Beckhoff CX52 0 Series User manual

Manual | EN
CX52x0
Embedded PC
12/15/2020 | Version: 1.0

Table of contents
CX52x0 3Version: 1.0
Table of contents
1 Notes on the documentation ....................................................................................................................5
1.1 Representation and structure of warnings.........................................................................................6
1.2 Documentation issue status ..............................................................................................................7
2 For your safety...........................................................................................................................................8
2.1 Intended use......................................................................................................................................8
2.2 Staff qualification ...............................................................................................................................8
2.3 Safety instructions .............................................................................................................................9
3 Transport and storage.............................................................................................................................10
4 Product overview.....................................................................................................................................11
4.1 Structure ..........................................................................................................................................13
4.2 Name plate ......................................................................................................................................14
4.3 Types...............................................................................................................................................15
4.4 Architecture overview ......................................................................................................................16
5 Interface description ...............................................................................................................................17
5.1 USB 3.0 (X100, X101, X102, X103) ................................................................................................17
5.2 Ethernet RJ45 (X000, X001) ...........................................................................................................18
5.3 DVI-D (X200) ...................................................................................................................................19
5.4 Optional interfaces...........................................................................................................................20
5.4.1 DVI-D (N010) ................................................................................................................... 20
5.4.2 DisplayPort (N011) .......................................................................................................... 21
5.4.3 Audio interface (N020)..................................................................................................... 22
5.4.4 RS232 (N030).................................................................................................................. 23
5.4.5 RS422/RS485 (N031)...................................................................................................... 24
5.4.6 EtherCAT slave (B110).................................................................................................... 25
5.4.7 PROFIBUS (x310) ........................................................................................................... 26
5.4.8 CANopen (x510) .............................................................................................................. 27
5.4.9 PROFINET RT (x930)...................................................................................................... 28
6 Commissioning........................................................................................................................................29
6.1 Assembly .........................................................................................................................................29
6.1.1 Permissible installation positions ..................................................................................... 30
6.1.2 Fastening to the DIN rail .................................................................................................. 31
6.1.3 Changing the MicroSD card............................................................................................. 32
6.1.4 Changing the CFast card................................................................................................. 33
6.1.5 Installing passive EtherCAT Terminals............................................................................ 34
6.2 Power supply ...................................................................................................................................35
6.2.1 Connect Embedded PC ................................................................................................... 36
6.2.2 UL requirements .............................................................................................................. 37
6.3 Switching on ....................................................................................................................................38
6.4 Switching off ....................................................................................................................................38
7 Configuration ...........................................................................................................................................39
7.1 Starting the Beckhoff Device Manager ............................................................................................39
7.2 Windows 10 IoT Enterprise .............................................................................................................40
7.2.1 Identification of the Ethernet interfaces (X000, X001) ..................................................... 40

Table of contents
CX52x04 Version: 1.0
7.2.2 Enabling jumbo frames .................................................................................................... 41
7.2.3 Set NIC Teaming ............................................................................................................. 42
7.2.4 Restoring the Beckhoff real-time driver ........................................................................... 44
7.3 TwinCAT..........................................................................................................................................45
7.3.1 Tree view ......................................................................................................................... 45
7.3.2 Searching for target systems ........................................................................................... 46
7.3.3 Scanning an Embedded PC ............................................................................................ 48
7.3.4 Configuring EtherCAT cable redundancy. ....................................................................... 49
7.3.5 Using a hardware watchdog ............................................................................................ 52
8 1-second UPS (persistent data)..............................................................................................................53
8.1 BIOS settings...................................................................................................................................54
8.2 Windows write filter..........................................................................................................................55
8.3 FB_S_UPS_BAPI ............................................................................................................................56
8.4 Mode and status of the function block .............................................................................................57
8.5 Checking the validity of the variables ..............................................................................................59
8.5.1 SYSTEMINFOTYPE ........................................................................................................ 59
8.5.2 PlcAppSystemInfo ........................................................................................................... 61
9 Error handling and diagnostics..............................................................................................................62
9.1 Diagnostic LEDs ..............................................................................................................................62
9.1.1 K-bus ............................................................................................................................... 62
9.1.2 E-bus ............................................................................................................................... 65
9.2 Faults...............................................................................................................................................66
10 Care and maintenance ...........................................................................................................................67
10.1 Replace the battery .........................................................................................................................67
10.2 Cleaning the Embedded PC ............................................................................................................68
11 Decommissioning....................................................................................................................................69
11.1 Removing cables .............................................................................................................................69
11.2 Dismantling the Embedded PC .......................................................................................................70
12 Technical data..........................................................................................................................................71
13 Appendix ..................................................................................................................................................73
13.1 Accessories .....................................................................................................................................73
13.2 Certifications....................................................................................................................................74
13.3 Support and Service ........................................................................................................................75
List of tables.............................................................................................................................................76
List of figures...........................................................................................................................................77

Notes on the documentation
CX52x0 5Version: 1.0
1 Notes on the documentation
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning the components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®, Safety over EtherCAT®,
TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation
GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents:
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702
with corresponding applications or registrations in various other countries.
EtherCAT® is a registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.

Notes on the documentation
CX52x06 Version: 1.0
1.1 Representation and structure of warnings
The following warnings are used in the documentation. Read and follow the warnings.
Warnings relating to personal injury:
DANGER
Hazard with high risk of death or serious injury.
WARNING
Hazard with medium risk of death or serious injury.
CAUTION
There is a low-risk hazard that can result in minor injury.
Warnings relating to damage to property or the environment:
NOTE
There is a potential hazard to the environment and equipment.
Notes showing further information or tips:
This notice provides important information that will be of assistance in dealing with the product or
software. There is no immediate danger to product, people or environment.

Notes on the documentation
CX52x0 7Version: 1.0
1.2 Documentation issue status
Version Modifications
1.0 First release

For your safety
CX52x08 Version: 1.0
2 For your safety
Read the chapter on safety and follow the instructions in order to protect from personal injury and damage to
equipment.
Limitation of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Unauthorized modifications and changes to the hardware or software configuration, which go
beyond the documented options, are prohibited and nullify the liability of Beckhoff Automation GmbH & Co.
KG.
In addition, the following actions are excluded from the liability of Beckhoff Automation GmbH & Co. KG:
• Failure to comply with this documentation.
• Improper use.
• Use of untrained personnel.
• Use of unauthorized replacement parts.
2.1 Intended use
The Embedded PC is a control system and is intended for mounting on a DIN rail in a control cabinet or
terminal box. The Embedded PC series is used in conjunction with Bus Terminals for recording digital or
analog signals from sensors and transferring them to actuators or higher-level controllers.
The Embedded PC is designed for a working environment that meets the requirements of protection class
IP20. This involves finger protection and protection against solid foreign objects up to 12.5 mm, but not
protection against water. Operation of the devices in wet and dusty environments is not permitted, unless
specified otherwise. The specified limits for electrical and technical data must be adhered to.
Improper use
The Embedded PC is not suitable for operation in the following areas:
• Potentially explosive atmospheres.
• Areas with an aggressive environment, e.g. aggressive gases or chemicals.
• Living areas. If the devices are to be used in living areas, the relevant standards and guidelines for
interference emissions must be adhered to, and the devices must be installed in housings or control
boxes with suitable shielding.
2.2 Staff qualification
All operations involving Beckhoff software and hardware may only be carried out by qualified personnel with
knowledge of control and automation engineering. The qualified personnel must have knowledge of the
administration of the Industrial PC and the associated network.
All interventions must be carried out with knowledge of control programming, and the qualified personnel
must be familiar with the current standards and guidelines for the automation environment.

For your safety
CX52x0 9Version: 1.0
2.3 Safety instructions
The following safety instructions must be followed during installation and working with networks and the
software.
Mounting
• Never work on live equipment. Always switch off the power supply for the device before installation,
troubleshooting or maintenance. Protect the device against unintentional switching on.
• Observe the relevant accident prevention regulations for your machine (e.g. the BGV A 3, electrical
systems and equipment).
• Ensure standard-compliant connection and avoid risks to personnel. Ensure that data and supply
cables are laid in a standard-compliant manner and ensure correct pin assignment.
• Observe the relevant EMC guidelines for your application.
• Avoid polarity reversal of the data and supply cables, as this may cause damage to the equipment.
• The devices contain electronic components, which may be destroyed by electrostatic discharge when
touched. Observe the safety precautions against electrostatic discharge according to DIN EN
61340-5-1/-3.
Working with networks
• Restrict access to all devices to an authorized circle of persons.
• Change the default passwords to reduce the risk of unauthorized access. Regularly change the
passwords.
• Protect the devices with a firewall.
• Apply the IT security precautions according to IEC 62443, in order to limit access to and control of
devices and networks.
Working with the software
• Use up-to-date security software. The safe function of the PC can be compromised by malicious
software such as viruses or Trojans.
• The sensitivity of a PC against malicious software increases with the number of installed and active
software.
• Uninstall or disable unnecessary software.
Further information about the safe handling of networks and software can be found in the Beckhoff
Information System:
http://infosys.beckhoff.com
Document name
IPC Security Guideline

Transport and storage
CX52x010 Version: 1.0
3 Transport and storage
Transport
NOTE
Short circuit due to moisture
Moisture can form during transport in cold weather or in the event of large temperature fluctuations.
Avoid moisture formation (condensation) in the Embedded PC, and leave it to adjust to room temperature
slowly. If condensation has occurred, wait at least 12 hours before switching on the Embedded PC.
Despite the robust design of the unit, the components are sensitive to strong vibrations and impacts. During
transport the Embedded PC must be protected from
• mechanical stress and
• use the original packaging.
Table1: Dimensions and weight of the individual modules.
CX5230 CX5240
Dimensions (W x H x D) 142 mm x 100 mm x 91 mm
Weight approx. 1195 g
Storage
• Remove the battery from the Embedded PC if storage temperatures exceed 60°C. The battery should
be stored separate from the Embedded PC in a dry environment at a temperature between 0°C and
30°C.
The preset date and time are lost if the battery is removed.
• Store the Embedded PC in the original packaging.

Product overview
CX52x0 11Version: 1.0
4 Product overview
The CX5200 product family includes two different Embedded PCs, which differ by their processor type and
RAM. The CX52x0 Embedded PC is a full-fledged PC with the following basic configuration:
• CFast card slot,
• MicroSD card slot,
• two independent Gbit Ethernet interfaces,
• four USB 3.0 interfaces,
• and a DVI-D interface
The Embedded PC features an internal 1-second UPS as persistent data memory. In the event of a power
failure the 1-second UPS can store up to 1 MB of persistent data on the CFast card or MicroSD card.
Microsoft Windows 10 IoT Enterprise 2019 LTSC or TwinCAT/BSD can be used as the operating system.
Extension modules
The basic CPU module can be extended if required and thus equipped with additional interfaces. To do this,
a system module or fieldbus module from the CX2500-xxxx series can be plugged in via the multi-pin
connection on the left-hand side of the device. In total, no more than one module can be plugged in.
Table2: Available extension modules for the CX52x0.
Module Description
CX2500-0030 RS232 serial interface, 2 x D-sub plug, 9-pin
CX2500-0031 RS422/RS485 serial interface, 2 x D-sub socket, 9-pin
CX2500-0060 Ethernet module, 2 x Ethernet, 10/100/1000 Mbit/s
CX2500-0061 Power-over-Ethernet module (PoE), 1 x RJ45, 10/100/1000 Mbit/s
CX2500-0070 USB 3.0 module, 4 x USB 3.0, type A
CX2500-M310 PROFIBUS fieldbus master module, 1 x D-sub socket, 9-pin
CX2500-B310 PROFIBUS fieldbus slave module, 1 x D-sub socket, 9-pin
CX2500-M510 CANopen fieldbus master module, 1 x D-sub plug, 9-pin
CX2500-B510 CANopen fieldbus slave module, 1 x D-sub plug, 9-pin
Optional interface
The Embedded PC can be ordered ex factory with an optional interface. The optional interface cannot be
retrofitted.
Table3: Available optional interfaces for the CX52x0.
CX52x0-xxxx Optional interfaces
CX52x0-N010 DVI-D, additional DVI-D socket for clone and extended display mode.1)
CX52x0-N011 DisplayPort, additional DisplayPort for clone and extended display mode.1)
CX52x0-N020 Audio interface, 3 x 3.5 mm jack plug, Line-In, Mic-In, Line-Out
CX52x0-N030 RS232, D-sub connector, 9-pole.
CX52x0-N031 RS422/RS485, D-sub socket, 9-pole.
CX52x0-M112 2 x EtherCAT-Master, RJ45.
CX52x0-B110 EtherCAT slave, EtherCAT IN and OUT (2 x RJ45).
CX52x0-M310 PROFIBUS master, D-sub socket, 9-pole.
CX52x0-B310 PROFIBUS slave, D-sub socket, 9-pole.
CX52x0-M510 CANopen master, D-sub connector, 9-pole.
CX52x0-B510 CANopen slave, D-sub connector, 9-pole.
CX52x0-M930 PROFINET RT, controller, Ethernet (2 x RJ-45).
CX52x0-B930 PROFINET RT, device, Ethernet (2 x RJ-45 switch).

Product overview
CX52x012 Version: 1.0
Power supply terminal
The power supply terminal for the Embedded PC is located on the right-hand side. Bus Terminals (K-bus) or
EtherCAT Terminals (E-bus) can be attached on the right-hand side of the power supply terminal. The power
supply terminal automatically recognizes the respective bus system (K-bus or E-bus).
Software
In combination with the TwinCAT automation software, the CX52x0 Embedded PC becomes a powerful IEC
61131-3 PLC with up to four user tasks.
Additionally, Motion Control tasks can also be executed. It may be possible to control several servo axes,
depending on the required sampling time. In addition to simple point-to-point movements, it is possible to
execute more complex multi-axis functions such as electronic gearing, cam plate and flying saw.
In addition to real-time execution of control tasks, the TwinCAT real-time kernel ensures that enough time
remains for the user interface (HMI), to communicate with the real-time components via software interfaces
such as ADS or OPC.

Product overview
CX52x0 13Version: 1.0
4.1 Structure
1
2
8
3
5
9
11
12
13
15
4
14
16
6
710
Fig.1: Example configuration of a CX5240 Embedded PC.
Table4: Legend for the configuration.
No. Component Description
1 Optional interface (X300). Space for interfaces such as RS232, EtherCAT, CANopen or
others.
The optional interface must be ordered ex factory and cannot be
retrofitted retrospectively.
2 DVI-D interface (X200). Interface for a monitor or Panel.
3 CFast card slot (under the
front flap).
Slot for industrial CFast cards.
4 MicroSD card slot (under
the front flap).
Slot for industrial MicroSD cards.
5 RJ45 Ethernet interfaces
(X000, X001).
For connecting to local networks or the internet.
6 Battery compartment
(under the front flap).
Power supply for the battery-backed clock for time and date.
7 Diagnostic LEDs. Diagnostic LEDs for power supply, TwinCAT and the optional
interface.
8 USB interfaces (X100,
X101, X102, X103).
Interfaces for peripheral devices such as mouse, keyboard or USB
memory.
9Diagnostic LEDs, power
supply terminal [}62].
Diagnosis of the power supply for the Embedded PC and the
terminal bus. Status of the E-bus and K-bus communication.
10 Spring-loaded terminals,
+24V and 0V
Power supply for Embedded PC.
11 Terminal bus (K-bus or E-
bus)
Interface for EtherCAT Terminals or Bus Terminals. Data exchange
and supply.
12 Spring-loaded terminal,
+24V
Power supply for Bus Terminals via power contact.
13 Spring-loaded terminal, 0V Power supply for Bus Terminals via power contact.
14 Terminal release Releases the power supply terminal and thus the Embedded PC
from the DIN rail.
15 Spring-loaded terminal, PE Spring-loaded terminal for power contact PE.
16 Power contacts, +24V,
0V, PE
Power contacts for Bus Terminals.

Product overview
CX52x014 Version: 1.0
4.2 Name plate
Fig.2: Name plate example.
Table5: Information on the name plate.
No. Description
1 Machine-readable information in the form of a Data Matrix Code (DMC, code scheme
ECC200) that you can use for better identification and management.
2 Variant number for identification of the Embedded PC configuration. With this number, the
exact configuration of Embedded PC, operating system, options and TwinCAT can be
reordered.
3 Product designation for identification of the Embedded PC
4 Serial number/ Beckhoff Traceability Number (BTN) for the unambiguous identification of
the product.
5 Hardware version and date of manufacture.
6 MAC addresses of the built-in Ethernet interfaces. The host name is made up of CX and
the last three bytes of the MAC address. Example: The host name CX-aabbcc results
from the MAC address 00-01-05-aa-bb-cc.
7 Power supply 24VDC
8 EAC approval
9 CE conformity
10 License sticker for operating system (optional).

Product overview
CX52x0 15Version: 1.0
4.3 Types
The CX52x0 Embedded PC can be ordered with different software options. Use this overview in conjunction
with the information on the name plate to ascertain the operating system and the TwinCAT version of the
Embedded PC.
Fig.3: Nomenclature for the CX52x0 Embedded PC.
The CX5230 and CX5240 Embedded PCs are available with the following software options:
Table6: CX52x0 ordering information.
Module no
operating sys-
tem
Windows 10 IoT
Enterprise 2016
LTSC 64-bit
TwinCAT/BSD no
TwinCAT
TwinCAT 3
XAR
CX52x0-0100 X - - X -
CX52x0-0170 - X - X -
CX52x0-0175 - X - - X
CX52x0-0185 - - X - X

Product overview
CX52x016 Version: 1.0
4.4 Architecture overview
The Embedded PCs of the CX52x0 family all have the same architecture. This is described below.
The CX52x0 Embedded PCs are based on the Intel Atom microarchitecture, which was developed by Intel.
The following CPUs are used:
• Intel® AtomTM x5-E3930 (dual-core)
• Intel® AtomTM x5-E3940 (quad-core)
In addition to the arithmetic unit, the CPU also contains the memory controller and the graphics controller.
The processors use the Intel® HD Graphics core. For details on the CPUs please refer to Intel. The memory
is connected directly to the CPU. The Embedded PCs are available in two memory configurations: 4 GB and
8 GB DDR4-RAM. The memory is not extendable.
The CPU provides all required interfaces:
• 1 PCI lane for each of the two Intel® i210 Gigabit Ethernet controllers
• 4x USB 3.0 (interfaces)
• DVI-D interface (second interface optional with CX52x0-N010)
• 1 PCIe for FPGA for K-/E-bus
• 1 SATA for CFast card interface
• 1 IDE for MicroSD card interface
The interfaces (USB, DVI, and LAN) are standard interfaces. Devices that meet the corresponding standard
can be connected to and operated at these interfaces.

Interface description
CX52x0 17Version: 1.0
5 Interface description
5.1 USB 3.0 (X100, X101, X102, X103)
The Embedded PC has four independent USB interfaces. for connecting keyboards, mice, touchscreens and
other input or data storage devices.
Fig.4: USB interfaces (X100, X101, X102, X103).
The USB interfaces are type A and comply with the USB 3.0 specification.
Table7: USB interfaces (X100, X101, X102, X103), pin assignment.
Pin Connection Typical assignment
1 VBUS Red
2 D- White
3 D+ Green
4 GND Black
5 StdA_SSRX− Blue
6 StdA_SSRX+ Yellow
7 GND_DRAIN N/A
8 StdA_SSTX− Purple
9 StdA_SSTX+ Orange
Shell Shield Drain Wire
Pay attention to the power consumption of the connected devices. No more than 900mA and 4.5W of
power can be output per interface. The USB interfaces support data rates of up to 5Gbit/s.

Interface description
CX52x018 Version: 1.0
5.2 Ethernet RJ45 (X000, X001)
The two Ethernet interfaces are independent; no switch is integrated. The independent Ethernet interfaces
can be configured in different ways. In the delivery state, the Ethernet interfaces (X000, X001) are configured
for EtherCAT communication.
Note that an additional switch is required for a line topology.
Fig.5: Ethernet interfaces X000, X001.
Both Ethernet interfaces reach speeds of 10 / 100 / 1000 Mbit. The LEDs on the left of the interfaces indicate
the connection status. The upper LED (LINK/ACT) indicates whether the interface is connected to a network.
If this is the case, the LED lights up green. The LED flashes when data transfer on the interface is in
progress.
The lower LED (SPEED) indicates the connection speed. At a speed of 10 Mbit, the LED does not light up. If
the speed is 100 Mbit, the LED lights up green. The LED lights up red if the speed is 1000 Mbit (gigabit).
Table8: Ethernet interface X000 and X001, pin assignment.
PIN Signal Description
1 T2 + Pair 2
2 T2 -
3 T3 + Pair 3
4 T1 + Pair 1
5 T1 -
6 T3 - Pair 3
7 T4 + Pair 4
8 T4 -

Interface description
CX52x0 19Version: 1.0
5.3 DVI-D (X200)
The DVI-D interface (X200) transfers digital data and is suitable for connection to digital displays. If the
optional N010 interface (DVI-D interface) is used, the first DVI-I interface can be operated either in VGA
mode or in DVI mode. The resolution at the display or the Beckhoff Control Panel depends on the distance
from the display device. The maximum distance is 5 m. Beckhoff offers various Panels with an integrated
“DVI extension”. These make a cable length of up to 50 meters possible.
Fig.6: DVI-D interface X200.
Table9: DVI-D interface X200, pin assignment.
Pin Connection Pin Connection Pin Connection
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield 19 TMDS Data 0/5 Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 + 5V Power 22 TMDS Clock Shield
7 DDC Data 15 Ground ( +5V, Analog H/
V Sync)
23 TMDS Clock +
8 Analog Vertical Sync 16 Hot Plug Detect 24 TMDA Clock -
Table10: DVI-D interface X200, resolution at the monitor.
Resolution in pixels Distance of the interface from the monitor
1920 x 1200 5 m
1920 x 1080 5 m
1600 x 1200 5 m
1280 x 1024 5 m
1024 x 768 5 m
800 x 600 5 m
640 x 480 5 m
The Embedded PC also supports higher resolutions, based on the DVI standard. A maximum resolution of
2560 x 1440 pixels can be set on the Embedded PC. Whether this resolution is achieved depends on the
monitor, the cable quality and the cable length.

Interface description
CX52x020 Version: 1.0
5.4 Optional interfaces
An optional interface is an additional interface that can be equipped with a wide range of signal types ex
factory and extends the Embedded PC beyond the basic equipment. The optional interface must be ordered
in advance and cannot be retrofitted to the device.
5.4.1 DVI-D (N010)
The DVI-D interface (X300) transfers digital data and is suitable for connection to digital displays. If the
optional N010 interface (DVI-D interface) is used, the first DVI-I interface can be operated either in VGA
mode or in DVI mode. The resolution at the display or the Beckhoff Control Panel depends on the distance
from the display device. The maximum distance is 5 m. Beckhoff offers various Panels with an integrated
“DVI extension”. These make a cable length of up to 50 meters possible.
Fig.7: DVI-D interface X300.
Table11: DVI-D interface X300, pin assignment.
Pin Connection Pin Connection Pin Connection
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield 19 TMDS Data 0/5 Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 + 5V Power 22 TMDS Clock Shield
7 DDC Data 15 Ground ( +5V, Analog H/
V Sync)
23 TMDS Clock +
8 Analog Vertical Sync 16 Hot Plug Detect 24 TMDA Clock -
Table12: DVI-D interface X300, resolution at the monitor.
Resolution in pixels Distance of the interface from the monitor
1920 x 1200 5 m
1920 x 1080 5 m
1600 x 1200 5 m
1280 x 1024 5 m
1024 x 768 5 m
800 x 600 5 m
640 x 480 5 m
The Embedded PC also supports higher resolutions, based on the DVI standard. A maximum resolution of
2560 x 1440 pixels can be set on the Embedded PC. Whether this resolution is achieved depends on the
monitor, the cable quality and the cable length.
