Baumatic BT98SS User manual

BT98SS
Cooker Hood

User Manual for your Baumatic
BT98SS
Cooker Hood
43cm Cooker Hood in Stainless Steel
You will be mine
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 09/10/06
2

3
Contents
Environmentalnote 4
Important safety information 5 – 7
Specifications of your cooker hood 8
Using your Baumatic cooker hood 9
Specialfunctions 10
Grease filters cleaning required warning 10
Carbon filters replacement warning 10
Cleaning and maintenance of your Baumatic 11
cooker hood
The grease filter 11
Removing and cleaning the grease filter 12
Changingalightbulb 13
Fitting the carbon filter 14
Installation 15
Electrical connection 15 – 16
Before beginning installation 16 – 17
Installing your cooker hood 17 – 20
Connecting to external ducting 21
Fitting the chimney section 22 – 23
Extraction mode or recirculation mode? 24
Troubleshooting 25
Baumatic Ltd. conditions of guarantee 26
Contactdetails 27

ENVIRONMENTAL NOTE
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any
plug useless. Cut the cable off directly behind the appliance to
prevent misuse. This should be undertaken by a competent
person.
CONFORMITY TO W.E.E.E. DIRECTIVE
4

IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of information contained in this
booklet, please contact the Baumatic Technical
Department.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.
oThe hood must be installed in accordance with the installation
instructions and all measurements followed.
oIf the cooker hood is installed for use above a gas appliance then
the provision for ventilation must be in accordance with the Gas
Safety Codes of Practice BS.6172, BS.5440 & BS.6891 (Natural
Gas) and BS.5482 (LP Gas) 1994, the Gas Safety (Installation &
Use) Regulations, the Building Regulations issued by the
Department of the Environment, the Building Standards
(Scotland) (Consolidated) Regulations issued by the Scottish
Development Department.
oIt is dangerous to alter the specifications or to modify this
product in any way. Do not tamper with it or attempt to modify
the appliance in any way.
oWhen installing the hood, ensure that the following
recommended distances are being observed between the cooker
top and the bottom of the cooker hood:
¾Electric cookers: 700 mm
¾Gas cookers: 700 mm
¾Coal/ oil cookers: 800 mm
IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS
THAN 700mm ABOVE YOUR COOKER.
oWhen installed between adjoining wall cabinets, the cabinets
must not overhang the hob.
5

oThe edges of the cooker hood are sharp – be mindful of this as
you handle your appliance, especially during installation and
cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS!
oIf the room where the cooker hood is to be used contains a fuel
burning appliance such as a central heating boiler then its flue
must be of the sealed or balanced flue type.
oIf other types of flue or appliances are fitted, ensure that there is
an adequate supply of air in the room.
oWhen the hood is being used in its extractor function, ensure
that the ducting is fire retardant and that there are no bends
sharper than 90 degrees as this will reduce the efficiency of the
hood.
oEnsure the ducting for the extractor function has the same
diameter as the outlet hole all the way through.
oKeep young children from using, playing with
or tampering with the cooker hood. Older
children and infirm persons should be
supervised if they are using the cooker hood.
oYour cooker hood is for domestic use only.
oPlease dispose of the packing material carefully – children are
especially vulnerable to it.
oDirty oil is an even greater fire risk.
oAlways put lids on pots and pans when cooking
on a gas cooker.
oThe manufacturer refuses to accept any responsibility for
damages arising to the hood or it catching on fire from failure to
observe fire safety advice in these instructions.
6

oRemember that when in extraction mode, your cooker hood is
removing air from your room. Ensure that proper ventilation
measures are being observed. Note that it removes odours
from your room, not steam.
oWarning - Always ensure that the cooker
hood has been disconnected from the
power supply before carrying out any work
on the hood, including replacing light bulbs.
oDo not connect the ducting system of this appliance to any
existing ventilation system which is being used for any other
purpose.
oDo not install above a cooker with a high level grill.
oNever leave frying pans unattended during use
as overheated fats and oils might catch fire.
oDo not leave naked flames under the cooker hood.
oDo not attempt to use the cooker hood if it is damaged in any
way. Never attempt to use it without the grease filters fitted or
if the filters are excessively greasy!
oNever flambé cook under this cooker hood.
THE MANUFACTURER DECLINES ALL
RESPONSIBILITY IN THE EVENT OF FAILURE TO
OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR
INSTALLATION, MAINTENANCE AND SUITABLE
USE OF THE HOOD.
7

8
Specifications of your cooker hood
Congratulations on purchasing a Baumatic Cooker
Hood!
DIMENSIONS:
Width (canopy): 430 mm
Depth (canopy): 430 mm
Height (with chimney) 710 mm – 1100 mm
DIMENSIONS OF CHIMNEY SECTION:
430 mm x 430 mm
Your stainless steel Cooker Hood is fitted with:
oSuperior extraction tangential motor
oTouch control operation
o5 Speeds and booster
o1 Metallic grease filters
o2 halogen lights
Extraction capacity: 750 m³/hr
Noise level min/max: 49 – 62 dB
Optional Extra: 1 x SCF11 carbon filter for air
recirculation mode (available from
the Baumatic Spares Department).

Using your Baumatic cooker hood
IMPORTANT: THE ELECTRONIC CONTROLS ON YOUR
OOKER HOOD HAVE MULTIPLE FUNCTIONS.
tart and Increase Speed (6 speeds)
The hood
utomatically sets itself to speed Level 1 when activated.
tton 1 for less than one second; the
isplay indicates the speed level.
utton 1 pressed longer than one second top speed is
elected.
otor stopping and decreasing speed
2 for less
an one second; the display indicates the speed level.
eeping button 1 pressed longer than one second turns the hood off.
imer Function
s after
ou have activated this function. To program: press button 3.
tion is activated you will see the number displayed
ulsing on and off.
ight on-off function
n and off by pressing button 4.
C
S
The Cooker hood motor is turned on by pressing button 1.
a
Speed is increased by pressing bu
d
Keeping b
s
M
The fan operating speed is decreased by pressing button
th
K
T
This function allows you to program the cooker hood’s motor and lights
in order to have them automatically switched off fifteen minute
y
When the timer func
p
L
The light is turned o
9

10
pecial functions
ial functions
esigned to facilitate maintenance and correct utilisation.
rease filters cleaning required warning
ing “A” on the display, that it is time to clean the metal
rease filters.
ill guarantee better ducting performance and
proved hygiene.
e
an
mber “8” will be displayed, it will
isappear after four seconds.
filters’ cleaning clock and begin the
ountdown to the next prompt.
arbon filters replacement warning (only if mounted)
ted air. It is necessary
set the cooker hood’s controls accordingly.
od is
ot in operation, hold down button 3 for more than 4 seconds.
he
eaning that the hood is now aware that there are carbon
lters fitted.
s of use. This indicates that the carbon filters require
placement.
o
processor will reset and begin the 120
our countdown once more.
S
Your cooker hood’s electronic system is equipped with spec
d
G
Every thirty hours of utilisation the microprocessor warns the user, by
means of a puls
g
Cleaning the filters w
im
To delete this prompt, once the filters have been cleaned and with th
cooker hood off (not powered). Hold buttons 2 and 3 for more th
four seconds: on screen the nu
d
The microprocessor will reset the
c
C
If your cooker hood is used in recirculation mode, it will need to have
active carbon filters fitted to purify the recircula
to
After fitting the carbon filter (see relevant section), whilst the ho
n
On the display, the symbol “-” will be displayed, this means that t
hood, for the time being, is not utilising the carbon filters. If you
continue to hold down button 3, after a further 4 seconds the letter “C”
will appear, m
fi
From now on the appliance will display a pulsing “C” on the display
every 120 hour
re
To reset the carbon filters replacement warning you should do the
following. When the cooker hood is switched off (i.e. not connected t
the mains supply), hold buttons no. 1 and no. 3 for more than four
seconds: on screen the number “8” will be displayed. It will disappear
after four seconds; the micro
h

11
leaning your Baumatic cooker hoodC
IMPORTANT: BEFORE CLEANING, ALWAYS
ENSURE THAT YOU HAVE SWITCHED YOUR
COOKER HOOD OFF AT THE OMNI-POLAR
SWITCH, SET AT THE WALL FROM THE CABLE.
le n
oker hood with mild liquid
oase filter grill with mild liquid
o
carbon filter”). A build up of grease
oNever attempt to clean the area above the grease filters.
he grease filter
C a ing
Clean the external parts of your coodetergent and a new damp cloth.
oNever use abrasive powder, corrosive solvents or brushes.
oNever insert pointed objects into the motor’s protective grid.
Only clean the control panel and gre
detergents and a new damp cloth.
If you are using the appliance in recirculation mode, then be
sure to replace the carbon filter at the recommended interval
(see section on “Fitting the
could cause a fire hazard.
T
oticles to protect your kitchen & furniture from greasy
ommable if it becomes
o.
t
month, using hot water and normal washing-up
oDO NOT WASH THE GREASE FILTER IN A DISHWASHER.
Your cooker hood includes a grease filter which helps to absorb
grease par
residues.
This metallic filter may become infla
saturated with this greasy residue.
To prevent this fire hazard, the filter should be cleaned regularly
Depending on use, this should be done every 10-15 days or a
least once a
detergent.

Maintenance
Removing and cleaning the grease filter
oUndo the side catches.
Soak the grease filter in hot water and washing up liquid for
se filters dry thoroughly before
refitting them in the cooker hood.
oFirst remove the grease filter by
pulling down on it.
oabout an hour.
oRinse them off thoroughly with hot water.
oRepeat the process if required.
12
oRefit the grease filters once they have dried.
oIMPORTANT: Let the grea

13
TING TO CHANGE
A LIGHT BULB, YOU MUST ENSURE THAT YOU
HAVE DISCONNECTED THE COOKER HOOD FROM
NS S P
oRemove the grease filters (as
described on page 11).
on.
oFind the bulb that r ement, you will find it located in
the light fi on of the
canopy.
new G4 20W (max) bulb.
oiately.
If the lights still do not work, make sure that the lamps are fitted
before you call for technical
oRefit the grease filters.
Changing a light bulb
IMPORTANT: BEFORE ATTEMP
U PLY.YOUR MAI
Prior to touching the light bulbs ensure they are cooled dow
equires replac
xture which is inside the exposed secti
oUnscrew the light bulb that needs to be replaced and insert a
IMPORTANT: Defective bulbs should be replaced immed
oproperly into their housings
assistance.

14
d to be used in recirculation mode then it
is necessary to fit carbon filters. This will help to absorb unpleasant
b
YOU HAVE DISCONNECTED THE
COOKER HOOD FROM YOUR MAINS SUPPLY.
) Remove the grease
lters.
filter. There are clips on one side
er and these should be facing the front of
) The clips will engage with the cooker
ood and it will slot into place.
, to
ake sure that the carbon filter is secured
side the cooker hood.
5) e
ohould be replaced
months or if they show
signs of damage.
Fitting the carbon filter
If the appliance is being use
y cooking.
IMPORTANT: BEFORE ATTEMPTING TO FIT OR
REMOVE THE CARBON FILTERS, YOU MUST
odours caused
ENSURE THAT
1
fi
2) Place the SCF11 carbon filter inside of the area
behind the grease
of the filt
the cooker hood.
3
h
4) Push the carbon filter up firmly
m
in
R fit the grease filters.
The carbon filters s
every three

Installation
IMPORTANT: Before installation and usage, read
all the instructions and make sure that the
voltage (V) and the frequency (Hz) indicated on
the rating plate are exactly the same as the
r
all the accident prevention regulations in force,
normal use and the regular operation of the
O R
PE
oble must be fitted upstream from the
electrical connection, using an omni-polar switch with a contact
be connected by a competent
voltage and frequency in your home. The rating
plate can be found behind the grease filters.
The manufacturer declines all responsibility in the event of the installe
failing to observe
which are necessary for
electric system.
Electrical connection
Y U COOKER HOOD IS INTENDED FOR FITTED AND
RMANENT INSTALLATION.
oThe power cable must be connected to the terminals marked L
(live) and N (neutral) in the hood and fixed with a cable clamp.
The cooker hood’s power ca
distance of at least 3 mm.
WARNING: THIS APPLIANCE MUST NOT BE
EARTHED. It should only
15
person, using fixed wiring via a double pole switched fused
spur outlet. (UK ONLY).
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
ith the I.E.E. and local regulation
coloured in accorda
ws. The wires in the mains lead are
nce with the following UK code:
Blue = Neutral, Brown = Live.

16
ou will only find two wires in the main’s lead (blue and
br
omains lead may not
spond with the coloured markings identifying the terminals
ox, p a
oe wire must be connected to the
terminal marked “N” (neutral), or coloured
oThe brown wire must be connected to the
terminal marked “L” (live), or coloured red.
Be r
o
If the product is going to be used in extraction mode,
then there should also be space to connect a ducting hose to the
oCarry out all necessary masonry work prior to the fitting of the
oEnsure that all electrical connections are carried out by a suitably
oBefore commencing installation of the cooker hood the grease
oging or any other materials, such as packets of screws,
guarantees etc. These should be removed and kept for future
o
ering
should be placed over the worktop, hob top or cooker. This will
oassembling the cooker hood. Cover that
surface with a protective covering and place all cooker hood
Yown), neither must be connected to the earth terminal.
As the colours of the wires in the appliance’s
corre
in your spur b le se proceed as follows:
The blu
black.
fo e beginning installation
Check that the product purchased is of a suitable size for the
chosen installation area. In addition check whether there is an
electrical socket available that will be accessible once the hood is
mounted.
outside.
cooker hood.
qualified person.
filter should be removed.
Check inside the product and insure that there is no transit
packa
use.
If possible, disconnect and move freestanding or slot-in cookers
from their position, to provide easier access to the rear wall and
ceiling. If this is not possible, then a thick, protective cov
help to protect these surfaces from damage and debris.
Select a flat surface for
parts and fittings on it.

17
o
essible after the hood is mounted. If you are
going to use the appliance in extractor mode, you should also
ce
oer a qualified technician must verify the
suitability of the materials, in accordance with the type of wall
ke
oDo not tile, grout or silicone this appliance to the wall. This
e surface mounted only.
y
EFORE E
ION MODE OR RECIRCULATION
MODE. PLEASE TURN TO PAGE 24 NOW TO
oker hood should not be exposed to a direct heat source
from the cooking device underneath it, i.e. naked flame from a
n
them.
o
oThe lights on this appliance should only be used during operation
of the cooker hood. They should not be left on permanently and
MPORTANT: YOUR COOKER HOOD SHOULD BE CONNECTED TO
In addition check whether there is an electrical socket available,
which will be acc
ensure that there is space to connect a fumes discharge devi
to the outside.
Raw plugs are provided to secure the hood to most types of
walls and ceilings. Howev
and ceiling. The wall and ceiling must be strong enough to ta
the weight of the hood.
appliance is designed to b
our cooker hood
IMPORTANT: YOU WILL HAVE TO DECIDE B
INSTALLING YOUR COOKER HOOD WHETHER TO US
IT IN EXTRACT
Installing
UNDERSTAND THE DIFFERENCES BETWEEN THESE
TWO MODES.
The coo
gas burner or heat from electric hob zones without a pan o
We recommend that at least two people install this hood.
used as a lighting source.
I
YOUR MAINS SUPPLY AFTER THE REST OF THE INSTALLATION
PROCESS HAS BEEN COMPLETED.
1) Remove the metal grease filters.

2) Figure 2 shows the support screw holes (A) and the anchoring
screw holes (B).
3) Place the hood against the wall
that you intend to install it on.
Using a pencil, mark the position of
the support screw holes on the
wall.
18

4) Using a pencil, mark the position of the anchoring screw holes on
the wall.
5a) Using a drill bit with a 6 mm diameter, make holes in the wall on
the positions that you have marked in steps 3 and 4.
5b) Insert raw plugs into all of the holes that you have drilled.
5c) Fasten the support screws halfway in, leaving them 10 mm out of
the wall.
19

6) Hang the hood onto the support screws.
6a) Fully tighten the support screws.
6b) Screw the anchoring screws (B) through the relevant holes in the
cooker hood. Tighten the anchoring screws fully into the wall.
20
