bbf A191596A User manual

Part Number A191596A Keep manual for future reference.
Lot Code #
72 W Hutc

A191596A
Get Ready to Assemble

Warning Do Don't Why it's
important
Serious
injury may
occur.
• Assemble following all instructions
using all indicated parts and hardware
provided.
• Attach hutch only as described in the
instructions.
• Verify furniture is stable on it's own.
• Only place against a permanent wall
structure at least as tall as the hutch or
place back-to-back with hutch of same
size.
• Do not move unit when loaded.
• Do not load with a television or other
heavy equipment.
• Do not exceed the maximum load limits
stated in the instructions.
• Do not allow children to climb, or hang
on furniture.
Improper
assembly, use
or loading
can lead
to product
instability,
tip-over or
collapse.
Advertencia Hacer No Por qué es
importante
Se pueden
producir
lesiones
graves.
• Ensamble siguiendo todas las
instrucciones utilizando todas las
piezas y ferretería indicados provistos.
• Conecte la conejera solo como se
describe en las instrucciones.
• Verique que los muebles sean
estables por sí mismos.
• Solo colóquelo contra una estructura
de pared permanente al menos tan
alta como la conejera o colóquelo
espalda con espalda con una conejera
del mismo tamaño.
• No mueva la unidad cuando esté cargada.
• No cargue con un televisor u otro equipo
pesado.
• No exceda los límites máximos de carga
establecidos en las instrucciones.
• No permita que los niños se paren, trepen
o cuelguen de muebles.
El
ensamblaje,
uso o carga
inadecuados
pueden
provocar
inestabilidad
del producto,
vuelco o
colapso.
PLEASE READ WARNINGS
Improper use can cause safety hazards, or damage
to your furniture and household items.
IMPORTANT SAFETY INFORMATION

Avertissement Faire Ne le fais pas Pourquoi c'est
important
Des
blessures
graves
peuvent
survenir.
• Assemblez en suivant toutes les
instructions en utilisant toutes les
pièces et le matériel indiqués fournis.
• Fixez la huche uniquement comme
décrit dans les instructions.
• Vériez que les meubles sont stables
par eux-mêmes.
• Placer uniquement contre une structure
murale permanente au moins aussi
haute que la huche ou placer dos à dos
avec une huche de même taille.
• Ne déplacez pas l'unité lorsqu'elle est
chargée.
• Ne chargez pas avec un téléviseur ou un
autre équipement lourd.
• Ne dépassez pas les limites de charge
maximale indiquées dans les instructions.
• Ne laissez pas les enfants grimper ou
s'accrocher aux meubles.
Un
assemblage,
une utilisation
ou un
chargement
incorrects
peuvent
entraîner une
instabilité du
produit, un
renversement
ou un
effondrement.
PLEASE READ WARNINGS
Improper use can cause safety hazards, or damage
to your furniture and household items.
IMPORTANT SAFETY INFORMATION

A191596A
Get to know your Boards
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
A
B
N
K M
LG
E
C
F
J
D
F
H
H

A191596A
Get to know your Fasteners
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Fasteners are s own actual size.
H23682 [ 8 ]
#10 x 1"
(Black)
H28917 [ 8 ]
#6 x 1/2"
(Silver)
H108982 [ 4 ]
M4 x 20mm
(Silver)
H171556 [ 43 ]
Quickfit TL4
H181468US [ 43 ]
KD Cam3000
H38169 [ 8 ]
Wood Dowel 8 x 30
H107572 [ 1 ]
#8 x 1-1/2"
H181434 [ 1 ]
#10 x 2"
H181419 [ 1 ]
Toggle Bolt

A191596A
Get to know your Hardware
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Hardware not to scale.
H126359 [ 4 ]
Hinge
H126364 [ 4 ]
Mounting Plate
H23604 [ 4 ]
S elf Pin
H126396 [ 4 ]
S elf Pin Sleeve
H77351 [ 1 ]
Bumper (4) per pack
H191524 [ 2 ]
Pull
H85966 [ 2 ]
Bracket
[ 43 ]
Cover Cap
H181411 [ 1 ]
Nylon Cable Tie
H181412 [ 2 ]
Connecting Plate

1
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Doors
N
N
H28917 [ 8 ]
#6 x 1/2"
(Silver)
H108982 [ 4 ]
M4 x 20mm
(Silver)
H126359 [ 4 ]
Hinge
H77351 [ 1 ]
Bumper (4) per pack
H191524 [ 2 ]
Pull

2
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Panel
H171556 [ 2 ]
Quickfit TL4
G

3
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assemble Panels
H181468US [ 2 ]
KD Cam3000
[ 2 ]
Cover Cap
K
L
G
12 3 4
190°
Minimum

4
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Panel
H171556 [ 7 ]
Quickfit TL4
E

5
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assemble Panel
E
H181468US [ 4 ]
KD Cam3000
[ 4 ]
Cover Cap
G
12 3 4
190°
Minimum
K
L

6
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Assemble
E
G
H181468US [ 3 ]
KD Cam3000
[ 3 ]
Cover Cap
H171556 [ 5 ]
Quickfit TL4
12 3 4
190°
Minimum
Team Lift

7
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare panels
H
H
H126364 [ 4 ]
Mounting Plate
H38169 [ 4 ]
Wood Dowel 8 x 30
Safety glasses
Gafas de seguridad
Lunettes de protection

8
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assemble Panels
H
H
H181468US [ 2 ]
KD Cam3000
[ 2 ]
Cover Cap
12 3 4
190°
Minimum
E
G

9
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assemble Panel
H181468US [ 3 ]
KD Cam3000
[ 3 ]
Cover Cap
F
12 3 4
190°
Minimum
E
H
H
Team Lift

10
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Panel
D
H171556 [ 5 ]
Quickfit TL4

11
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assemble Panel
H181468US [ 5 ]
KD Cam3000
[ 5 ]
Cover Cap
D
12 3 4
190°
Minimum
E
G
F
Team Lift

12
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Panel
H171556 [ 3 ]
Quickfit TL4
F
D
Team Lift

13
STEP A191596A
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Panel
H171556 [ 7 ]
Quickfit TL4
C
