Baxton Studio BW19-02T User manual

Model no : BW19-02T
ASSEMBLY INSTRUCTIONS
Step 1
Attach part 1 and 2 for all four sides and lock it using hardware A, B, C, and D.
M5 ALLEN KEY
JCBC Screw M8 x 60mm
Spring Washer
Read this instruction carefully. Remove all wrapping material, staples and straps from
the carton.
See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft
surface, such as a carpet or rug, to prevent from being scratched. Follow the figure to
start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw until all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
1
2
Part List Qty
No
Table Top
Table Leg
1
4
A
Description Qty
No
1
B
C
D
8
8
COMPLETE
ASSEMBLE
Flat Washer 8
A
B
C
D
1
1
2
2

M4 ALLEN KEY
CSK Screw M4 x 32mm
Wood Dowel 8 x 30mm
Spring Washer
1
2
3
4
Part List Qty
No
Side Rail
Front Leg
Back Rest 1
2
2
1
A
Description Qty
No
1
B
C
D
E
8
2
Cushion Seat
JCBC Screw M6 x 50mm
8
4
ASSEMBLY INSTRUCTIONS
Step 1
Firstly, attach part 1 and 2 for both left and right side
and lock using hardware A, B, and C.
Read this instruction carefully. Remove all wrapping material, staples and straps from
the carton.
See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft
surface, such as a carpet or rug, to prevent from being scratched. Follow the figure to
start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw until all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
Step 2
Attach part 3 with the assembled part 2, and
lock it using hardware A, B, C, and D.
Step 3
Locate part 4 on the assembled seating frame
as shown, and fully tighten it with hardware E.
COMPLETE
ASSEMBLE
Step 5
A
B
C
1
2
ABC D
23
1
2
3
Step 1
Step 2
E
EE
E
4
