GlassCrafters GC1624 User manual

Please use extreme care while unpacking and handling your GlassCrafters’ Mirrored Cabinet. Report any damage
immediately to our GlassCrafters customer service team at 800-233-7362,
Monday thru Friday from 8:00 am to 5:00 pm (EST)
GC1624
GC2036
GC1636 GC2030
GC2430
GC1630
GC2436
1
Congratulations on your purchase of Americas nest Mirrored Cabinet by GlassCrafters, Inc.
World class engineering and state of the art design will enable you to enjoy your cabinet for many years to come.
We realize that the marketplace offers many choices and we thank you for selecting
GlassCrafters for your Mirrored Cabinet needs.
The following instruction sheets include the ALL MODELS listed below in both 4” deep and 6” deep Mirrored Cabinets.
Revised 05/2016
GLASSCRAFTERS, INC
193 Veterans Blvd., Carlstadt, NJ 07072
1+(800) 233-7362 (F) 1+(888) 233-7362
Mirrored Cabinet Installation Instructions
To view a video showing helpful tips
on how to --
adjust our Cabinet HInges
or
to install our Mirrored Side Kits,
please go to:
GlassCraftersMirroredCabinets.com
and navigate to the
cabinet product that
you are installing.
Simply click on the
installation tab
(located below the
product images)
to view our
installation videos.
To insure proper installation we recommend installation by a professional installer.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
If your unit is an electried unit you should have the
GC Electric Option manual packed with your unit. If it is not
available for installation go on line and download the prod-
uct manual you need or contact your dealer.
ALL ELECTRIC UNITS REQUIRE INSTALLATION BY
A LICENSED ELECTRICIAN.

1
Section
2
Parts List
Carefully review all parts and read the installation
instruction before you start.
Please refer to pages 11 & 12 for the exact parts list
and item counts for each model number.
1. Cabinet
2. Door, (boxed separately)
3. Plastic Wall Anchors
4. Wall Anchor Screws
5. Bottom Surface Mount
Wall Bracket
6. Top Surface Mount Bracket
7. Screw Caps
8. Shelf Clips
9. Hole Plugs
10. Cabinet Connectors
4” deep*
11. Cabinet Connectors 6” deep*
12. Glass Shelves
13. Cabinet Connector Mounting
Screws
14. Hinge Cover Name Plates
15. 130 Degree Limit Clips
16. Soft Close Cushion
17. 3X Magnication Mirror
Note: Allen wrench provided for Electric
Option installation only.
Index
Parts List for All Models....................................2
Determining the Rough Opening......................3
Recessing the Cabinet .....................................4
Combining two (2) or three (3) Cabinets .........5
Surface Mount Cabinet.....................................6
Mirrored Cabinet Installation -- Unpack all parts carefully
and protect Glass and Mirror parts during installation.
Surface Mount Side Kit Installation...................7
Glass Shelves...................................................8
Door Installation and Adjustment......................9
Limit Clips.........................................................10
Cleaning Recommendation ..............................8 & 11
Parts Inventory by Model Number....................11-12
Warranty...........................................................12
* Special order
To insure proper installation
in complete compliance with
your warranty,
we recommend installation
by a professional installer.

Determining the Rough Opening “RO” Dimension
Framing in new construction should follow these dimension. Standard 2x4 studs and 1/2” sheetrock are shown
in the illustrations. For 6” deep models 2x6 studs are required or a semi-recessed application is necessary.
Model Number Rough Opening Single Cabinet Rough Opening Two (2) cabinets Rough Opening Three (3) cabinets
Width Height Width Height Width Height
GC1624 14 3/8” 23 3/8” 29 3/8” 23 3/8” 44 3/8” 23 3/8”
GC1630 14 3/8” 29 3/8” 29 3/8” 29 3/8” 44 3/8” 29 3/8”
GC1636 14 3/8” 35 3/8” 29 3/8” 35 3/8” 44 3/8” 35 3/8”
GC2030 18 3/8” 29 3/8” 37 3/8” 29 3/8” 56 3/8” 29 3/8”
GC2036 18 3/8” 35 3/8” 37 3/8” 35 3/8” 56 3/8” 35 3/8”
GC2430 22 3/8” 29 3/8” 45 3/8” 29 3/8” 68 3/8” 29 3/8”
GC2436 22 3/8” 35 3/8” 45 3/8” 35 3/8” 68 3/8” 35 3/8”
3
Tools Required for Installation
GlassCrafters recommends the following tools to
properly and safely install your Mirrored Cabinets.
A. Safety Glasses -- should be worn at all times
B. Tape Measure
C. Level
D. #2 Phillips Head Screw Driver
E. Power Screw Driver
F. Electric Drill
G. 8mm 3/16” Masonry Drill Bit
H. 7/32” Drill Bit
I. Non Ammonia Household Glass Cleaner
J. Soft Paper Towels
Single Cabinet “RO” Rough Opening formula: Overall cabinet width less 5/8” = Rough Opening
Two Cabinets “RO” Rough Opening formula: Overall cabinet width less 5/8” plus the overall width of the second added cabinet = Rough Opening
Three Cabinet “RO” Rough Opening formula: Overall cabinet width less 5/8” plus the overall width of the two added cabinets = Rough Opening
Example: Model GC1630 combined with Model GC2430 = 15” less 5/8” = 14 3/8” plus 23” = 37 3/8” R.O. width.
Height: overall cabinet height less 5/8” = R.O. Height.
Important: Make sure you allow for a
minimum of 1” clearance above any obstruction
such as faucets, etc.
Rough Opening:
Note: Cabinet installs over nished wall with sheetrock
and/or tile nishes completed. 3/4” Flange on all sides of
the cabinet will cover the remaining space in the R.O.

4
Installing a
Recessed & Semi-Recessed
Mirrored Cabinet
A. Determine the rough opening for the cabinet. Refer to
“R.O.” formula chart on page 3. Opening must be plumb
and level.
B. Cabinet can be hinged on left or right. Simply ip the
cabinet to change hinge location. For multiple cabinet
units determine the hinge location for each unit before
they are joined together and mark the top of each unit.
C. Insert cabinet in R.O. and center, Cabinet Flange cov-
ers any space in the R.O. around the cabinet and should
cover the nished surfaces--Sheetrock and/or tile.
Install the cabinet with four (4) #10 x 1 1/2” wood screws
(supplied). Use the pre-punched holes above and below
the hinge plates (as shown). Do not overtighten. Cover
screws with four screw caps (part #434).
For Multiple Cabinets: Two or Three unit cabinets must
be joined as shown on the facing page before installation.
Note: Three cabinet units require an additional installation
screw in the top center of the center unit. Drill an access
hole in the cabinet and install an additional #10 x 1 1/2”
wood screw. Cover the screws with four or ve screw
caps (part #434).
2x4
Framing
Shown
PLUMB
LEVEL
B
AC
Hinge Plate shown for right hinged door.

Parts required to join Two (2) Cabinets:
Cabinet Connector Screws Qty Screw Qty
depth Part# Qty Caps
4” deep #426 2
10-32 x 1 1/2”
8 #434 8
6” deep #429 2
10-32 x 1 1/2”
8 #434 8
Left Top
Right Top
Left Top
Center Top
Right Top
Left Top Right Top
Section 1 Cabinet Flanges
meet here
5
Combining Two (2) or Three (3)
Cabinet Units before Installation.
Any of the cabinets that are the same height my be
joined to form one unit. Follow these instructions to cre-
ate the nal size unit before attempting installation.
• Be sure to determine the hinge side door swing
location for each unit.
• Mark the top of each unit-- Left, Right or Center with
the Hinge plates in the proper position.
When the unit is fully assembled refer to “R.O.” formula
chart on page 3 to determine the R.O. required for the
unit as assembled.
Assembling multiple cabinet units:
1. Place the units on a 2x4 or 2x6 of sufficient horizontal
length to support all the units to be joined. Place 2” edge
of the wood at on the oor with the cabinet facing up
with the bottom ush to the inside edge of the 2x4.
2. Install the Cabinet Connector (part #426 or 429) on the
outside of the left hand cabinet. Use the pre-punched
holes immediately above and below the hinge plate loca-
tions. Use screws 10-32 x 1/2” as supplied. (See Section
#1)
3. Move the second cabinet into position so that the face
ange of both units are aligned. Fix the cabinets together
using screws 10-32 x 1/2” as supplied. (See Section #1).
4. If there is a third unit follow the steps above.
Shown here -- Left, Right and Right
hinge side door swings
Shown here -- Left and Right
hinge side door swings
Parts required to join Three (3) Cabinets:
Cabinet Connector Screws Qty Screw Qty
depth Part# Qty Caps
4” deep #426 4
10-32 x 1 1/2”
16 #434 16
6” deep #429 4
10-32 x 1 1/2”
16 #434 16

6
Installing a
Surface Mount Mirrored Cabinet
A. Determine the desired height and use a level to mark
a horizontal line. Be sure to allow a minimum clearance
of 1” above any obstruction and plumbing xtures. Re-
member the base of the cabinet box is 3/4” smaller than
the face and the door.
4
5

7
Side Mirror Kit parts list:
2 Mirror side panels to match
the model height ordered
4 Side kit brackets with adhe-
sive tape
6 2”x2” Black Foam Pads with
peel off adhesive tape on both
sides
8 Screws, 10-32 x 1/2”
8 Screw Caps ( part # 434-00)
2 Alcohol Pads
Align mirrorto level
with TopEdge
Side MirrorBracket
Side MirrorBracket
Side Mirror
Bracket
Side Mirror
Side MirrorKit
2”x 2”Black
Foam Pads
with peel off
adhesive side
affix pads
to the
cabinet
Peel off paper covering adhesive
Side Mirror
Install Side Mirror:
• Install foam pads
on the outside wall
above, below and
in between
the brackets
• Clean back side of
mirror with
alcohol pads
• Peel-off paper
covering the
adhesive tape
on the brackets-
(this holds the
mirror in place)
• Align mirror
top and bottom
• Press firmly in place
(Do not try to remove
mirror as it will break)
Peel off paper
covering adhesive
on Bracket
To view a video showing helpful tips on how to install mirrored side
kits, please go to GlassCraftersMirroredCabinets.com and navigate
to the cabinet product that you are installing. Simply click on the
installation tab (located below the product images) to view our
installation videos.
Side Mirror Kit Installation
For surface mounted 4” & 6” Mirrored Cabinets and
6” semi-recessed Mirrored Cabinets.
1) Attach the side mirror kit brackets thru the pre-punched
holes in your cabinet.
2) Try to use the rst row from the top and bottom of your cabi-
net. Using the eight 10-32 x 1/2” screws fasten the
brackets and nish with screw caps.
3) Attach the 2” x 2” foam pads to the outside cabinet wall
above, below and in between the position of the brackets.
4) Clean the backside of the side mirror kit panel with the Alco-
hol pads. Check alignment before you attach the mirror to be
sure it will align even with the top of the cabinet.
5) Peel off paper covering of the adhesive tape on the side kit
brackets pads. (This holds the mirror in place). Carefully align
the mirror to the cabinet evenly on all four sides. Press rmly
into place and attach to the side kit mirror to the cabinet body.
(Note: Once installed, do not try to remove the mirror as it will break.)
Side Mirror Bracket
Side Mirror
10-32 1/2” Screws
2” x2” Foam Pads

8
Glass Shelves Installation
After the Mirrored Cabinet box has been properly in-
stalled, determine the appropriate height and location for
the glass shelves.
Note: make sure the back wall mirror has been
completely cleaned after installation. If cleaning the back
wall mirror is necessary, use a household non-ammonia
glass cleaner.
Cleaning Recommendations:
Never use abrasive cleaners or cleaners containing
ammonia. This may cause chemical damage to the
mirror and void the warranty.
24” Height Series = 2 Shelves + 8 Shelf Clips
30” Height Series = 3 Shelves + 12 Shelf Clips
36” Height Series = 4 Shelves + 16 Shelf Clips
For cleaning the mirror, we recommend using
“ammonia free” Sprayway brand glass
cleaner, which is available at a variety of re-
tail outlets.
www.spraywayinc.com/content/glass-cleaner
Each glass shelf will require four (4) shelf
clips. Use care when handling the non-tem-
pered glass shelves. On a level plane insert
the shelf clips into the pre-punched holes.
The clips are designed for a tight tension t
to hold the shelf. Place each glass shelf on the top of
the left clip rst, then slowly lower onto the right clip with
a snap t.
After glass shelves are installed insert hole plugs in all
open holes to complete installation.
Hole Plugs

#3
Screws adjust
for Flush Fit
to cabinet face
#2
Screws adjust
for Fit to
Top and Bottom
to cabinet face
#1
Screws adjust
for Fit alignment
left and right
to cabinet face
9
Hinge CoverName Plate
#1 Screw-
Adjust Left to Right
#3Screw-
Adjust
Front to Back #2 Screw-
Adjust
Topto Bottom
Blum Hinge Adjustment
The doors after adjustments are completed place cover caps
on hinges.
Hinge Toe Plate
1) Insert into
Hinge Toe
first
Hinge Plate
2) Lift and snap
into place Doorwith Hinge
Hinge Plate* Factory Installed.
*If the door binds and does not fully close, adjust the
Hinge Plate on the cabinet up and down, to relieve the
tension
Corner Protectors
Door Installation
The doors are packed individually for protec-
tion of the mirror surfaces. Carefully remove
the door from the carton.* Hold the door in the
upright position snap open the factory in-
stalled hinges. Place the hinge onto the fac-
tory-installed mounting plate in the cabinet --
Toe rst -- and snap into position. Be careful
not to chip the door mirror.
*Do not remove corner protectors until the
door is installed
To view a video showing helpful tips on how to adjust our cabinet
hinges, please go to GlassCraftersMirroredCabinets.com and navigate
to the cabinet product that you are installing. Simply click on the
installation tab (located below the product images) to view our
installation videos.

10
Limit Clips
Limit Clips are provided should you need to reduce the
opening swing of the cabinet door from 170 degrees to
130 degrees (see top view) This will eliminate the possi-
bility of the door hitting a wall sconce or other decorative
items.
Rececess Cabinet DoorSwing Diagrams
Finishedsurface
Finishedsurface
Cabinet
Cabinet
170º swing
130º swing

11
Model: GC1624-4"
Qty. Part Number
Cabinet 4" Cabinet 1 GC1624-4-Cab
Door - Boxed Separately 1 GC1624-D
Plastic Wall Anchor 5 # 10 PWA
Wall Anchor Screws 5 # 10 x 1 1/2 Phillips
Bottom Surface Wall Mount Bracket 1 414-03
Top Surface Mount Brackets 2 425-00
Screw Caps 12 434-00
Shelf Clips 12 439-01
Hole Plugs 40 433-00
*Cabinet Connectors 4" Cabinet 2 426-00
*Cabinet Connector Mounting Screws 8 18-855 10/32” x 1/2"
Glass Shelves 4" Cabinet 2 417-01-A 3 7/16” x 13 1/4" x 5/16"
Hinge Cover Name Plates 2 904-00
130 Degree Limit Clip 2 901-00
Soft Close Cushion 2 900-00
3X Magnification Mirror 1 950-01
Model: GC1630-4" Model: GC1636-4"
Model: GC1630-6" Model: GC1636-6"
Qty. Part Number Qty.
Cabinet 4" Cabinet 1 GC1630-4-Cab 1 GC1636-4-Cab
Cabinet 6" Cabinet 1 GC1630-6-Cab 1 GC1636-6-Cab
Door - Boxed Separately 1 GC1630-D 1 GC1636-D
Plastic Wall Anchor 5 # 10 PWA 5 # 10 PWA
Wall Anchor Screws 5 # 10 x 1 1/2 Phillips 5 # 10 x 1 1/2 Phillips
Bottom Surface Wall Mount Bracket 1 414-03 1 414-03
Top Surface Mount Brackets 2 425-00 2 425-00
Screw Caps 12 434-00 12 434-00
Shelf Clips 12 439-01 16 439-01
Hole Plugs 40 433-00 40 433-00
*Cabinet Connectors 4" Cabinet 2 426-00 2 426-00
*Cabinet Connectors 6" Cabinet 2 429-00 2 429-00
Cabinet Connector Mounting Screws 8 18-855 10/32” x 1/2" 8 18-855 10/32” x 1/2"
Glass Shelves 4" Cabinet 3 417-01-A 3 7/16” x 13 1/4" x 5/16” 4 417-01-A 3 7/16” x 13 1/4" x 5/16"
Glass Shelves 6" Cabinet 3 417-06-A 5 7/16” x 13 1/4" X 5/16” 4 417-06-A 5 7/16” X 13 1/4" X 5/16"
Hinge Cover Name Plates 2 904-00 3 904-00
130 Degree Limit Clips 2 901-00 3 901-00
Soft Close Cushion 2 900-00 2 900-00
3X Magnification Mirror 1 950-01 1 950-01
*Cabinet Connectors -- Special Order
This installation manual serves the
complete line of GlassCrafters
Mirrored Cabinets including all 4”
deep and 6” deep models. The
general parts list pictured on page 2
shows the single images of a part.
To completely inventory the material
delivered for your particular model
please check the quantities
indicated in the part list here and on
pages 11 & 12.
Master Parts List for Mirrored Cabinets
Cleaning Recommendations:
Never use abrasive cleaners or
cleaners containing ammonia. This
may cause chemical damage to the
mirror and void the warranty.
For cleaning the mirror, we recommend
using ammonia free Sprayway brand
glass cleaner, which is available at a
variety of retail outlets. www.sprayway-
inc.com/content/glass-cleaner

12
Model: GC2030-4" Model: GC2036-4"
Model: GC2030-6" Model: GC2036-6"
Qty. Part Number Qty.
Cabinet 4" Cabinet 1 GC2030-4-Cab 1 GC2036-4-Cab.
Cabinet 6" Cabinet 1 GC2030-6-Cab 1 GC2036-6-Cab.
Door - Boxed Separately 1 GC2030-D 1 GC2036-D
Plastic Wall Anchor 5 # 10 PWA 5 #10 PWA
Wall Anchor Screws 5 # 10 x 1 1/2 Phillips 5 # 10 x 1 1/2 Phillips
Bottom Surface Wall Mount Bracket 1 414-03 1 414-03
Top Surface Mount Brackets 2 425-00 2 425-00
Screw Caps 12 434-00 12 434-00
Shelf Clips 12 439-01 16 439-01
Hole Plugs 40 433-00 40 433-00
*Cabinet Connectors 4" Cabinet 2 426-00 2 426-00
*Cabinet Connectors 6" Cabinet 2 429-00 2 429-00
Cabinet Connector Mounting Screws 8 18-855 10/32” x 1/2" 8 18-855 10/32” x 1/2"
Glass Shelves 4" Cabinet 3 417-02-A 3 7/16” x 17 1/4" x 5/16" 4 417-02-A 3 7/16” x 17 1/4" x 5/16"
Glass Shelves 6" Cabinet 3 417-07-A 5 7/16” x 17 1/4" x 5/16" 4 417-07-A 5 7/16” x 17 1/4" x 5/16"
Hinge Cover Name Plates 2 904-00 3 904-00
130 Degree Limit Clips 2 901-00 3 901-00
Soft Close Cushion 2 900-00 2 900-00
3X Magnification Mirror 1 950-01 1 950-01
Model: GC2430-4" Model: GC2436-4"
Model: GC2430-6" Model: GC2436-6"
Qty. Part Number Qty.
Cabinet 4" Cabinet 1 GC2430-4-Cab 1 GC2436-4-Cab
Cabinet 6" Cabinet 1 GC2430-6-Cab 1 GC2436-6-Cab
Door - Boxed Separately 1 GC2430-D 1 GC2436-D
Plastic Wall Anchor 5 # 10 PWA 5 # 10 PWA
Wall Anchor Screws 5 # 10 x 1 1/2 Phillips 5 # 10 x 1 1/2 Phillips
Bottom Surface Wall Mount Bracket 1 414-03 1 414-03
Top Surface Mount Brackets 2 425-00 2 425-00
Screw Caps 12 434-00 12 434-00
Shelf Clips 12 439-01 16 439-01
Hole Plugs 40 433-00 40 433-00
*Cabinet Connectors 4" Cabinet 2 426-00 2 426-00
*Cabinet Connectors 6" Cabinet 2 429-00 2 429-00
Cabinet Connector Mounting Screws 8 18-855 10-32 x 1/2" 8 18-855 10/32” x 1/2"
Glass Shelves 4" Cabinet 3 417-03-A 3 7/16” x 21 1/4" x 5/16" 4 417-03-A 3 7/16” x 21 1/4" x 5/16"
Glass Shelves 6" Cabinet 3 417-08-A 5 7/16” x 21 1/4" x 5/16" 4 417-08-A 5 7/16” x 21 1/4" x 5/16"
Hinge Cover Name Plates 2 904-00 3 904-00
130 Degree Limit Clips 2 901-00 3 901-00
Soft Close Cushion 2 900-00 2 900-00
3X Magnification Mirror. 1 950-01 1 950-01
*Cabinet Connectors -- Special Order
WARRANTY
GlassCrafters, Inc. offers a Limited 3 Year Warranty on all mirrored cabinet products.
GlassCrafters’ warranty provides the original purchaser a guarantee that it will replace or
at its own discretion repair products shown to have substantial defects in workmanship
or materials. These claims must be led with your dealer or professional installer and for-
warded in writing to GlassCrafters within three years of the delivery date to the end user
of the product. GlassCrafters shall not be responsible for any installation or removal
costs. This warranty does not apply to the following, chemical or natural corrosion of the
mirror. The use of abrasive cleaners or cleaners containing ammonia will cause chemi-
cal damage to the mirror, voiding this warranty.
The GlassCrafters warranty does not cover product that is damaged in shipping, acci-
dents in handling during installation or if the reported defects are a result of faulty instal-
lation, abuse, misuse, abnormal wear, poor maintenance, accident or repairs by service
personnel other than the original professional installer as authorized by GlassCrafters.
After the three year period GlassCrafters shall not have any further obligation, expressed
or implied including merchantability under the Limited Warranty.
Blum hinges and soft closing cushions have a separate lifetime warranty from
Blum, Inc. This warranty is against defects in materials and workmanship as long as
the original consumer owns the product. This is a warranty of replacement. After veri-
cation of defect, Blum, Inc. will send replacement hardware without charge.
GlassCrafters shall not have any liability for any consequential damages stemming
from or in connection with the use per performance of this product. Prevailing state
law on the limits of the implied warranty will apply.
The liability of GlassCrafters under any implied or expressed warranty, including mer-
chantability, is expressly limited to the terms of this warranty. Any claim under this
warranty must be made directly to the dealer of record.
Permission to return any merchandise under this warranty must be authorized in writ-
ing by GlassCrafters and must include prepaid shipping by the purchaser.
Revised 05/2016
GLASSCRAFTERS, INC
193 Veterans Blvd., Carlstadt, NJ 07072
1+(800) 233-7362 (F) 1+(888) 233-7362
Other manuals for GC1624
1
This manual suits for next models
6
Table of contents
Other GlassCrafters Indoor Furnishing manuals
Popular Indoor Furnishing manuals by other brands

Cooper Lighting
Cooper Lighting Neo-Ray 78 Specification sheet

Lyon Beton
Lyon Beton VERVEINE D-09541 Assembly instructions

Ilva
Ilva GAIN 1069668 Assembly instruction

LEGRAND
LEGRAND MIDDLE ATLANTIC C5 Series instruction sheet

OMT-Veyhl
OMT-Veyhl OV1018 user guide

Jysk
Jysk Verona 40177001 Assembly instruction

DURAVIT
DURAVIT LM 7874 Mounting instructions

Mainstays
Mainstays BUCHANNAN quick start guide

OYPLA Home
OYPLA Home 3823 user manual

Clou
Clou mini match me CL/07.56.402.50 installation instructions

PARAMOUNT BED
PARAMOUNT BED PS-0232S instruction manual

Home Decorators Collection
Home Decorators Collection 100 Series instruction manual
