Bayliner 2302 DXILX User manual

Hull Identification Number___________________________________________
Engine Serial Number _______________________________________________
Hull Identification Number:
The Hull Identification Number
(HIN) is located on the starboard
side of the transom. Record the
HIN and the engine serial number
in the space provided above. Refer
to the HIN for any correspondence
or orders.
© 2000 Bayliner Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted
in any form by any means, electronic, mechanical, photocopying, recording or otherwise,
without prior written permission of Bayliner. Printed in the United States of America.
Changes
The material in this document is for information only and is subject to change without notice.
While reasonable efforts have been made in the preparation of this document to assure its ac-
curacy, Bayliner assumes no liability resulting from errors or omissions in this document, or
from the use of information contained herein.
Bayliner reserves the right to make changes in the product design, specifications, and equip-
ment at any time without notice or obligation.
Illustrations and/or photos may show optional equipment.
HIN LOCATION (TYPICAL)
HULL
NUMBER
IDENTIFICATION
TRANSOM
The information in this Owner’s Manual Supplement relates to 2000 & 2001
2302 DX/LX, 2352 DX/LX 2359, DX/LX Bayliner Trophy Fishing Boats.

Contents
Chapter 1: Welcome Aboard!
1Dealer Service
1Boating Experience
1Qualified Maintenance
2Special Care For Moored Boats
2Engine & Accessories
Guidelines
3Safety Standards
3Hazard Warning Symbols
Chapter 2: Specifications &
Features
42302FP
10 2352 FN Features and Systems
16 2359 FB Features and Systems
Chapter 3: General Systems
23 Electrical System
24 12-Volt DC Electrical System
24 Fuses and Circuit Breakers
24 Batteries
24 Battery Switch (2359 FB)
25 Battery Charger (2359 FB LX)
26 AC Electrical System (2359 FB)
26 Connecting to Shore Power
28 Propulsion
28 Engine
28 Bilge Blower
29 Fuel System
29 Fuel Fills and Vents
29 Fuel Filters
29 Oil Injection System (2302 FP)
30 Trim Tabs
30 Power Trim and Tilt
31 Navigation and
Communication Equipment
31 VHF Radio (LX only)
31 Compass
31 Lighting
31 Navigation Lights
32 AM/FM Cassette Stereo
32 Alcohol Stove
32 Refrigerator (2359 FB LX)
32 Bilge Pumps
33 Bilge Pump Testing
33 Checking for clogging debris:
33 Autofloat Switches
34 Fresh Water System
34 Water Pump (2359FB LX)
34 Raw Water System
34 Seacocks
35 Head System
35 Portable Head
35 Marine Head with Holding Tank
(LX Only)
35 Macerator (LX Option)
36 Fishwells
36 Bait Well System
37 Recirculation System
(2352 FN, 2302 FP)
38 Canvas Top Installation
(2302 FP, 2352 FN)

Chapter 4: Electrical Routings
39 2302 FP Electrical Routings
39 Deck Harness Routing
40 Hull Harness Routing
40 2352 FN Electrical Routings
40 Hull Harness Routing
41 Deck Harness Routing
42 2359 FB Electrical Routings
42 Hull Harness Routing
43 Battery Cable Routings
44 Forward Deck Harness Routing
44 Mid Deck Harness Routing
45 Aft Deck
45 AC Panel Routings
Chapter 5: Wiring Diagrams
46 2302 FP Electrical System
47 2352 FN Electrical System
48 2359 FB AC Electrical System
49 2359 FB DC Electrical System
Appendix A: Limited Warranty
50 What Is Not Covered
50 Other Limitations
50 Your Obligation

23’ Trophy •Owner’s Manual Supplement
1
Chapter 1: Welcome Aboard!
Welcome aboard! This owner’s manual supplement provides specific information
about your boat that is not covered in the owner’s manual. Please study the owner’s
manual and this supplement carefully, paying particular attention to Appendix A:
Limited Warranty in this supplement. Keep the owner’s manual and this supple-
ment on your boat in a secure, yet readily available place.
Dealer Service
Make sure you receive a full explanation of all systems from the selling dealer
before taking delivery of your boat. Your selling dealer is your key to service. If
you experience any problems with your new boat, immediately contact the selling
dealer. If for any reason your selling dealer is unable to help, you can call us direct
on our customer service hotline: [phone] or send us a FAX: [phone].
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar
with, for your own comfort and safety, you must obtain handling and operating
experience before assuming command of the boat.
Take one of the boating safety classes offered by the U.S. Power Squadrons or the
U.S. Coast Guard Auxiliary. For more course information, including dates and
locations of upcoming classes, contact the organizations directly:
•U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet
at: http://www.usps.org
•U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet
at: http://www.cgaux.org
Outside the United States, your selling dealer, national sailing federation or local
yacht club can advise you of local sea schools or competent instructors.
Qualified Maintenance
Failure to maintain your boat’s systems as designed could violate the laws in your
jurisdiction and will expose you and other people to the danger of bodily injury or
accidental death. Follow the instructions provided in the owner’s manual, this
owner's manual supplement, the engine owner’s manual and all accessory instruc-
tion sheets/manuals included in your boat’s owner’s packet.
CONTROL HAZARD! A qualified operator must be in control of the boat at all
times. DO NOT operate your boat while under the influence of alcohol or drugs.
WARNING!
!

2 Chapter 1: Welcome Aboard!
23’Trophy •Owner’sManual Supplement
Special Care For Moored Boats
If moored in saltwater or fresh water, your boat will collect marine growth on its
hull bottom. This will detract from the boat’s beauty, greatly affect its performance
and may damage the gelcoat. There are two methods of slowing marine growth:
•Periodically haul the boat out of the water and scrub the hull bottom with a bristle
brush and a solution of soap and water.
•Paint the hull below the waterline with a good grade of anti-fouling paint.
Engine & Accessories Guidelines
Your boat’s engine and accessories were selected to provide optimum performance
and service. Installing different engines or accessories will cause unwanted han-
dling characteristics. Should you choose to install different engines or add accesso-
ries that will affect the boat’s running trim, have an experienced marine technician
perform a safety inspection and handling test before operating your boat again.
Please be advised that certain modifications to your boat can result in cancel-
lation of your warranty protection. Always check with your dealer before mak-
ing any modifications to your boat.
The engine and accessories installed on your boat come with their own operation
and maintenance manuals. Read and understand these manuals before operating the
engine and accessories.
To maintain the integrity and safety of your boat, only qualified personnel
should perform maintenance on, or in any way modify: The steering system,
propulsion system, engine control system, fuel system, environmental control
system, electrical system or navigational system.
WARNING!
!
NOTICE
To help seal the hull bottom and reduce the possibility of gelcoat blistering on
moored boats, Bayliner recommends the application of an epoxy barrier coat-
ing, such as Interlux, Interprotect 2000E/2001E. The barrier coating should be
covered with several coats of anti-fouling paint.
Many states regulate the chemical content of bottom paints in order to meet
environmental standards. Check with your local Bayliner dealer about recom-
mended bottom paints, and about the laws in effect in your area.
NOTICE
When storing your boat refer to your engine’s operation and mainte-
nance manuals.

Chapter 1: Welcome Aboard! 3
23’Trophy •Owner’s Manual Supplement
Safety Standards
Your boat’s mechanical and electrical systems were designed to meet safety stan-
dards in effect at the time it was built. Some of these standards were mandated by
law; all of them were designed to insure your safety, and the safety of other people,
vessels and property.
In addition to this supplement, read the owner’s manual and all accessory
instruction sheets included in your owner’s packet for important safety standards
and hazard information.
Hazard Warning Symbols
The hazard warning symbols shown below are used throughout this supplement
to call attention to potentially dangerous situations which will lead to either
personal injury or product damage. Read these warnings carefully and follow
all safety instructions.
DANGER
PERSONALSAFETYHAZARD! DO NOT allow anyone to ride on
parts of the boat not designated for such use. Sitting on seat
backs, lounging on the forward deck, bow riding, gunwale riding
or occupying the transom platform while underway is especially
hazardous and WILL cause personal injury or death.
DANGER!
!
DANGER
This symbol alerts you to immediate hazards which WILL cause severe per-
sonal injury or death if the warning is ignored.
DANGER!
!
This symbol alerts you to hazards or unsafe practices which COULD result in
severe personal injury or death if the warning is ignored.
WARNING!
!
CAUTION!
This symbol alerts you to hazards or unsafe practices which COULD result in
minor personal injury or cause product or property damage if the warning is
ignored.
!
NOTICE
This symbol calls attention to installation, operation or maintenance informa-
tion, which is important to proper operation but is not hazard related.
EXPLOSION
HAZARD!
HOT
HAZARD! ROTATING PROPELLER HAZARD!
PERSONAL INJURY
& FALLING HAZARD!
OPEN FLAME
HAZARD!
ELECTRICAL
HAZARD!

23’Trophy •Owner’s Manual Supplement
4
Chapter 2: Specifications & Features
2302FP
Dimensions and Tank Capacities
Layout View
Hull Exterior Drains & Hardware
Overall
Length Bridge Clearance Beam Draft (Drive Up) Water Capacity Fuel Tank Capacity
23’5" 7’11" 8’5" 1’7" 8 gal. 101 gal.
fish lockerfish well
bucket
seat
bucket
seat
stepstep
rope
locker
rope
locker
bucket
seat
bucket
seat
fish lockerfish well
storage
storage
storage
storage
storage
storage
storage
storage
storage
storage
storage
storage
table
table
stepstep
live
well
bait
well
cooler
cooler
galley
galley
fuel
fill
fuel
fill
coaming caps
coaming caps
coaming caps
coaming caps
jump
seat
jump
seat
jump
seat
jump
seat
BILGE PUMP
DRAIN FISHWELL DRAIN
BAITWELL DECK
DECK
FISHWELL
DRAIN
WASTE TANK
VENT (OPTION)
WATER TANK
VENT
DRAIN SINK DRAIN
DRAIN DRAIN
BOW
EYE
ANCHOR
LOCKER
DRAIN

Chapter 2: Specifications & Features 5
23’Trophy •Owner’s Manual Supplement
Transom Hardware
Foredeck Hardware
STERN EYE GARBOARD
DRAIN DECK DRAIN TRIM TAB (TYPICAL)(TYPICAL) (TYPICAL)
TRANSOM
BOWANCHOR
ROLLER NAV. LIGHTHORN (TYPICAL)CLEAT
ANCHOR
STORAGE
STBD.
FWD.

6 Chapter 2: Specifications & Features
23’Trophy •Owner’sManual Supplement
Helm Dash
Cockpit Features
TACHOMETER VOLTMETER FUEL SPEEDOMETER
ACCESSORY
SWITCHES
ACCESSORY
SWITCHES
STEERING
WHEEL CIRCUIT
BREAKERS
ROD
HOLDER
FUEL FILL
LOCATION ROD HOLDERS BATTERY ENGINE
FISHWELL
ACCESS
(TYPICAL)
TRIM TAB
PUMP ACCESS
HAWSE
PIPE
(TYPICAL)
(TYPICAL)

Chapter 2: Specifications & Features 7
23’Trophy •Owner’s Manual Supplement
Warning Labels
Bilge Pump Routing
CAPACITY
WARNING
TRIM TAB
WARNING
FUELING WARNING
LABELS
EMERGENCY
SHUTDOWN
FUEL FILL &
LABEL
LABEL
WARNING LABEL
STBD.
AFT
FWD.
THRU-HULL BILGE PUMP &
FLOAT SWITCH
AFT BILGE PUMP ROUTING
THRU-
BILGE PUMP &
FLOAT SWITCH
FWD. BILGE PUMP ROUTING
FWD.
PORT AFT
STBD.
HULL

8 Chapter 2: Specifications & Features
23’Trophy •Owner’sManual Supplement
Head & Waste Tank System (LX Only)
FWD.
PORT
VENTED LOOP
SEA WATER
PICK-UP TOILET
HEAD SYSTEM ROUTING
MACERATOR
HOLDING
TANK
WATER
PICK-UP
TOILET
TO PUMP- OUT
FITTING IN DECK
FWD.
SEA
(OPTIONAL) MACERATOR ROUTING
WASTE PUMP-
OUT FITTING
PORT DECK
PORT
FWD.

Chapter 2: Specifications & Features 9
23’Trophy •Owner’s Manual Supplement
Fuel System
Freshwater System
TO VENT
HOSE FUEL FILL
TO
FUEL
TANK
VIEW OF AFT DECK
MOTOR
FUEL FILL
AFT
STBD.
STBD. AFT
DECK
WATER FILL
ON DECK
WATER
TANK TO GALLEY SINK
FRESHWATER ROUTING WATER TANK
FITTING PORT SIDE
OF DECK
WATER FILL LOCATION
PORT FWD.
FWD.
FWD.

10 Chapter 2: Specifications & Features
23’Trophy •Owner’sManual Supplement
2352 FN Features and Systems
Dimensions and Tank Capacities
Layout View
Hull Exterior Hardware
Overall
Length Bridge Clearance Beam Draft (Drive Up) Water Capacity Fuel Tank Capacity
23’5" 7’11" 8’5" 1’7" 8 gal. 101 gal.
fish lockerfish well
bucket
seat
bucket
seat
stepstep
bucket
seat
bucket
seat
fish lockerfish well
storage
storage
storage
storage
storage
storage
storage
storage
storage
storage
stepstep
live
well
bait
well
galley
galley
coaming caps
coaming caps
coaming caps
coaming caps
removable
jump seat
removable
jump seat
removable
jump seat
removable
jump seat fuel
fill
fuel
fill
head
head
cooler
cooler
table
table
convertable
convertable
engine
compartment
BILGE PUMP
DRAIN FISHWELL DRAIN
BAITWELL DECK
ANCHOR
LOCKER
SINK
FISHWELL
DRAIN
WASTE TANK
VENT (OPTION)
WATER TANK
VENT
DRAIN BILGE PUMP DRAIN
DRAINDRAIN
BOW
EYE
DRAIN

Chapter 2: Specifications & Features 11
23’Trophy •Owner’s Manual Supplement
Transom Hardware
Foredeck Hardware
STERN EYEGARBOARD
DRAIN
DECK DRAIN TRIM TAB
(TYPICAL)(TYPICAL)(TYPICAL)
TRANSOM
BOWANCHOR
ROLLER NAV. LIGHTHORN (TYPICAL)CLEAT
ANCHOR
STORAGE
STBD.
FWD.

12 Chapter 2: Specifications & Features
23’Trophy •Owner’sManual Supplement
Helm Dash
Cockpit Features
TACHOMETER VOLTMETER FUEL SPEEDOMETER
ACCESSORY
SWITCHES
ACCESSORY
SWITCHES
STEERING
WHEEL CIRCUIT
BREAKERS
AFT PORT
ROD HOLDER
(TYPICAL)
FISHWELL
(TYPICAL)
ENGINE
ACCESS
HAWSE
PIPE
BAITWELL

Chapter 2: Specifications & Features 13
23’Trophy •Owner’s Manual Supplement
Warning Labels
Bilge Pump Routing
FUEL FILL & FUELING
AFT
STBD.
WARNING LABELS
FOREDECK
WARNING
CAPACITY
WARNING EMERGENCY
SHUTDOWN
TRIM TAB
WARNING
LABEL
LABEL
WARNING
LABEL
STBD.
LABEL
FWD.
AFT
STBD.
BILGE PUMP
FLOAT SWITCH
THRU-
HULL
THRU-
BILGE PUMP &
FLOAT SWITCH
FWD. BILGE PUMP ROUTING AFT BILGE PUMP ROUTING
HULL
FWD.
PORT

14 Chapter 2: Specifications & Features
23’Trophy •Owner’sManual Supplement
Fuel System
Freshwater System
FUEL
FUEL LINE
TO ENGINE
TO FUEL
FITTING ON
STBD. DECK
TO FUEL
VENT IN
HULL
ENGINE
COMPARTMENT
AFT
FWD.
FUEL FILL ON
STBD. DECK
STBD.
TANK
WATER FILL
ON DECK
WATER
TANK TO GALLEY SINK
FRESHWATER ROUTING WATER TANK
FITTING PORT SIDE
OF DECK
WATER FILL LOCATION
PORT FWD.
FWD.
FWD.
