Beam aura-t TP536/BEAM User manual

EN
axco MVHR controllerOwners Manual
aura-t TP536/BEAM

2
Warnings, Safety information and
Guidance
Important Information
Read instructions fully before the installing this appliance.
1. This manual covers the operation of the MVHR control
system only, it must therefore be read in conjunction with
the relevant heat recovery unit Product Manual.
2. Installation of the appliance and accessories must be car-
ried out by a qualied and suitable competent person and
be carried out in clean, dry conditions where dust and
humidity are at minimal levels.
3. All wiring must conform to current I.E.E. Wiring Regula-
tions and all applicable standards and Building Regula-
tions.
4. aura-t must be connected using the communication cable
provided.
5. Control & communication cables should not be placed
within 50mm or on the same metal cable tray as any 230V
lighting or power cables.
6. Ensure all cable glands are fully tightened.
7. The unit must be stored in a clean and dry environment.
Do not install the appliance in areas where the following
may be present or occur;
• Excessive oil or a grease laden atmosphere,
• Corrosive or ammable gases, liquids or vapours,
• Ambient temperatures above 40°C or below -5°C,
• Humidity levels above 90% or is a wet environment.

3
8. The appliance is not suitable for installation to the exterior
of the dwelling.
9. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the
hazards involved.
10.Children should be supervised to ensure that they do not
play with the appliance.
11.To avoid damaging the touch screen, do not operate it
with sharp or hard objects; do not apply excessive nger-
tip pressure.
12.Do not use abrasive cleaners, waxes, solvents or alcohol
based cleaning products; do not use paper towels for
cleaning the aura-t.

4
Warnings, Safety information and Guidance
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . .2
Product Overview
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Packaging Contents. . . . . . . . . . . . . . . . . . . . . . . .5
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Speed Selection & Display . . . . . . . . . . . . . . . . . .6
24 Hour Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Day of Week Display . . . . . . . . . . . . . . . . . . . . . . .6
Boost Overrun Timer . . . . . . . . . . . . . . . . . . . . . . .6
Internal Humidity Sensor . . . . . . . . . . . . . . . . . . .6
Filter Change Alert. . . . . . . . . . . . . . . . . . . . . . . . .6
Programmable Speeds . . . . . . . . . . . . . . . . . . . . .6
Boost Inhibit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Status Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
User Interface
Menu Tabs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Run Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Status Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Other Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installation
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fixing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Fan Commission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Controller Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Summer Bypass Setup . . . . . . . . . . . . . . . . . . . 18
Passcode Enable / Disable. . . . . . . . . . . . . . . . . 18
Switch Setup Menu . . . . . . . . . . . . . . . . . . . . . . 19
Maintenance
Cleaning Exterior . . . . . . . . . . . . . . . . . . . . . . . . 20
Appendix
aura-t Congurable Defaults . . . . . . . . . . . . . . . . . . . 20
axco MVHR Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Contents

5
Product Overview
Description
The aura-t is a programmable touch screen controller which monitors and displays
the status of a BEAM MVHR unit. It allows the unit to be commissioned, and gives the
user both manual and timed control of fan speeds. The aura-t is connected to the
MVHR via a low voltage connection and can be sited remotely from the unit.
Packaging Contents
Inspect the unit when taking delivery. Check the unit for damage and that all
accessories have been supplied.
Package supplied with:-
1 x aura-t controller.
1 x ~3m aura-t communication cable.
1 x Product Manual.
Any shortages or damage must be immediately reported to the supplier.
Dimensions
23.70
87
87
aura-t

6
Features
The following gives an outline description for each of the product features.
Filter Change Alert
The aura-t will display an alert after a
specied time when the MVHR lters
require changing. Filters should be
changed yearly. Replacment lters
availbale from:
www.beamcentralsystems.com
Programmable Speeds
The unit has 4 programmable speed
settings, all speeds are variable between
14-100% and allow independent speed
setting of both supply and extract
ventilation rates
Speed 1, Setback.
Reduced ventilation.
Speed 2, Continuous.
Normal ventilation.
Speed 3, Boost.
Increased ventilation
Speed 4, SUMMERboost®.
Very high ventilation.
Boost Inhibit
Boost Inhibit is used to prevent the
MVHR’s speed increasing. Boost Inhibit is
used in conjunction with a Timer event.
Speed Selection & Display
The unit speed can be manually selected
via the on screen 1, 2, 3 & 4 buttons/
icons which are also used to display any
automatically selected speed.
24 Hour Clock
The aura-t has a twenty four hour clock
with a battery backup.
Day of Week Display
The aura-t displays the days of the week
as numbers.
Boost Overrun Timer
A programmable timer that controls
the time the MVHR remains at Boost
Speed after all boost switches have been
released.
Internal Humidity Sensor
The MVHR has a relative humidity
(RH) sensor. The RH sensor can be
programmed to switch the MVHR into
Boost Speed.
Status Icons
The aura-t displays icons to indicates
modes of operation in Real-time.

7
User Interface
The aura-t is operated via a LCD touchscreen. The screen is backlit, the backlight
operates when the screen is touched.
Menu Tabs
The aura-t screen has three interactive menu screens which are selected via tabs at
the bottom of the touchscreen.
Tab
Function Monitor & Control
Fan Commission
None Setup
Name Run Mode Setup Mode
Description Displays Fan Speed,
Time, Day and Status.
Gives access to Fan
Speed Setup
Gives access to Time,
Day, RH threshold,
Overrun Timers,
Summer Bypass,
Passcode settings &
Filter Reset.
Switch Setup in a
Sub-Menu.
If passcode is enabled enter 3333 to activate the above menus.

8
Run Mode
The aura-t controls the MVHR unit’s 4 programmable speed settings.
This is the Run Mode screen; use the number buttons to select the required fan
speed.
Press and Hold the [1] or [2] button to enable boost Inhibit, the
Padlock icon will display to indicate Boost inhibit is active.
Pressing and Holding either the [1] or [2] button again will disable
Boost Inhibit.
The current running speed will be indicated by the corresponding
number button being highlighted.
The time of day is also shown on this screen in 24 hour format along
with the days of the week; the current day is ringed.
Status Icons
If the fan speed is being controlled by an external switch, a sensor or the timer this is
indicated by an icon beneath the speed selection buttons being visible.
The icons are as follows:
An external switch is active and is holding the MVHR at the indicated
speed.
The speed the MVHR is running at is being controlled by the internal
humidity sensor or an external Proportional Input sensor

9
Other Icons
Other status icon that may be visible on the screen are listed below:
The lters need changing or cleaning, refer to the Settings Menu for
details of how to reset the timer.
Frost Protection, if this icon is constantly lit the temperature outside
is low and the speed of the MVHR Supply Fan has been reduced to
prevent damage to the Heat Cell. If the Frost icon and backlight
are ashing the indoor temperature is low and both fans will have
stopped. Tap any of the fan speed number buttons to restart the
fans. If the temperature is still too cold, Frost Protection will be
activated.
Summer Bypass is in operation, air from outside is being supplied
directly to the property without recovering heat from the Heat Cell.
This is often accompanied by SUMMERboost®, both fans switch to
Speed 4 to increase the rate fresh air is supplied to the property and
stale hot air is extracted.
Press & Hold the [4] button to cancel SUMMERboost®.
The Boost Overrun timer is active and is holding the MVHR at Speed
3; this follows an external Boost switch being deactivated or if
the internal Humidity sensor has put the unit into Boost and the
Humidity has reduced below the set-point.
The padlock icon adjacent to the Speed 3 button and accompanying
the timer icon indicates Boost Inhibit is active. The MVHR is being
held at Speed 1 by the timer and will not respond to external Boost
switches or the internal Humidity sensor; it is also not possible
to manually increase the speed the MVHR’s running speed.
Proportional Input sensors are not aected.
The warning icon ashing at the bottom of the screen adjacent to
the Fan icon indicates a fan failure has been detected; contact the
installer. If very high temperatures are detected inside the MVHR,
fan failure mode will be enabled to protect the MVHR from damage.

10
Installation
Location
The aura-t should be mounted in position convenient for the householder and where
the supplied control cable will reach. As standard the aura-t is supplied with a 3m
control cable. If a longer cable is required 0.75mm² 4 core cable should be used, to
be supplied by your electrician.
Fixing
1. Un-clip the front of the aura-t case from the Back Plate.
2. Thread the control cable through the hole in the Back Plate.
3. Fix Back Plate .
4. Connect the communication cable, see Wiring section.
5. Clip the front of aura-t to the Back Plate.
Connection to MVHR
60
Fixing Holes
Wiring Access Hole

11
Wiring
The aura-t’s control cable may be supplied tted with a plug in connector for
connection to the MVHR, if the MVHR does not have a socket remove the plug and
use the wiring diagrams below.
12V
A
B
0V
HRV
12V A
B
0V
Connection to MVHR
Connection to aura-t

12
Controller Setup
Enter key.
Exit Key.
Tap the Setup Mode tab to enter the Setup Mode menu.
All the editable settings in the Controller Setup menu are accessed in the same way.
Menu navigation is achieved by rst Setting Selection and then Editing.
Setting Selection
Arrow keys are used to select a setting, the setting will ash.
Tapping the Enter key will allow the setting to edited.
Tap the Exit button to return to Run Mode.
Setting Editing
Arrow keys are used to change setting value.
Tapping the Enter key whist editing will save and move to the
next setting in the list.
The order in which editable settings are displayed is as follows.
1. Time (24 hour clock)
2. Day of week.

13
3. Humidity threshold
4. Kitchen Overrun timer.
5. Wet room Overrun timer.
6. Summer Bypass Setup.
7. Passcode Disable / Enable.
8. Filter Reset
If a lter change is required the reset ring will be ashing.
Tap the Enter key to reset or the Exit key.
If a lter change is not due but the lter timer requires
resetting press the Enter key twice.
Tap Exit key to return to Run Mode.

14
Summer Bypass Setup
Use to adjust value up or
down.
Enter key.
Extract
Supply
Use the Supply and Extract buttons to select which threshold is to
be adjusted. Supply represents from atmosphere air temperature;
Extract represents from dwelling air temperature.
Tap button[4] to enable / disable SUMMERboost.
Unlled icon (shown) represents disabled.
Passcode Enable / Disable
Tap Enter key
to edit state.
Use to enable / disable
Passcode.
- - - - indicates Passcode is disabled.
3 3 3 3 indicates Passcode is enabled.

15
Switch Setup Menu
In this Sub-Menu of the Setup Menu the installer can congure the function of the
MVHR unit’s switch inputs S1, S2, S3, LS1 & LS2 (see MVHR Product Manual for details)
Enter key.
Exit Key.
Press and Hold the Setup Mode tab to enter the Switch Setup Mode
menu.*
Switch Setup menu active.
All switch inputs to the MVHR unit; S1, S2, S3, LS1 & LS2 can be assigned any of the
following functions.
Kitchen Boost, Speed 3.
Wet Room, Boost, Speed 3.
Speed 1, Setback
SUMMERboost disable.
Speed 4
* If Passcode is enabled, acesss to the Switch Setup Menu is only avaiable from the
Time setup menu.

16
Maintenance
The aura-t is maintenance free.
Cleaning Exterior
For best results use a clean damp micro bre cloth. Do not use abrasive cleaners,
waxes, solvents or alcohol based cleaning products; do not use paper towels for
cleaning the aura-t.
Appendix
aura-t Congurable Defaults
The table below details the default values and the range of available settings, plus any
additional information about those settings the aura-t can congure. There is space
available in the table where the installer should record all conguration settings.
Congurable Item Range Default Congured Additional
information
Min Max
Time Any Time 00:00 24 hour clock.
Day of Week 1 7 1 Two groups, ve
week days & two
weekend days.
Boost Overrun Kitchen 0 mins 60 mins 15 mins
Wet
Room
0 mins 60 mins 15 mins
Boost Overrun timers are set independently for Kitchen and Wet Room inputs.
Boost Overrun timers must be set greater than zero for any momentary switch to trigger boost. When
using latching switches to initiate Speed 3, Boost, the Overrun timer will start when the latching switch is
disengaged.
Internal Humidity
Boost (Set point)
30% 89% 70%
Speed 1, Setback. Supply 14% 100% 18%
Extract 14% 100% 18%
Speed 2,
Continuous.
Supply 14% 100% 40%
Extract 14% 100% 40%
Speed 3, Boost. Supply 14% 100% 70%
Extract 14% 100% 70%

17
Congurable Item Range Default Congured Additional
information
Min Max
Speed 4,
SUMMERboost®
Supply 14% 100% 100%
Extract 14% 100% 100%
Summer Bypass Extract 17°C 35°C 25°C
Supply 10°C 20°C 18°C
In order for the Summer Bypass to operate the temperatures of both the air being extracted from the
property and supplied from outside must be above their individual thresholds. If the temperature of the
Supply air is less than 1°C cooler than the Extracted air the Summer Bypass does not operate to prevent
the warmer air being supplied directly to the property.
SUMMERboost® Enabled Disabled Enabled
SUMMERboost® operates in conjunction with Summer Bypass and switches the fans to Speed 4. It can
also be disabled by a latching switch if tted.
Switch Inputs SW1 Kitchen Boost
SW2 Wet Room
Boost
SW3 SUMMERboost®
Disable
Switch options are: Kitchen Boost, Wet Room Boost, Speed 1, Speed 4, SUMMERboost disable. When
congured as Kitchen or Wet room Boost, the switch will use the associated Boost overrun and delay
times for that room.
Live Switch Inputs LS1 Kitchen Boost
LS2 Wet Room
Boost
Live Switch options are: Kitchen Boost, Wetroom Boost. Live Switches also use the Boost overrun and
delay times for the rooms they have been congured to.
Some control features documented in this manual may not be compatible with older
BEAM MVHR units.

18
axco MVHR Defaults
The table below details MVHR settings and defaults, which that the aura-t CANNOT
congure. During installation and commissioning they may be changed from the
default values by an alternate BEAM controller. There is space available in the table
where the installer should record conguration settings.
Congurable Item Range Default Congured
Min Max
Boost Delay Timer Kitchen 0 mins 60 mins 0 mins
Wet Room 0 mins 60 mins 0 mins
If the Boost Delay Timer is set greater than zero momentary switches will not switch the MVHR into Speed 3 Boost. When using latching
switches the MVHR will not Boost until the Delay time has elapsed.
Filter Change Interval 3 Months 24 Months 12 Months
Summer Bypass Enable/Disable Enabled Disabled Enabled
Frost Protection Mode O Reduce O
Frost Protection Threshold -2°C 11.5°C 2°C
When Frost Protection is operating in O Mode the Supply fan is switched o when the temperature measured by the sensor on the to
atmosphere side of the heat cell drops below the Frost Protection Threshold. When operating in Reduce Mode the speed of the Supply Fan
is gradually reduced when the temperature drops below the threshold. At 4°C below the threshold it is stopped.
Duct Heater Enable/Disable Enabled Disabled Disabled
Duct Heater Mode Frost User Frost
Duct Heater Threshold -4°C 16°C 4°C
Duct Heater Hysteresis 1°C 10°C 1°C
When operating in Frost Mode the Duct Heater uses the sensor on the to atmosphere side of the Heat Cell and switches on 2°C above the
Frost Protection threshold. When operating in User Mode it uses the sensor on the from atmosphere side of the heat cell and the threshold
and hysteresis detailed above. In both modes the Duct Heater will be switched o if the Supply fan speed drops below 22.5% PWM.
Internal Humidity Boost On
RH Boost Overrun 1 min 60 mins 15 mins
RH Boost Hysteresis 1% 10% 1%
When the Humidity of the air being extracted from the property reaches the threshold congured by the aura-t the fans switch to Speed
3 Boost. They remain at Speed 3 until the Humidity has dropped below the threshold minus the hysteresis and the RH Boost Overrun time
has elapsed.

19
Congurable Item Range Default Congured
Min Max
Room Sensor 1 Enable/Disable Enabled Disabled Disabled
Sensor Type %RH
Lower threshold 60%
Upper threshold 70%
Room Sensor 2 Enable/Disable Enabled Disabled Disabled
Sensor Type CO2
Lower threshold 800PPM
Upper threshold 1400PPM
If tted, Room Sensors are used to provide Demand Control Ventilation based on the environmental parameter they are measuring.
Below their lower threshold they have no eect on the ventilation rate; once the lower threshold is exceeded the fan speeds proportionally
increase from Speed 2, Continuous until the upper threshold is reached when the fans will be running at Speed 3, Boost. In addition to the
%RH and CO2sensor detailed above Air Quality and Temperature Room Sensors may be tted. With any Room Sensor the range of Demand
Control Ventilation will be dependant on the individual sensor’s characteristics and the thresholds congured by the installer.

Installed by:
©2018 DO 5644 Iss 01
In the event of any queries please contact the system installer.
Ensure this booklet is passed to the householder once installation & commissioning of the
ventilation system is complete.
This Product Manual must be kept in the Home Information Pack.
BEAM Vacuum & Ventilation
Opus Business Park
35 Aughrim Road
Magherafelt
BT45 6BB, NI
telephone [ NI & UK ] [phone]
facsimile [ NI & UK] [phone]
telephone [ ROI ] [phone]
email [e-mail]
website www.beamcentralsystems.com
