Bebob COCO-FX9-AMICRO User manual

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
July 2020
Features
•Mounts onto the back of the SONX PXW-FX9
•Multi Voltage 5,0V, 14,4V unreg, 19,5V
•5 Outputs (1x USB, 1 Lemo 2p, 2 Twist Dtap, 1 Cinch)
•1 XLR4 Input with Hotswap function
•Main On-Off Switch with led for all accessories Output
•5 led dimmable/Switchable Fuel Gauge
Hotswap functionality
•1st option: Keep a BPU-35 in the camera to Swap the Vmount without interruption
•2nd option: Plug an external 10-17V Power Source into the XLR4 IN to Swap the Vmount
battery without interruption
•3rd option: Swap one Amicro battery after the other
COCO-FX9-AMICRO MULTI VOLTAGE
AMICRO JUNCTION BOX FOR SONY PXW-
FX9
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB COCO-FX9-AMICRO
ADAPTER! PLEASE KEEP THIS MANUAL
FOR FUTURE REFERENCE

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
July 2020
Fuel Gauge
Safety instructions
•Only for professional use! Keep the COCO-FX9-AMICRO out of reach of children and
personnel that has not been instructed in the use!
•Use only with recommended batteries.
•Keep the COCO-FX9-AMICRO dry and do not immerse in water.
•Do not attempt to open or repair the COCO-FX9-AMICRO. Contact your dealer for help if it
becomes defective.
•Handle with care! Do not throw! Do not drop!
•Remove the battery from the COCO-FX9-AMICRO when not in use for a longer period of
time
Warranty
•The COCO-FX9-AMICRO is covered by a 2 years unconditional warranty on all parts.
•For warranty issues or if you have any additional questions, please contact the appropriate
bebob distributor listed at www.bebob.de.

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
July 2020
Specifications
Model
COCO-FX9-AMICRO
Material
Aluminium
Battery Mount
2 Amicro
Voltages
5,0V/14,4V unreg/19,5V
Max. Draw
Depends on battery
Twist D-Tap
2 (14,4V unreg, / max. 5.0A) Self-reset Fuse
USB Port
1 (5,0V / max. 1,0A) Self-reset Fuse
Lemo 2p
1 (14,4V unreg. / max. 2,0A) Self reset Fuse
XLR4 IN
1 (10 to 17V) Hotswap
Dimensions (WXHXD)
45x 141 x 42mm
Weight
0,43 Kg
