Beckhoff CX1000 User manual

Manual | EN
CX1000
Embedded-PC
11/12/2021 | Version: 1.1

Table of contents
CX1000 3Version: 1.1
Table of contents
1 Foreword ....................................................................................................................................................5
1.1 Notes on the documentation..............................................................................................................5
1.2 Safety instructions .............................................................................................................................6
1.3 Notes on information security ............................................................................................................7
1.4 Documentation Issue Status..............................................................................................................7
2 Product Overview ......................................................................................................................................8
2.1 Appropriate Use.................................................................................................................................8
2.2 System Overview...............................................................................................................................8
2.3 Base Modules..................................................................................................................................10
2.3.1 Technical Data................................................................................................................. 10
2.3.2 Types ............................................................................................................................... 11
2.3.3 Connections..................................................................................................................... 12
2.3.4 Compact Flash slot .......................................................................................................... 14
2.3.5 Compact-Flash card ........................................................................................................ 15
2.3.6 PC 104 Bus...................................................................................................................... 15
2.4 System interfaces ............................................................................................................................17
2.4.1 Technical Data................................................................................................................. 17
2.4.2 CX1000-N001 connections.............................................................................................. 18
2.4.3 CX1000-N002 connections.............................................................................................. 19
2.4.4 CX1000-N003 connections.............................................................................................. 20
2.4.5 CX1000-N005 connections.............................................................................................. 20
2.5 Power supply ...................................................................................................................................23
2.5.1 Technical Data CX1100-0001.......................................................................................... 23
2.5.2 Technical Data CX1100-0002 / CX1100-0003 ................................................................ 24
2.5.3 CX1100-0001 Connections.............................................................................................. 24
2.5.4 CX1100-0002 Connections.............................................................................................. 25
2.5.5 CX1100-0003 Connections.............................................................................................. 26
2.5.6 LCD Display..................................................................................................................... 27
3 Transport..................................................................................................................................................28
3.1 Unpacking, installation and transport ..............................................................................................28
4 Fitting and wiring.....................................................................................................................................29
4.1 Mechanical mounting.......................................................................................................................29
4.1.1 Dimensions ...................................................................................................................... 29
4.1.2 Mechanical Assembly of the base module ...................................................................... 30
4.1.3 Mechanical mounting of the Fieldbus modules................................................................ 33
5 Error handling and diagnostics..............................................................................................................35
5.1 CPU base module ...........................................................................................................................35
5.1.1 LEDs of the basic CPU module ....................................................................................... 35
5.2 Power supplys .................................................................................................................................35
5.2.1 CX1100-0001 power supply LEDs................................................................................... 35
5.2.2 CX1100-0002 power supply LEDs................................................................................... 36
5.2.3 CX1100-0003 power supply LEDs................................................................................... 39
5.3 Faults...............................................................................................................................................42

Table of contents
CX10004 Version: 1.1
6 Decommissioning....................................................................................................................................43
6.1 Removal and disposal .....................................................................................................................43
7 Appendix ..................................................................................................................................................45
7.1 Accessories .....................................................................................................................................45
7.2 Certifications....................................................................................................................................45
7.3 Support and Service ........................................................................................................................46

Foreword
CX1000 5Version: 1.1
1 Foreword
1.1 Notes on the documentation
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning the components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, TwinCAT/BSD®, TC/BSD®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®,
Safety over EtherCAT®, TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by
Beckhoff Automation GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents:
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702
with corresponding applications or registrations in various other countries.
EtherCAT® is a registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.

Foreword
CX10006 Version: 1.1
1.2 Safety instructions
Safety regulations
Please note the following safety instructions and explanations!
Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,
commissioning etc.
Exclusion of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.
Personnel qualification
This description is only intended for trained specialists in control, automation and drive engineering who are
familiar with the applicable national standards.
Description of symbols
In this documentation the following symbols are used with an accompanying safety instruction or note. The
safety instructions must be read carefully and followed without fail!
DANGER
Serious risk of injury!
Failure to follow the safety instructions associated with this symbol directly endangers the life and health of
persons.
WARNING
Risk of injury!
Failure to follow the safety instructions associated with this symbol endangers the life and health of per-
sons.
CAUTION
Personal injuries!
Failure to follow the safety instructions associated with this symbol can lead to injuries to persons.
NOTE
Damage to the environment or devices
Failure to follow the instructions associated with this symbol can lead to damage to the environment or
equipment.
Tip or pointer
This symbol indicates information that contributes to better understanding.

Foreword
CX1000 7Version: 1.1
1.3 Notes on information security
The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online,
are equipped with security functions that support the secure operation of plants, systems, machines and
networks. Despite the security functions, the creation, implementation and constant updating of a holistic
security concept for the operation are necessary to protect the respective plant, system, machine and
networks against cyber threats. The products sold by Beckhoff are only part of the overall security concept.
The customer is responsible for preventing unauthorized access by third parties to its equipment, systems,
machines and networks. The latter should be connected to the corporate network or the Internet only if
appropriate protective measures have been set up.
In addition, the recommendations from Beckhoff regarding appropriate protective measures should be
observed. Further information regarding information security and industrial security can be found in our
https://www.beckhoff.com/secguide.
Beckhoff products and solutions undergo continuous further development. This also applies to security
functions. In light of this continuous further development, Beckhoff expressly recommends that the products
are kept up to date at all times and that updates are installed for the products once they have been made
available. Using outdated or unsupported product versions can increase the risk of cyber threats.
To stay informed about information security for Beckhoff products, subscribe to the RSS feed at https://
www.beckhoff.com/secinfo.
1.4 Documentation Issue Status
Version Changes
1.2 annotations to battery recycling added
1.1 comments on hardware watchdog added
1.0 updated version
0.1 preliminarily version

Product Overview
CX10008 Version: 1.1
2 Product Overview
2.1 Appropriate Use
The CX1000 device series is a modular control system that can be mounted on top hat rails. Its components
are plugged together and installed in the control cabinet or junction box, depending on the required function.
Note:
The device configuration CX1000 is not recommended for new projects.
As new standard configuration the type CX1010 is available.
2.2 System Overview
The System
The CX1000 system covers the whole range of Beckhoff control technology both in terms of price and
performance: The new product range is designed for tasks requiring the characteristics and computing
capacity of Industrial PCs, but whose budget does not stretch to full-blown Industrial PCs.
The system only uses those components that are actually required. For example, a CX1000 can be operated
in „headless“mode, i.e. without display or keyboard; in this case, the associated interface is not required.
Whilst the resulting control system has no visualisation, it does have communications capability via the built-
in Ethernet and RS 232 interfaces.
If local visualisation is required, this can be implemented via a DVI (digital video interface), to which all
Beckhoff Control Panels and all commercially available monitors with DVI-input can be connected. The touch
screen signal is read via one of the two available USB interfaces.
The components
The modules of the CX1000 series system are connected with each other via the standardised PC104 bus
(16 bit). The individual system components are modules that can be arranged in series. The basic unit
consists of a CPU module(CX1000-0000) and a power supply module(CX1100-000x). Further system
interfaces for serial communication(2x RS 232, and RS422, RS485) as well as audio signals are available
separately.
CPU base module
CPU base module [}10]
The CPU module is available in several variants. These relate to:

Product Overview
CX1000 9Version: 1.1
– Internal memory configuration: there are two options – either 16 MB Flash/32 MB RAM or 64 MB Flash /
128 MB RAM. The latter is required if the system is to be equipped with Windows XP Embedded.
– System interface configuration: as an option, a DVI and two USB Interfaces can be added to the
combination of Ethernet and RS 232 that is always present.
– Operating system: There is a choice between Microsoft Windows CE.NET and Microsoft Windows XP
Embedded.
– Pre-installed TwinCAT software: CX1000 can be preinstalled without a TwinCAT system, with TwinCAT CE
PLC or with TwinCAT CE NC PTP, or with the associated full version of the individual TwinCAT levels for
PLC and Motion Control.
System interfaces
System interfaces [}17]
Further system interfaces for serial communication(2x RS 232, and RS422, RS485) as well as audio signals
are available separately.
Fieldbus interfaces
The range of optional modules for theCX1000 is complemented by fieldbus connectionsfor Profibus,
CANopen, DeviceNet,SERCOS interface and Lightbus, both asmaster and slave versions.
The following fieldbus interfaces are available:
Beckhoff Lightbus (master and slave), Profibus DP (master and slave), CANopen (master and slave),
DeviceNet (master and slave) und SERCOS Interface (only master).
The use of fieldbus master modules in a CX1000 system enables the utilisation of all Beckhoff fieldbus
components (e. g. Bus Coupler, Bus Terminal Controller, drive technology) as distributed control
components for the assembly of complex systems
The use of fieldbus slave modules enables the utilisation of a CX1000 system as subordinate distributed
control for the configuration of complex or modular systems.
The Software
In combination with the TwinCAT automation software, the CX1000 Industrial PC becomes a powerful IEC
61131-3 PLC with up to four user tasks. Additionally, MotionControl tasks can also be executed. Depending
on the required cycle time, several servo axes can be controlled. Even special functions such as flying saw,
electronic gearbox and cam plate can be realised.
Remote programming via Ethernet
This option is used if the basic unit is equipped with Windows CE.NET. In this case, the system is
programmed via a laptop or a desktop PC, which is connected to the CX1000 via Ethernet (network or
crossover cable). The programs are developed on the laptop with a standard TwinCAT software licence and
then loaded into the target device.
Visualisation
The Beckhoff OPC server is available for interfacing with SCADA software on both operating system variants
Windows CE.NET or Windows XP Embedded. In other words, the CX1000 also offers unproblematic
visualisation and simultaneous control in realtime on a single system. Beckhoff control devices

Product Overview
CX100010 Version: 1.1
2.3 Base Modules
2.3.1 Technical Data
The CX1000 CPU module is the basic module of the CX system. It comprises the CPU and the internal flash
memory in two implementation levels and offers the option to operate an additional memory medium in
Compact Flash type II format. Ethernet and an RS 232 interface are also part of the basic configuration. All
other CX family components can be connected via the PC104 interface that is available on both sides. The
CPU module requires a CX1100 type power supply module.
Technical data CX1000-0000
Processor compatible with Pentium MMX, clock frequency 266
MHz
Flash memory 64 MByte Compact Flash card
Internal main memory 32 MByte RAM (expandable to 128 MByte)
Interfaces 1 x RJ45 (Ethernet) and 1 x 9-pinD-Sub (RS 232)
Diagnostics LED 1 x Power, 1 x Link, 1x 100 MBit , 1 x LAN Aktivität,
1 x Flash access
Expansion slot 1 x Compact Flash type II insert with ejector
Clock battery-powered internal clock for time and date
Operating system Microsoft Windows CE.NET or Microsoft
Windows XP Embedded
Control software TwinCAT PLC Runtime or TwinCAT NC PTP
Runtime
System bus 16 Bit ISA (PC104 standard)
Power supply via system bus (through CX1100 power supply
module)
Dimensions 57 mm x 100 mm x 91 mm
Weight approx. 355 g ( with DVI/USB 435 g)
The passive cooling module CX1000-COOL is included in the scope of supply.

Product Overview
CX1000 11Version: 1.1
Documents about this
2sc2200_ds.pdf (Resources/pdf/3219647627.pdf)
2.3.2 Types
The CPU module can be equipped with different hardware and software options: the internal memory is
expandable to 32 MB Flash/128 MB RAM; the operating systems can be Windows CE.NET or Windows XP
Embedded. The TwinCAT automation software transforms a CX1000 system into powerful PLC and Motion
Control system that can be operated with or without visualisation. Further system interfaces (pre-installed in
the factory) or fieldbus connections can be added to the basic CPU module.
Since not all combinations are sensible, the following table contains a breakdown of the permissible
combinations.
The CX 1000 modules are available in the following types:

Product Overview
CX100012 Version: 1.1
Requirements
Modules 16/32 MB 64/128 MB DVI / USB Windows
CE.NET
Windows
XPE
without
TwinCAT
TwinCAT
PLC Run-
time
TwinCAT
NC PTP
Runtime
CX1000-0
010
* * *
CX1000-0
011
***
CX1000-0
012
* * *
CX1000-0
110
* * * *
CX1000-0
111
* * * *
CX1000-0
112
* * * *
CX1001-0
000
*
CX1001-0
010
***
CX1001-0
011
* * *
CX1001-0
012
* * *
CX1001-0
020
* * *
CX1001-0
021
* * *
CX1001-0
022
***
CX1001-0
110
* * * *
CX1001-0
111
* * * *
CX1001-0
112
* * * *
CX1001-0
120
* * * *
CX1001-0
121
* * * *
CX1001-0
122
* * * *
CX1000 systems with Windows XP Embedded require a Compact Flash card with a minimum capacity of 1
GB.
Note:
A list of the different software images can be found in the CX1000 Software Documentation.
2.3.3 Connections
The basic CPU module is available with different hardware and software options. It is supplied from the
power supply unit, so that only the connections are described here.

Product Overview
CX1000 13Version: 1.1
Basic CPU module with Ethernet RJ 45 and COM1 (RS232) interface:
RJ 45 interface (socket):
Table1: Assignment of the RJ45 interface:
PIN Signal Description
1 TD + Transmit +
2 TD - Transmit -
3 RD + Receive +
4 connected not used
5
6 RD - Receive -
7 connected not used
8
TD & RD are exchanged at the hubs or between two PCs.
COM1 interface (connector):
Table2: Assignment of the COM1 interface:
PIN Signal Type Description
1 DCD Signal in Data Carrier Detect
2 RxD Signal in Receive Data
3 TxD Signal out Transmit Data
4 DTR Signal out Data Terminal Ready
5 GND Ground Ground
6 DSR Signal in Data Set Ready
7 RTS Signal out Request to Send
8 CTS Signal in Clear to Send
9 RI Signal in Ring Indicator
Basic CPU module with DVI/USB interface:
In addition to the Ethernet and COM interface, this basic module features a DVI-I and two USB interfaces.
The pin assignment of the basic CPU module with two USB and a DVI-I interface is explained under the
associated system interface CX1000-N001 [}18].
Applicable to all basic CPU modules:
LED
The green power LED (PWR) is on if the basic CPU module is connected correctly to a live power supply
unit.

Product Overview
CX100014 Version: 1.1
Compact Flash slot
Further information can be found under Compact Flash slot [}14].
PC 104 Bus
The PC 104 bus [}15] is a standardised bus with 104 ISA signals for compact embedded systems.
2.3.4 Compact Flash slot
A Compact Flash slot is provided at the front of the basic CPU module. This enables an additional Compact
Flash memory medium (format I or II) to be operated. The change is only allowed while the system is
powered down - otherwise the system could crash. The card can be removed for maintenance or to extend
the system storage capacity. The Compact Flash cards (CF cards) are available as accessories with different
storage capacities.
Activating the eject mechanism below the slot with a screwdriver causes the card to be ejected by approx. 4
mm (FIGURE 1), so that it can be pulled out (FIGURE 2). If the card is pushed in (FIGURE 3), the eject
mechanism will re-engage. The card is positioned correctly, if it is located approx. 1 mm lower than the front
of the housing.
 
FIG1: Ejecting the CF card FIG2: Removing the CF card

Product Overview
CX1000 15Version: 1.1
FIG3: Inserting the CF card
NOTE
The Compact Flash slot is a memory interface, not an I/O type CF slot.
2.3.5 Compact-Flash card
The Compact Flash card (CF card) is a non-volatile memory medium.
Data to be retained in the event of a power failure should be saved on the CF card. The CF card operates
similar to a hard disk.
NOTE
It is recommended only use CF cards supplied by Beckhoff Automation GmbH. The CF cards are made for
industrial use. They possess a higher number of read / write cycles and an enhance temperature range (up
to + 85°C).A proper operation of the CX-System can only be guaranteed with the use of CF cards from
Beckhoff Automation GmbH!
2.3.6 PC 104 Bus
The PC 104 bus is a standerdised bus with 104ISA signals for compact embedded systems.
For the functionality of the CX1000 modules eight further signals have been added ( here marked with color).

Product Overview
CX100016 Version: 1.1
Table3: Pin assignment of 16 bit PC 104 bus:
Pin
Number
J1/P1
Row A
J1/P1
Row B
J1/P1
Row C
J1/P1
Row D
0 -- -- GND GND
1 IOCHCHK* GND SBHE* MEMCS16*
2 SD7 RESETDRV LA23 IOCS16*
3 SD6 +5V LA22 IRQ10
4 SD5 IRQ9 LA21 IRQ11
5 SD4 -5V LA20 IRQ12
6 SD3 DRQ2 LA19 IRQ13
7 SD2 -12V LA18 IRQ14
8 SD1 ENDXFR* LA17 DACK0*
9 SD0 +12V MEMR* DRQ0
10 IOCHRDY (KEY)² MEMW* DACK5*
11 AEN SMEMW* SD8 DRQ5
12 SA19 SMEMR* SD9 DACK6*
13 SA18 IOW* SD10 DRQ6
14 SA17 IOR* SD11 DACK7*
15 SA16 DACK3* SD12 DRQ7
16 SA15 DRQ3 SD13 +5V
17 SA14 DACK1* SD14 MASTER*
18 SA13 DRQ1 SD15 GND
19 SA12 REFRESH* (KEY)² GND
20 SA11 SYSCLK -- --
21 SA10 IRQ7 -- --
22 SA9 IRQ6 -- --
23 SA8 IRQ5 -- --
24 SA7 IRQ4 -- --
25 SA6 IRQ3 -- --
26 SA5 DACK2* -- --
27 SA4 TC -- --
28 SA3 BALE -- --
29 SA2 +5V -- --
30 SA1 OSC -- --
31 SA0 GND -- --
32 GND GND -- --
Remarks:
2. B10 and C19 are key locations.
3. Signal timing and function are as specified in ISA specification.
4. Signal source/sink current differ from ISA values.
Pin assignment of the addtional signals

Product Overview
CX1000 17Version: 1.1
Pin number Assignment
1 I²C SCL
2 USB D+
3 I²C SDA
4 USB D-
5 ONCTRL
6 Ustby 5 V
7 POR
8 PWRBTN
Note:
Further information about the PC 104 bus can be found under http://www.pc104.org
2.4 System interfaces
2.4.1 Technical Data
Unlike other CX components, the system interfaces cannot be upgraded or expanded in the field. They are
supplied ex factory in the specified configuration and cannot be separated from the CPU module. The
system interfaces run through the internal PC104, so that further CX components can be connected. The
power supply of the system interface modules is ensured via the internal PC104 bus.

Product Overview
CX100018 Version: 1.1
Technical data CX1000-N001 CX1000-N002 CX1000-N003 CX1000-N005*
Interfaces 1 x DVI +
2 x USB 1.1
1 x COM2 +
1 x COM3
Line IN,
Line Mic IN,
Line OUT
1 x COM2 +
1 x COM3
Connection type DVI-I 29-pin socket
+ 2 USB ports type
A
2 x 9-pin D-Sub 3.5 mm socket for
jack plug
2 x 9-pin D-Sub
Properties DVI-I interface also
carries out VGA
signals (DVI-A)
max. Baud rate 115
kBaud on both
interfaces COM1:
RXD, TXD, DTR
COM2: RXD, TXD
built-in PC Beeper
Line OUT output,
max. 200 mW,
suitable for
earphones
max. Baud rate 115
kBaud on both
interfaces
2 x RS485/422,
optically isolated
Power supply via system bus (through CX1100 power supply module)
Dimensions 19 mm x 100 mm x 91 mm
Weight approx. 80 g
* can only be used instead of and not at the same time as CX1000-N002
2.4.2 CX1000-N001 connections
In addition to the Ethernet and RS232 interface, this module features a DVI-I and two USB interfaces.
DVI-I interface
The DVI-I interface transfers analog and digital data and is suitable for connection to analog graphics cards
with 15 pin D-Sub connector and digital graphics cards with DVI-D output. The resolution at the screen or the
Beckhoff Control Panel depends on the distance (maximum 7 m).
The DVI interface uses VGA signals, so that the connection of CRT VGA monitors to the CX1000 system
using a DVI to VGA adapter is also possible.
This adapter is available as an accessory.
DVI-I socket:
Pin Assignment Pin Assignment Pin Assignment
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4
Shield
11 TMDS Data 1/3
Shield
19 TMDS Data 0/5
Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 + 5V Power 22 TMDS Clock
Shield
7 DDC Data 15 Ground ( +5V,
Analog H/V
Sync)
23 TMDS Clock +
8 Analog Vertical
Sync
16 Hot Plug Detect 24 TMDA Clock -
Pin assignment (cross)

Product Overview
CX1000 19Version: 1.1
Pin Assignment
C1 Analog Red Video Out
C2 Analog Green Video Out
C3 Analog Blue Video Out
C4 Analog Horizontal Sync
Resolution at the monitor:
Resolution in pixels Distance of the interface from the monitor
1024 x 768 5 m
800 x 600 6 m
640 x 480 7 m
USB interface:
The USB socket is a type A socket. The USB interface complies to USB 1.1 specification
Pin Assignment Typical assignment
1 VBUS Red
2 D- White
3 D+ Green
4 GND Black
Shell Shield Drain Wire
2.4.3 CX1000-N002 connections
The CX1000-N002 system interface features two RS232 interfaces, COM2 and COM3 (9 pin Sub-D plug
connector).
The maximum baud rate on both channels is 115 kBit.
RS232 COM interface (connector):
Fig.1: RS232_Stecker
Table4: Pin assignment of the COM2 interface:
PIN Signal Type Description
2 RxD Signal in Receive Data
3 TxD Signal out Transmit Data
4 DTR Signal out Data Terminal Ready
5 GND Ground Ground
The pins not listed are not used.

Product Overview
CX100020 Version: 1.1
Table5: Pin assignment of the COM3 interface:
PIN Signal Type Description
2 RxD Signal in Receive Data
3 TxD Signal out Transmit Data
5 GND Ground Ground
The pins not listed are not used.
2.4.4 CX1000-N003 connections
This system interface contains the audio interfaces Line In, Mic In (microphone signal input) and Line Out
(also for earphones), max. 200 mW.
It also features a PC beeper.
The 3.5 mm sockets are designed for jack plugs.
Line In / Line Out stereo jack plugs:
Table6: Pin assignment Line In /Line Out:
Signal Description
L Left Signal
R Right Signal
Gound Ground
The left channel is transferred via the tip of the jack plug, the right channel via the first ring. The remainder of
the sleeve is used for earthing.
Mic In mono jack plug:
The only existing channel is transferred via the tip, the remainder of the sleeve is used for earthing.
2.4.5 CX1000-N005 connections
The system interface CX1000-N005 contains two RS422, RS485 interfaces, COM2 and COM3 (9 pin Sub-D
plug connector).
The maximum baud rate on both channels is 115 kBit.
