BC Biomedical CQM-2000 Series User manual
REM/ARM/CQM
TEST MODULE
CQM-2000 Series
USER MANUAL
i
WARNINGS, CAUTIONS, NOTICES...............................................................................ii
DESCRIPTION............................................................................................................... 1
MANUAL REVISIONS.................................................................................................... 2
LIMITED WARRANTY.................................................................................................... 2
SPECIFICATIONS ......................................................................................................... 3
NOTES........................................................................................................................... 4
BC BIOMEDICAL
CQM-2000 Series
TABLE OF CONTENTS
CALIBRATION INTERVAL
To ensure the accuracy of the CQM-2000, BC
Group International, Inc. recommends that it be
calibrated at least once every 12 months.
Calibration must be done by qualified personnel.
Contact BC Group International, Inc. for
calibration.
ii
WARNING - USERS
The CQM-2000 is for use by
skilled technical personnel only.
WARNING - USE
The CQM-2000 is intended for testing only
should never be used in diagnostics, treatment
or any other capacity where they would come in
contact with a patient.
WARNING - CONNECTIONS
All connections to patients must be removed
before connecting the DUT to the CQM-2000. A
serious hazard may occur if the patient is
connected when testing with the CQM-2000.
Do not connect any leads from the patient
directly to the CQM-2000 or DUT.
WARNING - LIQUIDS
Do not submerge or spill liquids on the CQM-
2000. Do not operate the CQM-2000 if internal
components not intended for use with fluids may
have been exposed to fluid, as the internal
leakage may have caused corrosion and be a
potential hazard.
WARNING - MODIFICATIONS
The CQM-2000 is intended for use within the
published specifications. Any application
beyond these specifications or any unauthorized
user modifications may result in hazards or
improper operation.
iii
CAUTION - SERVICE
The CQM-2000 is intended to be serviced only by
authorized service personnel. Troubleshooting
and service procedures should only be
performed by qualified technical personnel.
CAUTION - CLEANING
Do not immerse. The CQM-2000 should be
cleaned by wiping gently with a damp, lint-free
cloth.
A mild detergent can be used if desired.
CAUTION - INSPECTION
The CQM-2000 should be inspected before each
use for obvious signs of abuse and wear. The
CQM-2000 should not be used and should be
serviced if any parts are in question.
NOTICE –ABBREVIATIONS
ARM
Automatic Return Monitor
C
Celsius
CQM
Contact Quality Monitor
°
Degree(s)
DUT
Device Under Test
ESU
Electrosurgical Unit
F
Fahrenheit
kg
kilogram(s)
mm
millimeter(s)
Ω
ohm(s)
lbs
pounds
REM
Return Electrode Monitor
USA
United States of America
iv
CQM-2000 Series User Manual Copyright © 2020
www.bcgroupintl.com Made in the USA
01/20 Rev 05
NOTICE –DISCLAIMER
BC GROUP INTERNATIONAL, INC. RESERVES THE RIGHT TO
MAKE CHANGES TO ITS PRODUCTS OR SPECIFICATIONS AT
ANY TIME, WITHOUT NOTICE, IN ORDER TO IMPROVE THE
DESIGN OR PERFORMANCE AND TO SUPPLY THE BEST
POSSIBLE PRODUCT. THE INFORMATION IN THIS MANUAL
HAS BEEN CAREFULLY CHECKED AND IS BELIEVED TO BE
ACCURATE. HOWEVER, NO RESPONSIBILITY IS ASSUMED
FOR INACCURACIES.
NOTICE –CONTACT INFORMATION
BC BIOMEDICAL
BC GROUP INTERNATIONAL, INC.
3081 ELM POINT INDUSTRIAL DR.
ST. CHARLES, MO 63301
USA
1-800-242-8428
1-314-638-3800
www.bcgroupintl.com
sales@bcgroupintl.com
NOTICE –DISCLAIMER
BC GROUP INTERNATIONAL, INC. WILL NOT BE
RESPONSIBLE FOR ANY INJURIES SUSTAINED DUE TO
UNAUTHORIZED EQUIPMENT MODIFICATIONS OR
APPLICATION OF EQUIPMENT OUTSIDE OF THE PUBLISHED
INTENDED USE AND SPECIFICATIONS.
1
This manual covers the model CQM-2000 and CQM-2100 REM/ARM/CQM Test Module.
The term CQM-2000 will be used to apply to both models. Sections specific to the CQM-
2100 model will use the term CQM-2100 exclusively.
The CQM-2000 is used to test the Return Electrode Contact Quality Monitor of an
Electrosurgical Unit. The CQM-2000 provides an adjustable resistance from 0 to 210
ohms in 1 ohm increments. The CQM-2100 provides an adjustable resistance from 0 to
1110 ohms in 1 ohm increments. The internal switches are ‘make-before-break’ type to
ensure that the CQM circuit in the DUT does not see a momentary open condition.
To Operate the Unit:
•Connect the DUT Return electrodes to the CQM-2000 Test Jacks.
•Set the Resistance using the knobs on the CQM-2000 Front Panel.
Many ESUs measure a baseline resistance as the CQM connector is plugged in.
The DUT should alarm based on the following conditions:
•If the Resistance is too low, a CQM alarm should occur.
•If the Resistance is too high, a CQM alarm should occur.
•If the Resistance changes some percentage above or below the baseline
resistance, a CQM alarm should occur.
Baseline Resistance limits and percent resistance rise limits vary based on ESU
manufacturer. Consult DUT manual for these parameters.
BC BIOMEDICAL
CQM-2000 Series
REM/ARM/CQM TEST MODULE
2
Revision # Revisions Made
Rev 01 Origination
Rev 02 Updated Format
Rev 03 Updated Format
Rev 04 Format Updated, Misc. Edits
Rev 05 Addition of CQM-2100, Misc. Edits
MANUAL REVISIONS
LIMITED WARRANTY
WARRANTY: BC GROUP INTERNATIONAL, INC. WARRANTS ITS NEW PRODUCTS TO BE FREE
FROM DEFECTS IN MATERIALS AND WORKMANSHIP UNDER THE SERVICE FOR WHICH THEY
ARE INTENDED. THIS WARRANTY IS EFFECTIVE FOR TWELVE MONTHS FROM THE DATE OF
SHIPMENT.
EXCLUSIONS: THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
BC GROUP INTERNATIONAL, INC. IS NOT LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
NO PERSON OTHER THAN AN OFFICER IS AUTHORIZED TO GIVE ANY OTHER WARRANTY OR
ASSUME ANY LIABILITY.
REMEDIES: THE PURCHASER'S SOLE AND EXCLUSIVE REMEDY SHALL BE: (1) THE REPAIR
OR REPLACEMENT OF DEFECTIVE PARTS OR PRODUCTS, WITHOUT CHARGE. (2) AT THE
OPTION OF BC GROUP INTERNATIONAL, INC., THE REFUND OF THE PURCHASE PRICE.
3
RESISTANCE
RANGE (CQM-2000)
0 to 210 Ω
RANGE (CQM-2100)
0 to 1110 Ω
ACCURACY
± 0.5% Setting + 0.5 Ohm
(NOTE: Accuracy after subtraction of zero resistance.)
CONNECTIONS
Safety Jack, 4 mm
ENVIRONMENTAL AND PHYSICAL
OPERATING RANGE
15° to 40° C (59° to 104° F)
STORAGE RANGE
-20° to 65° C (-4° to 149° F)
CONSTRUCTION
Enclosure –ABS Plastic,
Face –Lexan Printed
SIZE
5.12 x 2.56 x 0.97 inches
(130 x 65 x 25 mm)
WEIGHT
≤0.4 lbs (0.18 kg)
SPECIFICATIONS
4
NOTES
NOTES
NOTES
