BCS BCS-8256BDNV User manual

Color Day & Night Vandal-Proof Dome Camera
INSTRUCTION MANUAL
Before operating this unit, please read this manual
thoroughly and retain it for future reference.
E ~ RoHS ISO 9001:2000

• Content
FCC Informalion -------------------------------------------------------------------------------------------------- 1
Wa rning------------------------------------------------------------------------------------------------------------- 1
Descri plion --------------------------------------------------------------------------------------------------------- 1
Ca me ra Fealu res------------------------------------------------------------------------------------------------- 2
Ca me ra Layoul ---------------------------------------------------------------------------------------------------- 2
Insla Iialion Inslruclio n------------------------------------------------------------------------------------------- 2
Fun clion Descri plion--------------------------------------------------------------------------------------------- 3
Specifi calion------------------------------------------------------------------------------------------------------ 3
• FCC Information
This equipment has been tested and found to comply with the limits of a class A digital device, pursuant to part 15 of
the FCC rules and also guaranteed with CE approval. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be
required to correct the interference at his or her own expense.
The user's manual or instruction manual for an intentional or unintentional radiator shall caution the user that
changes or modifications not expressly approved by the party responsible for compliance could void the users'
authority to operate the equipment.
• Warning
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
~ Handle the camera with care.
Be careful while handling or installing the camera. Do not drop it or subject it to strong shock or vibration to prevent
any damages to it. Do not disassemble it or place it on an unstable base.
~ Never face the camera toward the sun.
The camera's picture may be influenced when working in unusual brightness environment. Sun light may do
influence on the picture quality or camera itself. Never aim the camera at the sun or other extremely bright objects
whether it is in use or not.
~ Operation temperature.
This camera is designed for use in general purpose indoor CCTV application. Only operate your camera between
the temperature of -10·C to +60·C 14·F to 140·F)
• About this Manual
Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for later use.
• Description
High impact polymer dome withstands hammer impacts
The Vandal Resist Dome Cameras are super tough and easy to position anywhere. They work effectively on ceilings
or walls with fully adjustable tilt and swivel for maximum flexibility. Mounted in a virtually indestructible metal vandal
resistant housing, it has been withstood our jeep test, hammer and baseball bat bashing.

. Camera Features
• 420 TV Lines
• 1/3" Sharp CCD
• Waterproof (IP66) and Fireproof
• Min. illumination at 0.5 Lux, F 1.4
• Auto Back Light Compensation
• Auto Electronics Shutter
• Vandal Resist more than 30Kg rating
. 1 Camera Layout
(1). Waterproof gasket
(2). Pointed screw
(3). Main body, main frame
(4). Camera lens
(5). Flame-proof clear cover
(black inner cover included)
(6). Gasket, pad
(7). Metal ring for upper cover
(8). Special wrench
(9). Waterproof screw
2
3
4
. 1 Installation Instruction
(2)
(3)
(4)
5)-4 -\:;2
(8)
(9)
: (6)
(7)
a. Select a ceiling where you want to install the camera. Place the attached waterproof gasket. Use a driver to
tighten the attached pointed screws. Fixed above 1 -4 articles in order.
b. Put the flameproof clear cover (5) on the flute of the fixed base.
(Note: The black inner cover should not block the camera lens )
c. Use the special wrench (7) to turn the metal ring (6) of the upper cover till the flame-proof cover (5) is tightened.
""Note: While you turn the metal ring (6) of the upper cover, do not allow the flame-proof clear cover to turn The
metal ring (6) of upper cover is sharp. Be careful
d. Use a slot type screwdriver to tighten the waterproof screw (8)
2

. Function Description
1. Auto Electronics Shutter (AES)
When using a DC Drive or Video Drive Auto Iris Lens. turn off the AES. When a Fixed Iris or Manual Iris Lens is
used. turn the AES on to adjust the shutter speed automatically.
2. Automatic Gain Control (AGC)
AGC can automatically amplify the digital signal to adjust for the difference of light level.
3. Auto Tracking White Balance (ATW) Auto White Balance (AWB)
When the color difference is too obvious. turn the AWB on to have better balanced color. Set the switches to
ATW to have a normal color picture.
4. Back Light Compensation (BLC)
When BLC is ON. the AGC. AES and IRIS operating point is determined by averaging over the center area
instead of entire field-of-view. so that a dimly-lit foreground object at center area can be clearly distinguished
from brightly-lit backgrounds. When operating the camera outdoor. turn the BLC on to get clear picture of
object on screen. For indoor or in low light environment. the camera will turn the BLC ON as well.
. Specification
Item NO. BCS-8256BDNV
Description 1/3 Color Vandal Resist Day & Night Dome Camera
Pick up Element Sharp CCD Image Sensor
Number of Pixels <NTSC> 510 (H) x 492 (V) <PAL> 512(H) x582(V)
Back Light Compensation ON
Auto Electronics Shutter ON
AGC ON
ATW ON
Sync. Mode Internal Sync.
Scanning System 2:1 Interlace
Resolution 420TVL
SIN Ratio More than 48dB
Gamma 0.45
Minimum illumination 0.92 Lux. F 1.4
Horizontal Sync. Frequency <NTSC> 15.734 KHz <PAL> 15.625 KHz
Video Output 1.0 VP-P. 75 ohm
Power Source ACIDC(12-24
)V
Power Consumption 3.6W
Operating Temperature -10'C to +60'C
Waterproof IP66
Lens Amount 3.6mm Board Lens (Standard)
Shutter Control <NTSC>
1/60-1/100.000 sec. <PAL> 1/50-1/100.000 sec.
Dimension 126
(0) x 80(H) mm
Net Weight <DC Type> 0.85kg
