Bartell SPE DFG280 User manual

Doc. # OIPB-S30004
Orig. Rel. –11/2018
Curr. Rev. - 00
FLOOR GRINDER
DFG280
OWNER’S MANUAL AND PARTS BOOK
www.BARTELLGLOBAL.com

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
1
OIPB –S30004
www.BARTELLGLOBAL.com
Bartell Morrison Inc.
170 Traders Blvd E
Mississauga, Ontario, Canada
L4Z 1W7
Tel: [phone]
Fax: [phone]
Bartell Morrison USA LLC
200 Commerce Drive, Unit A
Freehold, NJ, USA
07728
Tel: [phone]
Fax: [phone]
SPE International Ltd
Honeyholes Lane
Dunholme, Lincoln, England
LN2 3SU
Tel: [phone]
Fax: [phone]
Innovatech
4701 Allmond Ave
Louisville, Kentucky, USA
40209
Tel: [phone]
Fax: [phone]
ORIGINAL LANGUAGE OPERATING MANUAL FOR
SPE FLOOR GRINDER
© 2019 Bartell Morrison Inc.
No part of this work may be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying and recording, or by any information storage or retrieval
system without the prior written permission of Bartell Morrison Inc. unless such copying is
permitted by federal copyright laws.
Address inquiries or reference permissions care of:
Bartell Morrison Inc., 170 Traders Blvd E., Mississauga, Ontario, Canada, L4Z 1W7
REV.
DATE
DESCRIPTION
APPROVED BY:
00
11/2018
Initial Release
AN

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
2
OIPB –S30004
SAFETY PRECAUTIONS
DANGER
EXPLOSION HAZARD
Never operate the machine in an explosive
atmosphere, near combustible materials, or
where ventilation does not clear exhaust fumes.
WARNING
BURN HAZARD
Never come into contact with the engine or
muffler when engine is operating or shortly after it
is turned off. Serious burns may occur.
CAUTION
ROTATING HAZARD
Never place hands or feet inside safety guard
rings. Serious injury will result from contact with
rotating blades.
CAUTION
MOVING PARTS
Before starting the machine, ensure that all
guards and safety devices are in place and
functioning properly.
ATTENTION
READ OWNER’S MANUAL
Read and understand owner’s manual before
using this machine. Failure to follow operating
instructions could result in serious injury or death.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
3
OIPB –S30004
This Page Intentionally Left Blank

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
4
OIPB –S30004
TABLE OF CONTENTS
QUALITY ASSURANCE/ MACHINE BREAK IN 5
WARRANTY INFORMATION 5
SPECIFICATIONS 6
PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN 7
oROUTINE SERVICE SCHEDULE 8
oROUTINE SERVICE INTERVALS 8
OPERATING SAFETY PRECAUTIONS 9
OPERATION INSTRUCTIONS 10
oSETTING UP YOUR FLOOR GRINDER 10
oPRIOR TO OPERATION 10
oCHANGING OR INSTALLING TOOLING 10
oOPERATION 11
ELECTRICAL INSTRUCTIONS 12
PARTS LIST 1 –DFG280 OVERVIEW 13
oDFG280 OVERVIEW –PARTS LIST 1 14
PARTS LIST 2 –DFG280 FASTENERS 15
oDFG280 FASTENERS –PARTS LIST 2 16
PARTS LIST 3 –DFG280 GRINDING HEAD 17
oDFG280 GRINDING HEAD –PARTS LIST 3 18
PARTS LIST 4 –DFG280 ADAPTER 19
oDFG280 ADAPTER –PARTS LIST 4 20
DECLARATION OF CONFORMITY 22

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
5
OIPB –S30004
QUALITY ASSURANCE/ MACHINE BREAK IN
The SPE Floor Grinder is the product of extensive engineering development designed to
give long life and unmatched performance. The Floor Grinders are shipped completely
assembled.
You can help ensure that your Floor Grinder will perform at top levels by observing a
simple routing on first use. Consider that your new Grinder is like a new car. Just as you would
break in a new car to the road or any new machine to the job, you should start gradually and
build up to full use. Learn what your machine can do and how it will respond. Full throttle and
control may be used after this time period, as allowed by material. This will serve to further
break in the machine on your specific application, as well as provide you with additional
practice using the machine.
We thank you for the confidence you have placed in us by purchasing a SPE Floor
Grinder and wish you many years of satisfied use.
WARRANTY INFORMATION
Bartell agrees to furnish without charge, F.O.B. our plant, a replacement for any part or
portion thereof, comprising the main unit of the SPE Floor Grinder, consisting of the handle,
housing assembly, save and except tooling, and power units, prove upon our examination, to
be defective in either material or workmanship within a period of twelve (12) months from date
of purchase, provided that notice of such defective part or portion thereof is given to Bartell Ltd.
within the twelve month warranty period. No further or other guarantee or warranty expressed
or implied in connection with the sale of the Grinder is given and our sole liability consists in
replacing defective parts or portions thereof. We shall not be responsible for any special,
indirect or consequential damages arising in any manner whatsoever.
This guarantee is for the sole benefit of the original purchaser as end user. Our
responsibility under this guarantee ends in the case the original purchaser transfers ownership
of the Floor Grinder, makes any changes or adds any parts or devices not of our manufacture
to the Floor Grinder machine.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
6
OIPB –S30004
SPECIFICATIONS
DFG280
Dimensions
Grinding Width, mm (in)
254 (10)
Overall Width, mm (in)
280 (11)
Overall Length, mm (in)
1020 (40)
Folded Length, mm (in)
660 (26)
Overall Height, mm (in)
940 (37)
Folded Height mm (in)
550 (21.6)
Weight
Weight, kg (lb.)
44 (97)
Performance
Speed of Grinding Head (RPM)
1720
Power Source
Power kw (HP)
1.1 (1.5)
Volts (V)
120
Frequency (Hz)
60
Amperage (A)
15

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
7
OIPB –S30004
PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN
This SPE Floor Grinder has been assembled with care and will provide years of service.
Preventative maintenance and routine service are essential to the long life of your Floor
Grinder. Your dealer is interested in your new machine and has the desire to help you get the
most value from it. After reading through this manual thoroughly, you will find that you can do
some of the regular maintenance yourself. However, when in need of parts or major service be
sure to see your Bartell dealer. For your convenience, we have provided this space to record
relevant data about your Floor Grinder. When in need of parts or service be prepared to provide
your Floor Grinder serial number. Locate the serial number now and record in the space below.
Date Purchased:
Type of Machine:
Dealer Name:
Model:
Dealer Phone:
Serial Number:
Replacement Parts Used
Maintenance Log:
Part No.
Quantity
Cost
Date
Date
Operation

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
8
OIPB –S30004
ROUTINE SERVICE SCHEDULE
Routine Service Intervals
Each
Use
After 1.5
months
or 50 hrs
Each 3
months
or 100
hrs
Each 6
months
or 200
hrs
Each 9
months
or 300
hrs
Each 12
months
or 400
hrs
General Inspection
Guards
Check
O
O
O
O
O
Warning Stickers
Check
O
O
O
O
O
Test Run
Check Operation
O
O
O
O
O
Fasteners
Check Tightness
O
Electrical
Cord
Check for
Damage
O
Plug
Check for
Damage
O
Switches/Buttons
Check
O
Grinding Components
Tooling
Check Life
O
Drive Coupling
Check for
Damage
O
Tooling Plate
Check
O
O
O
O
Motor
Fan
Check - Clean
O
O
O
O
O
ROUTINE SERVICE INTERVALS
Due to the nature and environment of use, Floor Grinders could be exposed to severe
operating conditions. Some general maintenance guidelines will extend the useful life of your
machine.
• The initial service for your grinder should be performed after 25 hours of use, at which time
your mechanic (or authorized repair shop) should complete all the recommended checks in the
schedule above. The maintenance log is handy for keeping a record of the maintenance
performed and the parts used for servicing your grinder.
• Regular service according to the schedule above will prolong the life of the floor grinder and
prevent expensive repairs.
• Keeping your floor grinder clean and free from debris is the single most important regular
maintenance operation, over and above the checks in the service schedule above, that can be
performed. After each use your grinder should be cleaned to remove any dust and debris from
the undercarriage and surrounding components.
• In the Service Schedule above, items that should be checked, replaced or adjusted are
indicated by “o” in the appropriate column. For ease of recording place, a checkmark through
the “o” when the item is complete. If an item is not required or not completed place an “x”
through the “o” in the box.
• Failure to have your floor grinder regularly serviced and properly maintained in accordance
with the manufacturer’s instructions will lead to premature failure and void the warranty.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
9
OIPB –S30004
OPERATING SAFETY PRECAUTIONS
The floor grinders are constructed according to existing safety rules and regulations.
These technical precautions should not be removed or changed under any circumstances.
While operating the machines the following points should also be kept in mind:
The instructions provided in this manual are done so to ensure the operator’s safety as well
as that of others, the equipment, and the job site. Failure to follow these guidelines can lead to
serious personal injury and even death. The operator and any service personnel should read
and understand the entire manual before working with or servicing any SPE Floor Grinder.
•The grinders should always be operated with all safety covers and technical precautions.
•During transport, cleaning, repair or maintenance the grinder must be disconnected from
the power supply. That also applies to the changing of tools.
•The safety ring can only be removed while operating the machine directly against the
wall. While operating the machine without the safety ring dust can be generated. In this
case the operator must wear a mask. In all other cases the grinder must be operated
with the safety ring.
•The operator should never leave the machine unattended during operation.
•Before leaving the machine, all rotary parts should be brought to a standstill. Electric
models must be disconnected from the power supply. Make sure that the machine cannot
roll or move by itself.
•After any maintenance and adjustment all safety covers must be reattached.
•Ear protectors must be worn.
•Eye protectors must be worn.
•Safety shoes with steel caps must be worn.
•In the event of a large amount of dust during operation, connect a dust collector to the
grinder.
•Depending on the floor (floor coating) grinding can produce gases. The operator must be
held responsible if these generated gases are dangerous and if protection is necessary.
Grinding floors containing asbestos is especially dangerous and can cause health
problems. Special masks must be worn which keep the breathing airclean. A dust collector
must be used and should be equipped with filters suitable for asbestos dust.
•The floor must be brushed before grinding because loose material could get into the tools
and fly away. Anchor screws and bolts coming out of the floor can also be seen better if
the floor is clean. If the grinding head hits a anchor screw or bolt then serious damage can
be caused to the machine or grinding head.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
10
OIPB –S30004
OPERATION INSTRUCTIONS
SETTING UP YOUR FLOOR GRINDER
Your Floor Grinder comes fully assembled with handle and motor fully installed. The
handle is folded to allow for easier transportation. The handle can be moved into operating
position by releasing the two locking pins on either side of the handle, the handle can then be
moved into 1 of 3 positions. With the handle in the desired position the locking pins can be
reengaged. Tooling can now be installed, and your Floor Grinder is ready for use.
PRIOR TO OPERATION
•Make sure that all dust, debris etc., are thoroughly removed from the unit prior to
operation. Special effort should be given to the bottom of the machine where the tooling
plate is located.
•Check all bolts and screws for tightness and make sure all bolts and screws are securely
tightened. Loose bolts and screws may cause damage to the unit. Make sure tooling is
properly installed.
•Connect the vacuum hose to the dust extraction port if a dust control vacuum is being
used.
•Ensure the power supply is correct for the machine before making the connection.
CHANGING OR INSTALLING TOOLING
•Tilt the machine onto the back wheels and rest it on the handlebar.
•All tooling is fixed in grooves and held in place by magnets.
•Check the grinding tool for wear and replace if needed.
•Remove tooling by sliding tooling to the centre of the disk.
•Fix new tools by sliding the tool in the groove starting from the centre of the machine
ATTENTION: Before working on the grinder bring the motor to a total stand still and
disconnect from the power supply.
CAUTION: Tools can be hot after use.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
11
OIPB –S30004
OPERATION
Operating
After mounting the appropriate tools and plugging the machine in to the correct power source
the operation of the grinder can begin.
Check that the stop button is out by rotating clockwise. Lift the grinding head slightly by tipping
the machine back, then press the start button. Lower the head back onto the floor, and ensure
the head moves evenly across the surface for a smooth finish.
•The machine is also fitted with two removable panels in the dust shroud which can assist
with edge work. Undo the two thumb nuts and remove the panel to allow the grinding head
to get closer to the vertical surface. Once done, replace the panel then refit and tighten the
two thumb nuts. (Turn off machine first before removing the panel)
Stopping procedure
To stop the machine, press the red stop button and allow grinding head to slow to a stop on the
floor. Unplug machine if job is finished and when changing tools or performing work.
ATTENTION: When switching on the motor, the machine may jump slightly due to
rotating tooling.
ATTENTION: Never switch on machine while the grinding head is on the floor.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
12
OIPB –S30004
ELECTRICAL INSTRUCTIONS
The DFG280 machine is supplied with a specially commissioned 110V electric motor and
starter switch assembly. Each unit is fully tested, and the safety overload relays have been
calibrated and set according to the manufacturer’s specifications. In the event of the
malfunction on a new machine the owner should first check that the power supply on-site is
suitable and adequate.
DFG280-6 (120V)
•The 120V motor requires a 15 Amp supply.
All cables should be fully uncoiled and never left wrapped around cable reels or tied in loops.
The motor is protected with a safety trip in the panel. Should the trip be activated, it will reset
automatically after cooling down. Damage will occur if the motor repeatedly cuts out. Possible
causes are either an inadequate power supply, overloading of the machine, or an electrical
fault.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
13
OIPB –S30004
PARTS LIST 1 –DFG280 OVERVIEW

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
14
OIPB –S30004
DFG280 OVERVIEW –PARTS LIST 1
Item #
Part #
Description
QTY
Remarks
101
905350
MAIN BODY PLATE
1
102
905351
HANDLE (BOTTOM SECTION)
1
103
905352
HANDLE (TOP)
1
104
905353
CONNECTOR
1
105*
905354
GRINDING PLATE ADAPTOR
1
107
905356
SHROUD
1
108
905357
FLOATING SHROUD
1
109
905358
EDGING SHROUD
2
110
905359
EXHAUST BRACKET
1
111
12116
MOTOR
1
112
905361
AXLE (REAR)
1
113
905362
AXLE SLEEVE
1
114
905363
PIVOT PLATE (10MM)
2
115
905364
PIVOT PLATE
2
116
905365
PIVOT PLATE PACKER
2
117
905366
CLAMPING BAR
4
118
905367
ELECTRICAL BOX PLATE
1
119
905368
END CAP
2
120
905369
END CAP (WITH HOLE)
1
121
905370
ROLL PIN, M6x20MM
2
122
905371
BEARING
4
123
905372
BEARING SPACER
4
124
905373
EXTRACTION TUBE
1
125
905374
FLEXI-COUPLING
1
127
905376
DUST SKIRT (580MM)
1
128
905377
DUST SKIRT (140MM)
1
130
905380
HANDLE GRIP (BACK)
1
131
905380
HANDLE GRIP (FRONT)
1
133
906013
WHEEL (REAR)
2
134
907379
LOCKING PIN
2
135
909104
HANDLEBAR GRIP
2
148
12128
CABLE GLAND EMC
1
149
12120
MOTOR STARTER
1
150
12118
UNDER VOLTAGE COIL
1
151
12121
ENCLOSURE W/ STOP BUTTON
1
152
153
TI/009
TUBE INSERT (BLACK)
2
*Only required if using grinding plate, instead of Slidemag or Tmag plate.

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
15
OIPB –S30004
PARTS LIST 2 –DFG280 FASTENERS

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
16
OIPB –S30004
DFG280 FASTENERS –PARTS LIST 2
Item #
Part #
Description
QTY
Remarks
126
905375
RETAINING SCREW
3
129
905378
THUMB NUT
4
136
11746
HHCS, M6-1.0 X 16MM
6
137
10999
HHCS, M8-1.25 X 20MM
2
138
11619
HHCS, M8-1.25 X 25MM
4
139
10155
HHCS, M8-1.25 X 35MM
4
140
12090
FHSCS, M10-1.5 X 60MM
2
141
11862
SHCS, M10-1.5 X 60MM
2
143
11933
BHSCS, M10-1.5 X 30MM
4
144
11934
BHSCS, M10-1.5 X 35MM
12
146
11617
LOCKNUT, M8-1.25
4
147
11802
LOCKNUT, M10-1.5
10
154
14447
FLAT WASHER, M6
9
155
11667
FLAT WASHER, M8
12
156
41516
FLAT WASHER, M10
14
157
41516
FLAT WASHER, M10
8
158
60754
FLAT WASHER, M20
2
159
14448
LOCKWASHER, M6
6
160
11614
LOCKWASHER, M8
6
161
64003
REPAIR WASHER, M8
2

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
17
OIPB –S30004
PARTS LIST 3 –DFG280 GRINDING HEAD

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
18
OIPB –S30004
DFG280 GRINDING HEAD –PARTS LIST 3
Item #
Part #
Description
QTY
Remarks
104
905382
CONNECTOR
1
107
905356
SHROUD
1
108
905357
FLOATING SHROUD
1
109
905358
SHROUD EDGING
2
111
12116
MOTOR (110V)
1
122
905371
BEARING
4
123
905372
BEARING SPACER
4
125
905374
FLEXI-COUPLING
1
126
905375
RETAINING SCREW
3
127
905376
DUST SKIRT (580MM)
1
128
905377
DUST SKIRT (140MM)
3
129
905378
THUMB NUT
4
132
905381
ADAPTER PLATE
1
139
10155
HHCS, M8-1.25 X 35MM
4
142
30217
SET SCREW, M8-1.25 X 10MM
2
144
11934
BHSCS, M10-1.5 X 35MM
12
145
50622
LOCKNUT, M6-1.0
3
147
11802
LOCKNUT, M10-1.5
10
154
14447
FLAT WASHER, M6
9
155
11667
FLAT WASHER, M8
12
156
41516
FLAT WASHER, M10
14
160
11614
LOCK WASHER, M8
6

DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
19
OIPB –S30004
PARTS LIST 4 –DFG280 ADAPTER
