BAT LOGIC ErgAdaptor User manual

BAT LOGIC ErgAdaptor
1 x ErgAdaptor Plate with Straps & Clips A
2 x BasePlates (1 x left & 1 x right) B
8 x Flat Head 12mm Screws C
8 x Nuts D
8 x Washers E
The ErgAdaptor contains:
FITMENT GUIDE
C D E
Philips Head Screw Driver
Equipment needed:
WWW.BATLOGIC.NET
FOR FURTHER INFORMATION
PLEASE VISIT OUR WEBSITE
THE ERGADAPTOR AND QUICKRELEASE
SYSTEM WILL FIT MOST ROWING SHOES.
WILL FIT CONCEPT2
MODEL D, E & DYNAMIC
ERGOMETERS.
Clip in with your ShoePlate
Tops or use your regular
rowing shoes directly on
the Adaptor.
Associated product:
ShoePlate Tops
SOLD
SEPARATELY
A
B

WWW.BATLOGIC.NET
FOR FURTHER INFORMATION
PLEASE VISIT OUR WEBSITE
ErgAdaptor
FITMENT GUIDE
Attach your BasePlates to the ErgAdaptor with the screws, washers and nuts provided.
Or attach your rowing shoes directly if you are not using the QuickRelease System. The
washers should go between the screws and the back of the ErgAdaptor plate. You can select
your desired height by sliding the BasePlates up or down the Adaptor slots.
RECOMMENDED HEIGHT:
This should be set to your comfort, the middle 5
notches on the Adaptor match the 5 height settings
on the Concept 2. Next, if needed, screw your rowing
shoes (and CustomPack if used) to your ShoePlate
Tops using the 8x8mm T-head screws supplied with the
ShoePlate Tops. Don’t use counter sunk screws to fit the
shoe to your ShoePlate Tops and do not over tighten
(hand tight or max 5Nm).
STEP 1 – ATTACH YOUR BASEPLATES
Remove the adjustable Concept2 heel cups from the ergo. This can be fiddly the first time. If you push down on the toe of them with your
palm and pull the heel at the same time they come out quickly and easily. You will not break them and they are simple to clip back in. Finally,
pull the Concept2 straps tight as shown, to ensure the buckles and straps sit neatly.
STEP 2 – REMOVE THE HEEL CUPS
Place the ErgAdaptor on the ergo, connect the straps around the back of the Concept2 ergo foot box as shown, with the clip and hook. Give the straps
a strong pull making sure there are no twists.
STEP 3 – ATTACH YOUR ERGADAPTOR TO THE CONCEPT2
Line up each ShoePlate Top with the release tab of the BasePlate and place on top of the BasePlate. Slide the ShoePlate Top upwards to engage into
the BasePlate, you should hear a click. Once engaged you should check the release tab on the ShoePlate Top is fully depressed by pushing down on it,
this ensures a proper locked fitment. To remove simply lift the tab on the ShoePlate Top and pull the plate downwards.
To remove the ErgAdaptor, simply unclip the straps and lift o the ergo, then refit the heel cups.
STEP 4 – CLICK IN YOUR SHOEPLATE TOPS
