Bayliner Rendezvous Configuration guide

Hull Identification Number:
The Hull Identification Number (HIN) is located on the starboard side of the transom. Be sure to
record the HIN in the space provided above and always refer to the HIN for all correspondence
or orders.
© Bayliner Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted in any
form by any means, electronic, mechanical, photocopying, recording or otherwise, without prior
written permission of Bayliner. Printed in the United States of America.
Proprietary Rights
This document discloses subject matter in which Bayliner has proprietary rights. The information
and design disclosed herein were originated by and are the property of Bayliner. Neither receipt nor
possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or
any part thereof, any information contained therein, or to construct boats or any item from it, except
by written permission from or written agreement with Bayliner. This document is to be returned
upon request to Bayliner.
General Notes
The material in this document is for information only and is subject to change without notice. While
reasonable efforts have been made in the preparation of this document to assure its accuracy, Bay-
liner assumes no liability resulting from errors or omissions in this document, or from the use of
information contained herein.
Due to our commitment to product improvement, Bayliner reserves the right to make changes in the
product design, specifications, and equipment at any time without notice or obligation. Illustrations
and/or photos may show optional equipment.
All Bayliner products meet or exceed USCG (Unites States Coast Guard) and/or NMMA (National
Marine Manufacturer’s Association) construction standards. Manufactured with 1,1,1 Trichloroet-
hane, a substance which harms public health and environment during the manufacturing process by
destroying ozone in the upper atmosphere.
TYPICAL HIN LOCATION
STARBOARD TRANSOM
BOARDING LADDER

CONTENTS
CHAPTER 1: WELCOME ABOARD!
1
Dealer Service
1
Boating Experience
1
Structural Limitations
2
Engines& AccessoriesGuidelines
2
Safety Standards
2
Qualified Maintenance
3
Special CareFor Moored Boats
3
Hazard Boxes & Symbols
CHAPTER 2: PRODUCT SPECIFICATIONS
4
2109
4
2159
4
2459
4
2659
CHAPTER 3: COMPONENTS / SYSTEMS
5Electrical System
6DC Electrical System
6Navigation Lights
7AM/FM Cassette Stereo
7Propulsion
8Bilge Systems
9Fuel System
10 Freshwater Systems
11 Live Well System (Option)
11 Portable Head
11 Deck Equipment
12
Canvas Installation
CHAPTER 4: SYSTEM DIAGRAMS
14
2109
17
21
25 2659
59
21
2459

CONTENTS
CHAPTER 5: WIRING SCHEMATICS
29 Engine/Accessory Harnesses
33 Deck Harnesses
34 Bilge Harness
34 Trolling Motor Harness
34 Water Pump Harness
35 Fuse Block Harness
APPENDIX A: LIMITED WARRANTY
36 What Is Not Covered
36 Other Limitations
36 Your Obligation

This Owner’s Manual Supplement contains
specific information about the following
Rendezvous boats:
2109, 2159, 2459, 2659

Rendezvous Owner’s Manual Supplement
1
CHAPTER 1: WELCOME ABOARD!
This owner’s manual supplement provides specific information about your boat
that is not covered in the owner’s manual. Please study the owner’s manual and
this supplement carefully, paying particular attention to Appendix A: LIMITED
WARRANTY. Keep the owner’s manual and this supplement on your boat in a
secure, yet readily available place.
Dealer Service
Make sure you receive a full explanation of all systems from the selling dealer
before taking delivery of your boat. Your selling dealer is your key to service. If
you experience any problems with your new boat, immediately contact the selling
dealer. If for any reason your selling dealer is unable to help, you can call us direct
on our customer service hotline: [phone] or send us aFAX: 360-403-4235.
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar
with, for your own comfort and safety, please ensure that you obtain handling and
operating experience before assuming command of the boat.
We strongly recommend that you take one of the boating safety classes offered
by the U.S. Power Squadrons or the U.S. Coast Guard Auxiliary. For more
course information, including dates and locations of upcoming classes, contact
the organizations directly:
• U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet
at: http://www.usps.org
• U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet at:
http://www.cgaux.org
Outside the United States, your selling dealer, national sailing federation or local
yacht club can advise you of local sea schools or competent instructors.
Structural Limitations
The transom platform and bow platform are designed to be lightweight for proper
boat balance. The load limit for these platforms is 30 pounds per square foot,
evenly distributed.
CONTROL HAZARD! A qualified operator must be in control of the boat at all
times. DO NOT operate your boat while under the influence of alcohol or drugs.
WARNING!
!

2 CHAPTER 1: WELCOME ABOARD!
Rendezvous Owner’s Manual Supplement
Engines & Accessories Guidelines
Your boat’s engines and accessories were selected to provide optimum performance
and service. Installing different engines or accessories may cause unwanted han-
dling characteristics. Should you choose to install different engines or add accesso-
ries that will affect the boat’s running trim, have an experienced marine technician
perform a safety inspection and handling test before operating your boat again.
Please be advised that certain modifications to your boat can result in cancel-
lation of your limited warranty protection. Always check with your dealer
before making any modifications to your boat.
The engines and accessories installed on your boat come with their own operation
and maintenance manuals. We strongly urge you to read and understand these man-
uals before operating the engines and accessories.
Safety Standards
Your boat’s mechanical and electrical systems were designed to meet safety stan-
dards in effect at the time it was built. Some of these standards were mandated by
law; all of them were designed to insure your safety, and the safety of other people,
vessels and property.
In addition to this supplement, please read the owner’s manual and all
accessory instruction sheets included in your owner’s packet for important
safety standards and hazard information.
Qualified Maintenance
Failure to maintain your boat’s systems as designed could violate the laws in
your jurisdiction and could expose you and other people to the danger of
bodily injury or accidental death. We recommend that you follow all mainte-
nance instructions provided in the owner’s manual, this supplement, the engine
owner’s manual as well as all accessory instruction sheets and manuals included in
your boat’s owner’s packet.
DANGER
PERSONALSAFETYHAZARD! DO NOT allow anyone to ride on
parts of the boat not designated for such use. Sitting on seat
backs, lounging on the forward deck, bow riding, gunwale riding
or occupying the transom platform while underway is especially
hazardous and WILL cause personal injury or death.
DANGER!
!
To maintain the integrity and safety of your boat, only qualified personnel
should perform maintenance on, or in any way modify: The steering system,
propulsion system, engine control system, fuel system, environmental control
system, electrical system or navigational system.
WARNING!
!

CHAPTER 1: WELCOME ABOARD! 3
Rendezvous Owner’s Manual Supplement
Special Care For Moored Boats
If moored in saltwater or fresh water, your boat will collect marine growth on its
hull bottom. This will detract from the boat’s beauty, greatly affect its performance
and may damage the gelcoat. There are two methods of slowing marine growth:
• Periodically haul the boat out of the water and scrub the hull bottom with a bristle
brush and a solution of soap and water.
• Paint the hull below the waterline with a good grade of anti-fouling paint.
Hazard Boxes & Symbols
The hazard boxes and symbols shown below are used throughout this supplement
to call attention to potentially dangerous situations which could lead to either per-
sonal injury, death or product damage. We urge you to read all hazard warn-
ings carefully and follow all safety recommendations.
NOTICE
To help seal the hull bottom and reduce the possibility of gelcoat blistering on
moored boats, we recommend the application of an epoxy barrier coating, such
as Interlux, Interprotect 2000E/2001E. The barrier coating should be covered
with several coats of anti-fouling paint.
Many states regulate the chemical content of bottom paints in order to meet
environmental standards. Check with your local dealer about recommended
bottom paints, and about the laws in effect in your area.
EXPLOSION
HAZARD!
HOT
HAZARD! ROTATING PROPELLER HAZARD!
PERSONAL INJURY
& FALLING HAZARD!
OPEN FLAME
HAZARD!
ELECTRICAL
HAZARD!
DANGER
This box alerts you to immediate hazards which WILL cause severe personal
injury or death if the warning is ignored.
DANGER!
!
This box alerts you to hazards or unsafe practices which COULD result in
severe personal injury or death if the warning is ignored.
WARNING!
!
CAUTION!
This box alerts you to hazards or unsafe practices which COULD result in
minor personal injury or cause product orproperty damage if the warning is
ignored.
!
NOTICE
This box calls attention to installation, operation or maintenance information,
which is important to proper operation but is not hazard related.

Rendezvous Owner’s Manual Supplement
4
CHAPTER 2: PRODUCT SPECIFICATIONS
2109
Length overall - 21' 3"
Beam - 8' 3"
Deadrise - 16 degrees
Weight (standard engine) - 3,1458 lb.
Draft hull - 1' 3"
Draft max - 2' 8"
Bridge clearance - 4' 2"
Fuel capacity -45 gal.
Freshwater capacity (option) -19 gal.
2159
Length overall - 21' 3"
Beam - 8' 3"
Deadrise - 16 degrees
Weight - 3,750 lb.
Draft hull - 1' 4"
Draft max - 2' 8"
Bridge clearance - 4' 1"
Fuel capacity -45 gal.
Freshwater capacity (option) -19 gal.
2459
Length overall - 24' 0"
Beam - 8' 3"
Deadrise - 17 degrees
Weight - 4,333 lb.
Draft hull - 1' 4"
Draft max - 2' 9"
Bridge clearance - 4' 3"
Fuel capacity - 65 gal.
Freshwater capacity (option) -19 gal.
2659
Length overall - 26' 5"
Beam - 8' 5"
Weight - 4,898 lb.
Draft hull - 1' 1"
Draft max - 2' 6"
Bridge clearance - 4' 5"
Fuel capacity - 57 gal.
Freshwater capacity -13 gal.
