BCS BCS-NVR0801X5ME-II User manual

User Manual
Code: BCS-NVR0801X5ME-II
IP DVR BCS-NVR0801X5ME-II 8 CHANNELS
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-06-07 BCS-NVR0801X5ME-II 1/4
Warning!
Please read the user manual included in this work as it contains important information related with safety of installation and use of
the device.
Only persons who read the user manual may use the device.
The user manual must be kept because it may be required in the future. The device is to be used exclusively for purposes specified
in this user manual.
The device must be unpacked prior to starting-up. After removing the packaging make sure the device is in working order.
If the product has defects, it should not be used until it is repaired.
The product is intended for use at home and commercial use and may not be used for other than intended use.
The manufacturer is not liable for damages resulting from not adhering to the rules contained in the user manual, therefore, we
recommend to follow the aforementioned safety rules for operation and maintenance of the device. In this way you will ensure
yourself safety and avoid causing damage to the device.
The manufacturer and the supplier are not liable for losses or damages arising out of the product, including financial or intangible
losses, loss of profits, income, data, pleasure from use of the product or other products related with it - indirect, incidental or
consequential loss or damage. The above provisions apply whether the loss or damage concerns:
1. Deterioration of quality or the lack of operation of the products or products related with it due to damage as well as the lack of
access to the product when it is undergoing repair, which results in stoppage the loss of user's time or a break in business activity;
2. Improper results of operation of the product or products related with it;
3. It applies to losses and damages according to any legal category, including negligence and other losses, termination of a
contract, expressed or implied guarantee and strict liability (even if the manufacturer or the supplier was notified about the
possibility of occurrence of such damages).
Safety measures:
Particular attention at designing was directed to quality standards of the device where ensuring safety of operation is the most
important factor.
The device must be secured against contact with caustic, staining and viscous fluids.
The device was designed in such a way that it restarts operation when power supply is restored after a break.
Attention! We recommend using protections to further protect the device from possible overvoltages in installations.
Surge protectors are effective protection against accidental pass to the device voltages higher than the rated. Damages
caused by pass the voltages higher than specified in manual, are not under warranty.
Turn off the device before transporting it.
Prior to connecting the device to a power source check whether the supplied voltage is consistent with rated voltage specified in
the user manual.
Proper product disposal:
A marking of a crossed out waste bin indicates that the product may not be disposed together with other household waste in the
entire EU. To avoid possible damage to the natural environment of health due to uncontrolled waste disposal, therefore, it should be
handed over for recycling, propagating in this way sustainable use of natural resources.
To return a worn-out product, use a collection and disposal system of this type of equipment or contact a seller from whom it was
purchased. He will then be recycled in an environmentally-friendly way.

User Manual
Code: BCS-NVR0801X5ME-II
IP DVR BCS-NVR0801X5ME-II 8 CHANNELS
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-06-07 BCS-NVR0801X5ME-II 2/4
Standard: TCP/IP
Supported resolutions:
8 @ 3840 x 2160 px,
8 @ 3072 x 2048 px,
8 @ 2560 x 1920 px,
8 @ 2688 x 1520 px,
8 @ 2048 x 1536 px,
8 @ 1920 x 1080 px,
8 @ 1280 x 720 px,
Video outputs: 1 pcs HDMI
1 pcs VGA
Audio support: 8 Channels - Audio from cameras, Bi-directional audio streaming support
Audio inputs: 1 pcs Microphone - CINCH
Audio outputs: 1 pcs - CINCH
Image compression method: H.265 / H.264 / MJPEG
Maximal total frame rate:
200 fps @ 3840 x 2160 px,
200 fps @ 3072 x 2048 px,
200 fps @ 2560 x 1920 px,
200 fps @ 2688 x 1520 px,
200 fps @ 2048 x 1536 px,
200 fps @ 1920 x 1080 px,
200 fps @ 1280 x 720 px,
Supported hard drives: 1 x 6 TB SATA
Recording modes: Manual, Motion Detection, Schedule
Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
DDNS, IP Filter, PPPoE, FTP, IP Search, ONVIF 2.4, ONVIF
External storage devices backup: Backup to USB drive (pendrive)
Searching and playback the records:
Records searching: by time and events type. Records playback: forward, backward,
fast, slow
Advanced searching (to the one second accuracy)
All channels synchronous playback, Smart Search function
Bitrate: max. 80 Mbps
Network functions: Full support via network, Remote records copying, Web Server built-in
max. 128 on-line users
ONVIF: 2.4
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P)
• Android: Free application gDMSS Plus or DMSS
• iOS (iPhone): Free application iDMSS Plus or DMSS
Default admin user / password: admin / admin
Default IP address: 192.168.1.108
Web browser access ports: 80, 37777
PC client access ports: 37777
Mobile client access ports: 37777

User Manual
Code: BCS-NVR0801X5ME-II
IP DVR BCS-NVR0801X5ME-II 8 CHANNELS
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-06-07 BCS-NVR0801X5ME-II 3/4
RTSP URL:
rtsp://admin:hasł[email protected]:554/cam/realmonitor?channel=1&subtype=0 -
Main stream
rtsp://admin:hasł[email protected]:554/cam/realmonitor?channel=1&subtype=1 - Sub
stream
Alarm inputs / outputs:
PTZ control: IP Speed Dome Cameras
Motion Detection: 22 x 18 motion zones
Intelligent Image Analysis:
Mouse support:
IR remote controller in the set:
Power supply: 12 V DC / 2 A
Weight: 0.822 kg
Dimensions: 260 x 232 x 47 mm
Supported languages: English, Polish
Country of origin: China
Manufacturer / Brand: BCS
Guarantee: 2 years
For products purchased after 01.01.2018, a 3-year warranty applies
Front panel:
Rear panel:

User Manual
Code: BCS-NVR0801X5ME-II
IP DVR BCS-NVR0801X5ME-II 8 CHANNELS
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-06-07 BCS-NVR0801X5ME-II 4/4
In the kit:
