Beckhoff PS2001-4810-0000 Operator's manual

Documentation | EN
PS2001-4810-0000
Power supply 48 V DC, 10 A, 1-phase
2020-10-08 | Version: 1.0

Table of contents
PS2001-4810-0000 3Version: 1.0
Table of contents
1 Overview.....................................................................................................................................................5
2 Foreword ....................................................................................................................................................6
2.1 Notes on the documentation..............................................................................................................6
2.2 Safety instructions .............................................................................................................................7
2.3 Terminology and abbreviations .......................................................................................................10
3 Technical data, mounting, wiring...........................................................................................................11
3.1 AC input...........................................................................................................................................11
3.2 DC input...........................................................................................................................................13
3.3 Input inrush current..........................................................................................................................14
3.4 Output..............................................................................................................................................15
3.5 Hold-up time ....................................................................................................................................16
3.6 DC-OK relay contact........................................................................................................................17
3.7 Efficiency and losses .......................................................................................................................18
3.8 Lifetime expectancy.........................................................................................................................19
3.9 MTBF...............................................................................................................................................19
3.10 Terminals and wiring .......................................................................................................................20
3.11 Functional wiring diagram................................................................................................................21
3.12 Front side and operating elements ..................................................................................................22
3.13 EMC.................................................................................................................................................23
3.14 Environment ....................................................................................................................................24
3.15 Protective functions .........................................................................................................................25
3.16 Safety features ................................................................................................................................25
3.17 Dielectric strength............................................................................................................................26
3.18 Declaration of conformity and approvals .........................................................................................27
3.19 Dimensions and weight ...................................................................................................................28
4 Application notes.....................................................................................................................................29
4.1 Peak current capability ....................................................................................................................29
4.2 Output circuit breakers ....................................................................................................................31
4.3 Charging batteries ...........................................................................................................................32
4.4 Series connection ............................................................................................................................32
4.5 Parallel use to increase power ........................................................................................................32
4.6 Operation on two phases.................................................................................................................34
4.7 Use in a tightly sealed enclosure.....................................................................................................34
4.8 Installation positions ........................................................................................................................34
5 Appendix ..................................................................................................................................................36
5.1 Accessories .....................................................................................................................................36
5.2 Documentation issue status ............................................................................................................37
5.3 Support and Service ........................................................................................................................38

Table of contents
PS2001-4810-00004 Version: 1.0

Overview
PS2001-4810-0000 5Version: 1.0
1 Overview
PS2001-4810-0000 | Power supply 48V, 10A, 1 phase, Extra Power
• AC 100-240V wide-range input
• Width only 48mm
• Efficiency of up to 96.3%
• Excellent part-load efficiency
• 120% peak power, 576W
• Safe hiccup overload mode
• Precise triggering of fuses through high overload / peak current
• Active Power Factor Correction (PFC)
• Minimum inrush current surge
• Full output between -25°C and +60°C
• DC-OK relay contact
• Current-sharing function for parallel use
The power supply PS2001-4810-0000 is a single-phase, 48 V DC power supply with an output current of 10
A and an output power of 480 W.
On the input side, the device features a wide-range input, Active Power Factor Correction (PFC) and inrush
current limiting. The output operates according to the UI characteristic curve and switches to the safe hiccup
mode in case of overload/short-circuit.
The PS2001-4810-0000 features extra power with a continuous maximum output power of 120% and can
precisely trigger fuses with a short peak current.
The power supply unit is part of the PS2000 family and has a width of 48 mm. A DC-OK LED and a potential-
free relay contact monitor the status of the output voltage. The power supply unit has ATEX/IECEx and
Class I Div2 approval to meet the requirements of the process industry.
Overview of technical data *)
Overview of technical data PS2001-4810-0000
Output voltage DC48V (nominal factory setting 48V)
Adjustment range 48 - 56V
Output current 12.0-10.3A (amb. below +45°C)
10.0-8.6A (amb. at +60°C)
7.5-6.5A (amb. at +70°C)
Linear load reduction between +45°C and +70°C
Input voltage AC AC 100-240V -15%/+10%
Mains frequency 50-60Hz ±6%
Input current AC 4.26 / 2.23A at 120 / 230Vac
Input voltage DC DC 110-150V ±20%
Efficiency 95.0 / 96.3% at 120 / 230Vac
Temperature range -25°C to +70°C
Size (W x H x D) 48 x 124 x 117mm (without DIN rail)
Weight 830g
Approvals/markings CE
cULus
Class I Div2
ATEX
IECEx
EAC
*) All values typical for 48V, 10A, 230Vac, 50Hz, +25°C ambient temperature and after a warm-up period of five minutes, unless other-
wise stated.

Foreword
PS2001-4810-00006 Version: 1.0
2 Foreword
2.1 Notes on the documentation
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, EtherCAT®, EtherCATG®, EtherCATG10®, EtherCATP®, SafetyoverEtherCAT®,
TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation
GmbH. Other designations used in this publication may be trademarks whose use by third parties for their
own purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents: EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding
applications or registrations in various other countries.
Intended audience
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with the applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning these components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Foreword
PS2001-4810-0000 7Version: 1.0
2.2 Safety instructions
Description of instructions
In this documentation the following instructions are used.
These instructions must be read carefully and followed without fail!
DANGER
Serious risk of injury!
Failure to follow this safety instruction directly endangers the life and health of persons.
WARNING
Risk of injury!
Failure to follow this safety instruction endangers the life and health of persons.
CAUTION
Personal injuries!
Failure to follow this safety instruction can lead to injuries to persons.
NOTE
Damage to environment/equipment or data loss
Failure to follow this instruction can lead to environmental damage, equipment damage or data loss.
Tip or pointer
This symbol indicates information that contributes to better understanding.
Intended use
This device is designed for installation in a housing and is intended for general professional use, for example
in industrial control systems or office, communication and measuring equipment.
Do not use this power supply in installations where a malfunction could cause serious injury or danger to
human life.
Exclusion of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.
Personnel qualification
This description is only intended for trained specialists in control, automation and drive engineering who are
familiar with the applicable national standards.
Safety regulations
Please note the following safety instructions and explanations!
Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,
commissioning etc.

Foreword
PS2001-4810-00008 Version: 1.0
Safety instructions and installation requirements for PS2001-4810-0000 power supply unit
DANGER
Danger of electric shock, fire, injuries, injuries resulting in death!
• Do not use the power supply without proper earthing (protective conductor). Use the terminal at the input
terminal strip for the earth connection, not one of the screws on the housing.
• Switch off the power supply before working on the device. Provide protection against unintentional re-
connection.
• Ensure proper wiring by following all local and national regulations.
• Do not modify or attempt to repair the device.
• Do not open the device, as high voltages are present inside.
• Avoid foreign bodies entering the housing.
• Do not use the device in damp locations or in areas where moisture or condensation is likely to occur.
• Do not touch the device when it is switched on or immediately after it has been switched off. Hot sur-
faces can cause burns.
WARNING
Explosion hazard warning!
Do not use with DC input voltages.
Do not use with AC input voltages below 90Vac.
Use only in standard vertical mounting orientation with the input terminals at the bottom of the device.
Replacement of components may affect the suitability for this environment.
Do not disconnect the device from the mains and do not operate the voltage adjustment unless the power is
switched off or the environment can be considered safe.
For the end product a suitable housing must be provided, which has a minimum protection class of IP54
and meets the requirements of EN 60079-0.
NOTE
Instructions for use in potentially explosive atmospheres
The device is suitable for use in the following areas:
Class I Division 2 Groups A, B, C, D
and for use in Group II environments of Category 3 (Zone 2).
Classification:
ATEX: EPS 17 ATEX 1 089 X, II 3G EX ec nC IIC T4 Gc / IECEx EPS 20.0047X.

Foreword
PS2001-4810-0000 9Version: 1.0
Further notes on installation requirements
• This device contains no parts that require maintenance. If an internal fuse trips, this is due to an
internal defect.
• If any damage or malfunction occurs during installation or operation, turn off the power immedi-
ately and return the device to the factory for inspection.
• Install the device on a DIN rail according to EN 60715, with the input terminals at the bottom of
the device. Other mounting positions require a reduction of the output current.
• Make sure that the wiring is correct. Make sure that all individual wires of a strand enter the ter-
minal connection.
• Unused screw terminals should be tightened firmly.
• The device is designed for areas with contamination level 2 in controlled environments. No con-
densation or frost is allowed.
• The device housing offers IP20 protection.
• The device insulation is designed to withstand pulse voltages of overvoltage category III accord-
ing to IEC 60664-1.
• The device is designed to meet the requirements of protection class I according to IEC 61140.
• Do not use the device without a proper PE connection (protective earth). For the earth connec-
tion use the terminal on the input block, not one of the screws on the housing.
• The device is suitable for supply from TN, TT and IT networks. The voltage between the L or N
terminal and the PE terminal must not exceed 300Vac continuously.
• The input can also be powered from batteries or similar DC power sources. The voltage between
the input terminal and the PE terminal must not exceed 375Vdc continuously.
• An isolating device must be provided for the device input.
• This device is designed for convection cooling and does not require an external fan. Do not ob-
struct the air circulation. No more than 15% of the ventilation grille may be covered (e.g. by cable
ducts)!
• The device is designed for altitudes up to 6000m (19685ft). Above 2000m (6560ft) a reduction of
the output current and overvoltage category is required.
• Maintain the following installation distances: 40mm at the top, 20mm at the bottom and 5mm
on the left and right are recommended if the device continuously runs at more than 50% of the
rated output. Increase this distance to 15mm if the adjacent device is a heat source (e.g. an-
other power supply unit). If the device continuously runs at less than 50%, the 5mm distance
can be reduced to zero.
• The device is designed, tested and approved for branch-circuit currents up to 32A (IEC) and
30A (UL) without additional protection. If an external fuse is used, do not use circuit breakers
smaller than 10A (B or C characteristic) to avoid unwanted tripping of the circuit breaker.
• The maximum ambient air temperature is +70°C (+158°F). The operating temperature corre-
sponds to the ambient or ambient air temperature, per definition at 2 cm below the device.
• The device is designed for operation in the relative humidity range between 5% and 95%.

Foreword
PS2001-4810-000010 Version: 1.0
2.3 Terminology and abbreviations
PE and the earthing
symbol
PE is the abbreviation for "protective earth" and has the same meaning as the
earthing symbol
Earth, ground This document uses the term “earth” which is the same as the U.S. term “ground”.
T.b.d. Still to be defined, value or description will follow in due course.
AC 230V A value preceded by "AC" or "DC" represents a nominal voltage or a nominal
voltage range. The nominal voltage or the nominal voltage range may be provided
with tolerances. (e.g. AC 230V ±10%). The calculated total range then indicates
the working range of the device.
Example:
DC 12V refers to a 12V battery, regardless of whether it is fully charged
(13.7Vdc) or discharged (10Vdc).
230Vac A value followed by the unit Vac or Vdc is an instantaneous value that does not
contain any additional tolerances.
50Hz vs. 60Hz Unless otherwise specified, AC 100V and AC 230V parameters are valid at a
mains frequency of 50Hz. AC 120V parameters are valid for a mains frequency of
60Hz.
may A keyword indicating a choice without implied preference.
shall A keyword indicating a mandatory requirement.
should A keyword indicating a choice with a clearly preferred method of implementation.

Technical data, mounting, wiring
PS2001-4810-0000 11Version: 1.0
3 Technical data, mounting, wiring
3.1 AC input
The device is suitable for being supplied with AC voltage from TN, TT and IT networks. For suitable DC
supply voltages see chapter DC input [}13].
AC input
AC input Nom. AC 100-240V Suitable for TN, TT and IT networks
AC input range Min. 85-264Vac Continuous operation
Min. 264-300Vac For up to 500ms max.
Permissible voltage L or N to earth Max. 300Vac Continuous according to IEC 60664-1
Input frequency Nom. 50-60Hz ±6%
Turn-on voltage Typ. 82Vac Static, see Fig. Input voltage range; switch-on behavior definitions
Shut-down voltage Typ. 72Vac Static, see Fig. Input voltage range; switch-on behavior definitions
AC input AC 100V AC120V AC230V
Input current Typ. 5.15A 4.26A 2.23A At 48V, 10A, see Fig. Input current over output
current; power factor over output current
Power factor*) Typ. 0.996 0.996 0.980 At 48V, 10A, see Fig. Input current over output
current; power factor over output current
Peak factor**) Typ. 1.65 1.63 1.63 At 48V, 10A
Start-up delay Typ. 450ms 450ms 450ms See Fig. Input voltage range; switch-on behav-
ior definitions
Rise time Typ. 120ms 120ms 120ms At 48V, 10A constant current load, 0mF load
capacity, see Fig. Input voltage range; switch-
on behavior definitions
Typ. 170mV 170mV 170mV At 48V, 10A constant current load, 10mF
load capacity, see Fig. Input voltage range;
switch-on behavior definitions
Turn-on overshoot Max. 500mV 500mV 500mV See Fig. Input voltage range; switch-on behav-
ior definitions
*) The power factor is the ratio of real (or active) power to apparent power in an AC circuit.
**) The peak factor is the mathematical ratio of the peak value to the RMS value of the input current
waveform.
Fig.1: Input voltage range; switch-on behavior definitions

Technical data, mounting, wiring
PS2001-4810-000012 Version: 1.0
Fig.2: Input current over output current; power factor over output current

Technical data, mounting, wiring
PS2001-4810-0000 13Version: 1.0
3.2 DC input
DC input
DC input Nom. DC 110-150V ±20%
DC input range Min. 88-180Vdc Continuous operation
DC input current Typ. 4.64A at 110Vdc, at 24V, 20A
Permissible voltage L or N
to earth
Max. 375 Vdc Continuous according to IEC 60664-1
Turn-on voltage Typ. 80 Vdc static
Shut-down voltage Typ. 70 Vdc static
Instructions for DC operation
• The device is suitable for supply from a DC input voltage
• Use a battery or a comparable DC source. Operation on the DC link of frequency converters is not
recommended and may lead to defects or malfunctions.
• Connect the positive pole to L and the negative pole to N.
• Connect the PE terminal to the protective conductor or machine ground.
Fig.3: Wiring for DC input

Technical data, mounting, wiring
PS2001-4810-000014 Version: 1.0
3.3 Input inrush current
Active inrush current limitation limits the inrush current surge after the input voltage is switched on.
The charge current of the interference suppression capacitors during the first few microseconds after
switching on is not taken into account.
AC 100V AC 120V AC 230V
Input inrush
current
Max. 15Apeak 12Apeak 5.5Apeak temperature-independent
Typ. 12Apeak 10Apeak 4.5Apeak
Inrush energy Max. 1A²s 1A²s 1A²s
Fig.4: Typical switch-on behavior at nominal load, 25°C ambient temperature

Technical data, mounting, wiring
PS2001-4810-0000 15Version: 1.0
3.4 Output
The output provides an SELV/PELV/ES1 nominal voltage that is electrically isolated from the input voltage.
The device is designed to supply any type of load, including capacitive and inductive loads. If very large
capacitors, such as EDLCs (electrical double-layer capacitors or "UltraCaps") with a capacitance > 0.25F are
connected to the output, the device can charge the capacitor intermittently.
The output is electronically protected against overload, no-load and short circuit. In the event of a protection
event, audible noises may occur
Output voltage Nom. 48V
Adjustment range Min. 48-56V Guaranteed value
Max. 60V This is the maximum output voltage that can occur in the end position of the po-
tentiometer in clockwise direction due to tolerances. It is not a guaranteed
value that can be achieved.
Factory settings Typ. 48.0V ±0.2%, single use at full load (cold device)
Typ. 47.0V ±0.2%, parallel use at 10A (cold device)
(46.6V ±0.2% at 12A and 49.0V ±0.2% at zero load)
Line regulation Max. 10mV Between 85 and 300Vac
Load regulation Max. 150mV Between 0 and 10A, static value, "single use"
Typ. 2000mV Between 0 and 10A, static value, "parallel use", see Fig. Output voltage over
output current (parallel use) typ.
Residual ripple and ripple
voltage
Max. 50mVSS Bandwidth 20Hz to 20MHz, 50Ohm
Output current Nom. 12A1) At 48V and ambient temperature below 45°C
Nom. 10A At 48V and 60°C ambient temperature
Nom. 7.5A At 48V and 70°C ambient temperature
Nom. 10.3A1) At 56V and ambient temperature below 45°C
Nom. 8.6A At 56V and 60°C ambient temperature
Nom. 6.5A At 56V and 70°C ambient temperature
Linear derating between +45°C and +70°C
Safety
switch-off current
Typ. 30A Up to 12ms once every five seconds, see Fig. Dynamic output current capacity,
typ.
The fuse switch-off current is an increased transient current that contributes to
the tripping of fuses on faulty output branches. The output voltage remains
above 40V.
Overload behavior Continuous cur-
rent
Output voltage > 26Vdc, see Fig. Output voltage over output current, typ.
Hiccup mode 2) Output voltage < 26Vdc, see Fig. Output voltage over output current, typ.
Short circuit current Max. 14.8A Continuous current, see Fig. Output voltage over output current, typ.
Typ. 15A Intermittent current peak value for typ. 2s
Load impedance 10mOhm, see Fig. Short circuit at the output,
The discharge current of the output capacitors is not included.
max 4.7A RMS value of the current,
Load impedance 10mOhm, see Fig. Short circuit at the output,
Output capacity Typ. 2500μF Included in the power supply
Load feedback Max. 63V The device is resistant to load feedback and will not indicate a malfunction if a
load is feeding voltage back into the power supply. It does not matter whether
the power supply is switched on or off. The absorbed energy can be deter-
mined by means of the built-in large-size output capacitor.
1) This current is also available for temperatures up to +70°C with a duty cycle of 10% and/or no more than 1
minute every 10 minutes.
2) In the event of heavy overload (when the output voltage drops below 13V), the power supply provides
continuous output current for 2s. The output is then switched off for about 18 seconds before a new switch-
on attempt is automatically made. This cycle is repeated as long as the overload persists. After the overload
has been rectified, the device will operate normally. See Fig. Short circuit at output, hiccup mode, typ.

Technical data, mounting, wiring
PS2001-4810-000016 Version: 1.0
Fig.5: Output voltage over output current (single use); output voltage over output current (parallel use)
Fig.6: Short circuit at output, hiccup mode, typ.; Dynamic output current capacity, typ.
3.5 Hold-up time
The Hold-up time is the time during which the output voltage of a power supply unit remains within the
specification after a loss of input power. The Hold-up time depends on the output load. At no load the Hold-
up time can be up to several seconds. The green DC-OK lamp also lights up during this time.
AC 100V AC 120V AC 230V
Power failure
Hold-up time
Typ. 65ms 65ms 65ms At 48V, 5A, see Fig. Hold-up time over input
voltage
Min. 54ms 54ms 54ms At 48V, 5A, see Fig. Hold-up time over input
voltage
Typ. 32ms 32ms 32ms At 48V, 10A, see Fig. Hold-up time over input
voltage
Min. 24ms 24ms 24ms At 48V, 10A, see Fig. Hold-up time over input
voltage
Fig.7: Hold-up time over input voltage; switch-off behavior, definitions

Technical data, mounting, wiring
PS2001-4810-0000 17Version: 1.0
3.6 DC-OK relay contact
This feature monitors the output voltage at the output terminals of an active power supply.
The contact closes when the output voltage typically reaches 90% of the set output voltage.
The contact opens when the output voltage drops more than 10% below the set output voltage.
Short drops are extended to a signal length of 100ms. Drops that are shorter
than 1ms are ignored.
Switching hysteresis 2 V
Contact load capacity Maximum 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A, ohmic load
Minimum permissible load: 1mA at 5Vdc
Insulation voltage See the dielectric strength table in the chapter on Safety features [}25]
Fig.8: Behavior of the DC-OK relay contact

Technical data, mounting, wiring
PS2001-4810-000018 Version: 1.0
3.7 Efficiency and losses
AC 100V AC 120V AC 230V
Efficiency Typ. 94.4% 95.0% 96.3% At 48V, 10A
Typ. 94.2% 94.9% 96.2% At 48V, 12A (Extra Power)
Average efficiency*) Typ. 94.1% 94.6% 95.5% 25% at 2.5A, 25% at 5A,
25% at 7.5A, 25% at 10A
Losses Typ. 2.7W 2.4W 2.4W At 48V, 0A
Typ. 14.2W 12.5W 10.6W At 48V, 5A
Typ. 28.5W 25.1W 18.4W At 48V, 10A
Typ. 35.4W 31.0W 22.7W At 48V, 12A (Extra Power)
*) The average efficiency is based on assumptions for a typical application with the power supply unit
operating at 25% of the nominal load during 25% of the time, 50% of the nominal load during 25% of the
time, 75% of the nominal load during 25% of the time and 100% of the nominal load during the remaining
time.
Fig.9: Efficiency over output current; losses over output current
Fig.10: Efficiency over input voltage; losses over input voltage

Technical data, mounting, wiring
PS2001-4810-0000 19Version: 1.0
3.8 Lifetime expectancy
The lifetime expectancy shown in the table indicates the minimum number of operating hours (service life)
and is determined by the lifetime expectancy of the built-in electrolytic capacitors. The lifetime expectancy is
stated in operating hours and is calculated according to the specifications of the capacitor manufacturer. The
manufacturer of the electrolytic capacitors only guarantees a maximum life of up to 15 years (131,400h). Any
number exceeding this value represents a calculated theoretical lifetime which can be used to compare
devices.
AC 100V AC 120V AC 230V
Lifetime
expectancy
52,000h 66,000h 110,000h At 48V, 10A and +40°C
130,000h 152,000h 180,000h At 48V, 5A and +40°C
33,000h 45,000h 89,000h At 48V, 12A and +40°C
148,000h 188,000h 311,000h At 48V, 10A and +25°C
368,000h 431,000h 509,000h At 48V, 5A and +25°C
93,000h 128,000h 251,000h At 48V, 12A and +25°C
3.9 MTBF
MTBF stands for Mean Time Between Failure, which is calculated from the statistical failure rate of the
components and indicates the reliability of a device. It is a statistical representation of the probability of
equipment failure and does not necessarily represent the service life of a product.
The MTBF number is a statistical representation of the probability of equipment failure. An MTBF number of
1,000,000h, for example, means that statistically, if there are 10,000 devices in use, one device will fail every
100 hours. However, it is not possible to say whether the failed device has been in operation for 50,000
hours or only 100 hours.
For these device types the MTTF value (Mean Time To Failure) is identical to the MTBF value.
AC 100V AC 120V AC 230V
MTBF
SN 29500,
IEC 61709
430,000h 443,000h 540,000h At 48V, 10A and +40°C
790,000h 810,000h 973,000h At 48V, 10A and +25°C
MTBF
MIL HDBK 217F
207,000h 209,000h 244,000h At 48V, 10A and +40°C
Ground Benign GB40
279,000h 283,000h 334,000h At 48V, 10A and +25°C
Ground Benign GB25
44,000h 45,000h 54,000h At 48V, 10A and +40°C,
Ground Fixed GF40
58,000h 59,000h 72,000h At 48V, 10A and +25°C,
Ground Fixed GF25

Technical data, mounting, wiring
PS2001-4810-000020 Version: 1.0
3.10 Terminals and wiring
The terminals are designed to be finger-safe according to IP20 and are suitable for field or factory wiring.
Technical data Input Output DC-OK signal
Connection cross-section e*: max. 6mm²
f*: max. 4mm²
a*: max. 4mm² (d<2.8mm)
e*: max. 6mm²
f*: max. 4mm²
a*: max 4mm² (d<2.8mm)
e*: max. 1.5mm²
f*: max. 1.5mm²
a*: max. 1.5mm²
(d<1.6mm)
Connection cross section
(AWG)
e*: AWG 20-10
f*: AWG 20-10
a* AWG 20-10 (d<2.8mm)
e*: AWG 20-10
f*: AWG 20-10
a* AWG 20-10
(d<2.8mm)
e*: AWG 24-16
f*: AWG 24-16
a*: AWG 24-16
(d<1.6mm)
Strip length 7mm / 0.28inch 7mm / 0.28inch 7mm / 0.28inch
e* = solid single wire
f* = stranded wire
a* = with ferrule
Wiring instructions:
• Use suitable copper cables that are designed for at least the following operating temperatures: +60°C
for ambient temperatures up to +45°C, +75°C for ambient temperatures up to +60°C, and +90°C for
ambient temperatures up to +70°C.
• Observe the national installation rules and regulations!
• Make sure that all single wires of a strand are connected to the terminal!
• Unused terminals should be tightened firmly.
• Ferrules are permitted.
Series connection of power supply units:
Power supply units may be connected in series.
Series connection (looping from one power supply output to the next) is permitted as long as the average
output current flowing through a connection pin does not exceed 25A. For higher currents please use a
separate distributor terminal strip as shown in Fig. Using distribution terminals.
Fig.11: Series connection of outputs; use of distribution terminals
