FLAIL MOWER
CAR-TMXXXX
OPERATIONS & PARTS MANUAL
FOR MODELS:
• CAR-TM1300
• CAR-TM1600
• CAR-TM1900

TABLE OF CONTENTS
3SAFETY
9PRODUCT SPECIFICATIONS
10 OPERATION
13 SERVICE & MAINTENANCE
15 STORAGE
16 TROUBLESHOOTING
17 EXPLODED VIEWS & PARTS LISTS

CAR-TMXXXX USER MANUAL 3
The presence of this symbol of danger in the manual points out important instructions
concerning safety. It is first of all meant for the operator. The operator shall comply with the
compliance with the warning contained in the message by himself but also by other people
exposed to the machine risks. Lack of compliance with the instructions can cause damage
to people which could sometimes even be cause of death.
This “instruction” symbol in the manual points out important instructions concerning the
correct start-up, operation and in general conditions which could jeopardize the life of the
product.
FOREWORD
CARONI SPA would like to thank you for your preference in choosing our quality machines.
Aiming at obtain the longest possible eciency of the machines, you have purchased, we kindly invite
you to read and thoroughly understand the instructions for use and maintenance in this manual. A careful
compliance with these instructions permits to prevent troubles and accidents or injuries caused by
carelessness or lack of compliance with the safety standards and in that case our company shall not be held
liable.
This manual complies with the requirements of the machine directive 98/37/EC. This manual is integral with
the machine and shall therefore accompany the machine should it be sold to a new user.
i
The instructions contained in this manual should be read carefully before carrying out any operation with
and on the machine, in order to work in safety and preserving its correct operation.
Apart from the main technical and safety features of the machines, the manufacturer reserves the right of
carrying out modifications to the machine at any time for reasons of ongoing technical and technological
evolution without having to be fined for that.
Furthermore, we stress the fact that the only expected use of this machine is the one described in the
manual, any other application is forbidden.
MARKING AND IDENTIFICATION
MARKING
Each machine bears the EC identification label (for its position see fig. 4). Which contains not only the EC
mark but also the following data:
A – Manufacturer logo
B – Model
C – Serial number
D – Year of manufacture
E – EC mark of conformity
F – Mass in kg

4 CAR-TMXXXX USER MANUAL
WARNING PICTOGRAMS
The following warning pictograms can be found on the machine (see fig. 4)
1. Identification Signal: Indicates the data relevant to the machine.
2. Indication Signal: Indicates the direction of rotating of the machine.
3. Warning Signal: Indicates it is necessary to fill the reduction unit with oil when the piece of equipment is
used for the first time.
4. General Danger: Before any intervention, read the manual carefully.
5. Warning Signal: Indicates the rpm of the power takeo.
6. Danger of Limb Shearing: Do not insert your limbs within removing parts. Anyway, before any intervention
make sure the tractor engine is o.
7. Danger of Object projection: Keep at safety distance while working.
8. General Danger: Do not remove guards when parts are in motion.
9. General Danger: Do not climb on machine when parts are in motion.
Aerial noise and technical test data
TYPE OF
MACHINE
FTL-TL-FRTL
0900
FTL-TL-FRTL
1200
FTL-TL-FRTL
1500
FTM-TM-TRTM
1300
FTM-TM-TRTM
1300
FTM-TM-TRTM
1900
PTO RPM 540
Engine RPM 2000
Tractor power
supply Diesel Oil
Tractor KW 37
Lpa (dBA) 89
Lwa (dBA) 106
Acoustic power has been measured according to pos. D4 and D5 of EN standard 1553
Acoustic pressure has been determined analytically by means of acoustic power at a distance defined by pos
D224 a) of EN standard 1553
THIRD POINT HITCH CATEGORIES
CATEGORY 1: Third Point Hitch
Rear Flail Mowers: TL0900 / TL1200 / TL 1500 / TM1300 / TM1600 / TM1900
Front Flail Mowers: FTL0900 / FTL1200 / FTL1500 / FRTM1300 / FRTM1600 / FRTM1900
Front and Rear Flail Mowers: FRTL / FRTL1200 / FRTL1500 / FRTM1300 / FRTM1600 / FRTM1900
CONDITIONS AND LIMITS OF USE
The destination of use of the flail mowers is finalized to cultivating the ground through a series of
mechanical parts (tines) rotating on a horizontal axis parallel with the ground.
The machine is designed to be connected exclusively with the three-point hitch of a tractor and driven by
the PTO mounted on the tractor.
Choose the tractor based on the power, loads, and overhang given in the table by using the data declared by
the tractor manufacturer.
Any use apart from the specified one shall be considered improper, very dangerous and therefore prohibited.
In particular we wish to highlight the fact that it is forbidden to use the machine to carry people, animals or
loads.
For all the operations of use, adjustment and maintenance a single operator will be enough.
The presence of other people during the operations for linking the piece of equipment to the tractor is
allowed only when the PTO is detached, the tractor engine is o and the brake is pulled. In fact, in such a
situation do not displace the tractor but the mower, by using a suitable piece of equipment.

CAR-TMXXXX USER MANUAL 5
Should it be impossible to find the data useful to choose the right tractor, the user shall make sure of having
someone check that suitable safety margins are applied at work, the max. load limit of the axles is not
exceeded and the breaking ability is adequate.
TYPE OF MACHINE (FTL-M / FRTL-M / TL-M) 0900 1200 1500 1300 1600 1900
Mass (Kg) 195 218 228 261 293 318
Position of the barycenter in working
conditions (mm) ‘X‘ 463
Position of the overhang in working conditions
(mm) ‘Y‘ 860
Position of the barycenter in transfer
conditions (mm) ‘X1‘ 433
Position of the overhang in transfer conditions
(mm) ‘Y1‘ 830

6 CAR-TMXXXX USER MANUAL
USE IN SAFETY CONDITIONS
Most accidents that take place at work, maintenance operations and machine displacement are due to lack
of compliance with the most elementary norms of accident prevention.
Therefore, it is essential for those who are authorized to use the machines to read and thoroughly follow
both the instructions below and the stickers applied to the machine.
1. Read this manual carefully before carrying out any operations of use, adjustment and maintenance.
2. Always stop the tractor engine, wait until all moving parts have stopped and detach the PTO shaft, before
carrying out any operations for adjustment, maintenance or cleaning. Always rest the machine on the
ground or on strong stands. Never lay down under the machine without these stands or without checking
the stability of the machine.
3. Before use always make sure the screws or the nuts are tight, specially for blades or tines.
4. Always work with guards mounted, both on machine and PTO shaft. Should the guards be damaged, they
should be replaced at once.
5. Keep anyone and all animals away before starting your machine. The dangerous area extends 15 meters
around the machine.
6. Be particularly careful when working along roads or paths because of the possible projection of stones.
Never exceed the prescribed slopes when using your tractor and always avoid particularly steep working
areas.
7. Operate with suitable lighting only
8. A tractor with a cabin to protect the operator should be preferred.
9. Do not let the machine run unattended.
10.During checks and repairs make sure no one can start the machine accidentally.
11. Wear tight clothes without any loose parts which could be caught in moving parts or in the machine
rotating parts. Wear accident prevention shoes and wear gloves if you have to handle blades or parts with
sharp edges. In case of extended use and on tractor with no cabin use suitable sound deadening devices
(ear plugs or head sets).
12. Do not carry people or property on the machine or tractor at work during a road transfer
13. The PTO shaft guards shall always be in good operating conditions at work and fixed with the safety
chains preventing them from turning. Should the guards be damaged or worn, replace them immediately
with other original guards
14. Or circulating on public roads, the operator shall make sure his/her machine complies with the
current highway code and shall personally comply with the current standards in force in their country
scrupulously.
15. For your safety and that of any third parties and not to make the guarantee null and void, use original
spare parts only. Use the required personal protection means at all times.
16. Mind the dangers any rotating tools may cause.
17. Always use the machine on a grassy ground. Stop the gearbox to stop the tines for transportation or
when crossing areas with no grass.
18. CARONY SPA shall not be liable for lack of compliance with these standards
START-UP
Carry out all the operations for start-up when the tractor engine is stopped, the PTO shaft is disconnected
and all the transmission parts to the tools are stopped.
Before start working fill the gearbox with oil HD 80 W 90. When closing the cap, do not tighten it too tight
in order to prevent the gasket deformation which could generate oil leaks.
Check the direction of rotation and the rpm of the tractor and of the machine PTO, which shall necessarily
be the same as the ones signaled on the machine next to the PTO with two yellow stickers.
DANGER
It is forbidden to use the machine at a speed either than the one specified in the label.
USE ONLY
CE marked PTO shaft with guards. Once the machine has been hitched to the tractor, check the exact
length of the PTO shaft.

CAR-TMXXXX USER MANUAL 7
IN THE VARIOUS WORKING POSITIONS
the PTO shaft transmission hoses shall telescopically insert of at least 150mm as shown in the figure
below. Repeat the check when the tool is hitched to a dierent tractor.
ANY MODIFICATIONS
to the PTO shaft are strictly prohibited. It is strictly prohibited to cut the PTO shaft in order to adapt its
lenght.
i
THE PTO SHAFT GUARDS
Shall be still and in good conditions while the PTO shaft rotates, therefore, only the pre-stablished chains
shall be used. For your safety, when the PTO shaft guards are worn, they shall promptly be replaced.
When the machine is not in service, to prevent the PTO shaft from resting on the ground, use the extra
chain supplied in our kit rather than the two small rotation-proofing chains supplied with the PTO shaft.
Never leave the PTO shaft on the ground. When the PTO shaft is being clutched in, make sure it is
correctly locked in position.
COMMISSIONING.
See picture nr. 1
1. Position U-Bolt “6” and tighten screws “7”, washers “8” and nuts “9”. For models with displaceable hitch,
choose the position most suitable for your work.
2. Place guards “2” (Which shall never be removed for safety reasons) and for packaging cannot be
mounted before shipment. Tighten them with screws “3” and washers “4”. Place the plastic PTO guard “5”
by interposing the preset reinforcement disc under the screws (Guards “2” are necessary and demanded
for the CE European market only).
3. Fill the gearbox with oil as shown in the table on page 8 of the manual. Then grease points 1 with EP2
grease every 8 to 10 hours’ work.
Adjustment of belt tension and cutting height
See picture nr. 2
1. A correct stretch of the belts will let your machines run smoothly for their best performance. Every 10
hours’ operation check the belt stretch carefully. Proceed as follows after the tractor engine o and
waiting until all moving parts have stopped:
• Remove the guard
• Tighten nut “10” to stretch the belts, loosen the belts
• Mount the guard back in place
2. Proceed as follows after switching the tractor engine o and waiting until all moving parts have stopped:
• Lift and rest the machine on solid stands
• Loosen and remove screws “11” and adjust the height by lowering shoe “12” and roller “13” to the same
height.
• Repeat the operation on the opposite shoe. Remember that to be able to use the machine correctly, shoe
“12” and roller “13” shall work at the same height. For packaging reasons, the roller can be positioned
higher

8 CAR-TMXXXX USER MANUAL
MAINTENANCE
Carry out all the operations for start up, when the tractor engine is stopped, the PTO shaft is
disconnected and all the transmission parts to the tools are stopped.
Once your work is over, wash the underframe thoroughly in order to keep the machine perfectly
eective.
Use only original cutting tools in order to guarantee your safety and that of any third parties (also for
guarantee purposes).
Oil Quantity and Greasing
BEFORE STARTING
working fill the gearbox with oil HD 80W-90. After the first 40 hours’ work change the oil of the gearboxes
by draining them o the drain plug. Fill with oil of the prescribed type through the topping up cap and
check the quantity of oil filled in on the level rod. See table below. Dispose of the exhaust oil according to
the current regulations. Do not abandon them in the environment.
i
Grease the points specified in pos. 1 fig. 1 every 10 to 12 hours. Use grease EP2.
Tine Replacement
See picture nr. 3
WARNING
Before carrying out any intervention on the machine, make sure the tractor engine is o, the PTO shaft
has been detached from the PTO and all moving parts have stopped.
To replace the blades proceed as follows:
1. Lift and rest the machine on solid stands
2. Loosen nut “14” and take out screw “15”, position the new tines as shown by figure 3.
3. Tighten screw “15” and nuts “14”.
4. Not to apply any stresses or useless vibrations to the machine, we recommend you replace all the tines at
the same time.
Once your work is over, wash the underframe thoroughly in order to keep the machine perfectly eective.
WARNING
Use original cutting tools in order to guarantee your safety and that of any third parties (also for
guarantee purposes).
TRANSPORT AND STORAGE
Transport can be carried out with dierent means also in view of the destination site.
To make transportation easier, shipment can be carried out after disassembling a few parts, duly protected
and packed. While unpacking, check the integrity and correct quantity components. The packaging material
shall be disposed of in compliance with the current laws.
The personnel loading, unloading and handling the machine shall have abilities and experience acquired
and acknowledged in this specific field.
To take the machine out of its packing correctly, we recommend you use the 4 holes as shown in the
figure below with bolts and belts required by the current standards relevant to load handling. If the
machines are packed two by two, use the 4 holes as shown in the figure below and loosen the coupling
screw on the shoes. Before you loosen the screw, we recommend you make sure the machines rest on
even ground to avoid shocks against the gearbox.

CAR-TMXXXX USER MANUAL 9
During the period when the machine is not used, carry out the cleaning and maintenance operations
specified in chapter 6 of the manual and store the machine in a dry and sheltered place.
To transport the machine on public roads, follow the highway code in force in your country.

10 CAR-TMXXXX USER MANUAL

CAR-TMXXXX USER MANUAL 11

12 CAR-TMXXXX USER MANUAL
BREAKDOWN CAR-TMxxxx
EXPLODED VIEW & PARTS LIST

CAR-TMXXXX USER MANUAL 13
REF PART NUM DESCRIPTION QTY
1 1234 Fitting 6
2 10004300 Belt Stretcher 1
3 1546 Cir Clip 2
4 1545 Cir Clip 6
5 1112 Bearing 2
6 20005610 Stretcher 1
7 1088 Screw 14
8 10013200 Rotor 1900 1
10012900 Rotor 1600 1
10012600 Rotor 1300 1
9
1220
Nut 1900 24
Nut 1600 20
Nut 1300 28
10 2000700 Support 1900 24
Support 1600 20
Support 1300 56
11 10007400 Blade 1900 48
Blade 1600 40
Blade 1300 28
12 1407 Screw 1900 24
Screw 1600 20
Screw 1300 1
13 10008300 Support 23
14 1227 Washer 23
15 1091 Nut 1
16 10003500 Roller 1900 1
10006500 Roller 1600 1
10006600 Roller 1300 1
17 10002700 Scraping 1900 1
10006900 Scraping 1600 1
10007000 Scraping 1300 1
18 1439 Key 3
19 1994 Screw 6
20 1874 Bearing 2
21 20008200 Washer 2
22 10008200 Support 1
26 10002300 Frame 1900 1
10005400 Frame 1600 1
10005500 Frame 1300 1
27 10001600 Support 2
28 1206 Oil Seal 2
29 1872 Bearing 2
30 1240 Cir Clip 3
31 1568 Washer 2
32 1572 Cir Clip 2
REF PART NUM DESCRIPTION QTY
33 10006300 Cover 1
34 1659 Screw 6
35 10013500 Complete Trans. Box 1
36 1078 Screw 6
37 2011 Screw 2
38 1225 Washer 18
39 1080 Nut 18
40 10007800 Pin 1
41 15001510 Pin 4
42 1183 Lynch Pin 4
43 59003800 Pin 2
44 10003800 Blade 2
45 1829 Washer 2
46 1027 Nut 2
47 10003000 Hitch Frame 1
48 1357 Nut 2
49 2142 Belt 3
50 10005900 Pulley 1
51 1870 Fitting 1
52 10006020 Pulley 1
53 10005800 Spacer 1
54 1868 Oil Seal 1
55 10006100 Cover 2
56 1080 Nut 18
57 1225 Washer 18
58 1571 Cir Clip 1
59 1222 Nut 5
60 1231 Washer 4
61 10001200 Cover 1
62 10003700 Skid Right 1
63 10003600 Skid Left 1
64 10006200 Guard 1900 14
Guard 1600 12
Guard 1300 10
65 10004600 Axle 1900 1
10004500 Axle 1600 1
10004400 Axle 1300 1
66 1556 Lynch Pin 2
67 20005800 Pin 1
68 10009000 Spring 1
69 1558 Nut 2
70 10000900 Spacer 1
71 10007300 Pin 1
72 1222 Nut 1

14 CAR-TMXXXX USER MANUAL
PHONE: [phone]
FAX: [phone]
TOLL FREE PHONE: [phone]
TOLL FREE FAX: [phone]
BRABEREQ.COM
[e-mail]
