic
safety instructions
POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 2/88
Technical ata subject to change.
09/2020
ATTENTION
ATTENTION escribes a possibly amaging situation. If not avoi e , the plant or
objects in its vicinity may be amage .
Important instructions an information on effective, economical an environmentally
compatible han ling.
1.1.1 Languages
The original user manual is written in German. All other available languages are translations
of the original user manual.
The user manual is available in German an English. If you require any other languages,
please ask BARTEC or request them when placing the or er.
1.1.2 Changes to the document
BARTEC reserves the right to alter the contents of this ocument without notice. No
guarantee is given for the correctness of the information. In case of oubt, the German
safety instructions shall apply because it is not possible to rule out errors in translation or in
printing. In the event of a legal ispute, the “General Terms an Con itions” of the BARTEC
group shall apply in a ition.
The respective up-to- ate versions of ata sheets, manuals, certificates, EU Declaration of
Conformity may be ownloa e at www.bartec. e or or ere irectly from BARTEC GmbH.
1.2 Handling the product
The pro uct escribe in these operating instructions has been teste an left the factory
in perfect con ition as regar s meeting safety requirements. To maintain this con ition an
ensure that this pro uct operates perfectly an safely, it may be use only in the manner
escribe by the manufacturer. Appropriate transportation, suitable storage an careful
operation are also essential for the perfect an safe operation of this pro uct. The POLARIS
must be installe properly an securely if it is to work perfectly an correctly.
The safe an perfect mounting of the POLARIS is a precon ition for faultless an correct
operation.
1.3 Use in accordance with the intended purpose
1.3.1 Exclusive purpose
It is use exclusively in combination with operating evices which satisfy the requirements
for Overvoltage Category I.
The POLARIS REMOTE series have been esigne specially for use in hazar ous
(potentially explosive) areas in Zone 2 or Zones 22.
It is essential to observe the permissible operational ata for the evice being use .

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
Basic
safety instructions
Technical ata subject to change.
09/2020
EN 3/88
1.3.2 Improper use
Any other use is not in accor ance with the inten e purpose an can cause amage an
acci ents. The manufacturer will not be liable for any use beyon that of its Exclusive II
inten e purpose.
1.4 Owner’s Managing operator’s obligations
The owner/managing operator un ertakes to restrict permission to work with the POLARIS
to people who:
– are familiar with the basic regulations on safety an acci ent prevention an have
been instructe in the use of the POLARIS;
– have rea an un erstoo the ocumentation, the chapter on safety an the
warnings.
The owner/managing operator must check that the safety regulations an acci ent
prevention rules vali for the respective application are being observe .
1.5 Safety instructions
1.5.1 General safety instructions
– Take the evice out of the hazar ous area before wiping it with a ry cloth or
cleaning it!
– Do not open evices in a hazar ous area.
– The general statutory regulations or irectives relating to safety at work, acci ent
prevention an environmental protection legislation must be observe , e.g. the
German in ustrial health an safety or inance (BetrSichV) or the applicable
national or inances.
– In view of the risk of angerous electrostatic charging, wear appropriate clothing
an footwear.
– Avoi the influence of heat that is higher or lower than the specifie temperature
range.
– Protect the evice from external influences! Do not expose the evice to any
caustic/aggressive liqui s, vapours or mist! In the event of malfunctioning or
amage to the enclosure, take the evice out of the potentially explosive area
imme iately an bring it to a safe place.
1.6 Safety instructions for operation
1.6.1 Upkeep
For electrical systems the relevant installation an operating regulations must be complie
with (e.g. Directive 2014/34/EU an the national applicable or inances EN 60079-14 an
the DIN VDE 0100 series)!
The isposal of this equipment must comply with the national regulations on the isposal of
waste.

Basic
safety instructions
POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 4/88
Technical ata subject to change.
09/2020
1.6.2 Maintenance
Regular servicing is not necessary if the equipment is operate correctly in accor ance with
the installation instructions an environmental con itions. In this context, please refer to
Chapter "Maintenance, Inspection, Repair".
1.6.3 Inspection
Un er EN/IEC 60079-17 an EN/IEC 60079-19, the owner/managing operator of electrical
installations in hazar ous areas is oblige to have these installations checke by a qualifie
electrician to ensure that they are in a proper con ition.
1.6.4 Repairs
Repairs on explosion-protecte operating equipment may be one only by authorise
persons working in accor ance with the latest evelopments in technology an using
original spare parts. The applicable regulations must be observe .
1.6.5 Commissioning
Before commissioning, check that all components an ocuments are there.
1.7 Ex protection type, certification and standards
Markings specifying Ex protection an certification are put on the evice. For Ex protection
markings, see chapter 4 "Technical Data ".
The POLARIS REMOTE series conform to Directive 2014/34/EU for evices an protective
systems for use to their inten e purpose in potentially explosive areas (ATEX Directive).
For the stan ar s conforme to, see chapter 3 "Explosion protection an approvals".
1.8 Warranty
WARNING
Explosion protection cannot be guaranteed if non-specified components are used.
 Do not make any changes or perform any reconstruction work on the evice.
 Use only original spare parts.
The manufacturer provi es a full warranty exclusively for the spare parts it supplies.
When using parts from thir parties, there is no guarantee that they have been esigne
or manufacture to han le the requisite stress or offer the requisite egree of safety.

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
Basic
safety instructions
Technical ata subject to change.
09/2020
EN 5/88
As a fun amental rule, our “General Con itions of Sale an Delivery” apply. These are
ma e available to the owner/managing operator at the latest on formation of a contract.
Guarantee an liability claims for personal injury an amage to property are exclu e if
they are ue to one or more of the following reasons:
– Use of the POLARIS for a purpose other than that for which it is inten e .
– Incorrect installation, commissioning, operation an maintenance.
– Non-compliance with the instructions in the manual with respect to transport,
storage, assembly, commissioning, operation an maintenance.
– Structural mo ifications without our prior authorisation.
– Ina equate monitoring of components that are subject to wear
– Repairs one incorrectly.
– Disasters ue to the effects of foreign matter or Act of Go (events outsi e human
control).
We guarantee the POLARIS an its accessories for a perio of 1 year starting on the ate
of elivery from the Ba Mergentheim factory. This guarantee covers all parts of the elivery
an is restricte to the replacement free of charge or the repair of the efective parts in our
Ba Mergentheim factory. As far as possible, the elivery packaging shoul be kept for this
purpose. In the event of such a claim, the pro uct must be returne to us after written
arrangement. The customer cannot claim to have the repairs one at the site of installation.

Product description POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 6/88
Technical ata subject to change.
09/2020
2. Product description
2.1 Definition
POLARIS ZeroClient is a Security an reliability are particularly important quality features
of software solutions in many areas. Increasing eman s on the availability of in ustrial
HMIs an the re uction of maintenance an a ministration costs lea to the increasing use
of centralise systems that can share the require performance an capacities. The
BARTEC ZeroClient is esigne as a robust solution for such networke systems of this
kin with increase security an availability criteria.
Abbildung 1: Übersicht
The ZeroClient is a workplace client with re uce configuration tasks an security risks.
The client protocol (RDP) containe in the ZeroClient is use for the interaction of the evice
with the external or company network. The ZeroClient oes not perform any processing
tasks itself, but enables remote access to an in ustrial server. Therefore, it is rea y for use
as elivere without any great work require on the part of the a ministrator. As the actual
ata processing is one by the in ustrial server, it is ensure that the ZeroClient is now able
to cope with its task ue to higher eman s.
Bartec’s ZeroClient solution is a comprehensive combination of operating system,
configuration tool (ZeroClient Control Center) an integrate user interface (ZeroClient
Shell).
Touchscreen an high quality keyboar s in ifferent national languages an ifferent
mouse versions exten the operating comfort.
The front-panel mounting esign makes installation easy. On request, the evices are also
available as a rea y-ma e system solution in a stainless steel enclosure for wall, floor or
table mounting.
For particularly harsh areas of use with temperatures as low as own to -40 °C, we equip
the POLARIS series with electrical heating. On request, we pro uce customise solutions
with more comman an signalling evices.

POLARIS REMOTE- for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Product description
Technical ata subject to change.
09/2020
EN 7/88
2.2 Schematic design
Illustration 1: Simple system structure

Technical data POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 8/88
Technical ata subject to change.
09/2020
3. Explosion protection and approvals
POLARIS REMOTE Zero Client
Type B7-72V1-….
ATEX
Ex protection type II 3G Ex nA IIC T4.
II 3D Ex tb IIIC T120°
-20 °C ≤ Ta ≤ 60 °C
Standards EN 60079-0:2012 +A11:2013
EN 60079-15:2010
EN 60079-31:2014
Special conditions Do not connect or open terminal compartments
while the voltage supply is active.
Always use a cable glan when inserting external
cables an connectors into the junction box.
There must be equipotential bon ing along the
entire course of the installation.
Make sure there are no high-energy charging
mechanisms at the user interface on the isplay
units or accessories (e.g. pneumatic particle
transport) uring use.
Zone 22 Dust:
The IP protection rating must be ensure by fitting
the evices into IP enclosures.
Directives 2014/34/EU
2014/30/EU
2011/65/EU
Product marking 0044

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Technical data
Technical ata subject to change.
09/2020
EN 9/88
4. Technical data
4.1 POLARIS Zero Client
Construction Front panel fitting; Optional turn-key system solutions in
a stainless steel enclosure as wall, floor or table
mounting versions.
Operating system Zero Client
proprietary Win ows® 10 Embe e
Interface
(basic version)
1 x Ethernet 100/10BaseT
1 x USB socket, type A (power limite )
1 x USB on terminal
2 x PS/2 for POLARIS, zone 2, keyboar
an mouse
Display Antireflection coating glass pane
Optional touchscreen
Max. power consumption P
max
< 100 W epen ing on the version
Relative air humidity 5 to 95 % non-con ensing
Vibration 0.7 G/1 mm; 5 Hz-500 Hz pulse in all 3 axes
Schock 15 G, 11 ms pulse in all 3 axes
Material
Front
Rear panel
Polyester foil on ano ise aluminium plate
(con itionally UV-resistant)
galvanise sheet steel, bichromate
Protection class
Front
Rear site
IP65
IP54
Optional approved accessories Keyboar
Mouse variants
Memory stick

Technical data POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 10/88
Technical ata subject to change.
09/2020
4.1.1 Characteristics POLARIS Zero Client 12.1" W
Display 12.1" graphics-capable TFT isplay
WXGA resolution
1280 x 800 pixels
262.144 colours
Brightness 400 c /m
2
Visible surface approx. 246 x 166 mm
Contrast 1200:1
Backlighting LED technology, Service life
approx. 50,000 hours (at +25 °C)
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +50 °C
0 °C to +50 °C
Power supply DC 24 V ±10 %
Dimensions
(wi th x height x epth) 400 mm x 246 mm x approx. 130 mm
Wall cut-out
(wi th x height) 386 mm x 226 mm ± 0.5 mm
Weight approx. 8 kg

POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24” Technical data
Technical ata subject to change.
09/2020
EN 11/88
4.1.2 Characteristics POLARIS Zero Client 15" POLARIS Zero Client 15 " Sunlight
Display 15" graphics-capable TFT isplay
XGA resolution
1024 x 768 pixels
16,7 million colours
Brightness 350 c /m
2
Brightness 1000 c /m
2
(suitable for aylight)
Visible surface approx. 304 x 228 mm
Contrast 700:1
Backlighting LED technology, Service life
approx. 50,000 hours (at +25 °C)
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +50 °C
0 °C to +50 °C
Power supply AC 90 V to 253 V ± 10 %, 50 Hz to 60 Hz
DC 24 V ±10 %
Dimensions
(wi th x height x epth) 411 mm x 332 mm x approx. 135 mm
Wall cut-out
(wi th x height) 394.5 mm x 315.5 mm + 0.5 mm
Weight approx. 12 kg
POLARIS Zero Client 15" Sunlight
Exten e ambient temperatures
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +60 °C
-20 °C to +60 °C

Technical data POLARIS REMOTE - for Zone 2 22
POLARIS Zero Client 12,1” W 15” 17,3” 19,1” 24”
EN 12/88
Technical ata subject to change.
09/2020
4.1.3 Characteristics POLARIS Zero Client 17.3"
Display
17.3" graphics-capable TFT isplay
WSXGA resolution
1920 x 1080 pixels
16,7 million colours
Brightness 400 c /m
2
Visible surface approx. 382 x 215 mm
Contrast 600:1
Backlighting LED technology, Service life
approx. 50,000 hours (at +25 °C)
Power supply AC 90 V to 253 V ± 10 %, 50 Hz to 60 Hz
DC 24 V ±10 %
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +50 °C
0 °C to +50 °C
Dimensions
(wi th x height x epth) 503 mm x 314 mm x approx. 135 mm
Wall cut-out
(wi th x height) 489 mm x 301 mm +0.5 mm
Weight approx. 15 kg
