Baxton Studio Benjamin B52D User manual

G
14PCS
FLAT WASHER
M6 x 19MM
D4PCS
SPRING WASHER
M6 x 12MM
4PCS
L - KEY
M5 x 65MM
M4 x 65MM
8PCS
M4 x 32MM
L - KEY
SCREW
M6 x 50MM
JCBC SCREW
M8 x 20MM
1PC
JCBB SCREW
1PC
E
4PCS
F
C
B
A
L
CENTER
SUPPORT
SUPPORT LEG
EG
QTY
HARDWARE
ITEM
74PCS
8
92PCS
FRONT RAIL
6
5
4
3
2
2SETS
1PC
SIDE PANEL
(L)
SLAT
STEP 2
SIDE PANEL
(R)
1PC
1PC
1PC
BACK RAIL
1PC
BACK PANEL 1PC
1
QTY
PARTLISTNO
STEP 1
ITEM : BENJAMIN FULL DAYBED
7
23
G
A
2
4
5
3
ASSEMBLY INSTRUCTION
Begin assembly by attaching each Leg (7) to the bottom of Left Side Panel (2) & Right Side Panel (3).
Tighten the Legs (7) clockwise until secure.
Attach the Front Rail (4) and Back Rail (5) to the Left Side Panel (2) and Right Side Panel (3).
Aligning the holes and securing with 2 Allen Bolts (A) per each end by using L-Key (G).
(DO NOT FULLY TIGHTEN BOLTS FOR THIS STEP)

STEP 4
STEP 3
STEP 4.2
STEP 4.3
8
E
STEP 4.1 8
9
F
B
C
D
3
2
4
1
5
8
9
ASSEMBLY INSTRUCTION
Attach the Back Panel (1) to the Left Side Panel (2) and Right Side Panel (3), and securing with 2 Allen Bolts (B),
2 Spring Washer (C ), 2 Flat Washer (D) each side of the Back Panel by using L-Key (F).
Secure 2 Support Leg (9) to the Center Support (8) as shown on step 4.1. Insert the pre-set metal on Slat Support (8)
to the metal bracket on each of Side Panel (2) & (3) as shown on Step 4.2.
Then securing the metal bracket as shown in step 4.3 with 1 Screw (E) each side using Phillips Head Screwdriver
(NOT INCLUDED).

STEP 6
STEP 5
ASSEMBLY
COMPLETED
E
E
6
6
6
ASSEMBLY INSTRUCTION
Tighten all Bolts on step 2 by using the L-Key (G) and following step 3 using L-Key (F) that has been provided.
Attach slats (6) to the Front Rail (4) and Back Rail (5) by Screwdriver unrolling and securing with 6 Screws (E )
per set using Phillips Head.
Repeat the same step to attach another set of Slats (6).
