Bauknecht TRKK 6710 User manual

5019 407 00107
Very
Wet
Load
Wet
Load Load
Kg Fabric
programmes
& Drying
levels
Drying options
Gentle
Reduces drying intensity
(recommended for
delicate items)
Dryness Adjustment
(Adjusts Dryness Level
according to wishes)
Indicative drying
times (in minutes)
95’
135’ 80’ 110’ 3.0 5.0 Cotton
max 5 kg
Cupboard extra dry
80’
110’ 60’ 90’ 3.0 5.0 Cupboard dry *
60’
90’ 50’ 70’ 3.0 5.0 Iron dry *
25’
45’ 20’ 35’ 1.0 2.5 Synthetics
max 2.5 kg
Cupboard dry * -
20’
35’ 15’ 25’ 1.0 2.5 Iron dry -
30’ 20’ 1.5 Delicate
max 1.5 kg
Especially for delicate items (e.g.
shirts). --
--- Airing Laundry is aired and refreshed for
30 minutes without heating. --
--- Completes drying or dries single
items (suitable for all fabrics). --
+1
Standard
-1
TRKK 6710GB
QUICK REFERENCE GUIDE
Please also carefully read the
“Instructions for Use”.
Cotton
Synthetics
Delicate
Airing
Time
* Test programmes according IEC 61121
Start / Pauze
Départ / Pause Starts the drying cycle. The Start/
Pause indicator lamp is blinking
during the selection phase.
Press to confirm the final selection.
Programme
selection Turn the programme selector knob to
the desired programme. The indicator
next to the programme name lights up.
The start indicator blinks to show, that
the dryer is in selection mode. After
the Start / Pause button is pressed the
start indicator lamp lights up and the
programme starts.
Dryness
Adjustment
Dryness adjustment is an option to adjust
the dryness of the laundry according to
your wishes. Select the desired
programme and the option dryness level
adjustment by pressing the button “+“
for more dry or the button “–“ for more
humid. The selected dryness will be
stored as a pre-setting to the selected
drying programme. Using the drying
programme next time the pre-setting
appears. By pressing the dryness
adjustment buttons “+” or “–” the pre-
setting can be changed.
Filter The indicator lamp lights up when the
filter needs cleaning. Clean the filter
at the end of every cycle.
Water
Container
Lights up when water container needs
to be emptied. The drying cycle is
automatically interrupted. Empty the
water container. PresstheStart/Pause
button to restart the dryer and to
continue the programme.
PROGRAMME SEQUENCE INDICATION
End
Anti-Crease
The programme sequence is
indicated by lamps, switching on
when programme step starts and
switching off when the
programme step is passed.

5019 407 00107
1. Checkthatallfasteningsareclosedand
that pockets are empty.
2. Turn the articles inside out.
3. Place laundry loosely in the drum to
make sure it doesn’t become tangled.
Sort laundry as follows:
A) By care symbols (on the collar or
inside seam):
Suitable for tumble drying
Tumble drying with reduced
drying intensity only. Press
gentle button
Do not tumble dry
B) By amount and thickness/weight
Whenever the load to be dried exceeds
dryer capacity, separate laundry
according to weight (e.g. towels from
thin underwear).
C) By type of fabrics
Cotton/linen: towels, cotton jersey,
bed and table linen made of cotton or
linen.
Synthetics/Easy Care: blouses, shirts,
overalls, etc. made of polyester or
polyamide, as well as cotton/synthetic
mixes.
D) By drying level
• Sort into: iron dry, cupboard dry, etc.
Do not tumble dry: woollens, silk, nylon
stockings, delicate embroidery, fabrics
withmetallicdecorations,bulkyitemssuch
as sleeping bags, etc.
Important: only use specific indicated
dryer-safe additives and rinse items
that have been treated with stain remover
thoroughly in plenty of water before
drying. Only use specific indicated
dryer-safe plastic items and never dry
rubber or articles contaminated with
vegetable oil in the dryer.
Programme and Options:
• To select a programme, turn the
programme selector knob to the
required position. The Start/Pause
indicator lamp is blinking, indicating
that the cycle needs to be started.
• To select an option, press the
correspondingbutton. Theindicator light
above the button lights up confirming
that the selection has been made.
• Presstheoptionbuttonagain to cancel
the option.
1. Having selected the desired
programme and options, press the
Start/Pause button.
If the laundry is not removed at the
end of the drying cycle, an automatic
anti-crease cycle will operate for
maximum 60 min. The drum rotates at
regular intervals, preventing the
laundry from creasing.
Anti-Crease protection re-distributes
laundry in the drum.
When the Anti-Crease option is selected
and laundry has not been taken out, an
anti-crease cycle is activated for 12 hrs.
2. On completion of the programme, set
the programme selector knob to
position “0”.
When changing the programme during
the drying cycle, the dryer stops. The Start/
Pause indicator lamp is blinking.
To operate the new programme, press the
Start/Pause button.
To interrupt the dryer during operation
1. Set the programme selector knob to
Airing.
2. Press the Start/Pause button.
Wait at least 5 minutes before opening
the door to allow the dryer to cool down.
For your safety the programme stops
automatically if you open the door.
3. To restart, after door opening, close
the door and press the Start/Pause
button again.
Clean the lint filter at the end of every
drying cycle:
1. Open the door.
2. Pull the filter upwards.
3. Open the filter.
4. Remove lint using a soft brush or your
fingertips.
5. Close the filter.
6. Push the filter back into place.
Empty the water container at the end
of every drying cycle.
1. Pull the handle to remove the water
container.
2. Empty the water container.
3. Replace the water container when
empty by pushing it completely back
in place.
If a fault occurs, before contacting our
After-Sales Service, make the
following checks to try and remedy
the problem:
Drying takes too long / laundry is not
dry enough:
• Was the correct programme selected?
• Was the inserted laundry too wet
(Washing machine spin speed less than
800 rpm? When the spinning speed is
less than 800 rpm the water container
fault may occur during the dryingcycle)?
• Is the lint filter dirty (filter indicator
lamp on)?
• Istheheat exchanger dirty (refertothe
Instructions for use)?
• Is the ambient temperature too high?
The dryer does not operate:
(after a power failure and/or
interruption to the mains supply,
always press the Start/Pause button).
• Is the plug properly inserted into the
mains electricity socket?
• Is there a power failure?
• Has the fuse blown?
• Is the door properly closed?
• Has the programme been selected?
• Has the Start/Pause button been
pressed?
Lint filter or water container indicator
lamp on:
• Is the lint filter clean?
• Is the water container empty?
• Is the water container correctly
positioned?
• Is the heat exchanger clean?
Water droplets underneath the dryer:
• Is the heat exchanger correctly
positioned?
• Has any fluff on the heat exchanger
seal been wiped away?
• Has any fluff on the door seal been
wiped away?
• Has the water container been
positioned correctly?
All programme sequence indicators
blinking:
• Service call necessary.
Replacing the drum light bulb (if
supplied):
• Iftheinsidelampdoes notwork,thebulb
may be faulty.
• Unplug the dryer.
• Open the door and unscrew the glass
cover insie the drum.
• Replace the faulty bulb with a new one
and screw the glass cover back on.
• Replacement bulb: Philips 15W,
230/240V, E14.
If, after carrying out the above checks the
malfunctionpersistsorappearsagain,turn
the dryer off and ca
