Aufbauanleitung / assembly instructions mod.
2057, 2058 mit Mittenauszug
1. Montagematerial
1. fitting material
2. Den Oberbau auspacken und umgedreht auf
gepolsterten Montageböcken ablegen.
2. Unpack the table-top and put it upside down
onto padded assembling trestles.
3. Die Schrauben des lattenträgers mit einem
Inbusschlüssel lösen.
3. Loosen the screws of the top holder with a
hex-wrench
4. Den lattenträger umgedreht auf gepolsterten
Montageböcken ablegen.
4. Lay the top holder onto padded assembling
trestles.
2057, 2058 mit Mittenauszug 1 / 4 Änderungsdatum: 19.02.19
2x
M10 x 635
2x
M10 x 16
SW4
8x
5. Die Unterbau-Säule über den Löchern des lattenträgers positionieren.
Die beiden Gewindestangen durch die Unterbau-Säule stecken und in den lattenträger etwa 5
Umdrehungen eindrehen.
Die Distanzplatte mit dem Falz in die Tischsäule stecken.
Mit zwei Hutmuttern fixieren.
. Position the frame over the holes of the top holder.
Put both treaded bars in the frame and screw them in approx. turns.
Put the distance plate with its rabbet into the table collum.
Fix with two cap nuts.
6. Den Tisch wenden.
6. Turn the table.
2057, 2058 mit Mittenauszug 2 / 4 Änderungsdatum: 19.02.19
Falz
rabbet
M10 x 16
M10 x 635
SW6
7. Den Oberbau wenden und so auf dem latten-
träger des Unterbaus absetzen, dass die
Löcher fluchten.
Achtung: Beim Absetzen die Blendleisten nicht
zu stark belasten, da diese sonst brechen
können.
7. Turn the table-top and put it on the base so the
holes are in line.
Take care: Don‘t load the decorative frames
when turning the top! They can break!
8. Auf beiden Seiten die zuvor ausgedrehten
Schrauben wieder eindrehen.
8. Screw back in the the screws you unscrewed
earlier.
9. Vor dem Ausziehen auf beiden Seiten die
schwarzen Bremshebel lösen.
9. Unfasten the breaks on both sides before you
pull out the extension.
2057, 2058 mit Mittenauszug 3 / 4 Änderungsdatum: 19.02.19
SW4
8x
10. Fertig (Grundzustand).
10. Ready (not extended).
11. Fertig (ausgezogen).
11. Ready (extended).
2057, 2058 mit Mittenauszug 4 / 4 Änderungsdatum: 19.02.19
