BCP SKY5230 User manual

SKY5230
Ver. 1
INSTRUCTION
MANUAL
35-Inch Propane Fire Pit Table

bestchoiceproducts.com
Parts are located
underneath the fire pit.
Make sure to remove all
items before use.
A propane tank will not
fit underneath the fire
pit; it should be placed
to the side in the tank
table.
bestchoiceproducts.com

CALIFORNIA PROPOSITION 65
WARNING: This product can expose you to Carbon monoxide, which is known to the State of California
to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| 3
Please retain these instructions for future reference.
WARNING
•Children are not allowed to operate this fire pit.
•Fire pit must be attended by adults at all times. Do not leave children and pets around a fire pit when in use.
•For outdoor use only; do not use in a building, garage, or any other enclosed area.
•For use with propane gas tanks only (not included).
•Improper adjustment, installation, usage, and maintenance could result in an explosion and cause
serious injury or property damage.
•Read and follow all warnings and instructions thoroughly before appliance assembly, service, and use.
•Failure to follow warnings and instructions may cause death, serious injury, or property damage.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
•This fire pit produces carbon monoxide which has no odor. Do not use in enclosed area.
•If you smell gas during operation, immediately shut o gas and extinguish flames.
•Do not use a flame to check for gas leaks.
•Only use this appliance on a hard and level surface such as concrete or rock.
•Do not use this fire pit under trees or near any other unprotected combustible area.
•Fire pit must have a minimum clearance of 72 inches above and 48 inches from the sides. Make sure
area is clear and free from combustible objects/constructions.
•Do not connect to a remote gas supply.
•Do not use with natural gas.
•Do not use solid fuel or charcoal on this fire pit.
•Do not burn anything other than what is provided.
•Do not place clothing or flammable materials near the fire pit.
•Fire pit is not intended for cooking.
•Do not place food or eat on the surface of fire pit.
•Be careful when igniting fire pit as flame may flare and cause injury.
•Do not use if lava rocks are wet. Ensure that rocks are completely dry before use.
•Keep a safe distance from the fire pit when in use. Do not sit or rest hands/feet on fire pit or tank table.
•To avoid burns, do not touch or move any part of this fire pit when in use; wait until it has completely cooled.
•Do not breathe smoke from the fire pit and avoid getting smoke in your eyes.
•Do not alter this appliance. Any alteration can cause a safety hazard.
•Do not use any accessory or fitting other than original accessories and fittings.
•Keep all electrical cords and hoses away from heated surfaces.
•Routinely check hoses for wear or abrasions. Do not use if hoses are damaged.

4 |
TANK SEAT
D
1 PC
FEET
E
4 PCS
TANK TABLE
C
1 PC
4 |
PARTS
PROPANE TANK WARNINGS
1 SET
LAVA ROCKS
A
TOOLS REQUIRED
1 AAA BATTERY
(PROVIDED)
+AAA -
COVER
1 PC
B
30 LBS
TANK TABLE
CAPACITY
LBS
•Keep propane tank at least 5 feet away from fire pit when in use.
•Make sure to organize fuel hose to prevent accidental tripping.
•Only use standard 20-pound propane tanks.
•Do not fill tank more than 80% of its capacity.
•Do not use tank if any part of it is damaged; rust and dents can be dangerous.
•Propane tank must have a collar to protect the gas valve.
•Using too much propane gas may result in gas pooling and will not burn.
•Check for leaks by brushing a mixture of soap and water on all connections. If large bubbles form when
gas is turned on, there may be a leak.
•If propane tank is leaking gas, immediately do the following:
- Turn o fire pit and disconnect tank
- Move people away from the immediate area
•Do not try to repair leaking tank. Contact a professional to repair or replace tank.
NOTE: Battery comes installed in igniter.

| 5
DIAGRAM
•Lava rocks are located in a box underneath the fire pit.
•Place rocks in fire pit and spread them according to your preference.
-You may place rocks around burner but do NOT cover the guard.
•Rocks should not be more than ¼inch above the burner holes.
•Excessive rocks will suocate the flame.
PLACING LAVA ROCKS
THERMOCOUPLE
IGNITER PIN
BURNER
GUARD
CONTROL PANEL
FUEL HOSE
REGULATOR
COUPLING NUT

6 |
E
C
D
TANK TABLE ASSEMBLY
12Place propane tank on part D tank seat.
Turn wingnut clockwise to secure tank.
NOTE: Only use standard 20-pound propane tanks.
Screw four part E feet onto the part C
tank table. If necessary, adjust feet to
level the tank table.
Place the tank table over the
propane tank.
4
Attach fuel hose to tank (see Attaching
Propane section).
3

| 7
Turn release valve on tank counterclockwise to
release gas.
ATTACHING PROPANE
1Make sure release valve on tank
is firmly screwed shut.
2Attach fuel hose regulator to the output of the
tank by turning the coupling nut clockwise.
3

8 |
OPERATING INSTRUCTIONS
REPLACING BATTERY
WARNING: Before using this outdoor fire pit, please thoroughly read and follow all warnings and
instructions written in this manual. Failure to follow warnings and instructions may cause death, serious
injury, or property damage.
NOTE: During first use, leave fire pit ignited for 20 minutes as lava rocks may pop and cause injury.
1. Push and turn control knob counterclockwise to low/ignite.
2. Press the ignitor button repeatedly to light burner.
-If flames do not ignite after 45 seconds, turn o, wait 5 minutes, and try again.
-If necessary, light burner with a match or lighter.
3. Adjust flames with the control knob.
4. When finished, push and turn control knob clockwise to o position.
5. Turn valve on propane tank clockwise to turn o gas flow.
CONTROL PANEL
If the burner is not lighting, you may need to replace the battery in the igniter.
1. Unscrew igniter button.
2. Insert AAA battery with the positive side facing outwards.
3. Replace igniter button.
OFF (ARRÊT)
LOW(BAS)
HIGH(ÉLEVÉ)
IGNITER PUSH
ALLUMEUR-POUSSER
OFF
HIGH
LOW/IGNITE CONTROL KNOB
IGNITER: PUSH TO
LIGHT BURNER

| 9
CLEANING
STORAGE
•Immediately wipe spills before they absorb into surface.
•Make sure fire pit is completely cool before cleaning.
•Use a soft brush or cloth to wipe stains and dirt.
•If necessary, clean with mild detergent and a soft cloth/sponge.
•Thoroughly dry fire pit after cleaning.
•Do not use petroleum-based or abrasive cleaners as it may damage the finish.
•Do not use rough or harsh sponges/brushes.
•Allow fire pit to cool 10 minutes before storage.
•Place cover on fire pit to protect from harsh weather.
•Do not store in direct sunlight.
•Do not store or use gasoline, or any other flammable vapors or liquids, in the vicinity of the fire pit.
•If propane tank is disconnected, do not store it in the vicinity of the fire pit.
•It is recommended that the fire pit is stored indoors during winter.
•If fire pit is stored indoors, disconnect and leave propane tank outdoors.
EXCESS FLOW SAFETY DEVICE
If too much gas is flowing into fire pit, the excess flow safety device will activate to drastically reduce
gas flow. To reset the safety device, turn fire pit o, wait 30 seconds, then turn on again.
If flames are still low, do the following:
1. Turn o fire pit and turn o gas flow from propane tank.
2. Disconnect the fuel hose from the tank.
3. Turn control knob to high and wait 5 minutes. Turn control knob to o position.
4. Reconnect fuel hose and turn on gas flow. After 30 seconds, light fire pit.

TROUBLESHOOTING
PROBLEM REASON SOLUTION
Burner not lighting with
igniter
Burner does not light
Flames blow out
Emits a lot of black smoke
Drop in gas flow, reduced
flame height
Irregular flame pattern, or
does not run length of burner
Dry electrode/burner
Clear guard of obstructions
Replace AAA battery in
igniter
Remove obstructions or clean
holes
Replace/refill tank
Fully tighten coupling nut
Straighten hose
Ice buildup on propane tank
Electrode/burner wet
Igniter pin is bent
Guard obstructed
Coupling nut loose
Bent hose
High winds Turn control knob to high
Excess flow safety device
activated
Follow steps to reset safety
device
Propane tank is empty Replace/refill tank
Excess flow safety device
activated
Propane tank is empty Replace/refill tank
Follow steps to reset safety
device
Remove obstructions or clean
holes
Burner holes obstructed
Burner holes obstructed Remove obstructions or clean
holes
Straighten hose
Bent hose
Propane tank is empty
Bend igniter pin back towards
thermocouple
Igniter battery dead
Burner holes obstructed
Replace tank
Flames lose heat in cold
weather
10 |
