Bauknecht TRK 67200 User manual

5019 407 00134
Very
Wet
Load
Wet
Load Load
Fabric Drying
Cycles
& Drying levels
Drying options
Gentle
Reduces drying
intensity
(recommended for
delicate items)
Dryness
Adjustment
(Adjusts Dryness
Level according to
wishes)
Buzzer
Signals/Sounds
end of drying
cycle at Intervals
Indicative
drying times
(in minutes)
Kg
95’
135’ 80’ 110’ 3.0
5.0 Cotton
max 5 kg
Cupboard dry plus
80’
110’ 60’ 90’ 3.0
5.0 Cupboard dry *
60’
90’ 50’ 70’ 3.0
5.0 Iron dry *
25’
45’ 20’ 35’ 1.0 2.5 Synthetics
max 2.5 kg
Cupboard dry * -
20’
35’ 15’ 25’ 1.0 2.5 Iron dry -
30’ 20’ 1.5
Delicate
max 1.5 kg
Especially for delicate items
(e.g. shirts). --
--- Airing Laundry is aired and refreshed for 30
minutes without heating. --
--- Time
Completes drying or dries single
items (suitable for all fabrics). --
QUICK REFERENCE GUIDE
Please also carefully read the
“Instructions for Use”.
TRK 67200
GB
Cotton
Synthetics
Delicate
AiringTime
* Test programmes according IEC 61121.
Start
Pause Starts the drying cycle. The Start/
Pause indicator lamp is blinking
during the selection phase.
Press to confirm the final
selection.
Programme
selection
Turn the programme selector
knob to the desired programme.
The indicator next to the
programme name lights up. The
start indicator blinks to show,
that the dryer is in selection
mode. After the Start / Pause
button is pressed the start
indicator lamp lights up and the
programme starts.
Dryness
Adjustment
Dryness adjustment is an option
to adjust the dryness of the
laundry according to your wishes.
Select the desired programme
and the option dryness level
adjustment by pressing the
button “+“ for more dry or the
button “–“ for more humid. The
selected dryness will be stored as
a pre-setting to the selected
drying programme. Using the
drying programme next time the
pre-setting appears. By pressing
the dryness adjustment buttons
‘+’ or ‘–‘ the pre-setting can be
changed.
Filter The indicator lamp lights upwhen
the filter needs cleaning. Clean
the filter at the end of every
cycle.
PROGRAMME SEQUENCE INDICATION
End The programme sequence is
indicated by lamps, switching
on when programme step
starts and and switching off
when the programme step is
passed.

5019 407 00134
1. Checkthatallfasteningsareclosedand
that pockets are empty.
2. Turn the articles inside out.
3. Place laundry loosely in the drum to
make sure it doesn’t become tangled.
Sort laundry as follows:
A) By care symbols
(on the collar or inside seam):
Suitable for tumble drying
Tumble drying with reduced
drying intensity only. Press
gentle button
Do not tumble dry
B) By amount and thickness/weight
Whenever the load to be dried exceeds
dryer capacity, separate laundry
according to weight (e.g. towels from
thin underwear).
C) By type of fabrics
Cotton/linen: towels, cotton jersey,
bed and table linen made of cotton or
linen.
Synthetics/Easy Care: blouses, shirts,
overalls, etc. made of polyester or
polyamide, as well as cotton/synthetic
mixes.
D) By drying level
• Sort into: iron dry, cupboard dry, etc.
Do not tumble dry: woollens, silk, nylon
stockings, delicate embroidery, fabrics
withmetallicdecorations,bulkyitemssuch
as sleeping bags, etc.
Important: only use specific indicated
dryer-safe additives and rinse items
that have been treated with stain remover
thoroughly in plenty of water before
drying. Only use specific indicated
dryer-safe plastic items and never dry
rubber or articles contaminated with
vegetable oil in the dryer.
Programme and Options:
• To select a programme, turn the
programmeselectorknob.TheStart/Pause
indicator lamp is blinking, indicating that
the cycle needs to be started.
• To select an option, press the
corresponding button. The indicator
lamp above the button confirms that a
selection has been made.
•Press the button again to cancel the
option.
1. Having selected the desired
programme and options, press the
Start button.
If the laundry is not removed at the
end of the drying cycle, an automatic
anti-crease cycle will operate for
maximum 60 min. The drum rotates at
regular intervals, preventing the
laundry from creasing.
Anti-Crease protection re-
distributes laundry in the drum.
2. On completion of the programme, set
the programme selector knob to
position “0”.
When changing the programme during
the drying cycle, the dryer stops. The Start/
Pause indicator lamp is blinking.
To operate the new programme, press the
Start/Pause button again.
To interrupt the dryer during
operation
1. Set the programme selector knob to
Airing.
2. Press the Start button.
Wait at least 5 minutes before opening
the door to allow the dryer to cool
down.
For your safety the programme stops
automatically if you open the door.
3. To restart, after door opening, close
the door and press the Start/Pause
button again.
Clean the lint filter at the end of every
drying cycle:
1. Open the door.
2. Pull the filter upwards.
3. Remove lint using a soft brush or your
fingertips.
4. Push the filter back into place.
If a fault occurs, before contacting our
After-Sales Service, make the following
checks to try and remedy the problem:
Drying takes too long / laundry is not
dry enough:
• Was the correct programme selected?
• Was the inserted laundry too wet
(Washing machine spin speed less than
800 rpm)?
• Is the lint filter dirty (filter indicator
lamp on)?
The dryer does not operate:
(after a power failure and/or
interruption to the mains supply,
always press the Start button).
• Is the plug properly inserted into the
mains electricity socket?
• Is there a power failure?
• Has the fuse blown?
• Is the door well closed?
• Has the programme been selected?
• Has the Start/Pause button been
pressed?
Lint filter indicator lamp on:
• Is the lint filter clean?
• Is the vent hose blocked?
All programme sequence indicators
blinking:
•Service call necessary.
If, after carrying out the above checks the
malfunctionpersistsorappearsagain,turn
the dryer off and call our After-Sales
Service (refer to guarantee).
Please specify:
• The nature of the fault.
• The dryer type and model.
• The service code (the number after the
word Service on the adhesive rating
plate) on the right-hand side when the
door is open.
•Your full address and phone number.
PREPARING THE LAUNDRY SELECTING A PROGRAMME & OPTIONS
STARTING & COMPLETING A
PROGRAMME
CHANGING A PROGRAMME
INTERRUPTING A PROGRAMME
DAILY MAINTENANCE & CLEANING
TROUBLESHOOTING GUIDE
AFTER-SALES SERVICE
