Revitive Arthritis-Knee User manual

Numéro de modèle / Modelnummer / Modellnummer: 2836AB
User’s Manual
PLEASE READ THE USER’S MANUAL
CAREFULLY BEFORE USING THIS PRODUCT
USE ONLY AS DIRECTED
If symptoms persist, consult
your healthcare professional
®
KLINISCH GETEST
ZONDER MEDICIJNEN
MEDISCH HULPMIDDEL
VEUILLEZ LIRE ATTENTIVEMENT LE
MANUEL DE L’UTILISATEUR AVANT
D’UTILISER CE PRODUIT.
LEES VÓÓR GEBRUIK VAN DIT PRODUCT
DEZE GEBRUIKERSHANDLEIDING
ZORGVULDIG DOOR
BITTE LESEN SIE SICH VOR DER
INBETRIEBNAHME DIESES PRODUKTS DIE
BEDIENUNGSANLEITUNG AUFMERKSAM
DURCH.
EN
Manuel de l’utilisateur
FR
Bedienungsanleitung
DE
Gebruikershandleiding
NL
UTILISEZ EXCLUSIVEMENT SELON L’USAGE
PRÉCONISÉ. Si les symptômes persistent,
veuillez consulter un professionnel de santé
UITSLUITEND GEBRUIKEN VOLGENS DE AANWIJZINGEN.
Raadpleeg bij aanhoudende klachten een professionele
zorgverlener
BEFOLGEN SIE DIE ANWENDUNGSHINWEISE.
Suchen Sie bei anhaltenden Beschwerden bitte
einen Arzt auf.
CLINICALLY TESTED
DRUG FREE
MEDICAL DEVICE
TESTÉ CLINIQUEMENT
SANS MÉDICAMENT
DISPOSITIF MÉDICAL
KLINISCH GETESTET
MEDIKAMENTENFREI
MEDIZINPRODUKT
4397_IFU02_16220241.indd 1 25/01/2019 14:50

23
Table of contents
What is inside the box? 4
Parts and Controls 5-6
Introduction to REVITIVE 7-9
Indications for use 7-8
How REVITIVE works 9
Important Safeguards 10-14
Who Should NOT use REVITIVE 10
Warnings and Cautions 10-13
Safety Precautions 13-14
Adverse Reactions 14
Instructions for use 15-35
How do I get the most from REVITIVE? 15
Step 1: Setting up REVITIVE for the first time 15
Step 2: Setting up the IsoRocker® 16
Step 3: Powering REVITIVE 17-18
Step 4: Using the foot-pads 19-21
Step 5: Using the Electrode Pads 22
5.1: Using the Electrode Arthritis Pads for EMS 23-28
5.2: Using the Electrode Body Pads for TENS 29-33
5.3: Switching between EMS and TENS mode 33
Step 6: Recharging the battery 34
Step 7: Cleaning and storing 35
Replacing the batteries & Body Pads 35
Troubleshooting 36-38
Technical Specifications 39-41
Warranty 42
EN
FR Manuel de l’utilisateur 3-42
FR Manuel de l’utilisateur 43-82
NL Gebruikershandleiding 83-122
DE Bedienungsanleitung 123-162
Manuel de l’utilisateur
Gebruikershandleiding
Bedienungsanleitung
EN
FR
DE
NL
User’s Manual
ENGLISH
4397_IFU02_16220241.indd 2-3 25/01/2019 14:50

45
What is inside the box?
On opening the carton, please check that the following components are provided. If
you think anything is missing, please contact us using the helpline numbers on the
back of this booklet.
Parts and Controls
Large Electrode
Arthritis Pads
AAC/DC power adaptor
REVITIVE Arthritis-Knee
Small Electrode Body Pads
Electrode cords x2
Remote control
AAA batteries x 2
Carry handle
Control panel
/display
Power ON/OFF
Foot-pads
AC/DC power
adaptor socket
Electrode Pads socket
Advanced
IsoRocker®
IsoRocker Disabler
C
B
D
E
F
G
H
I
J
K
L
M
NO
EN
EN
4397_IFU02_16220241.indd 4-5 25/01/2019 14:50

67
Introduction to REVITIVE
Indications for use
Using REVITIVE Arthritis-Knee is intended to:
•Reduce pain and discomfort associated with knee osteoarthritis, or
following knee surgery. Reduce pain and discomfort in the legs caused
by poor circulation (Peripheral Arterial Disease), or caused by diabetic
peripheral neuropathy;
• Reduce swelling in the knee caused by osteoarthritis, or in the ankle
following acute ankle injury;
•Improve circulation in the legs caused by being immobile following lower
limb surgery. Improve circulation caused by poor circulation (Peripheral
Arterial Disease, or Chronic Venous Insuiciency);
•Increase muscle strength in the legs of people with knee osteoarthritis,
patients following lower limb surgery; and people aected by COPD;
•Increase walking distance before the onset of claudication symptoms (pain) –
caused by Peripheral Arterial Disease;
•Improve symptoms associated with varicose veins/ Chronic Venous
Insuiciency.
When using REVITIVE to deliver Transcutaneous Electrical Nerve
Stimulation (TENS), it is intended to provide:
•Relief of chronic pain in the knee caused by osteoarthritis;
•Temporary relief of post-surgical pain in the knee;
•Relief of chronic neuropathic pain;
•Relief of chronic elbow or shoulder pain caused by injury or overuse;
•Temporary relief of lower back pain;
The above Indications for Use are certified under the Medical Devices Directive 93/42/EEC.
The above intended purpose is included on the Australian Register of Therapeutic Goods
(ARTG).
Time
Control – /+
Power
ON/OFF
TENS
EMS
Remote control
Control panel
Time display
Intensity level
Intensity
Control – /+
Battery
indicator
Time
Control – /+
Intensity
Control – /+
EMS TENS
Parts and Controls EN
EN
4397_IFU02_16220241.indd 6-7 25/01/2019 14:50

89
How REVITIVE Arthritis-Knee Works
With its unique TripleAction REVITIVE Arthritis-Knee works in three ways:
1. Delivers Electrical Muscle Stimulation (EMS) to your feet via a pair of
cushioned foot-pads, while you are seated. The EMS causes muscles in your
calf and foot to contract, which helps to increase circulation in your legs.
REVITIVE has been developed so that it is comfortable for you to use. It features
a patented IsoRocker® that allows for natural ankle movement when applying
the EMS to your feet. Ankle movement is a key factor in increasing circulation in
the lower legs. You can choose to enable or disable the IsoRocker® at any time.
REVITIVE is designed to be easy to use and comes with a remote control,
which means you do not have to reach down to adjust settings during use.
2. Delivers Electrical Muscle Stimulation to the front of the thighs/quadriceps
through the use of the Arthritis (Electrode) Pads - to strengthen the
quadriceps. Strengthening your quadriceps muscles may help to:
• Support and stabilise the knee
• Reduce stress on the knee
• Relieve knee pain
To get the most out of REVITIVE, it is recommended that you use:
• REVITIVE foot-pads for at least 30-60 minutes each day.
• REVITIVE Arthritis Pads on the thigh of your aected leg (knee) once a day for
20 minutes, 5 days per week.
3. Delivers Transcutaneous Electrical Nerve Stimulation (TENS) through
the smaller Body (Electrode) Pads - to provide immediate, temporary relief
of pain for your legs and other areas of your body. Use as and when you need
relief.
Visit www.revitive.com for more information
Introduction to REVITIVE
In addition, if you have a sedentary lifestyle or spend long periods inactive, REVITIVE
may help to:
• Reduce foot & leg discomfort
• Reduce swollen feet & ankles
• Relieve leg cramps
• Strengthen leg muscles
• Actively increase circulation.
Always consult with your health care professional before use. Do not use if fitted
with an electronic implanted device such as a heart pacemaker or Automatic
Implantable Cardioverter Defibrillator (AICD); you are pregnant; being treated
for, or have symptoms of Deep Vein Thrombosis (DVT): such as pain, swelling and
tenderness, heavy ache, warm or red skin in the leg.
EN
EN
4397_IFU02_16220241.indd 8-9 25/01/2019 14:50

10 11
Important Safeguards
Warnings
• Consult with your doctor before using this device if:
•You are in the care of a doctor
•You have a history of heart problems
•You have had medical or physical treatment for your pain
•You have suspected or diagnosed heart disease
•You have suspected or diagnosed epilepsy
•You are unsure about the suitability of the REVITIVE for you
•You are unsure about the cause of your symptoms
• If you have a metallic implant, you may experience pain or discomfort near the
implant when applying electrical stimulation, if this should occur discontinue
use and seek advice from your doctor
• The electrical stimulation may feel more intense close to a metallic implant. It is
safe to continue use provided no pain is experienced. You may need to adjust
the intensity to a comfortable level
• If your Arthritis symptoms worsen, or you have had knee surgery (within the last
six months), consult with your doctor before reusing REVITIVE
• Do not use the Electrode Pads on your head, face, neck or chest
• Do not apply foot-pads or Electrode Pads directly:
•on open wounds or rashes, swollen, red, infected, or inflamed areas or skin
eruptions (such as phlebitis, thrombophlebitis, varicose veins, cellulitis)
•on or close to, malignant tumours
•on areas treated with radiotherapy (within the past 6 months)
•on reproductive organs
• Electrode pads are for single person use only. Do not share with others
• Do not use the Arthritis Pads in conjunction with a brace or cast without first
consulting with your doctor
• Do not use Electrode Pads aer their use by date
• There is a chance you may experience skin irritation or burns beneath
the Electrodes Pads or hypersensitivity due to the electrical stimulation
• Ensure that moisturiser/gel/balm is evenly applied and thoroughly
Read all instructions before use
Who should not use REVITIVE
REVITIVE should NOT be used by some people.
Do not use if (contraindications):
•You are fitted with an electronic implanted device such as a heart pacemaker
or Automatic Implantable Cardioverter Defibrillator (AICD)
•You are pregnant
• You are being treated for, or have the symptoms of, an existing Deep Vein
Thrombosis (“DVT”)
Long periods of inactivity can put you at greater risk of developing Deep
Vein Thrombosis (DVT). DVT is a blood clot and usually occurs in a deep
leg vein. If part of the DVT breaks o it may lead to potentially life-
threatening complications such as pulmonary embolism.
If you have been inactive for prolonged periods and suspect you may
have a DVT, consult your doctor immediately. To prevent dislodging the
clot do not use REVITIVE.
In some cases of DVT there may be no symptoms. However it is important
to be aware of the symptoms that may include:
•pain, swelling and tenderness in one of your legs (usually your calf)
•a heavy ache in the aected area
•warm skin in the area of the clot
•redness of your skin, particularly at the back of your leg, below
the knee
Consult your doctor as soon as possible if you show any signs of the
above symptoms.
EN
EN
4397_IFU02_16220241.indd 10-11 25/01/2019 14:50

12 13
absorbed into the skin before applying stimulation. There is a chance that
uneven application of a moisturiser/gel/balm could increase the risk of
skin irritation or burn, when using the electrical stimulation.
• Do not use the device:
• In the presence of electronic monitoring equipment
•Together with a life-supporting medical electronic device
•When you are in the bath or shower
•While you are sleeping.
Warnings - EMS only
• Symptoms may worsen during the initial treatment phase before getting better.
This may occur if the body has not yet adjusted to increased muscular activity
and blood circulation. If this occurs, reduce the intensity and the duration of
treatment which will reduce the initial symptoms. If symptoms persist consult
with your doctor.
Warnings - TENS only
• When using TENS do not apply to areas of skin that lack sensation.
Cautions
• Be careful when applying stimulation over areas of skin that lack normal
sensation. It may cause skin irritation due to the inability to feel stimulation
until the intensity is too high - use a low intensity to achieve a gentle muscle
contraction, and/or use for a shorter time, to avoid overstimulation. Check for
signs of skin irritation (redness), bruising or pain. If in doubt consult your doctor
• When using EMS be careful when applying stimulation:
• Over the abdomen during menstruation
• Aer recent surgical procedures (within the past 6 months) as
stimulation may disrupt your healing process
•If your tissues are likely to bleed following an injury such as a muscle tear -
it is recommended not to stimulate the immediate area within the first
12 hours aer sustaining the injury. Use a low intensity and/or shorter
time to avoid over-stimulation
• Aer a long period of immobility or inactivity – use a low intensity and
shorter time to avoid overstimulation or muscle fatigue. Look for signs of
skin irritation (redness), bruising or pain. If in doubt, consult your doctor
• When using TENS:
•It is possible REVITIVE may reduce the sensation of pain that would
normally act as a warning of an underlying problem
•If your pain does not improve, gets worse or continues for more than 5
days, stop using the device and seek advice from your doctor
•TENS is not eective in treating the original source or cause of pain
• The long term eects of electrical stimulation are unknown
• Electrical stimulation may not work for every user, please seek advice from
your Doctor
• This product is not intended for use by persons with reduced physical, sensory
or mental capabilities, unless they are supervised by a person responsible for
their safety.
Safety Precautions
• Do not stand on the machine. Use only when sitting down
• Use the device only for its intended purpose
• Do not expose the device to extreme heat
• Do not spill liquid on the device or its accessories
• Do not overload the electrical socket
• Keep device out of the reach of children
• Keep power cords and cables out of the reach of children to prevent risk of
strangulation
Important Safeguards EN
EN
4397_IFU02_16220241.indd 12-13 25/01/2019 14:50

14 15
• REVITIVE may be used by multiple persons, ensure device is cleaned aer each
use
• Use REVITIVE only with the accessories supplied by, or purchased from, the
manufacturer
• Check body pads, cords and cables periodically for damage
• Do not open REVITIVE or repair it yourself. This will invalidate your warranty and
may cause serious harm
• In the unlikely event your REVITIVE malfunctions, disconnect it from the power
source and contact your nearest authorised agent
• With the increased number of electronic devices such as personal computers
and mobile (cellular) telephones, medical devices may be susceptible to
electromagnetic interference from other devices. REVITIVE has passed
the required tests for Electromagnetic Interference (EMI); it may still be aected
by excessive emissions and/or may interfere with more sensitive equipment
• It has been reported that some universal remote control devices (e.g. for TV etc.)
can change the settings on REVITIVE if used during a treatment. If this should
occur, simply adjust the time or intensity settings on REVITIVE back to where
you want them to be using the REVITIVE Remote Control,or using the device
Control Panel
• Aer any exposure to hot or cold temperatures outside the specified operating
range of 10 – 40°C allow the product to re-adjust to the recommended operating
temperatures to ensure continued product performance.
Adverse Reactions
• If you experience adverse reactions, stop using REVITIVE and consult with your
doctor.
Save these instructions
Instructions for use
Step 1:
Setting up REVITIVE for the first time
aRemove all parts from the box:
• REVITIVE Arthritis-Knee device • AC/DC power adaptor
• Small Electrode Body Pads • Electrode cord x2
• Large Electrode Arthritis Pads • Remote control
• AAA batteries x 2
See What is inside the Box? on pages 4-6 to help identify the parts.
bLocate the remote control and insert the batteries.
Before you use REVITIVE for the first time, read the
Warnings and Cautions on pages 9-14. If in doubt,
consult your doctor before using the product.
How do I get the most from REVITIVE?
EMS Stimulation - for best results:
• Use REVITIVE foot-pads for at least 30 to 60 minutes each day, 7 days a
week and use the large REVITIVE Arthritis Pads on your aected leg
(knee) once a day for 20 minutes, 5 days a week.
• It is important to use REVITIVE at a high enough intensity to give you a
strong comfortable muscle contraction. Most people achieve a strong
muscle contraction over intensity level 40 (intensity range 1-99).
• It can take up to 12 weeks to help reduce symptoms associated with
arthritis.
Do not use REVITIVE, using EMS stimulation, for more than 6 sessions of
30 minutes (or the equivalent) per day.
TENS stimulation
For TENS Stimulation, through the smaller REVITIVE Body Pads, use as and
when required, for 20-30 minutes each session.
Important Safeguards EN
EN
4397_IFU02_16220241.indd 14-15 25/01/2019 14:50

16 17
Step 2:
Setting up REVITIVE the IsoRocker®
aTurn the device over so that you can see the IsoRocker® and IsoRocker Disabler.
• The IsoRocker allows REVITIVE to rock while stimulating your legs & feet.
• REVITIVE will begin rocking on the IsoRocker once muscle contractions
are strong enough.
• The IsoRocker feature can be disabled, by ‘opening’ the IsoRocker Disabler.
REVITIVE will then be static and it will not rock during use.
bIf you want to use the IsoRocker, leave the
IsoRocker Disabler in place (ie flat) on the of the
device, as shown.
cIf you do not want to use the IsoRocker
• Open the IsoRocker Disabler on the bottom of
REVITIVE.
• Pull the IsoRocker Disabler back until it clicks
open, as shown.
• To re-enable the IsoRocker, pull the IsoRocker
Disabler and press into place on the bottom
of the device (ie flat).
Step 3:
Powering REVITIVE
REVITIVE can be powered from either the rechargeable battery or by connecting it to
an electrical socket.
Instructions for use
Battery power option
If you want to use the device without connecting it to an electrical
socket, it can run from the battery.
When the device is running from the battery, an indicator will show the
remaining battery level.
Follow Step 4 Using The Foot-pads or Step 5 Using the Electrode Body
Pads to continue setting up REVITIVE.
When the battery drops to the low level, it will require recharging.
See Step 6, Recharging Battery on page 34.
If you turn the device o and the low battery level indictor blinks for
10 seconds, the battery requires recharging.
Please note that if the battery runs out, the device can still be used,
by connecting to an electrical socket.
Full Battery Low Battery
EN
EN
4397_IFU02_16220241.indd 16-17 25/01/2019 14:50

18 19
Mains power option
If you want to use REVITIVE when the battery is low or to preserve the
battery level REVITIVE can be used by connecting it to an electrical socket.
aLocate the AC/DC power adaptor.
bPlug the small end of the power cord into the
opening on the side of the REVITIVE.
cPlug the power adaptor into the nearest
electrical socket. This will start charging the
(integrated) rechargeable battery.
Once you have connected REVITIVE to the electrical socket follow Step 4
Using the Foot-pads or Step 5 Using the Electrode Body Pads to continue
setting up REVITIVE.
Instructions for use
aIt is important that you are hydrated. We recommend
drinking a glass of water before using REVITIVE.
You may also apply a moisturiser to the soles of
the feet to help hydrate the skin.
Hint: Applying a moisturiser to the soles of the feet before
using REVITIVE can help improve the delivery of electrical
stimulation.
bGet into a comfortable seated position.
For best results sit with your knees at a 90 degree angle
(right angle).
cPlace REVITIVE on the floor in front of you.
REVITIVE is designed to be used while seated.
Never stand on the REVITIVE unit.
dPlace both bare feet on the foot-pads.
Make sure you remove all footwear, including socks/
stockings.
ePress the power button on the device or on the remote
control to turn REVITIVE on.
You will hear a beep and the display lights will light up.
The time will read 30 minutes and Intensity will
read 00.
To turn o REVITIVE at any time during operation,
press the power button on the device or on the remote
control.
Sit with
both bare feet
on the foot-pads
Step 4:
Using the foot-pads
The foot-pads will only deliver EMS to your feet and legs.
You can use the Body Pads to receive TENS, see page 29 for details.
EN
EN
4397_IFU02_16220241.indd 18-19 25/01/2019 14:50

20 21
fSet the time for REVITIVE. The default time is 30
minutes. You can set the timer for up to 60 minutes. If
you do not want to use the default time of 30 minutes,
set the time for the number of minutes you want.
You can use the controls on the control panel or on the
remote control.
Press the (+) Time Control to increase the time.
Press the (–) Time Control to decrease the time.
gPress the (+) Intensity Control one time to
start stimulation.
You can use the buttons on the control panel or
remote control.
Press the (+) button to increase the level.
Press the (–) button to decrease the level.
hEnsure you familiarise yourself with the feeling of
Electrical Muscle Stimulation (EMS). Use on a low
intensity for 30-60 minutes once per day for a few days.
For best results use REVITIVE foot-pads for at least 30 to 60 minutes each day,
seven days a week.
It is important to use REVITIVE at a high enough intensity to give you a strong
comfortable muscle contraction. Most people achieve a strong muscle
contraction over intensity level 40 (intensity range 1-99).
If you are diagnosed with a long term medical condition such as High Blood
Pressure, High Cholesterol, Diabetes, Osteoarthrtis, Chronic Venous Insuiciency
(CVI), Peripheral Arterial Disease (PAD), or COPD, we recommend a minimum of
two (2) x 30 minute sessions per day. It can take up to 12 weeks to help reduce
symptoms associated with these chronic conditions.
Do not use REVITIVE more than 6 sessions of 30 minutes (or the equivalent) per
day. This may result in muscle fatigue.
Instructions for use
Set the intensity at a level where you can feel the stimulation in your
feet which creates a calf contraction. This will likely be less than
intensity 40.
It is normal to feel tingling or varying sensations in your feet and
calf muscles.
REVITIVE does not vibrate.
iAer a few days of familiarisation, use a higher intensity that provides
you with strong but comfortable calf muscle contractions.
Most people experience a strong contraction at intensity level 40
or over. You can set the intensity between 1-99.
Please note that the intensity required may vary from day to day.
If you feel pain or discomfort:
• Remove one or both feet from the foot-pads to stop the
stimulation
• Lower the intensity of the foot-pads using the (–) Intensity
Control on the control panel, or remote control, before replacing
your feet on REVITIVE
jThe Time Display will start to count down in minutes as REVITIVE
cycles through its program.
kWhen REVITIVE times out, the Time Display reads 00 and you will
hear three beeps.
lThe REVITIVE switches itself o automatically.
EN
EN
4397_IFU02_16220241.indd 20-21 25/01/2019 14:51

22 23
Step 5:
Using the Electrode Pads
Electrode Body and Arthritis Pads are for single person use only. Do not share
with others.
REVITIVE comes with one pair of reusable (up to 20-30 applications) Arthritis Pads that
can be used to deliver Electrical Muscle Stimulation (EMS) to strengthen the muscles
at the front of your thigh (quadriceps).
Strengthening your quadriceps muscles may help to support and stabilise the knee,
reduce stress on the knee and relieve knee pain.
REVITIVE also comes with one pair of smaller reusable (up to 20-30 applications) Body
Pads that can be used to deliver Transcutaneous Electrical Nerve Stimulation (TENS)
to other parts of the body.
TENS provides stimulation of your nerves, which blocks the pain you experience in
a particular area of your body. TENS can be used to provide pain relief to the areas
shown on page 29. For instructions on how to use TENS, go to page 29.
Before using the Body Pads, select the area you wish to apply stimulation to and
which stimulation mode you would like to use.
The positioning of the Electrode Pads will depend on which stimulation mode (EMS
or TENS) you choose. The Electrode Pads cannot be used at the same time as the
foot-pads. Using the Electrode Pads will automatically turn the foot-pads o.
Step 5.1:
Using the Large Arthritis Pads for Electrical Muscle Stimulation
(EMS)
aClean and dry the thigh where you will place the Arthritis Pads (see next page for
positioning instructions).
bMake sure REVITIVE is switched o. If the control panel
is still illuminated, press the power button and turn
REVITIVE o.
c Attach the ends of the Arthritis Pads to the Electrode
cord.
Press connectors until there is no gap
between them.
Leaving a gap may cause discomfort.
dPlug the other end of the Electrode cord into
the opening on the side of REVITIVE.
It is recommended that the Arthritis Pads be used on the aected leg (knee) for
20 minutes, once a day, 5 days per week. Find a routine that works for you,
perhaps using the Arthritis Pads Monday - Friday and not at the weekend.
Do not use REVITIVE more than 6 sessions of 30 minutes (or the equivalent) per day.
This may result in muscle fatigue.
Instructions for use EN
EN
4397_IFU02_16220241.indd 22-23 25/01/2019 14:51

24 25
eRemove the plastic liner from the Arthritis Pads, by
peeling it o carefully. Replace the Arthritis Pads onto
the plastic liner aer use.
fGently press one Arthritis Pad across your thigh (1), a
few centimetres away from your groin area, with the
adhesive side against the skin.
gGently press second Arthritis Pad across your thigh
(2), a few centimetres from the top of your kneecap,
with the adhesive side against the skin.
The Arthritis Pads do not need to be lined up exactly
with each other. They need to be in a position that is
comfortable and that allows you to see your thigh
muscles contract & relax.
REVITIVE Arthritis Pads are designed to be used
whilst seated.
1
2
NB The Arthritis Pads are only suitable for use on the thigh muscle with the
REVITIVE Arthritis-Knee device in EMS mode and will not be eective for any
other areas of the body.
hPress the power button on the device or on the remote
control to turn REVITIVE on.
You will hear a beep and the display lights will light up.
The time will read 30 minutes, the Intensity will
read 00 and the EMS symbol will be displayed.
NB REVITIVE Electrode Pads will automatically provide
stimulation in EMS mode.
See page 29 for instructions on how to use in TENS
mode.
i Set the time for the number of minutes you want to use
REVITIVE. The default time for the Arthritis Pads is 20
minutes.
You can use the buttons on the device or remote control.
Press the (+) Time Contol to increase the time.
Press the (–) Time Contol to decrease the time.
Do NOT use the Arthritis Pads on your head, face, neck or chest.
Instructions for use EN
EN
4397_IFU02_16220241.indd 24-25 25/01/2019 14:51

26 27
jPress the (+) Intensity Control, one time, to start
stimulation.
You can use the buttons on the device or remote control.
Press the (+) button to increase the level.
Press the (–) button to decrease the level.
kEnsure you familiarise yourself with the feeling of
Electrical Muscle Stimulation (EMS). Use on a low
intensity for 20 minutes once per day for a few days.
Set the intensity at a level where you can feel the
stimulation in your feet which creates a calf contraction.
This will likely be less than intensity 40.
It is normal to feel tingling or varying sensations in
your muscles you are treating.
l Aer a few days of familiarisation, use a higher intensity
that provides you with strong but comfortable muscle
contractions.
Most people experience a strong contraction at intensity
level 40 or over. You can set the intensity between 1-99.
Adjusting the intensity level - At the start of therapy there will be 30 seconds of
stimulation to help you set the right intensity level. This is followed by a rest period of
30 seconds, when you will feel no stimulation.
For the remainder of the therapy session you will feel 10 seconds of stimulation,
followed by a 20 second rest period which repeats until the end of therapy.
Adjust the intensity when you can feel the stimulation being applied to your thigh.
It is not possible to adjust the intensity during the rest period.
Please note that the intensity required may vary from day
to day.
mThe time control/display will start to count down in
minutes as REVITIVE cycles through its program.
nWhen REVITIVE times out, the time display reads 00 and
you will hear three beeps.
oREVITIVE switches itself o automatically.
pEnsuring that the device has switched itself o, then
gently peel the Arthritis Pads from the skin.
Do not pull the Arthritis Pads o the skin using the
Electrode cords as this may damage the cords.
Instructions for use
If you feel pain or discomfort:
• lower the intensity of the Arthritis Pads using either the (–)
Intensity Control on the control panel of the device or on the remote
control.
• You can also choose to stop therapy before the end of the 20 minute
session to avoid muscle fatigue. You can do this by pressing the
power button on the device or on the remote control.
EN
EN
4397_IFU02_16220241.indd 27 25/01/2019 14:51

28 29
q Replace the Arthritis Pads onto their plastic liner
aer use.
rUnplug the Electrode cord from the opening on REVITIVE.
You do not need to detach the Arthritis Pads from
the Electrode cords.
Instructions for use
Step 5.2:
Using the Small Body Pads for Transcutaneous Electrical
Nerve Stimulation (TENS)
aSelect the area you wish to apply electrical stimulation to.
Recommended Body Pad placements are shown below:
If using TENS for pain relief, position the Body Pads on either side of the area
causing you pain.
It is recommended to use REVITIVE, in TENS mode, for 20-30 minutes per session.
TENS mode may be used as and when required.
Thigh
Inside of
Ankle/foot
✔
✔
✔
✔
✔
Outside of
Ankle/foot Caf
Knee
Lower back
Back of
Shoulder
✔✔
✔
Upper back
EN
EN
4397_IFU02_16220241.indd 29 25/01/2019 14:51

30 31
bClean and dry the area where you will place the Body Pads.
cMake sure REVITIVE is switched o. If the control panel is
still illuminated, press the power button and turn REVITIVE
o.
dAttach the ends of the Body Pads to the Electrode cord.
Press connectors until there is no gap between them.
Leaving a gap may cause discomfort.
ePlug the other end of the Electrode cord into the opening
on the side of REVITIVE.
Plugging in the Electrode cord will automatically turn the
foot-pads o.
R
R
R
R
R
Do NOT use the Body Pads on your head, face, neck or chest.
Instructions for use
fRemove the plastic liner from the Body Pads, by peeling it
o carefully. Replace the Body Pads onto the plastic liner
aer use.
gPress the Body Pads on the area you wish to apply
electrical stimulation, as shown on page 29, gently
pressing the adhesive side against the skin.
hPress the power button on the device or on the remote
control to turn REVITIVE on.
You will hear a beep and the display lights will light up.
The time will read 30 minutes, the Intensity will
read 00 and the EMS symbol will be displayed.
NB REVITIVE Body Pads will automatically provide
stimulation in EMS mode.
See page 23 for instructions on how to use EMS mode.
iPress the TENS button on the remote control.
You will then see the TENS symbol on the display.
R
R
R
R
R
R
R
R
R
R
EN
EN
4397_IFU02_16220241.indd 30-31 25/01/2019 14:51

32 33
jPress the (+) Intensity Control once to start
stimulation.
Continue to increase the intensity until you feel
a strong but comfortable tingling sensation without
it causing you pain. You can set the intensity between
1-99.
You can use the buttons on the device or
remote control.
Press the (+) button to increase the level.
Press the (–) button to decrease the level.
If you feel pain or discomfort:
• Lower the intensity of the Body Pads using the (–)
Intensity Control on the device or remote control.
• You can also choose to stop therapy before the end of
the 30 minute session to avoid skin irritation. You can do
this by pressing the power button on the device or on
the remote control.
kThe Time display will start to count down in
minutes as REVITIVE cycles through its program.
When REVITIVE times out, you will hear three beeps,
and the device will switch itself o automatically.
lEnsuring that the device has switched itself o, then
gently peel the Body Pads from the skin.
Do not pull the Body Pads o the skin using the
Electrode cords as this may damage the cords.
R
R
R
R
R
Instructions for use
mReplace the Body Pads onto their plastic liner aer use.
nUnplug the Electrode cord from the opening on
REVITIVE.
You do not need to detach the Body Pads from the
Electrode cord.
R
R
R
R
R
Step 5.3:
Switching between EMS and TENS mode
To change between EMS and TENS mode,
press the button of the stimulation mode
you require on the remote control.
During use, switching from EMS to TENS
mode (or vice versa), will reset the timer back
to 30 minutes. The intensity will also be
reset to zero.
EN
EN
4397_IFU02_16220241.indd 32-33 25/01/2019 14:51

34 35
aLocate the AC/DC power adaptor.
bPlug the small end of the power cord into the opening
on the side of the REVITIVE.
Step 6:
Recharging the battery
REVITIVE can be powered from either the rechargeable battery or by connecting it to
an electrical socket.
Low Battery Full Battery
cPlug the power adaptor into the nearest electrical socket. This will start charging
the (integrated) rechargeable battery.
The battery indicator will illuminate constantly to indicate the device is charging
and to show the battery level, as below.
A full charge will take approximately 3 hours.
dOnce fully charged, the full battery indicator will stay illuminated until the power
adaptor is unplugged from the device or the electrical socket.
A full charge enables approximately 3½ hours of use (the equivalent of seven
(daily) 30 minute sessions).
Please note you can still use the device while it is charging but the battery
indicator will not show.
Instructions for use
Step 7:
Cleaning and storing REVITIVE
aEnsure REVITIVE is switched o.
bWipe down the foot-pads with a so damp cloth.
Do not clean with chemicals.
Do not immerse REVITIVE in water.
cStore REVITIVE in a cool, dry and dust-free location.
Store out of direct sunlight.
dPlace Electrode Pads onto the plastic liner.
eStore the Electrode Pads in a dry and ventilated location.
Store out of direct sunlight.
You do not have to detach the Electrode Pads from the Electrode cords to
store them.
Replacing the Batteries
The remote control requires two AAA 1.5V batteries to operate.
Replacing the Electrode Pads
The Large Electrode Arthritis Pads and Smaller Electrode Body Pads are reusable
up to 20-30 applications. If the Electrode Pads start to lose their adhesiveness, rub
a few drops of water into the surface. Replacement Pads can be obtained via www.
revitive.com
EN
EN
4397_IFU02_16220241.indd 34-35 25/01/2019 14:51

36 37
Troubleshooting
Problem Possible Cause Solution
REVITIVE is on (lights
illuminated on the
LED display) but
I cannot feel the
electrical stimulation
through the foot-
pads.
Not placing both bare feet on the
foot-pads at the same time.
Ensure that your feet are bare and
each foot is placed on each of the
foot-pads at the same time. Keep
increasing the intensity up to a
maximum of 99 until you feel the
stimulation.
Your feet may be dry. Moisturise the soles of your feet
to improve conductivity and
stimulation and try the procedure
again. You may also have to
increase the intensity level.
You may be dehydrated. Drink plenty of water before
and aer using the device. The
device uses your body to create
the electrical circuit. Water is an
excellent conductor of electricity
and if your body is less hydrated
(below 60%) then the stimulation
may be less, therefore it is
important to always remain well
hydrated.
The intensity level may be on
too low a setting.
This is a very safe device. Keep
increasing the intensity
level towards 99 until you feel
the stimulation. You may find
that you have to increase the
intensity level as you get used
to the therapy. The aim is not to get
to 99 but to find a setting that is
comfortable for you.
Electrode cord is connected to
device.
Disconnect the Electrode cord - the
foot-pads will not work while the
Electrode cord is plugged in.
If, having tried the solutions
above, you still cannot feel the
stimulation:
Test the device by placing one hand
across both footpads at the same
time (The heel end of the footpads
is easiest). With your other hand,
and starting from zero, increase
the intensity level until you can
feel the stimulation. If you can feel
the stimulation through your hand
then the device is working. If on 99
you still cannot feel the stimulation
then please contact your authorised
dealer.
Problem Possible Cause Solution
No power or lights to
REVITIVE when it is
switched on.
AC Adaptor not switched on at the
electrical socket or AC Adaptor not
plugged into device properly.
Check electrical socket power
is switched on and the AC Adaptor
is plugged into the device correctly.
If still not working – contact your
authorised dealer.
Flat battery Plug device in an electrical socket
and charge battery or run using
mains power option.
REVITIVE is not
vibrating. REVITIVE IS NOT DESIGNED TO VIBRATE.
The IsoRocker® is not
"rocking".
It is the muscles in your legs that
cause the "rocking", the IsoRocker®
is not mechanical.
The IsoRocker® will only rock
when increased to an intensity
which causes suicient calf muscle
contraction. It may be that you
cannot comfortably increase the
intensity high enough until you
get used to the sensation. It is
important that intensity is adjusted
to a level that is comfortable.
The device is too far in front
of you.
Sit with your knees at a 90 degree
angle.
The IsoRocker® system is not
enabled.
Ensure IsoRocker® Disabler is “flat”,
in centre position (see page 16).
My legs are aching
aer treatment.
You may have the
intensity on
too high a setting and your muscles
are being overworked.
Leave adequate time aer each
treatment to allow the muscles
to recover (just like aer vigorous
exercise!). On your next session
start on a lower setting (where
you can feel the mild electrical
stimulation and it is comfortable)
and reduce the duration until your
muscles have acclimatized to the
stimulation.
When using the
IsoRocker® on a
hard floor it makes a
tapping noise.
Incorrect positioning of the device
or too high an intensity level.
Adjust the positioning of the
device or lower the intensity level
to reduce the device tapping.
Alternatively use a floor mat under
the device to cushion the sound.
EN
EN
4397_IFU02_16220241.indd 36-37 25/01/2019 14:51

38 39
For more information, including Frequently Asked Questions,
please visit www.revitive.com
Problem Possible Cause Solution
I have placed my feet
on the device but am
unable to see the TENS
symbol on the display.
TENS is only available through
the Body Pads. The foot-pads
provide EMS only.
When using the Body
Pads, the stimulation
feels uncomfortable.
The level of stimulation you are
using may be too high.
Decrease the stimulation level
using the (-) intensity control on
the device or remote control.
I am unsure of which
therapy mode I am
using when using the
Body Pads.
Look at the display on the device. If
the Body Pads are in EMS mode,
you will see the EMS symbol. If
the Body Pads are in TENS mode,
you will see the TENS symbol.
I suddenly can’t feel
stimulation when using
the Body Pads.
You may have pressed the other
stimulation mode button by
accident.
Pressing the opposite stimula-
tion mode button (i.e. pressing
the TENS button when already in
EMS mode or vice versa), will reset
the timer back to 30 minutes. The
intensity will also be reset to zero.
When using the
Arthritis Pads, my
thigh muscles are
aching before the end
of the treatment.
Your muscles may not yet be
strong enough to carry out a full
20 minute session.
Turn the device o and end the ses-
sion before the end of the 20 min-
utes. On your next session start on
a lower setting (where you can feel
the mild electrical stimulation and
it is comfortable) and reduce the
duration until your muscles have
acclimatised to the stimulation.
When using the
Arthritis Pads, I can’t
feel the stimulation in
my thigh.
Therapy has started and has
reached the rest period.
You will need to wait for up to 20
seconds before the stimulation will
start again.
Technical Specifications
The Remote Control replicates the controls found on the device
Operating Frequencies
38 KHz
Operating Range Distance
0 to 25m at horizontal
0 to 18m at +/- 30 degree angle
from the horizontal.
Name of product REVITIVE Arthritis-Knee
Model 2836AB
Frequency EMS: 1Hz – 50Hz
TENS: 80Hz - 130Hz
Output current EMS: Max 15mA
TENS: Max 19mA
Weight 1.5kg
Dimensions (with IsoRocker® enabled and disabled) enabled: 355(W)x355(H)x75(D) mm
disabled: 355(W)x355(H)x90(D) mm
Power consumption 5W
AC adaptor
CE Approved
Battery and battery life Li-Ion / 500 recharge cycles
Power source
Input (adaptor used)
Output
100-240V AC ( ), 50/60Hz, 0.18A
5V ( ) DC ,1.0A
Troubleshooting EN
EN
4397_IFU02_16220241.indd 38-39 25/01/2019 14:51
