BCP SKY6215 User manual

SKY6215 + SKY6216Ver. 3
42in Outdoor Firepit
INSTRUCTION
MANUAL

bestchoiceproducts.com
WARNING: DO NOT LEAVE FIRE PIT
UNATTENDED WHEN IN USE
• This product is intended for use on non-flammable
surfaces only.
• Do not use on fabric, carpets, rugs, or wood and
outdoor decks.
• Do not use this product near a side wall.
FUEL HOSE
• Do not allow the feed hose to contact the burner
tray or fire bowl as this could cause a gas leak, fire,
personal injury, and death.
• Check the hose before each use.
• A damaged, bad, or failing hose should not be used.
• Regulator and hose must go through the black ring
when installing the gas tank.
IF YOU SMELL GAS OR
BURNING RUBBER
• Do not attempt to light appliance.
• Extinguish flames and disconnect tank.
• Move people away from the immediate area.

| 3
Please retain these instructions for future reference.
•For outdoor use only; do not use in a building, garage, or any other enclosed area.
•Fire pit operates at reduced eciency in temperatures below 40°F.
•Only use this appliance on a hard and level surface such as concrete or rock.
•Do not use on plastic composite or artificial wood decks.
•For use with propane gas tanks only (not included).
•Children are not allowed to operate this fire pit.
•Fire pit must be attended by adults at all times. Do not leave children and pets around a fire pit when in use.
•Do not stand on or use any part of this item as a step ladder.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Improper adjustment, installation, usage, and maintenance could result in an explosion and cause
serious injury or property damage.
•Read and follow all warnings and instructions thoroughly before appliance assembly, service, and use.
•Failure to follow warnings and instructions may cause death, serious injury, or property damage.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
•This fire pit produces carbon monoxide which has no odor. Do not use in enclosed area.
•If you smell gas during operation, immediately shut o gas and extinguish flames.
•Do not use a flame to check for gas leaks.
•Do not use this fire pit under trees or near any other unprotected combustible area.
•Fire pit must have a minimum clearance of 72 inches above and 24 inches from the sides. Make sure
area is clear and free from combustible objects/constructions.
•Do not connect to a remote gas supply.
•Do not use with natural gas.
•Do not use solid fuel or charcoal on this fire pit.
•Do not burn anything other than what is provided.
•Do not place clothing or flammable materials near the fire pit.
•Fire pit is not intended for cooking.
•Do not place food or eat on the surface of fire pit.
•Be careful when igniting fire pit as flame may flare and cause injury.
•Do not pour water onto any part of the fire pit.
•Keep a safe distance from the fire pit when in use. Do not sit or rest hands/feet on fire pit.
•To avoid burns, do not touch or move any part of this fire pit when in use; wait until it has completely cooled.
•Do not breathe smoke from the fire pit and avoid getting smoke in your eyes.
•Do not alter this appliance. Any alteration can cause a safety hazard.
•Do not use any accessory or fitting other than original accessories and fittings.
•Keep all electrical cords and hoses away from heated surfaces.
•Routinely check hoses for wear or abrasions. Do not use if hoses are damaged.
•Be aware that items stored under the fire pit will be subject to radiant heat and could be damaged.
CALIFORNIA PROPOSITION 65
WARNING: This product can expose you to Carbon monoxide, which is known to the State of California
to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WARNING

4|
PROPANE TANK WARNINGS
•Make sure to organize fuel hose to prevent accidental tripping.
•Only use standard 20-pound propane tanks.
•Maximum gas supply pressure is 250 PSI.
•Do not fill tank more than 80% of its capacity.
•Do not use tank if any part of it is damaged; rust and dents can be dangerous.
•Propane tank must have a collar to protect the gas valve.
•Using too much propane gas may result in gas pooling and will not burn.
•Check for leaks by brushing a mixture of soap and water on all connections. If large bubbles form when
gas is turned on, there may be a leak.
•If you smell gas:
- Do not attempt to light appliance.
- Extinguish flames and disconnect tank.
- Move people away from the immediate area.
•Do not try to repair leaking tank. Contact a professional to repair or replace tank.
HARDWARE
1
20 PCS
M6 x 12mm
SCREW
M6 WASHER
2
20 PCS
M6 x 20mm
SCREW
3
1 PC
TOOLS REQUIRED
UP TO 45 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
ALLEN WRENCH
(PROVIDED)
PARTS
1 PC
LEFT LEG PANEL
A
1 PC
RIGHT LEG I
B
1 PC
RIGHT LEG II
C
2 AA BATTERIES
(PROVIDED)
+AA -

| 5
G
1 PC
DOOR
PARTS
1 PC
REAR PANEL
D
1 PC
RIGHT SIDE PANEL
E
1 PC
CONTROL KNOB
I
H
1 PC
TANK HOLDER/BASE
1 PC
FRONT PANEL
F
M
1 PC
LAVA ROCKS
1 PC
TABLE LID
J
1 PC
TABLE TOP WITH
BURNER
K
1 PC
PVC COVER
L

6|
PRODUCT ASSEMBLY
1Attach the part B & C right legs to the part E right side panel with four part 1 screws and four
part 2 washers.
Locate the part A left leg panel, then attach the part F & D front and rear panel with four part 1
screws and four part 2 washers. Attach the right leg assembly with four part 1 screws and four
part 2 washers.
NOTE: Assemble all fastenings loosely, do not tighten the panels down until final assembly.
2Flip the assembly, then attach the part H tank holder/base to the part F & D panels with four
part 1 screws and four part 2 washers.
1x12 2x12
A
E
D
B
C
F
H
1
x4
2
x4

| 7
PRODUCT ASSEMBLY
3Insert the bottom of the part G door in the part A left leg panel, then secure the top of the door
with one part 3 screw.
4Flip the assembly, then attach the part K table top to the part A, B, and C legs with four part 1
screws and four part 2 washers. Make sure the table top’s control panel fits into the recess on
the part F front panel.
Finish assembly by returning to steps 1 & 2, tightening down all bolts in the panel assembly, and
ensuring proper alignment.
3
G
K
1
x4
2
x4

8|
PRODUCT ASSEMBLY
5Place the part J table lid onto the table top and place the part I control knob onto the
control panel.
6Install the propane tank (see Install propane tank section) then add the lava rocks to the
fire bowl.
NOTE: Do not cover the burner valves with fire rocks to ensure proper flow.
J
I

| 9
INSTALLING PROPANE TANK
1NOTE: Only use standard 20-pound propane tanks.
Open the door and make sure the release valve on the tank is firmly screwed shut.
Attach the preassembled regulator from the table top (B) to the cylinder valve by turning the
regulator coupling nut clockwise. Make sure it is fastened securely and tighten connections by
hand only.
2 3
Unscrew the wingnut on the part H
tank holder, then place the tank on the
tank holder. Make sure the tank sits
completely on the stand, then tighten
the wingnut to secure the tank.
Turn the release valve on the tank
counterclockwise to release the gas,
then close the door and enjoy.
COUPLING NUT
REGULATOR

10 |
CLEANING
•Make sure the fire pit is completely cool before cleaning or storage.
•Use a soft brush or cloth to wipe stains and dirt.
•If necessary, clean with mild detergent and a soft cloth/sponge.
•Thoroughly dry the fire pit after cleaning.
•Do not submerge control panel or burner assembly in water.
•Do not use petroleum-based or abrasive cleaners as it may damage the finish.
•Do not use rough or harsh sponges/brushes.
EXTINGUISHING
1. Turn the control knob to the o position.
2. Close o the gas supply to ensure there are no leaks.
3. Allow this item to cool before handling, cleaning, or storage.
LIGHTING
1. Check that the control knob is in the "OFF" position.
2. Connect a propane cylinder and open the gas supply line.
3. Push down and hold the control knob while turning it counterclockwise to the "LOW" position (you
should hear a clicking sound), this will light the burner. If this does work, repeat this process.
4. If the burner has not lit after a second attempt, shut o the gas, wait 5 minutes, and repeat step 3.
5. If the burner does not light, use a long match or long butane lighter.
6. Adjust flame to desired level with the control knob.
INSTALLING BATTERY
1. Unscrew igniter button.
2. Insert two AA battery with the positive side facing outwards.
3. Replace igniter button.
NOTE: If the burner is not lighting, you may need to replace the battery in the igniter.

| 11
TROUBLESHOOTING
PROBLEM REASON SOLUTION
Burner not lighting
with igniter
Burner does not light
Flames blow out
Emits a lot of black smoke
Drop in gas flow, reduced
flame height
Irregular flame pattern, or
does not run length of burner
Dry burner
Clear guard of obstructions
Replace battery in igniter
Remove obstructions or
clean holes
Replace/refill tank
Fully tighten coupling nut
Straighten hose
Ice buildup on propane tank
Burner wet
Guard obstructed
Coupling nut loose
Bent hose
Turn control knob onControl knob o
High winds Turn control knob to high
Propane tank is empty
Temperature less than 40°F,
tank less than ¼full
Replace/refill tank
Propane tank is empty Replace/refill tank
Remove obstructions or
clean holes
Burner holes obstructed
Burner holes obstructed Remove obstructions or
clean holes
Straighten hose
Bent hose
Clean burner
Dirt or film on burner
Propane tank is empty
Igniter battery dead
Burner holes obstructed
Replace tank
Flames lose heat in
cold weather
STORAGE
•Allow fire pit to cool 10 minutes before storage.
•Disconnect propane tank when putting fire pit in storage. Do not store propane tank in the vicinity of
the fire pit.
•Do not store propane tank in temperatures over 120°F.
• Protect your fire pit with the PVC cover when not in use. Cover is for UV protection and not suitable for
protection from inclement weather.
•Do not store in direct sunlight.
•Do not store/use gasoline, or any other flammable vapors or liquids, in the vicinity of the fire pit.
•It is recommended that the fire pit is stored indoors during winter.
•If fire pit is stored indoors, disconnect and leave propane tank outdoors.
•For extended storage, remove the battery from the ignitor.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, unapproved modification, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
