Assembly Instructions
Flexi-News™ quad B001650
1. 2. 3.
4.
First, take base (A) and ensure brakes are
applied to the two castors that have them.
Braked castors are at opposite corners of
base.
With the base locked in place, drop the first
RH panel (C) into the base (A) as shown above.
Secure in place with x2 thumb screws (G).
Next postion the first LH panel (B) in place
and secure with x2 thumb screws (G).
5. 6.
Repeat steps 2-5 to install the remaining
set of LH and RH panels as shown above.
Secure both panels to the upright tab on the
base with x2 thumb screws (G). Ensure the 90°
returns of both panels sit on the same side of
the upright tab on base (A) as shown.
Next secure the panels together at the top using
x2 plastic rivets (H). The plastic rivet (H) is a 2
piece component that secures the panels when
pressed together from both sides.
Tel: [phone] Fax: [phone] email: [email protected] web: www.bartuf.com
All dimensions are approximate and may be subject to change.
All drawings and designs are protected by design right and copyright©
Patents GB 2293538B.GB 2317328 US 6,112,912
A
G x2
G x2
C
C
B
B
x1
x2
x4
x2
x8
x12
x2
x4
G
H
G

Tel: [phone] Fax: [phone] email: [email protected] web: www.bartuf.com
All dimensions are approximate and may be subject to change.
All drawings and designs are protected by design right and copyright©
Patents GB 2293538B.GB 2317328 US 6,112,912
7. 8. 9.
Next take the first of the 100mm deep shelves (D).
Locate the slots on the sides of the shelf with the
studs on the LH and RH panels.
Guide the slots on the sides of the shelf onto
the metal studs on the LH and RH panels (B,C).
Push down and pull towards the front until the
shelf ‘snaps’ into place.
With the first shelf (D) installed, the display should
appear as above.
10.
Install the remaining shelves on this side of the
display following steps 7-8.
E
D
D
DB
B
D
i.PUSH
DOWN
ii.PULL
DOWN
11. 12.
Repeat steps 7-10 to install the shelves on
the opposite side of the display.
To complete the assembly place the dividers (F) into
the shelves (D) and (E) on both sides.
D
F
F
F
F
