Baumatic HUZ107.1 User manual

USER MANUAL FOR YOUR
HUZ107.1 107 litre
Built-under freezer
NOTE : This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance
DD 26/08/14

2
C ntents
Envir nmental n te 3
Imp rtant safety inf rmati n 4–5
Specificati ns f y ur freezer 6-7
Dimensions 6
Description of the appliance 7
Using y ur freezer 7-9
Before switchin on 7
Durin first use 8
Turnin on the appliance and settin the thermostat 8-9
Arranging and st ring f d in the fridge secti n 9-10
Makin ice-cubes 10
Cleaning and maintenance 11-12
Defrostin the freezer 11-12
Installati n 13-23
Electrical connection 13
Positionin 14
Aperture and appliance dimensions 15
Supplied installation components 15-16
Installin your freezer 16-21
Ventilation requirements 21
Reversin the door of your appliance 22
Tr ublesh ting 23-24
Technical data 25
C ntact details 28

3
Envir nmental n te
Note : Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.

4
Imp rtant safety inf rmati n
Your safety is of the utmost importance to us. Please
make sure that you read this instruction booklet
before attemptin to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Customer Care
Department.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person
Use f the appliance
oYour appliance is only desi ned to be used in the
home. It is suitable for storin food that needs to
be kept frozen. If it is used for any other purpose
or it is not used correctly, then the manufacturer
will accept no liability for any dama e that may be
caused.
oAlterin the specification of the appliance must not be attempted
for reasons of safety.
Bef re using y ur appliance
oCheck the appliance for any si ns of transport dama e. If you
notice any dama e, then you should not connect your appliance
to your mains supply and should contact your retailer.
Refrigerant
oYour appliance contains R600a refri erant, which is a natural as
that does not contain CFCs that can dama e the environment.
However it is a flammable substance, therefore care should be
taken:
Durin the transportation and installation of the
appliance, make sure that the refri eration pipe work
does not et dama ed.
If it does become dama ed then sources of i nition
and open flames should be avoided. Also the room
that the appliance is situated in should be thorou hly
ventilated.
oDo not place any objects on top of the appliance,
as this may dama e the table top.

5
Child safety
oPacka in material should be kept away from
children.
oChildren should not be allowed to touch the
controls or play with the appliance.
General safety
oDo not pull on the power supply cable to remove the plu from
your mains supply socket.
oDo not pull out or insert the plu with wet hands.
oDo not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
oBefore cleanin the appliance or performin
maintenance work, ensure that the appliance has been
disconnected from your mains supply.
oNever allow the back coils of the appliance to come into contact
with the wall surface.
oAlways ensure that the location where you are installin your
appliance is free of stored items such as papers and other
flammable materials.
oNever block the ventilation openin s of the appliance, either on
the inside or its exterior.
oIt is vital to keep your appliance well ventilated,
so that there is proper air flow between the
bottom of the unit and the plinth/kick plate
which it is sittin on.
oDo not place electrical devices inside of the appliance, such as
mixers and electric ice cream makers.
Service
You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Customer Care Department.

6
Specificati ns f y ur freezer
oTotal ross capacity: 107 litres
oTotal net capacity: 95 litres
oManual defrost
oFreezin capacity: 9 k / 24 hours
oAdjustable thermostat
o3 Freezer drawers
oReversible door
oDoor-on-door fittin s
Dimensi ns f appliance
Height: 818 - 889 mm
Width: 595 mm
Depth: 548 mm
Dimensi ns f aperture*
Height: 820 - 890 mm
Width: 600 mm
Depth: 550 mm MIN
Energy efficiency class
Ener y class: A+
* Please refer to the installation instructions for more specific
information on the size of aperture that you will require.
IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.
In order to find out the climatic ratin of your appliance, you should
check the ratin plate. The ratin plate is located on the front left ed e
of the inside of the freezer section. You will need to open the door of
your appliance to be able to find it. The ratin plate will indicate the
ambient temperature ran e that your appliance will function correctly
within.

7
Descripti n f the appliance
1) Thermostat dial
2) Freezer drawers
Using y ur freezer
Bef re switching n
oMake sure that it has been installed by a suitably qualified
person, as per the information contained in the installation
instructions.
oAfter delivery, wait for ei ht hours before connectin the
appliance to your mains supply. This will allow any refri erant
asses that may have been disturbed durin the transportation
process to settle.
oThe outside of the appliance and the removable accessories
contained within it, should be cleaned with a solution of liquid
deter ent and water.
oThe interior of the appliance should be cleaned with
a solution of sodium bicarbonate dissolved in
lukewarm water. The interior and accessories
should be thorou hly dried, after the cleanin
process has been completed.
oThere can be an odour when you first switch on the appliance. It
will lessen as the appliance starts to cool.

8
During first use
oWhen you first switch on the appliance, the compressor will run
continuously for approximately 24 hours or until the freezer
reaches a cool enou h temperature.
oDurin this period of time, you should try not to open the door
frequently or place a lar e amount of food within the appliance.
oIf the unit is switched off or unplu ed, you must allow at least 5
minutes before restartin the appliance on the thermostat or
connectin it to your mains supply.
Turning n the appliance and setting the therm stat
You switch on your appliance by connectin it to your mains supply
and settin the thermostat. The thermostat dial is located at the base
of the freezer.
oThe thermostat automatically re ulates the temperature inside
the freezer, dependin on what number you have turned the
thermostat control knob to.
oPosition <0> means that the appliance will not cool.
oPosition <1> will ive you a hi her temperature inside the
freezer.
oPosition <5> will ive you a lower temperature inside the
freezer.
oIdeally the thermostat should be set to a position between <3>
and <4>.
oIMPORTANT: The ambient temperature of the room,
the temperature of food and the amount of food that
has been placed in the appliance and how often the door
is opened, will all affect the temperature being
maintained by the appliance.

9
oOn the maximum settin s (position <5>), your frid e will work
harder to maintain a lower temperature and will increase the
ener y usa e. There is no need to run your appliance on this
settin for prolon ed periods and you should return the
thermostat knob to between <3> to <4>.
Arranging and st ring f d in the freezer
oThe freezer should be used for freezin fresh foods and for
storin frozen foods for the period of time indicated on the
packa in and for makin ice cubes.
oFor freezin fresh food, wrap and seal fresh food properly. The
packa in should be air ti ht and should not leak. Special
freezer ba s, aluminium foil (heavy rade or double wrap),
polythene ba s and plastic containers are ideal.
oThe maximum amount of fresh food that can be frozen in 24
hours is 9 k .
oFor optimum appliance performance and to reach maximum
freezin capacity, turn the thermostat dial to the <5> position
when placin fresh food in the freezer.
oAfter placin fresh food in the freezer, 24 hours on settin <5>
is enerally sufficient. After 24 hours you should turn the
thermostat back to its normal position.
oIMPORTANT: In order to save energy, when freezing small
amounts of food, setting <5> is not necessary
oDo not allow the fresh food to be frozen to come into contact
with the already frozen food.
oAlways mark the date and content on the pack and do not
exceed the stated stora e time.
oIn case of power failure or malfunction, the freezer compartment
will maintain a sufficiently low temperature for food stora e for
approximately 18 hours. However, avoid openin the freezer
door to slow down the temperature rise within the freezer
compartment.
oNever place warm food into the freezer compartment.
oWhen purchasin and storin frozen food products, ensure that
the packa in is not dama ed.

10
oThe stora e time and the recommended temperature for storin
frozen foods are indicated on the packa in . For storin and
usin , follow the manufacturer’s instructions. If no information is
provided the food should not be stored for lon er than 3 months.
oPlace the frozen food in the freezer compartment as soon as
possible after buyin it.
oOnce the food is thawed, it must not be refrozen. You must
cook it as quickly as possible in order to consume or to freeze it
once a ain.
oIf you want to use the maximum capacity, you can remove the
drawers and store the items directly on the coolin tubes. This
will enable you to make use of the entire volume of the
compartment but you must ensure you do not overload the
freezer as this will affect the performance.
oDo not open the freezer door too often or leave the door open
for lon periods of time, as this will increase the temperature
inside of the appliance and will increase the ener y usa e.
oWarm food should be allowed to cool down before you attempt
to freeze it. If you place warm food in the freezer section, then
the increased humidity will cause quicker ice formation and
increase the amount of power that the appliance uses.
Making ice-cubes
oWhen makin ice-cubes, fill the ice tray 2/3 with water and place
it in the freezer compartment.
oAfter the water has completely turned to ice, you can twist the
tray as shown in the dia ram above in order to release the ice-
cubes.

11
Cleaning and maintenance
WARNING: PLEASE ENSURE THAT YOUR
APPLIANCE IS DISCONNECTED FROM
YOUR MAINS SUPPLY BEFORE
ATTEMPTING TO CLEAN IT
oDo not clean the appliance by pourin water onto it or
sprayin water over it.
oThe freezer should be cleaned periodically, usin a
solution of bicarbonate of soda and lukewarm water.
oClean the accessories separately with soap and water.
Do not clean them in a dishwasher.
oDo not use abrasive products, deter ents or soaps.
oAfter washin the appliance, wipe over the area that you have
cleaned with a damp cloth and then dry it thorou hly.
oWhen cleanin is complete, dry your hands and then reconnect
the plu to your mains supply.
Defr sting the freezer
IMPORTANT: Never use sharp metal tools to remove the frost
as this can damage the refrigeration circuit
oAfter a period of time, frost will build up in certain areas in the
freezer compartment. The frost should be removed periodically.
You can use a plastic ice-scraper for this procedure.
oA complete defrost will become necessary if the frost layer
exceeds 3-5 mm to maintain the efficiency of the freezer.
oThe day before you defrost, set the thermostat dial to position
<5> to freeze the foods completely.

12
oDurin defrostin , frozen foods should be wrapped in several
layers of paper and kept in a cool place. The inevitable rise in
temperature will shorten their stora e life. Remember to use
these foods within a relatively short period of time.
oSet the thermostat dial to position <0> and switch off the
appliance.
IMPORTANT: You must unplug the appliance from the mains
supply before continuing
oLeave the door open to accelerate the defrostin process.
Remove the defrost water from the compartment. If there is
defrost water on the freezer floor you can clear it up usin a
spon e.
oClean the interior by hand usin lukewarm water and a little
deter ent. NEVER use abrasive products or aggressive
cleaning agents
oDry the inside of the appliance and plu in the mains. Set the
thermostat dial to position <5> for 24 hours before resettin the
thermostat dial to the normal position.
oIMPORTANT: Do not reintroduce the food into the freezer
until it has sufficiently cooled

13
Installati n
IMPORTANT: Before installation and usage,
read all the instructions and make sure that the
voltage (V) and the frequency (Hz) indicated on
the rating plate are exactly the same as the
voltage and frequency in your home The rating
plate can be found on the front left edge of the
inside of the freezer
The manufacturer declines all responsibility in the event of the installer
failin to observe all the accident prevention re ulations in force,
which are necessary for normal use and the re ular operation of the
electric system.
Electrical c nnecti n
YOUR FREEZER IS INTENDED FOR FITTED AND
PERMANENT INSTALLATION
We recommend that the appliance is connected by a
qualified electrician, who is a member of the N.I.C.E.I.C.
and who will comply with the I.E.E. and local re ulations.
oYour freezer comes supplied with a 13 amp plu fitted. If in
future you need to chan e the fuse in this plu , then a 13 amp
ASTA approved (BS 1362) fuse must be used.
oThe wirin in the mains lead is coloured as follows:
Brown Live
Blue Neutral
Green and yellow Earth
oAs the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markin s identifyin the terminals
in your spur box, please proceed as follows:
The brown wire must be connected to the terminal marked “L”
(live), or coloured red.
The blue wire must be connected to the terminal marked “N”
(neutral), or coloured black.
The green and yellow wire must be connected to the terminal
marked “E” (earth), or by the earth symbol, or coloured green
and yellow.
oWhen the connection is completed, no stray strands or cut wire
should be present. The cord clamp must be secured over the
outer sheath.

14
P siti ning
oIt is advisable that your appliance is only installed in a location
where the ambient temperature of the room, corresponds with
the climate classification that is stated on the ratin plate of your
appliance. Your appliance may not function correctly if the
ambient temperature falls outside of the followin ran es.
Climate classification Appropriate ambient temperature
SN +10 to +32 de rees centi rade
oYour appliance should not be located in direct sunli ht or
exposed to continuous heat or extremes of temperature (e. .
next to a radiator or boiler).
oThe door should be able to open completely and freely
oThe appliance should be situated so you can easily access the
food that is stored in it.
oYou should check whether there is an electrical socket available,
which will be accessible after your appliance is installed.

15
Aperture and appliance dimensi ns
oThe dia ram above shows the aperture size that you will need to
be able to install your appliance.
Supplied installati n c mp nents
oThe dia rams below show the contents of the supplied
installation kit and the tools you will require to carry out the
installation process.
oThrou hout the installation instructions, you will see the
dia rams contain number references to show which component
the ima e is referrin to.
1) Wood screw (17 pcs)
2) Door han
3) Door bottom fixin s (2 pcs)
4) Han cover
5) Screw
6) Top bracket

16
T ls required
7) Water au e
8) Wrench
9) Setsquare
10) Screwdriver
Installing y ur freezer
If you need the appliance door to open from the
other side, then please reverse the door before
commencing the installation process (See “Reversin
the door” section).
oRemove the screw (5) at the top of the appliance and place the
top bracket (6) in its place.

17
oFix the bracket with the screw (5).
oTake out the asket (11) located on the side panel and remove
the protective tape.
oStick the asket on the reverse side of the door hin es of the
appliance.
oYou should use a water au e (7) to ensure the appliance is
level.

18
oSlide the appliance into the kitchen unit and ali n the hin e
surface with the front surface of the kitchen unit usin a
setsquare (9).
oScrew the hin es and metal bracket to the kitchen unit usin
screws (1).
oUnscrew and remove the nuts and washers from the appliance
door. Place the door han (2) on the appliance door by insertin
the holes on the adjustment bolts.

19
oDimension B: Measure from the underside surface of the
kitchen unit to the bottom of the door han .
oDimension C: Measure from the underside surface of the
kitchen unit to the top of the next unit door.
oSubtract measurement C from measurement B. Place the door
han (2) usin this dimension for the vertical position and place
it in the centre for the horizontal position.
oScrew the door han (2) into place usin the screws (1).
oPlace the cabinet door onto the appliance door by insertin the
adjustment bolts into the slots on the door han .
oPlace the washers and screw nuts onto the adjustment bolts.

20
oClose the door and check the ali nment with the other cabinet
doors. Make the adjustment of the unit door by screwin or
unscrewin the adjustment bolts usin a screwdriver (10) for
vertical adjustment and by the help of the slots on the door han
for other directions.
oTi hten the nuts usin a wrench (8) to fix the bracket.
oRemove the screws (1) at the bottom of the appliance door.
oPlace the door bottom fixin s (3) into position and screw the
fixin s to the appliance door and the cabinet door.
