Baxton Studio Canopy Queen Bed 0021-3 User manual

0021-3 Canopy Queen Bed
Assembly Instructions
Assembled View
1
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
Use 2 People
WI-0820
Page 1 of 8
Headboard Panel x1
A
Parts List
2
Parts in Box A:
Headboard Support x1
B
Footboard Panel x1
C
Footboard
Support Bar
x1
D

0021-3 Canopy Queen Bed
Assembly Instructions
Parts List
2
Page 2 of 8
Parts in Box B:
ETo p Bar (Short) x2
FTo p Bar (Long) x2
GSide Rail x2
HLong Support x1
JSupport
Leg x3
KSet of
Bed Slats x1
Headboard
Post
(Left Hand)
x1
LHeadboard
Post
(Right Hand)
x1
M
Footboard
Post
(Left Hand)
x1
N
Footboard
Post
(Right Hand)
x1
O
WI-0820

0021-3 Canopy Queen Bed
Assembly Instructions
Page 3 of 8
4
3
J
H
2
2
2
9
15
J
9
15
J
9
15
Note: Extra
holes on top
Assemble the Support Leg (J) to the Long Support (H).
Hardware List
Wood Dowel
(M10 x 40mm) x10
1M6 x 100mm JCB
x14
8Barrel Nut
x17
9Spring Washer
x8
10 Flat Washer
x8
11
Wood Screw
(M4 x 32mm) x18
12 Center Rail
Bracket x2
13 Allen Key
x1
14 Adjustable
Foot x3
15
2M6 x 90mm JCB
x3
3M6 x 50mm JCB
x4
4M6 x 40mm JCB
x12
6M6 x 20mm JCB
x8
7M6 x 15mm JCB
x4
5M6 x 30mm JCB
x2
WI-0820

Short Tab of
Metal Bracket (13)
7
0021-3 Canopy Queen Bed
Assembly Instructions
Page 4 of 8
6Attach the Footboard Post (N & O)
to the Footboard Panel (C) &
To p Bar- Short (E).Fit the
Footboard Support Bar (D) &
Center Rail Bracket to the
Footboard Panel (C).
Attach the Headboard Post (L & M)
to the Headboard Panel (A),
Headboard Support (B) &
To p Bar- Short (E).Fit the
Center Rail Bracket to
the Headboard
Support (B).
5
C
E
O
N
1
8
8
9
1
9
8
8
1
9
91
1
E
1
9
A
B
1
1
9
8
1
1
8
9
8
9
L
M
9
1
8
Short Tab of
Metal Bracket (13)
7
5D
5
WI-0820

0021-3 Canopy Queen Bed
Assembly Instructions
Page 5 of 8
Assemble the Side Rail (G) to the
Head / Footboard.
7
G
G
Footboard
Headboard
6
10
11
G
Head /
Footboard
WI-0820

0021-3 Canopy Queen Bed
Assembly Instructions
Page 6 of 8
Bolt the Long Support (H) to the
Center Rail Brackets on the
Head / Footboard.
8
G
Footboard
G
H
Headboard
7
H
13
Head /
Footboard
WI-0820

9
0021-3 Canopy Queen Bed
Assembly Instructions
Page 7 of 8
Bolt & screw the Bed Slats (K) to the Side Rail (G).
G
Footboard
4
4
4
12
12
12
04
04
4
K
Headboard
WI-0820

0021-3 Canopy Queen Bed
Assembly Instructions
Page 8 of 8
Fit the Top Bar- Long (F) on top of the
Head / Footboard Post.
10
G
Footboard
G
K
F
F
3
3
3
3
Headboard
WI-0820
