BCP SKY5267 User manual

SKY5267 + SKY5268
Ver. 3
INSTRUCTION
MANUAL
Wicker Fire Pit Table

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

bestchoiceproducts.com
WARNING
Do not use this product
directly on a wood deck
or near a side wall.
IF YOU SMELL GAS
• Do not attempt to light appliance.
• Extinguish flames and
disconnect the tank.
• Move people away from the
immediate area.

4| | 3
bestchoiceproducts.com
WARNING
Do not allow the gas
hose to contact the
burner or fire bowl.
IF YOU SMELL
BURNING RUBBER
• Extinguish flames and
disconnect the tank.
• Move people away from the
immediate area.

Please retain these instructions for future reference.
•For outdoor use only; do not use in a building, garage, or any other enclosed area.
•Fire pit operates at reduced eciency in temperatures below 40°F or wind velocity higher than 10 mph.
•Only use this appliance on a hard and level surface such as concrete or rock.
•Do not use on plastic composite or artificial wood decks.
•For use with propane gas tanks only (not included).
•Children are not allowed to operate this fire pit.
•Fire pit must be attended by adults at all times. Do not leave children and pets around a fire pit when in use.
•Do not stand on or use any part of this item as a step ladder.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Improper adjustment, installation, usage, and maintenance could result in an explosion and cause
serious injury or property damage.
•Read and follow all warnings and instructions thoroughly before appliance assembly, service, and use.
•Failure to follow warnings and instructions may cause death, serious injury, or property damage.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
•This fire pit produces carbon monoxide which has no odor. Do not use in enclosed area.
•If you smell gas during operation, immediately shut o gas and extinguish flames.
•Do not use a flame to check for gas leaks.
•Do not use this fire pit under trees or near any other unprotected combustible area.
•Fire pit must have a minimum clearance of 72 inches above and 36 inches from the sides. Make sure
area is clear and free from combustible objects/constructions.
•Do not connect to a remote gas supply.
•Do not use with natural gas.
•Do not use solid fuel or charcoal on this fire pit.
•Do not burn anything other than what is provided.
•Do not place clothing or flammable materials near the fire pit.
•Fire pit is not intended for cooking.
•Do not place food or eat on the surface of fire pit.
• Do not firmly tighten the screws until the item is completely assembled, this may result in damage to
this product and personal injury.
•Be careful when igniting fire pit as flame may flare and cause injury.
•Do not pour water onto any part of the fire pit.
•Keep a safe distance from the fire pit when in use. Do not sit or rest hands/feet on fire pit.
•To avoid burns, do not touch or move any part of this fire pit when in use; wait until it has completely cooled.
•Do not breathe smoke from the fire pit and avoid getting smoke in your eyes.
•Do not alter this appliance. Any alteration can cause a safety hazard.
•Do not use any accessory or fitting other than original accessories and fittings.
• Do not allow the gas hose to contact the burner as this may result in a gas leak and possible explosion.
•Keep all electrical cords and hoses away from heated surfaces.
•Routinely check hoses for wear or abrasions. Do not use if hoses are damaged.
•Be aware that items stored under the fire pit will be subject to radiant heat and could be damaged.
CALIFORNIA PROPOSITION 65
WARNING: This product can expose you to Carbon monoxide, which is known to the State of California
to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WARNING

6|
PROPANE TANK WARNINGS
•Make sure to organize fuel hose to prevent accidental tripping.
•Only use standard 20-pound propane tanks.
•Maximum gas supply pressure is 250 PSI.
•Do not fill tank more than 80% of its capacity.
•Do not use tank if any part of it is damaged; rust and dents can be dangerous.
•Propane tank must have a collar to protect the gas valve.
•Using too much propane gas may result in gas pooling and will not burn.
•Check for leaks by brushing a mixture of soap and water on all connections. If large bubbles form when
gas is turned on, there may be a leak.
•If you smell gas:
- Do not attempt to light appliance.
- Extinguish flames and disconnect tank.
- Move people away from the immediate area.
•Do not try to repair leaking tank. Contact a professional to repair or replace tank.
HARDWARE
1
4 PCS
M6 x 15mm
SCREW
M6 x 20mm
SCREW
M6 x 35mm
SCREW
2
16 PCS
3
2 PCS
TOOLS REQUIRED
APPROXIMATELY
30 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
M6 WASHER
4
22 PCS
ALLEN WRENCH
(PROVIDED)
1 AAA BATTERY
+AAA -
5
4 PCS
BRACKET BRACKET WITH
FOOT
6
4 PCS
FLAT HEAD
SCREWDRIVER
BURNER
SCREW
7
4 PCS
BURNER
WASHER
8
4 PCS

| 7
PARTS
1 PC
BACK
1 PC
RIGHT SIDE
AB
1 PC
TANK SEAT
FRAME
1 PC
TANK SEAT
SUPPORT
CD
1 PC
LEFT SIDE
1 PC
DOOR
EF
2 PCS
DOOR SUPPORT
(L/R)
1 PC
TABLETOP
WITH BURNER
GH
2 PCS
GLASS SHORT
PANEL
2 PCS
GLASS LONG
PANEL
I J
1 PC
LID
1 SET
FIRE GLASS
KL
1 PC
BURNER UNIT
M
1 PC
COVER
N

8|
2Attach one side of the part C tank seat frame and part D tank seat support with two part 2
screws, a part 1 screw, and three part 4 washers.
PRODUCT ASSEMBLY
1Attach part B right side to part A back with two part 2 screws and two part 4 washers.
x2
4
x2
2
1
x2
2
AB
D
C
x3
4

| 9
PRODUCT ASSEMBLY
3Attach part E left side to the back with two part 2 screws and
two part 4 washers.
Attach the other side of the tank seat frame and tank
seat support with two part 2 screws, a part 1 screw,
and three part 4 washers.
1
E
F
x2
3
x2
4
4Pull out the tank seat frame and attach the part F door with two part 3 screws and two part 4 washers.
x5
4
x4
2

10 |
6Carefully flip the table base over and
attach it to the part H tabletop with six
part 2 screws and six part 4 washers.
Flip table onto its base.
PRODUCT ASSEMBLY
5Attach two part G door supports (L/R)
with two part 1 screws, two part 2
screws, and four part 4 washers.
x2
x2
1
x2
2
x6
2
x6
4
G
H
x4
4

| 11
PRODUCT ASSEMBLY
7Locate the part M burner unit and insert into the tabletop cavity. Make sure the burner control
panel fits in the opening on the side of the table (see diagram below)
8Secure the burner unit with four part 7 burner screws and four part 8 burner washers.
x4
8
x4
7
M

12 |
PRODUCT ASSEMBLY
10 Slide two part J glass long panels onto the brackets. Secure the brackets to the long panels by
tightening four attached screws.
9
11 Slide four part 5 brackets onto the top of the glass panels.
Secure the brackets by tightening eight attached screws.
Slide four part 6 brackets with feet onto two part I glass short panels. Secure the brackets to
the short panels by tightening four attached screws.
x4
6
x4
5
x2
I
x2
J

| 13
13 Place the part K lid.
NOTE: Hang lid on hangers when not in use.
PRODUCT ASSEMBLY
12 Place the part L fire glass (see Placing Fire Glass section) and glass panels.
K
L

14 |
CONTROL
PANEL
DIAGRAM
•Place fire glass in fire pit and spread them according to your preference.
- You may place fire glass on burner but do NOT cover the guard.
•Excessive fire glass will suocate the flame.
PLACING FIRE GLASS
GUARD
BURNER
COUPLING NUT
REGULATOR
FUEL HOSE
HANGERS

| 15
23
Attach fuel hose regulator to the output
of the tank by turning the coupling
nut clockwise.
- If door does not close, readjust position
of tank and hose until door closes.
Turn release valve on tank counterclockwise
to release gas.
INSTALLING PROPANE TANK
1NOTE: Only use standard 20-pound propane tanks.
Slide open door and place propane tank on the tank seat frame.
Turn wingnut clockwise to secure tank.
Make sure release valve on tank is firmly screwed shut.

16 |
CONTROL PANEL
CONTROL KNOB
IGNITER:
Push to light burner
IGNITE
INSTALLING BATTERY
1. Unscrew igniter button.
2. Insert AAA battery with the positive side facing outwards.
3. Replace igniter button.
NOTE: If the burner is not lighting, you may need to replace the battery in the igniter.
HIGH

STORAGE
•Allow fire pit to cool 10 minutes before storage.
•Disconnect propane tank when putting fire pit in storage. Do not store propane tank in the vicinity of
the fire pit.
•Do not store propane tank in temperatures over 120°F.
•Place cover on fire pit to protect from harsh weather.
•Do not store in direct sunlight.
•Do not store/use gasoline, or any other flammable vapors or liquids, in the vicinity of the fire pit.
•It is recommended that the fire pit is stored indoors during winter.
•If fire pit is stored indoors, disconnect and leave propane tank outdoors.
•For extended storage, remove the battery from the ignitor.
CLEANING
•Make sure fire pit is completely cool before cleaning or storage.
•Use a soft brush or cloth to wipe stains and dirt.
•If necessary, clean with mild detergent and a soft cloth/sponge.
•Black soot may develop on rocks after use; use a damp cloth to clean debris as needed.
•Thoroughly dry fire pit after cleaning.
•Do not submerge control panel or burner assembly in water.
•Do not use petroleum-based or abrasive cleaners as it may damage the finish.
•Do not use rough or harsh sponges/brushes.
•Do not clean fire pit in a self-cleaning oven.
•Do not enlarge burner holes when cleaning burner.
OPERATING INSTRUCTIONS
NOTE: Before use, inspect burner, propane tank, and connectors for damage, debris, obstructions, or dirt.
Do not operate if there is any blockage.
1. Push and turn control knob counterclockwise to low/ignite.
2. Press the ignitor button repeatedly to light burner.
- If flames do not ignite after 45 seconds, turn o, wait 5 minutes, and try again.
- If necessary, keep control knob pushed in while pressing ignitor button.
- If necessary, carefully light burner with a match or lighter. When lighting, do not push and hold
control knob for more than 10 seconds.
3. Adjust flames with the control knob.
4. When finished, push and turn control knob clockwise to o position. Place lid to cover fire glass.
5. Turn valve on propane tank clockwise to turn o gas flow.
| 17

TROUBLESHOOTING
PROBLEM REASON SOLUTION
Burner not lighting
with igniter
Burner does not light
Flames blow out
Emits a lot of black smoke
Drop in gas flow, reduced
flame height
Irregular flame pattern, or
does not run length of burner
Dry burner
Clear guard of obstructions
Replace battery in igniter
Remove obstructions or
clean holes
Replace/refill tank
Fully tighten coupling nut
Straighten hose
Ice buildup on propane tank
Burner wet
Guard obstructed
Coupling nut loose
Bent hose
Turn control knob onControl knob o
High winds Turn control knob to high
Propane tank is empty
Temperature less than 40°F,
tank less than ¼full
Replace/refill tank
Propane tank is empty Replace/refill tank
Remove obstructions or
clean holes
Burner holes obstructed
Burner holes obstructed Remove obstructions or
clean holes
Straighten hose
Bent hose
Clean burner
Dirt or film on burner
Propane tank is empty
Igniter battery dead
Burner holes obstructed
Replace tank
Flames lose heat in
cold weather
18 |

| 15
Earn points while you shop. Join today!
bestchoiceproducts.com
Give your friends 15% o their first order! For each
successful referral you’ll receive 100 points.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
