Bayliner 195 Configuration guide

Date of Purchase: _________________________________________________
Engine Serial Number: _____________________________________________
Hull Identification Number:__________________________________________
Hull Identification Number
The Hull Identification Number (HIN) is located just
below the deck gunnel at the starboard aft corner of the
boat.
Record the HIN (and the engine serial number) in the
space provided above.
Include the HIN with any correspondence or orders.
© 2011 Bayliner Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying,
recording or otherwise, without prior written permission of Bayliner.
Printed in the United States of America.
General Notes
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Bayliner assumes no liability resulting from errors or omissions in this document, or from the use of information contained herein.
Due to our commitment to product improvement, Bayliner reserves the right to make changes in the product design, specifications, and equipment at any time
without notice or obligation. Illustrations and/or photos may show optional equipment.
All Bayliner products meet or exceed USCG (United States Coast Guard) and/or NMMA (National Marine Manufacturer’s Association) construction standards.
Manufactured with 1,1,1 Trichloroethane, a substance which harms public health and environment during the manufacturing process by destroying ozone in the
upper atmosphere.
Proprietary Rights
This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the prop-
erty of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any
information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Bayliner. This document is to
be returned upon request to Bayliner.

CONTENTS
Chapter 1: Welcome Aboard! 1
195 Dimensions & Tank Capacities 1
215 Dimensions & Tank Capacities 1
Dealer Service 1
Warranty Information 2
Boating Experience 2
Engine & Accessory Guidelines & Literature 3
Propeller 3
Load Limit for Swim Platform
Extension (If Equipped) 3
Qualified Maintenance 4
Special Care for Moored Boats 4
Safety Standards 5
Carbon Monoxide (CO) 6
CO Facts 6
Factors that Increase the Effects of CO Poisoning 6
Where & How CO Can Accumulate 7
How to Protect Yourself & Others From CO 8
CO Checklists 8
More Information 9
Engine Compartment Fires 9
Chapter 2: Locations 10
Exterior Views 10
195 Hull Views 10
215 Hull Views 11
195 Deck Views 12
215 Deck Views 13
195 Helm 14
215 Helm 15
Component Locations 16
Chapter 3: Propulsion & Related Systems 22
Engine 22
Bilge Blower System 22
Fuel System 23
Fuel Fill & Vent 24
Fuel Filters 24
Anti-siphon Valve 24
Chapter 4: Controls & Gauges 25
Steering 25
Shift/Throttle Control 25
Power Trim & Tilt 25
Gauges 26
Cleaning the Gauges 26
Gauge Fogging 26
Radio Transmission Interference 26
Fuel Gauge 26
Depth Finder (If Equipped) 26
Chapter 5: Plumbing 27
Bilge Pump 27
Bilge Pump & Autofloat Switch -
Testing & Maintenance 27
Drain Systems 28
Deck Drains 28

Chapter 6: Deck Equipment 29
Cleats & Bow/Stern Eyes 29
Ski-Tow Ring 29
Ski-Tow Tower (If Equipped) 30
Attaching the Ski-tow Rope 30
Folding the Ski-tow Tower (If Equipped) 31
Canvas & Vinyl Tops & Enclosures 32
Canvas Care 32
Clear Vinyl Care 33
Chapter 7: Entertainment Systems 35
Audio Equipment 35
Chapter 8: Convertible Seats,
Beds, & Tables 36
Sleeper Seats (If Equipped) 36
Operating Positions 36
Lounge Positions 36
Jump Seat to Sunlounge Conversion (If Equipped) 37
Chapter 9: Lights 38
Care & Maintenance 38
Interior & Exterior Lights 38
Navigation Lights 38
Chapter 10: Electrical System 39
12-Volt DC System 40
Battery 40
Battery Switch 40
Fuses 41
12-Volt DC Accessory Outlet(s) 41
Alternator 41
Electrical Routings 42
12-Volt DC Hull Harness 42
195 12-Volt DC Deck Harness 43
215 12-Volt DC Deck Harness 43
Battery Cable Routings 44
Important Records 45
Float Plan 46

Hazard Boxes & Symbols
The hazard boxes and symbols shown below are used throughout this supplement to call attention to potentially dan-
gerous situations which could lead to either personal injury or product damage. Read all warnings carefully and fol-
low all safety instructions.
This box alerts you to immediate hazards which WILL cause severe personal injury or death if
the warning is ignored.
DANGER!
!
This box alerts you to hazards or unsafe practices which COULD result in severe personal
injury or death if the warning is ignored.
WARNING!
!
This box alerts you to hazards or unsafe practices which COULD result in minor personal
injury or cause product or property damage if the warning is ignored.
CAUTION
!
This box calls attention to installation, operation or maintenance information, which is impor-
tant to proper operation but is not hazard related.
NOTICE
CO POISONING
HAZARD!
EXPLOSION
HAZARD!
NO OPEN
FLAME!
HOT
HAZARD!
ROTATING
PROPELLER HAZARD!
FALLING
HAZARD!
ELECTRICAL
HAZARD!
FIRE
HAZARD!
RUN BILGE BLOWERS
FOR 4 MINUTES!

195 & 215 Bowriders •Owner’s Manual Supplement
1
Chapter 1: Welcome Aboard!
This Owner’s Manual Supplement provides specific information about your boat that is not covered in the Sport
Boat Owner’s Manual.
The Sport Boat Owner’s Manual contains general information about safe operating practices, general boating reg-
ulations, and general maintenance techniques.
Before using your boat, study this Owner’s Manual Supplement, the Sport Boat Owner’s Manual, and all engine
and accessory literature. When similar instructions are found in more than one manual, always refer to the specific
manufacturer’s manual first (such as the engine manual) for the most complete and accurate information.
Keep this Owner’s Manual Supplement and the Sport Boat Owner’s Manual on your boat in a secure, yet readily
available place.
Dimensions & Tank Capacities
195
215
Dealer Service
Your dealer is your key to service.
Ask your dealer to explain all systems before taking delivery of your boat.
Contact your dealer if you have any problems with your new boat.
If your dealer cannot help, call our customer service hotline: [phone] or send us a FAX: [phone].
Buy replacement parts from any authorized Bayliner dealer.
You can access on-line parts catalogs, links to vendor websites, and other helpful features by logging on
to www.baylinercustomercare.com.
Overall
Length
Length
Rigged
Bridge
Clearance Beam Draft (Hull)
Draft
(Maximum)
Fuel
Tank
19' 0" 21' 0" 7' 1" 7' 11" 1' 10" 3' 3" 35 Gallons
Overall
Length
Length
Rigged
Bridge
Clearance Beam Draft (Hull)
Draft
(Maximum)
Fuel
Tank
20' 5" 21' 2" 7' 1" 8' 2" 1' 8" 3' 1" 37 Gallons

Chapter 1: Welcome Aboard! 195 & 215 Bowriders •Owner’s Manual Supplement
2
Warranty Information
Bayliner offers a Limited Warranty on each new Bayliner purchased through an authorized Bayliner dealer.
A copy of the Limited Warranty was included in your owner’s packet.
If you did not get a copy of the Limited Warranty, please contact your Bayliner dealer or call 360-435-8957
for a copy.
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar with, for your own comfort and
safety, get handling and operating experience before assuming command of your boat.
Take one of the boating safety classes offered by the U.S. Power Squadrons or the U.S. Coast Guard Auxiliary. For
more course information, including dates and locations of upcoming classes, contact the organizations directly:
U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet at: www.usps.org
In Canada, for the CPS courses call 1-888-CPS-BOAT.
U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet at: www.cgaux.org
Outside the United States, your selling dealer, national sailing federation, or local boat club can advise you of local
sea schools or competent instructors.
CONTROL HAZARD!
An experienced operator MUST be in control of your boat at ALL times. Do NOT operate your
boat while under the influence of alcohol or drugs.
WARNING!
!

195 & 215 Bowriders •Owner’s Manual Supplement Chapter 1: Welcome Aboard!
3
Engine & Accessory Guidelines & Literature
Your boat’s engine and accessories were selected to provide optimum performance and service.
Installing a different engine or adding accessories may affect your boat’s running trim.
If you choose to install a different engine or add accessories that may affect your boat’s running trim, have a
trained marine technician perform a safety inspection and handling test before using your boat again.
The engine and accessories on your boat have their own manuals. Read these manuals before using the engine and
accessories.
Unless noted otherwise, all engine and accessory literature referred to in this supplement is included in your owner’s
packet.
While the topics listed below may be included in this supplement and in the Sport Boat Owner’s Manual, always
refer to the engine manual first for specific information on these important subjects:
Propeller
Keep the propeller in good repair and at the correct pitch for your particular situation.
A slightly bent or nicked propeller will adversely affect the performance of your boat.
Load Limit for Swim Platform Extension (If Equipped)
The swim platform extension is designed to be lightweight for proper boat balance. The load limit for the swim
platform extension is 30 pounds per square foot, evenly distributed.
BEFORE starting or working on your engine, read the engine manual.
BEFORE using the accessories on your boat, read the accessory manuals.
BEFORE storing your boat, refer to your engine and accessory manuals for storage/winter-
ization instructions.
Certain modifications to your boat WILL result in cancellation of your warranty protection.
ALWAYS check with your dealer BEFORE making any modifications to your boat.
NOTICE
Engine Break-in Procedure
Engine Starting and Stopping
Gear Shifting
Fuel and Oil Recommendations
Engine Maintenance
Engine Storage/Winterization
ENGINE DAMAGE HAZARD!
The factory standard propeller may not be the best for your particular boat and load condi-
tions. Refer to the engine manual for engine RPM ratings. The engine should reach, but not
exceed its full rated RPM when full-throttle is applied.
Immediately contact your local BRAND NAME dealer if:
The engine cannot reach its full rated RPM when full-throttle is applied, or;
The engine exceeds its full rated RPM when full-throttle is applied.
CAUTION
!

Chapter 1: Welcome Aboard! 195 & 215 Bowriders •Owner’s Manual Supplement
4
Qualified Maintenance
Failure to maintain your boat’s systems (listed in the warning above) as designed could violate the laws in your juris-
diction and could expose yourself and others to the danger of bodily injury or accidental death.
Follow the maintenance instructions in:
Special Care for Moored Boats
Whether moored in saltwater or freshwater, your boat will collect marine growth on its hull bottom.
This will detract from your boat’s beauty, greatly affect its performance, and may damage the gel coat.
Periodically haul your boat out of the water and scrub the hull bottom with a bristle brush and a solution of soap
and water.
To maintain the safety of your boat, allow ONLY trained personnel to work on, or change, in
any way, the:
Steering system
Propulsion system
Engine control system
Fuel system
Environmental control system
Electrical system
Navigation system
WARNING!
!
This Owner’s Manual Supplement
The Sport Boat Owner’s Manual
The engine owner’s manual, and;
All accessory literature.
Applying an epoxy barrier coating to the hull bottom will help prevent gel coat blistering
while your boat is moored.
Cover the barrier coating with several coats of anti-fouling paint.
Many states have environmental standards regulating the chemical content of bottom
paints. Your local dealer can recommend bottom paints approved for use in your state.
NOTICE
