Bartscher 110.709 User manual

110.709
110.710
V
2
/
0712

- 17 -
1. General Information 18
1.1 Information about the instruction manual 18
1.2 Key to symbols 18
1.3 Liability and Warrantees 19
1.4 Copyright protection 19
1.5 Declaration of conformity 19
2. Safety 20
2.1 General information 20
2.2 Safety instructions for use of the device 20-21
2.3 Intended use 21
3. Delivery, packaging and storage 22
3.1 Delivery check 22
3.2 Packaging 22
3.3 Storage 22
4. Technical data 23
4.1 Overview of parts 23
4.2 Technical specification 24
5. Installation and operation 24
5.1 Safety instructions 24
5.2 Installation and connection 25
5.3 Operating 25-29
6. Cleaning and maintenance 29
6.1 Safety advice 29
6.2 Cleaning 29
6.3 Safety instructions for maintenance 30
7. Possible Malfunctions 31
8. Waste disposal 32
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 18 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device and
easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.

- 19 -
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any form
or by any means without permission in writing from the manufacturer. Any person who
commits any unauthorized act in relation to this publication shall be liable to claims for
damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.

- 20 -
2. Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General Information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.

- 21 -
CAUTION!
oThe device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
oChildren should be observed to ensure that they are not playing with the device.
oPreserve this manual safely. When passing on/selling the device to a third party, the
manuals must be handed over along with the device.
oEvery person using the device must act in accordance to the manuals and under
consideration of the safety advice.
oThe device is to be used indoors only.
2.3 Intended use
CAUTION!
This device is intended for commercial use only and should be operated by
qualified personnel in professional food service organizations.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The cooled table is intended only for preparing and cooling appropriate food
products.
Do not use the cooled table for:
-storage of flammable or explosive materials such as ether, alcohol, oil or glue;
-storage of pharmaceutical products or blood.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the device
is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.

- 22 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure
you check the state of the packaging and the parts
regularly. If required refresh or renew.

- 23 -
4. Technical data
4.1 Overview of parts
① Housing
② Marble countertop
③ ON/OFF switch with
integrated control light
④ Ventilation ducts
⑤ Digital temperature regulator
⑥ Door
⑦ Drawer
⑧ Adjustable legs
⑥⑤
⑧
①
②③
④
⑦

- 24 -
4.2 Technical specification
Name Cooled table
Article no.:
110.709 110.710
Material: chrome-nickle steel, marble countertop
Construction: 2 refrigerated doors 1 door, 2 drawers GN 1/1,
depth 150 mm, refrigerated
Coolant: R134a/400 g
Power: 0.385 kW / 1 NAC 230 V
Temperature range: 0 °C - 10 °C
Dimensions: W 1400 x D 700 x H 950 mm W 1400 x D 700 x H 950 mm
Weight: 198 kg 213 kg
We reserve the right to make technical changes!
5. Installation and operation
5.1 Safety instructions
WARNING! Electrical hazard!
The device must only be connected to a properly installed single socket with
protective contact.
Never yank cord to disconnect from outlet. Cable must not touch any hot parts.
•See that the cable does not touch any heat sources or sharp edges. Do not let the
cable dangle over the counter edge.
•Do not use the device in case it does not function properly, has been damaged or
dropped.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
•Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with that
of the device (see type label).
Connect the device only in case of compliance! Take note of the security advice!

- 25 -
5.2 Installation and connection
CAUTION!
Installation and connection of the device may only be performed by certified
specialists.
•Unpack the device and remove the packing material. Remove the entire protective
foil from the device.
•Place the device on a flat, secure surface that can support its weight.
•Never place the device on a flammable surface (e.g. carpet).
•Do not place the device near an open flame, electric ovens, coal furnaces or other
sources of heat such as direct sunlight. High temperatures may have a negative
effect on cooling power and increase energy consumption.
•Place the device so as to allow proper air circulation. Keep a minimum distance of 5 cm
from the rear, 10 cm at the sides and 30 cm from the ceiling or shelves.
•Never cover the device’s ventilation ducts.
•Do not place the device where high levels of ambient humidity occur. Such high
humidity may damage the device.
•The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
•Place the device so that the plug is easily accessible and can be quickly removed
from its socket in case of necessity.
5.3 Operating
•Clean the device after unpacking and again before connecting it to a power
source (see 6.2 Cleaning).
•Connect the device to a single grounded outlet.
•Turn the device on using the ON/OFF switch at the front. The green control light will
come on.
•After turning the device on, the LED display will show the following symbols:
and . The factory pre-set temperature will also be shown.
•During first use, allow the device to reach the desired temperature prior to placing
any food products or beverages inside.

- 26 -
Digital temperature regulator
Display and functions
Primary temperature settings are established at the factory and correspond to a working
temperature in the device of approx. 0 °C - 10 °C.
During normal use, the display will show the temperature as measured by the sensor.
The LED will also show the current state of functions (table 1), and by using the 3 buttons
some functions can be activated/deactivated (table 2).
Tab. 1
LED Function Normal working mode Start
ON OFF Flashing
①
Compressor
On Off Needed ON
②
Ventilator On Off Needed ON
③
Defrost
On Off Needed ON
④
Aux Device is on Device is off - ON
⑤
Time
RTC function
is available
and/or active
and set for at
least 1 time
period
RTC function is
not available or
turned off, or no
time period has
been set
- ON, if the
RTC
function
is
available
⑥
Alarm All No alarm - ON
⑦
Digital
display
Composed of 3 lighted values with comma/period and
range of -199…999. See parameters /4, /5, /6 for the
display of values detected by sensor, values in °C/ °F and
after the comma/period

- 27 -
Button functions
Tab. 2
Button Normal work mode Start
Pressing buttons
individually
Pressing
buttons
together
①
Longer than 3 sec.:
alternating display of
ON/OFF
Pressed
together –
constant
operation
mode turned
on / off
-
UP
ON/OFF
③
Longer than 3 sec.:
Defrost turned on / off
Pressed
together –
RESET of
paramaters
activated
1 sec:
Programmin
g version
displayed
Down
Defrost
②
Set
mute
1 sec.: display/ setting
of
- longer than 3 sec.:
access to paramater
configuration menu
(enter code 22)
-Deactivates signal
(buzzer).
- 1 sec: reset
current EZY
settings
Setting desired values (required temperature)
To regulate and change desired values:
•Press for one second: the set value will begin flashing;
•increase or lower the value by pressing
or ;
•confirm the new value by pressing .

- 28 -
Defrost
Automatic defrost
The device automatically defrosts 3 times per 24 hours. The internal clock is activated the
first time the device is turned on.
If you want to reset the automatic defrost cycle, press and hold for over 3 seconds.
The display will show the symbol . The device will immediately begin automatic
defrost, then the next defrost will begin in 8 hours.
Manual defrost
Manual defrost can be activated at any time in addition to automatic defrost: to do so,
press and hold for over 3 seconds.
Manual defrost will begin, and the display will show the symbol .
NOTE!
If you wish to change other settings or parameters, instructions on how to do so
can be found in the information included concerning temperature control, or such
changes can be performed by qualified service personnel.
Tips for the user
•The cooled table should be filled when it reaches the desired temperature, which will
be readable on the display.
•Never place warm food products, liquids or uncovered food products inside the
refrigerated cabinet.
•Use hermitically sealable containers for storing food products and beverages, to
prevent mixing of aromas inside the cooled table.
•When first filling the cooled table, open and fill only one shelf to prevent the device
from tipping over.
•While placing products inside the cooled table, ensure that sufficient space is left
between the inside walls of the device and food products, in order to guarantee
proper air circulation inside the device.
•More items inside the cooled table, as well as opening the doors / drawers often
increase energy use and accelerate the appearance of defects.
•To reduce cold loss, keep doors and drawers open for as short a time as possible,
and do not open them too often.

- 29 -
•To avoid unpleasant odors inside the cooled table, observe the recommended use
by dates.
•In the event of a power outage, avoid opening the doors and drawers as much as
possible to avoid cold loss.
•After a power outage or after removing the plug from its socket, do not
reconnect the device for at least 5 minutes to a power source.
6. Cleaning and maintenance
6.1 Safety advice
oBefore beginning with repair or cleaning works make sure the device has been
disconnected from power socket (pull the power plug!!!) and has cooled down.
oDo not use any acid agents and make sure no water ingresses the device.
oTo protect yourself from electric shock, never immerse the device, its cables and the
plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets. Therefore, you must not
use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
oClean the table regularly.
oDisconnect the device from its power source by removing the plug.
oClean the shelves and drawers with an appropriate disinfecting agent.
oClean the unit’s marble countertop and housing with a moist, soft cloth. Dry the unit
thoroughly.
oNever use harsh cleaning substances such as scouring powder or those containing
alcohol or solvents that could damage the device’s surface.
oAfter cleaning, dry and polish the device with a soft, dry cloth.
If the device is not going to be used for a longer period of time:
remove the plug from its socket;
remove all food products from the cooled table;
clean the interior and exterior of the cooled table with a moist, soft cloth and mild
cleaning agent. Wipe the device down with clean water and dry thoroughly.
leave the doors open for some time to allow the device to dry thoroughly.

- 30 -
6.3 Safety instructions for maintenance
oCheck the mains connection cable for damage from time to time. Never operate the
device when the cable is damaged. A damaged cable must immediately be replaced
by customer service or a qualified electrician to avoid dangers.
oIn case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
oOnly a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
Maintenance
So that the cooling device will function properly for a long period of time, perform the
following maintenance work on the condensator regularly:
oremove the device’s plug from its socket
oopen the cooling device to get access to the condensator.
WARNING! Danger of burns!
The compressor’s surface may be very hot during normal use.
Never touch it with bare hands.
oUse a vacuum cleaner or brush to delicately clean the surface of the condensator,
following the ridges.
oClose the shelf after cleaning.
CAUTION!
Handle the cable carefully – do not pull it!

- 31 -
7. Possible Malfunctions
Problem Cause Solution
Does not cool
•Plug improperly inserted
into socket.
•Safety fuse has discon-
nected power source.
•Power outage
•Damaged temperature
regulator.
•Remove plug and reinsert
properly into socket.
•Check fuses, connect device
to another socket.
•Check power supply.
•Contact a sales agent.
Not enough
cooling power
•Device is near a heat
source or in direct sunlight.
•Poor air circulation inside
the device.
•Products placed inside the
device are too hot.
•Cooled table is overfilled.
•Ensure proper distance
between cooled table and
heat source.
•Ensure proper distance from
walls and other objects.
•Allow products to cool before
placing them inside the
cooled table.
•Do not overfill the cooled
table; remove unneeded food
products if possible.
The above situations are only examples designed to assist you in determining the
possible sources of problems. If such problems or other similar ones occur,
immediately turn off the device and do not use it. Contact qualified personnel or a
sales agent in order to arrange examination of the device and its repair.

- 32 -
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act
according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
