Baxton Studio 0042 Twin Captain's Bed User manual

0042 Twin Captain's Bed
Assembly Instructions
Parts List
1
Page 1 of 13
Headboard Panel x1
A
Headboard Post x1
B
Set of Bed Slats x1
C
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
Use 2 People
WII-0120
Parts in Box A:
DSide Rail x2
EBack Panel x1
FLower Drawer- Support Bar x5
Parts in Box B:
Storage can be assmbled
on the left or on the right.
Left Right

0042 Twin Captain's Bed
Assembly Instructions
Page 2 of 13
Part List
1
WII-0120
Parts in Box C:
QLower Drawer-
Side Panel (Left Hand) x 1 RLower Drawer- Center Panel x1
SLower Drawer-
Side Panel (Right Hand) x1
TLower Storage-
Side Panel (Left Hand) x 1 ULower Storage- Center Panel x 1 VLower Storage- Side Panel (Right Hand) x 1
Extra holes
(shown inside)
GFootboard Panel x1
HLower Storage-
Support Rail x2
MLower Storage-
Back Panel x1 OLower Storage- Lower Panel x1
LLower Storage-
Front Frame x1
PLower Drawer-
Back Panel x2
J
Lower Storage-
Support Bar
(Left Hand) x1
NLower Storage-
Shelf x1
K
Lower Storage-
Support Bar
(Right Hand) x1
W1 Drawer Face x4
W2 Drawer Back x4
W3 Drawer Bottom x4
W4 Drawer
Rail x4
W5
Drawer Side Panel
(Left Hand) x4
W6
Drawer Side Panel
(Right Hand) x4

0042 Twin Captain's Bed
Assembly Instructions
Page 3 of 13
Hardware List
WII-0120
M6 x 90mm JCB
x8
1M6 x 40mm JCB
x8
2M6 x 30mm JCB
x27
3M6 x 20mm JCB
x8
4
M6 x 15mm JCB
x16
5Wood Dowel
(6 x 25mm) x16
6Barrel Nut
x6
7Flat Washer
x8
8Spring
Washer x8
9
CSK Cap Wood Screw
(M6 x 50mm) x8
10 Wood Screw
(M4 x 32mm) x18
11 Wood Screw
(M4 x 25mm) x40
12 Wood Screw
(M4 x 16mm) x22
13
Allen Key x1
16
'L' Bracket (5005-3) x8
14 'L' Bracket (5003) x2 15
Fit the 'L' Bracket (14) to the Lower Storage- Front Frame (L).
3
2
L
5
14

0042 Twin Captain's Bed
Assembly Instructions
Page 4 of 13
Attach the Lower Storage- Support Bar (H) &
Lower Panel (O) to the Center
Panel (U).
WII-0120
4
U
O
10
10
H
10
3
3
H
O
U
V
T
3
3
3
3
3
Extra holes
(shown inside)
Assemble the Lower Storage- Left & Right hand
Side Panel (T & V) to the Support Rail (H) &
Lower Panel (O).
5
Back

5
14
x 4
0042 Twin Captain's Bed
Assembly Instructions
Page 5 of 13
Attach the Lower Storage- Support Rail (H) & Front
Frame (L). Lastly, tighten Left & Right hand
Side Panel (T & V) with using 15mm JCBs (5).
WII-0120
6
L
H
VU
T
Fit the 'L' Bracket (14) to the Lower Storage- Right hand Side Panel (V) &
Center Panel (U).
7
L
H
V
U
T
5
14
x 4
Back
Back

0042 Twin Captain's Bed
Assembly Instructions
Page 6 of 13
Slide in the Lower Storage- Shelf (N) inside the frame.
Tighthen the Lower Storage- Shelf (N) with bolts.
WII-0120
8
N
V
T
Fit the Lower Storage- Back Panel (M).
9
Back
5
x 4
13
13
13
13
13
13
M
V
T

M
10
10
10
10
J
K
V
T
0042 Twin Captain's Bed
Assembly Instructions
Page 7 of 13
Attach the Left & Right hand Lower Storage- Support Bar (J & K)
to the Side Panel (T & V).
WII-0120
10
Assemble the Lower Drawer- Support Bar (F)
to the Lower Drawer- Center Panel (R).
11
Back
Back
F
F
3
3
3
R
F
3

0042 Twin Captain's Bed
Assembly Instructions
Page 8 of 13
Assemble the Left & Right hand Lower Drawer- Side Panel (Q & S)
to the end of the Lower Drawer- Support Bar (F).
WII-0120
F
F
S
Q
3
3
3
3
3
F
3
3
R
12
Fit the Lower Drawer- Back Panel (P) in place.
13
Back
Back
P
P
13
13
13
13
13
13
13
13
S
13

0042 Twin Captain's Bed
Assembly Instructions
Page 9 of 13
Slide the Drawer Bottom (W3) into the
groove on the Drawer Sides (W5 & W6).
Assemble the Drawer Back (W2) to the Drawer Sides (W5 & W6).
12
6
W1
W4
6
12
W6
W5
Important: Assemble the
Drawer Runner facing
Drawer Face.
W3
W6
W5
12
12
W2
W5
W6
Assemble the Left and Right hand Drawer Sides (W5 & W6) and Drawer Rail (W4)
to the Drawer Face (W1).
WII-0120
Turn the Drawer over to fit angled
25mm Wood screws (12)
to the Drawer
Rail (W4).W1
12
W2
W4
14
15
16
17
x4

3
0042 Twin Captain's Bed
Assembly Instructions
Page 10 of 13
Storage can be assembled on the left or on the right.
WII-0120
18
On the Left
Assemble the assembled Lower
Storage and assembled Lower
Drawer together.
Assembled
Lower Drawer
Assembled
Lower Storage
Left
Assembled
Lower Drawer
Assembled
Lower Storage
On the Right
Right

0042 Twin Captain's Bed
Assembly Instructions
Page 11 of 13
Assemble the Side Rail (D) & Back Panel (E) to the
Headboard Panel (A) & Headboard Post (B).
B
A
E
D
D
G
19
4
8
9
7
1
Use 2 People
WII-0120
9
4
8
1
D
B
1
7
A
1
E
7
Attach the Footboard Panel (G) to the
Headboard Post (B) & Side Rail (D).
20

0042 Twin Captain's Bed
Assembly Instructions
Page 12 of 13
Assemble the assembled Lower Drawer
to the Headboard Panel (A).
WII-0120
21
Use 2 People
D
G
Assembled
Lower Storage
B
D
E
Assembled
Lower Drawer
1
1
13
15
Back
A
D
Assembled
Lower Drawer
G
Assembled
Lower Storage
3
Bolt the assembled Lower Storage to the
Headboard Post (B) and tighten the
'L' Bracket with M4 x 16mm
Wood Screw.
22

0042 Twin Captain's Bed
Assembly Instructions
Page 13 of 13
Screw & bolt the Bed Slats (C) between
the Side Rail (D). Finally, fit the
assembled Drawers.
WII-0120
2
2
11
2
11
11
2
C
D
23
Assembled Drawer
