Bartscher 1K1500 User manual

1K1500 - 2K2500
150320 - 150310

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Service hotline: [phone]
www.bartscher.com
Version: 4.0
Date of preparation: 2022-01-28
EN

150320 1 / 18
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................6
1.4 Unintended Use.......................................................................................6
2General information.......................................................................................7
2.1 Liability and Warranty ..............................................................................7
2.2 Copyright Protection ................................................................................7
2.3 Declaration of Conformity ........................................................................7
3Transport, Packaging and Storage................................................................8
3.1 Delivery Check.........................................................................................8
3.2 Packaging................................................................................................8
3.3 Storage....................................................................................................8
4Technical Data...............................................................................................9
4.1 Technical Specifications ..........................................................................9
4.2 Functions of the Appliance.....................................................................10
4.3 List of Components of the Appliance .....................................................11
5Installation and operation ............................................................................13
5.1 Installation..............................................................................................13
5.2 Operation...............................................................................................14
6Cleaning ......................................................................................................15
6.1 Safety Instructions for Cleaning.............................................................15
6.2 Cleaning.................................................................................................16
7Disposal....................................................................................................... 16

Safety
2 / 18 150320
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schafft die V oraussetzung für das sichere un ds achgerechte Arbeite n mit dem Gerät. Darüber hi naus müssen die für de nEins atzbereich des Geräts gelt enden örtlich enU nfallverhütungs vorschriften und allge meinen Sicherheits bestimmungen eing ehalten werden. Diese Be dienungsanleitung is t Bestandt eild es Produkts und muss i n unmittelbarer Nähe d es Geräts für das In¬stall ations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn d as Gerät an eine dritte Pers on
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
150320 3 / 18
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 18 150320
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Hot Surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
Flammable Materials
•Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
•To avoid fire hazard, clean the appliance regularly.
•Do not cover the appliance with, e.g., aluminium foil or cloths.
•Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
•Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.

Safety
150320 5 / 18
EN
Operating personnel
•This appliance is not intended to be used by persons (including children) with
limited physical, sensory or mental capabilities, nor by persons with limited
experience and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching the appliance on.
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.

Safety
6 / 18 150320
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Preparing and heating-up foods with the use of suitable cookware.
This appliance is intended for use in households and similar places, e.g.:
–in employee canteens in shops, offices, and similar areas;
–on farms;
–by customers in hotels, motels, and other typical accommodation
establishments;
–in lodging-houses.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Heating of rooms.
–Heating-up flammable, hazardous to health and volatile, etc. liquids and
materials.

General information
150320 7 / 18
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
8 / 18 150320
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
150320 9 / 18
EN
4 Technical Data
4.1 Technical Specifications
Name:
Countertop electric hob 1K1500
Art. No.:
150320
Material:
stainless steel
Number of hobs:
1
Max. power output per hob, in kW:
1,5
Hob diameter, in mm:
185
Power supply:
1,5 kW | 230 V | 50/60 Hz
Dimensions (W x D x H), in mm:
305 x 245 x 85
Weight, in kg:
2,1
We reserve the right to implement technical modifications.
Name:
Countertop electric hob 2K2500
Art. No.:
150310
Material:
stainless steel
Number of hobs:
2
Max. power output per left / right hob,
in kW:
1,5 / 1,0
Left/right hob diameter, in mm:
190 / 155
Power supply:
2,5 kW | 230 V | 50/60 Hz
Dimensions (W x D x H), in mm:
535 x 225 x 90
Weight, in kg:
4,0
We reserve the right to implement technical modifications.

Technical Data
10 / 18 150320
EN
Version / Characteristics
•Appliance connection: ready to plug in
•Hob type: electric
•Arrangement of the hobs 150310: next to each other
•Control: electronic, knob
•Temperature control: stepless
•Overheating protection
•ON/OFF switch
•Indicator lamp: heating up
4.2 Functions of the Appliance
With this electric hob, you can prepare and heat up dishes using the appropriate
cookware. You can smoothly adjust the temperature to each prepared dish,
separately for each hotplate.

Technical Data
150320 11 / 18
EN
4.3 List of Components of the Appliance
150320 / 1K1500
Fig. 1
1. Knob ‘ON/OFF’
2. ‘ON’ Position
3. Hob
4. Power cord
5. Housing
6. Temperature controller
7. Feet (4x)
8. Heating-up indicator lamp (orange)

Technical Data
12 / 18 150320
EN
150310 / 2K2500
Fig. 2
1. Knob ‘ON/OFF’
2. Left hob
3. Right hob
4. Power cord
5. Right-hand side temperature
controller
6. Feet (4x)
7. The temperature setting marker of
the right-hand side hob
8. The heating up indicator lamp
(orange) of the right-hand side hob
9. The heating up indicator lamp
(orange) of the left-hand side hob
10.The temperature setting marker of
the left-hand side hob
11.The temperature controller of the
left-hand side hob
12.Housing

Installation and operation
150320 13 / 18
EN
5 Installation and operation
5.1 Installation
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
•Leave at least 10 cm clearance from flammable walls and items.
Power supply connection
•Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
•Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.

Installation and operation
14 / 18 150320
EN
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
5.2 Operation
Before First Use
1. Before use, clean the appliance according to the instructions set out in section
'Cleaning'.
2. Dry the appliance thoroughly.
Operation of the Appliance
1. Turn the control ‘ON/OFF’ knob to the ‘OFF’ position.
2. Plug the appliance into a suitable single socket.
3. Place appropriate cookware in the middle of the selected hob.
HINWEIS!
Do not use unstable cookware that can tip over easily.
Only use cookware with a flat bottom to ensure full contact with the hob
surface for maximum use of heat.
4. Turn the control ‘ON/ON’ knob to the ‘OFF’ position.
5. Use the temperature knob to set the
temperature for the selected heating plate,
appropriate to the prepared product.
By turning the temperature knob clockwise, the
temperature can be smoothly adjusted between
the ‘MIN’ and ‘MAX’ positions.
The heating indicator lamp (orange) turns on and
goes out when the set temperature is reached.
When the temperature drops, the thermostat is
activated and the hob heats up again. The
heating control lamp then comes on again.
Fig. 3
CAUTION!
The appliance and the hobs becomes hot during operation. They also
remain hot for a while after work.
Do not touch them with bare hands. To remove the cooking utensils from the
cooking zone, use protective gloves or a dish cloth.

Cleaning
150320 15 / 18
EN
6. If the appliance is not used, turn the temperature 'ON/OFF’ knob to ‘OFF’
position.
7. Disconnect the appliance from the mains socket (pull the plug out).
Overheating Protection
The appliance is equipped with the overheating protection. In case of overheating, it
automatically switches off.
1. Disconnect the appliance from the mains socket (pull the plug out).
2. Wait for the appliance to cool off.
3. After cooling down, the electric hob may be operated again as described.
6 Cleaning
6.1 Safety Instructions for Cleaning
•Before cleaning, disconnect the appliance from the power supply.
•Leave the appliance to cool down completely.
•Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
•Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
•For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.

Disposal
16 / 18 150320
EN
6.2 Cleaning
1. Clean the appliance after each use.
2. Clean the surface with a soft cloth, soaked in warm water and a gentle cleaning
agent.
3. Wipe all washed surfaces with a clean cloth.
4. Wipe the power cord and plug only with a slightly damp cloth.
5. Thoroughly clean the appliance with a soft cloth.
7 Disposal
Electrical Appliance
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
Electrical appliances should be returned to designated collection points.
