Baudcom BD-3224V User manual

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Model: BD-3224V
HEVC AVC H.265 H265 Encoder
User Manual

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
DIRECTORY
Chapter 1 Product Introduction ..............................................................................................................1
1.1 Outline .................................................................................................................................................1
1.2 Main Features ....................................................................................................................................1
1.3 Specifications .....................................................................................................................................1
1.4 Principle Chart (Per Module) ...........................................................................................................2
1.5 Appearance and Illustration .............................................................................................................2
Chapter 2 Installation Guide ...................................................................................................................4
2.1 Acquisition Check ..............................................................................................................................4
2.2 Installation Preparation .....................................................................................................................4
2.3 Wire’s Connection .............................................................................................................................6
Chapter 3 WEB NMS Operation ............................................................................................................7
3.1 login .....................................................................................................................................................7
3.2 Operation ............................................................................................................................................7
Chapter 4 Troubleshooting ...................................................................................................................14
Chapter 5 Packing list ...........................................................................................................................15

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Chapter 1 Product Introduction
1.1 Outline
Baudcom BD-3224V HEVC/H.265 HD Encoder is a professional HD audio & video
encoding and multiplexing device. It has 4/8/12 HDMI video input interfaces, and
supports HEVC/H.265 & MPEG 4 AVC/H.264 AVC video encoding and MPEG 1
Layer 2, LC-AAC, HE-AAC, HE-AAC V2 audio encoding. This device can
simultaneously encode 4/8/12 channels HD audio & video; moreover, it supports IP
out (1 MPTS and max 4 SPTS per module) from Data port.
1.2 Main Features
 Support 4/8/12 HDMI(1.4) (HDCP1.4) inputs, maximum support 3 modules
 Support HEVC/ H.265 & MPEG 4 AVC/H.264 AVC video encoding
 Support MPEG-1 Layer 2, LC-AAC, HE-AAC and HE-AAC V2 Audio encoding and AC3
Passthrough
 Support 1 MPTS and maximum 4 SPTS (per module) output over UDP/RTP/RTSP
 Up to 2160P 30Hz
 Ultra low bit rate: save 75% bandwidth
 Enhance picture quality: Advanced compressing algorithm
 Advanced Pretreatment: De-interlacing, Noise Reduction, Sharpening
 STB available with Ensurity CAS
 Decoding chipset: Montage CS8051/8021, NationalChip GX3201H
 Control and easy updates via web management
1.3 Specifications
Input 4/8/12×HDMI input (1.4), HDCP 1.4
Video
Encoding
Encoding Format HEVC/ H.265 , MPEG 4 AVC/H.264
Resolution
3840×2160_30P, 3840×2160_29.97P
(Encoding 2 CHs per module for H.265, and encoding 1
CH for H.264 )
1920×1080_60P,1920×1080_59.94P,1920×1080_50P,

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
(Encoding 4 CHs per module for H.265, and encoding 2
CHs for H.264)
1280×720_60P, 1280×720_59.94P, 1280×720_50P
(Encoding 4 CHs per module for H.264 and H.265)
Chroma 4:2:0
Bitrate 0.5Mbps~20Mbps (each channel)
Rate Control CBR/VBR
GOP Structure IBBP, IPPP
Advanced Pretreatment De-interlacing, Noise Reduction, Sharpening
Audio
Encoding
Encoding Format MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3
Passthrough
Sampling rate 48KHz
Bit-rate (each channel)
48Kbps~384Kbps (MPEG-1 Layer 2 & LC-AAC)
24 Kbps~128 Kbps (HE-AAC)
18 Kbps~56 Kbps (HE-AAC V2)
Audio Gain 0~255
Stream output
1 MPTS and maximum 4 SPTS output over UDP/RTP/RTSP per module,
1000M/100M Base-T Ethernet interface (unicast/ multicast)
IP null packet filter
System
Web based management
Chinese-English control interface
Ethernet software upgrade
Miscellaneous
Dimension (W× L× H) 482mm×328mm×44mm
Approx weight 5kg
Temperature 0~45℃(work), -20~80℃（Storage）
Power AC 100V-220V±10%, 50/60Hz
1.4 Principle Chart of Per Module (the number of encoding
channels depend on encoding format and resolution)

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
1.5 Appearance and Illustration
Front Panel Illustration:
Rear Panel Illustration:
1
NMS (Network Management Port)
Data Port (for IP output)
2 Indicators: Run and Power
3 Grounding Pole/ Power Switch and socket
4 4 HDMI input ports

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Chapter 2 Installation Guide
2.1 Acquisition Check
When users open the package of the device, it is necessary to check items according to packing
list. Normally it should include the following items:
 BD-3224V HEVC/H.265 HD Encoder
 Power Cord
 HDMI cable
 Network cable
If any item is missing or mismatching with the list above, please contact local dealer.
2.2 Installation Preparation
When users install device, please follow the below steps. The details of installation will be
described at the rest part of this chapter. Users can also refer rear panel chart during the
installation.
The main content of this chapter including:
 Checking the possible device missing or damage during the transportation
 Preparing relevant environment for installation
 Installing Encoder
 Connecting signal cables
 Connecting communication port (if it is necessary)
2.2.1 Device’s Installation Flow Chart is Illustrated as following：
Connecting
Grouding
Wire and
Power
Cord
Acquisition
Check
Fixing
Device
Setting
Parameter
Running
Device
Connecting
Signal Wire
2.2.2 Environment Requirement
Item Requirement

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Machine Hall Space
When user installs machine frame array in one machine hall, the
distance between 2 rows of machine frames should be 1.2~1.5m
and the distance against wall should be no less than 0.8m.
Machine Hall Floor
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material:
1X107~1X1010，Grounding current limiting resistance: 1M
(Floor bearing should be greater than 450Kg/㎡)
Environment
Temperature
5~40℃(sustainable )，0~45℃(short time)，
installing air-conditioning is recommended
Relative Temperature 20%~80% sustainable 10%~90% short time
Pressure 86~105KPa
Door & Window Installing rubber strip for sealing door-gaps and dual level
glasses for window
Wall It can be covered with wallpaper, or brightness less paint.
Fire Protection Fire alarm system and extinguisher
Power
Requiring device power, air-conditioning power and lighting
power are independent to each other. Device power requires AC
power 220V 50Hz. Please carefully check before running.
2.2.3 Grounding Requirement
 All function modules’ good grounding designs are the basis of reliability and stability of
devices. Also, they are the most important guarantee of lightning arresting and interference
rejection. Therefore, the system must follow this rule.
 Coaxial cable’s outer conductor and isolation layer should keep proper electric conducting
with the metal housing of device.
 Grounding conductor must adopt copper conductor in order to reduce high frequency
impedance, and the grounding wire must be as thick and short as possible.
 Users should make sure the 2 ends of grounding wire well electric conducted and be antirust.
 It is prohibited to use any other device as part of grounding electric circuit
 The area of the conduction between grounding wire and device’s frame should be no less
than 25mm2.
2.2.4 Frame Grounding

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
All the machine frames should be connected with protective copper strip. The grounding wire
should be as short as possible and avoid circling. The area of the conduction between grounding
wire and grounding strip should be no less than 25mm2.
2.2.5 Device Grounding
Connecting the device’s grounding rod to frame’s grounding pole with copper wire.
2.3 Wire’s Connection
The grounding wire conductive screw is located at the right end of rear panel, and the power
switch, fuse, power supply socket is just beside ,whose order goes like this, power switch is on
the left ,power supply socket is on the right and the fuse is just between them.
 Connecting Power Cord
User can insert one end into power supply socket, while insert the other end to AC power.
 Connecting Grounding Wire
When the device solely connects to protective ground, it should adopt independent way, say,
share the same ground with other devices. When the device adopts united way, the
grounding resistance should be smaller than 1Ω.
Caution:
Before connecting power cord to BD-3224V HEVC/H.265 HD Encoder, user should
set the power switch to “OFF”.

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Chapter 3 WEB NMS Operation
BD-3224V does not support front buttons and LCD, users can only control and set the
configuration in computer by connecting the device to web NMS Port. User should ensure that
the computer’s IP address is different from the BD-3224V’s IP address; otherwise, it would
cause IP conflict.
3.1 login
The default IP address of this device is 192.168.0.136.
Connect the PC (Personal Computer) and the device with net cable, and use ping command to
confirm they are on the same network segment.
I.G. the PC IP address is 192.168.99.252, we then change the device IP to 192.168.99.xxx (xxx
can be 0 to 255 except 252 to avoid IP conflict).
Use web browser to connect the device with PC by inputting the Encoder’s IP address in the
browser’s address bar and press Enter.
It displays the Login interface as Figure-1. Input the Username and Password (Both the default
Username and Password are “admin”.) and then click “LOGIN” to start the device setting.
Figure-1
3.2 Operation
When we confirm the login, it displays the WELCOME interface as Figure-2.

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Figure-2
Parameters →Encoder:
From the menu on left side of the webpage, clicking “Encoder”, it displays the programs
information of each encoding channel and interface where users can set video and audio
parameters as Figure-3.
Note:
Encoding with H.265 and 4K resolution, only “Enc CH3 and CH4” can be connected, if users
want to encode 1 channel, “Enc CH4” must be connected.
Encoding with H.264 and 4K resolution, only “Enc CH4” can be connected.
Encoding with H.264 and 1080 resolution, only “Enc CH3 and CH4” can be connected, if users
want to encode 1 channel, “Enc CH4” must be connected.
The number of encoding channels depends on encoding format and resolution, please view
datasheet.
HDMI:
User can click any
item here to enter the
corresponding
interface to check
information or set the
parameters
.
System information

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Figure-3
Click this button to apply the modified parameters.
Different audio format, audio bit rate will be different:
MPEG-1 Layer 2 & LC-AAC: 48Kbps~384Kbps
HE-AAC: 24 Kbps~128 Kbps
HE-AAC V2: 18 Kbps~56 Kbps
Parameter → IP Stream:
BD-3224V supports TS to output in IP (maximum 4 SPTS and 1 MPTS per module) format
through the DATA port on the front channel.
Encoding channel selection area:
The interface and setting principle
of each channel are the same.
If users set the
“Video” and “Audio”
parameters in “Enc
CH 1”, “Enc CH 2-4”
will be the same.
Users can check
input program
information
Users can check the
encoding bit rate
oscillograph trace
Check the encoding
status

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
“SPTS 1-4” is corresponding to “Enc CH 1-4” separately, and the number of SPTS depends on
encoding format and resolution.
Clicking “IP Stream”, it displays the interface where to set IP out parameters (Figure-4).
Figure-4
When users click “quickly config” button, it triggers a dialog box (Figure-5) where users can set
all channels configuration.
Figure-5
When users click “Channel config” button, it triggers a dialog box (Figure-6) where users can set
the corresponding channel configuration.
Figure-6
Parameter →Network:
Clicking “Network”, it displays the interface as Figure-7 where to set NMS parameters.
Quickly Config
Channel Config
Set output IP address
Click to active the status

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Figure-7
System → Account:
Clicking “Account”, it displays the screen as Figure-8 where to set new login account and
password for the web NMS. Both the current username and password are “admin”.
Figure-8
System → Configuration:
Clicking “Configuration”, it displays the screen as Figure-9 where to set save/ restore/ factory
set/ backup/ load configurations.
Set NMS address to login to
the web management
interface. The default IP
address is 192.168.0.136
Set data port IP address

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Figure-9
System → Firmware:
Clicking “Firmware”, it displays the screen as Figure-10 where to upgrade firmware for the
encoder.
Figure-10
System → Logo:
Clicking “Log”, it displays the log interface as Figure-11 where to check or export the
Kernel/System log.

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Figure-12

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Chapter 4 Troubleshooting
BAUDCOM’s ISO9001 quality assurance system has been approved by CQC organization. For
guarantee the products’ quality, reliability and stability. All BAUDCOM products have been
passed the testing and inspection before ship out factory. The testing and inspection scheme
already covers all the Optical, Electronic and Mechanical criteria which have been published by
BAUDCOM. To prevent potential hazard, please strictly follow the operation conditions.
Prevention Measure
 Installing the device at the place in which environment temperature between 0 to 45 °C
 Making sure good ventilation for the heat-sink on the rear panel and other heat-sink bores if
necessary
 Checking the input AC within the power supply working range and the connection is correct
before switching on device
 Checking the RF output level varies within tolerant range if it is necessary
 Checking all signal cables have been properly connected
 Frequently switching on/off device is prohibited; the interval between every switching on/off
must greater than 10 seconds.
Conditions need to unplug power cord
 Power cord or socket damaged.
 Any liquid flowed into device.
 Any stuff causes circuit short
 Device in damp environment
 Device was suffered from physical damage
 Longtime idle.
 After switching on and restoring to factory setting, device still cannot work properly.
 Maintenance needed

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Http://www.baudcom.com.cn Tel:[phone] Email: [e-mail]
Chapter 5 Packing list
 BD-3224V HEVC/H.265 HD Encoder
 Power cord
 HDMI cable
 Network cable
