Baumatic BHI100 User manual

1
BHI100
Freestanding 1 zone
induction hob

2
User Manual for your Baumatic
BHI100
Freestanding 1 zone induction
hob
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 01/12/11

3
Contents
Environmental note 4
Important safety information 5 – 8
Specifications 9 -11
Productdimensions 9
Productspecifications 9
Electricaldetails 9
Ceramic hob surface layout 10
Controlpanellayout 10-11
Usingtheceramichob 11-17
Beforefirstuse 11
Touchcontrols 11
Induction cooking 12
Cooking on an induction zone 12-13
Powerlevelsettings 13-14
Usingthetimer 14
Turning off the induction zone after cooking 14
Suitablecookware 15-16
Cookingtips 16
Hobguidelines 16-17
Cleaning and maintenance 17-19
Cleaning the ceramic hob top 17-18
Aftereachuse 18
Cleaningtable 18
Using a ceramic hob scraper 18-19
Using a specialist ceramic hob cleaner 19
Installation 19-21
Unpacking the appliance 19
Positioning 19-20
Electricalconnection 20
Replacing the mains supply cable 21
My appliance isn’t working correctly 22-24
Errorcodes 22
General troubleshooting 22-23
Baumatic consumables 25
Contactdetails 26

4
Environmental note
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Customer Care
Department.
General Information
oThis appliance is designed for domestic household use and for
the cooking and frying of domestic foodstuffs.
oIMPORTANT: The adjacent furniture and all materials used in
the installation must be able to withstand a minimum
temperature of 85°C above the ambient temperature of the
room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, will be the liability of
the owner.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYou should not use this appliance to store items on or as a work
surface.
oNo modifications to the appliance are permitted by Baumatic Ltd.
oYou should not store or place flammable or highly flammable
liquids/materials on top of or near the appliance. Items made
from aluminium, plastic or plastic film should also be kept away
from the appliance, as they may fuse to the surface.
oRepairs may only be carried out by Baumatic Service
Engineers or their authorised service agent.

6
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and should not
be allowed to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
oOlder children should only be allowed to utilise the appliance
when supervised.
General Safety
oThe appliance should only be installed and connected by a
suitably qualified person.
oIf you notice any scratches, splits or cracks in the ceramic glass,
you should immediately switch off the appliance and disconnect
it from your mains supply. Otherwise there is the risk of electric
shock occurring.
oDO NOT insert any foreign objects into, or block, the air
ventilation openings.
During use
oAny film or stickers that are present on the hob surface when it
is delivered should be removed before use.
oCare should be taken when utilising the appliance, otherwise
there is a risk of burns being caused.
oThe induction hob can not withstand abnormally heavy weights.
Take care not to overload the hob.
oYou should not allow the electrical connection cables to come
into contact with the hob surface when it is hot or any hot
cookware.
oThe electrical connection cable should not hang over the edge of
the table or counter.
oIf fat and oil overheats, then it can ignite extremely quickly. For
this reason, when cooking with fat and oil the appliance should
not be left unattended.
oMake sure that the appliance is switched off after use.

7
oThe appliance surfaces will become hot during use and retain
heat afterwards. Care should be taken to avoid burns from
touching the hob surface when it is still hot.
oIMPORTANT: This ceramic induction hob fully complies
with current legislation regarding electro-magnetic
interference and is designed not to interfere with other
electronic appliances providing these comply with the
same legislation.
oAs the hob generates magnetic fields in its immediate
vicinity, pacemakers and active heart implants must be
designed to comply with relevant regulations. If in doubt,
you should consult the manufacturer of your device or
your Doctor. In this respect, Baumatic can only guarantee
the conformity of our own product.
oIf an object made of metal, (e.g. saucepan lid, knife, fork
or spoon) is placed on a cooking zone that is switched on,
it can get hot.
oDo not place the induction hob onto a surface made from
iron, stainless steel or aluminium during use as this could
cause the surface to heat up.
Cleaning
oCleaning of the hob should be carried out on a regular basis.
oIMPORTANT: Before attempting to clean the appliance, it
should be disconnected from the mains and allowed to cool.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oYou should not use a steam jet or any other high pressure
cleaning equipment to clean the appliance.
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions. Please see
the specific section of this booklet that refers to
installation.
Baumatic Ltd. declines any responsibility for injury or damage,
to person or property, as a result of improper use or incorrect
installation of this appliance.

8
Declaration of conformity
This appliance complies with the following European Directives:
-2006/95/CE General regulations / Low tension
-1935/2004/CE 90/128/EEC This appliance is suitable to come in
contact with food
-2004/108/CE Electromagnetic compatibility
oThe manufacturer declares that the hob is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
To avoid damaging your appliance
oThe ceramic glass can be damaged by objects falling onto it.
oThe ceramic glass edge can be damaged by knocks from
cookware.
oCast iron and cast aluminium cookware with damaged bases
may scratch the ceramic surface if they are dragged across it.
oPans should be lifted on and off the hob surface and not
dragged.
oThe cooking zone should not be switched on without cookware
placed on it. Also the cookware should not be empty.
oFood or liquid that has high sugar content may damage the hob
top, if it comes into contact with the ceramic hob surface. Any
spillages should be wiped up immediately, however this may not
prevent the hob surface from becoming damaged.

9
Specifications
Product dimensions
Depth: 345 mm
Width: 280 mm
Height: 60 mm
Product specifications:
o1 x 2.00 kW standard induction zone (Ø 190 mm)
oFront touch control operation
oElectronic timer
Electrical details
Rated Voltage: 220 - 240 Vac 50/60 Hz
Supply Connection: 13 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 2.00 kW
Mains Supply Lead: 3 core x 1.5 mm²
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate of your hob is located on
the underneath of the appliance.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….

10
Ceramic hob surface layout
Control panel layout
1. ON/STANDBY button
2. Power light
3. Heat button
4. Heat “W” light
5. LED display
6. Temperature light
7. Temperature button

11
8. Timer button
9. Minus button
10. Timer “min” light
11. Plus button
Using the ceramic hob
Before first use
IMPORTANT: You should clean the ceramic hob surface (see
“Cleaning and maintenance” section).
oYou should switch on the hob for 5 minutes at the maximum
setting. This will help to eliminate any new smell that exists and
evaporate any humidity that has formed on the heating elements
during transit.
oYou must place a saucepan filled half full with cold water on the
zone as you burn it off. Otherwise the induction zone will not
operate.
Touch controls
oAll operations are performed by means of the touch controls that
can be found on the control panel. The controls respond to touch
so you don’t need to apply any pressure.
oTake care to ensure the controls are always clean and dry and
that there are no objects such as utensils and cloths covering
them. Even a thin film of water can make the control difficult to
operate.
oUse the ball of your finger to press a control, not the tip.

12
Induction cooking
oInduction cooking is a safe, advanced, efficient and economical
cooking technology.
oIt works by electromagnetic vibrations
generating heat directly in the pan, rather
than indirectly through heating the glass
surface. The only heat present on the glass
surface is from the pan which warms it up.
Cooking on the induction zone
oWhen the appliance is first connected to the
electrical supply, the power light (2) will flash to
indicate that the hob is in a standby state.
oPress the ON/STANDBY button (1). A buzzer will sound and the
power light (2) will turn on.
oPlace a suitable pan on the cooking zone. Make sure that the
bottom of the pan and the surface of the cooking zone are clean
and dry.
oPress the heat button (3) and a buzzer will sound.
The heat “W” light (4) will turn on to indicate that
the hob is heating up.

13
oThe hob will be set at the default temperature
setting of 3. You can change the power level by
pressing the temperature button (7).
oYou can then use the plus (11) and minus (9)
buttons to choose a different power level. The
temperature light (6) will turn on.
oYou can adjust the heat setting at any time during the cooking
process.
IMPORTANT: A buzzer will sound for 10 seconds before the hob
turns off if:
oThe pan is not placed correctly on the cooking zone
oThe pan you are using is not suitable for induction cooking. No
heating will occur unless there is a suitable pan on the cooking
zone.
oThe pan is too large or too small for the cooking zone.
Power level settings
oThe settings below are to be used as a guideline only. The exact
setting required will depend on several factors, including your
cookware and the amount of food that you are cooking.
oYou should experiment with the induction hob power levels to
find the best settings to suit you.
Power
setting Suggested use
1 – 2
oDelicate warming for small amounts of food.
oMelting chocolate, butter and foods that burn
quickly.
oGentle simmering.
oSlow warming.
3 – 4 oReheating.
oRapid simmering.
oCooking rice.
5 – 6 oPancakes.
7 – 8 oSautéing.

14
oCooking pasta.
9 oStir-frying.
oSearing.
oBringing soup to the boil.
oBoiling water.
Using the timer
oWhen the cooking zone is in use, it is possible to set a
countdown time after which the hob will turn off automatically.
oTo set a countdown time, press the timer button
(8) and a buzzer will sound. The display will flash
“0:00” and the timer “min” light (10) will come
on to indicate that the hob has entered the time
setting mode.
oUse the plus (11) and minus (9) buttons to set
the required countdown time. Each press of
these buttons which increase or decrease the
time by 1 minute. If either of the buttons is held
down, the time will increase or decrease by 10
minutes.
oWhen the display shows the correct countdown time release all
buttons. The display will flash for 5 seconds before the timer will
be set. The countdown will then begin straight away.
oWhen the timer reaches “0:00” the hob will automatically switch
off. The default time for the hob to automatically switch off after
is 2 hours.
oYou can cancel the timer function at any time during the
countdown by pressing the timer button (8).
Turning off the induction zone after cooking
oAfter you have finished using the induction zone,
press the ON/STANDBY button (1) to turn the
hob off and stop the zone heating.

15
Suitable cookware
oYou should only use cookware with a base that is suitable for
induction cooking. Look for the induction symbol on the
packaging or on the bottom of the pan.
oYou can check whether your cookware is
suitable by carrying out a magnet test.
Move a magnet towards the base of the
pan. If it is attracted, the pan is suitable
for induction.
oIf you do not have a magnet, you can fill the pan with water and
place it on a cooking zone. If the buzzer does not sound and the
water is heating, the pan is suitable.
oCookware made from pure stainless steel, aluminium or copper
without a magnetic base, glass, wood, porcelain, ceramic and
earthenware are not suitable.
oDo not attempt to heat items made of iron as this can cause
dangerously high temperatures.
oDo not place paper, aluminium foil, cloths or other unsuitable
materials into the induction hob for heating.
oDo not use cookware with jagged edges or a curved base.
oMake sure that the base of your pan is smooth, sits flat against
the glass and is the same size as the cooking zone.
oUse pans with a diameter as large as the induction zone. By
using a slightly wider pot, energy will be used at its maximum
efficiency. If you use a smaller pot, the efficiency of the hob
could be less than expected.
oPots should have a diameter of between 12 cm and 18 cm to be
detected by the induction zone. Always centre your pan on the
cooking zone.

16
oAlways lift pans off the induction hob, do not slide them as they
may scratch the glass.
Cooking tips
oIMPORTANT: Take care when frying as the oil and fat heat
up very quickly. At very high temperatures, oil and fat will
ignite spontaneously which presents a serious fire risk.
oWhen food comes to the boil, reduce the power level setting.
oUsing a lid on pans will reduce cooking times and save energy by
retaining the heat.
oMinimise the amount of liquid or fat used to reduce cooking
times.
oStart cooking on a high power setting and reduce the power level
when the food has heated through.
Hob guidelines
oThe first few times the hob is used, it may give off an acrid,
burning smell. This smell will disappear completely with repeated
use.
oThe saucepan must be positioned exactly on the zone for
efficient heating to occur. Pans should have the same diameter
as the cooking zone that it is being used on.
oYou should not use saucepans with rough bottoms, as this can
scratch the ceramic surface.
oBefore use, make sure that the bottom of the saucepan is clean
and dry.
oWhen cold, the bottom of the pan should be slightly concave, as
it will expand when hot and lie flat on the surface of the hob.
This will allow the heat to transfer more easily.
oThe best thickness for the bottom of the pans is 2 – 3 mm of
enamelled steel and 4 – 6 mm for stainless steel with sandwich
type bottoms.

17
oIf these rules are not followed, then there will be a great loss of
heat and energy. Heat not absorbed by the saucepan, will spread
to the hob, frame and surrounding areas.
oPreferably cover pans with a lid to permit cooking at a lower
heat.
oAlways cook vegetables and potatoes, etc. in as little water as
possible, to reduce cooking times.
oDO NOT attempt to heat an empty pot.
oYou should never leave the hob unattended at any time during
use.
oFood or liquid that has high sugar content may damage the hob
if it comes into contact with the ceramic hob surface. Any
spillages should be wiped up immediately, however this may not
prevent the hob surface from becoming damaged.
oNever heat foods in sealed containers, such as compressed
products or cans to avoid an explosion caused by heat
expansion.
oIMPORTANT: The ceramic hob surface is tough; however it is
not unbreakable and can be damaged. Especially if pointed or
hard objects are allowed to fall on it with some force.
oDO NOT USE THE HOB IF THE SURFACE BECOMES BROKEN
OR CRACKED. YOU SHOULD CONTACT THE BAUMATIC
SERVICE DEPARTMENT IMMEDIATELY.
Cleaning and maintenance
Cleaning operations must only be carried out
when the oven is cool.
The appliance should be disconnected from your
mains supply before commencing any cleaning
process.
Cleaning the ceramic hob top
Any residues that are left on the hob top surface from cleaning
agents will damage it. You should remove any residues with
water and a little washing up liquid.

18
Abrasive cleaners or sharp objects will damage the hob surface;
you should clean it using water and a little washing up liquid.
Although it is easier to clean some deposits whilst the hob
surface is still warm. You should take care not to burn yourself if
cleaning the hob surface when it is still warm.
oDO NOT directly rinse the induction hob under water. No liquids
should come into contact with the internal parts of the appliance.
After each use
oWipe the appliance over with a damp cloth.
oDry the appliance by rubbing the surface with a clean cloth.
Cleaning table
Type of deposit Remove
immediately?
Remove
when the
appliance
has cooled
down?
What should I
use to remove
the deposit?
Sugar or
food/liquid
containing sugar
Yes No Ceramic hob
scraper
Tin foil or plastic Yes No Ceramic hob
scraper
Fat splashes No Yes Ceramic hob
cleaner
Metallic
discolorations No Yes Ceramic hob cleaner
Water splashes or
water rings No Yes Ceramic hob cleaner
Using a ceramic hob scraper
Your appliance will be provided with a scraper. The following guidelines
should also be followed when using the ceramic hob scraper:-
oThe scraper should be placed on the ceramic surface at an angle.

19
oResidues should be removed by sliding the blade carefully over
the ceramic surface.
oThe ceramic surface should be wiped with a damp cloth that has
been dipped in warm, soapy water.
oDry the appliance by rubbing the surface with a dry clean cloth.
Using a specialist ceramic hob cleaner
It is possible to purchase specialist ceramic hob cleaner/conditioner.
You should follow the instructions given by the manufacturer of the
specialist ceramic hob cleaner. You should ensure that it is suitable for
use on your appliance.
Installation
The installation must be carried out by a suitably
qualified person.
Unpacking the appliance
When unpacking the appliance please check that the following items
are contained within the packaging:
1 Baumatic induction hob
1 Ceramic hob scraper
1 Installation and instruction manual
1 Baumatic guarantee card
Positioning
The adjacent furniture must be able to withstand a
minimum temperature rise of 85°C above the ambient
temperature of the room it is located in, during
periods of use.
oNEVER place the appliance on a gas cooker or hob during use as
the magnetic lines can heat the metal parts of the gas cooker or
hob.
oTo use the induction hob it should be placed horizontally on an
appropriate surface. There should be a space of at least 10 cm
between the sides and rear of the hob and any adjacent wall or
cupboard.

20
oDo not use the induction hob in narrow spaces to avoid hindering
the release of heat through the ventilation gaps.
oDo not place the appliance onto carpet, a tablecloth or paper to
avoid blocking the air vents which can result in overheating.
oThe appliance should not be located near any other heat source
such as radiators, heaters, cookers, ovens and hobs.
Electrical connection
Before connecting the appliance, make sure that the supply voltage
marked on the rating plate corresponds with your mains supply
voltage.
WARNING: THIS APPLIANCE MUST BE EARTHED.
oThis appliance should be wired into a 13 A double pole
switched fused spur outlet, having 3 mm contact
separation and placed in an easily accessible position
adjacent to the appliance. The spur outlet must still be
accessible even when your hob is located in its housing.
oIf you have to change the hob power cord, the earthing
(yellow/green) conductor must always be 10 mm longer than the
line conductors.
oCare must be taken to ensure that the temperature of the mains
supply cable does not exceed 50°C.
oIf the mains supply cable is damaged, then it must be replaced
by an appropriate replacement.
oCable type: H05 RRF 3 core x 1.5 mm²
