Beckhoff PS2031-2410-0000 Operator's manual

Documentation | EN
PS2031-2410-0000
Power supply 24 V DC, 10 A, 3-phase
2020-10-08 | Version: 1.0

Table of contents
PS2031-2410-0000 3Version: 1.0
Table of contents
1 Overview.....................................................................................................................................................5
2 Foreword ....................................................................................................................................................6
2.1 Notes on the documentation..............................................................................................................6
2.2 Safety instructions .............................................................................................................................7
2.3 Terminology and abbreviations .......................................................................................................10
3 Technical data, mounting, wiring...........................................................................................................11
3.1 AC input...........................................................................................................................................11
3.2 DC input...........................................................................................................................................13
3.3 Input inrush current..........................................................................................................................14
3.4 Output..............................................................................................................................................15
3.5 Hold-up time ....................................................................................................................................16
3.6 Efficiency and losses .......................................................................................................................17
3.7 Lifetime expectancy.........................................................................................................................18
3.8 MTBF...............................................................................................................................................19
3.9 Terminals and wiring .......................................................................................................................20
3.10 Functional wiring diagram................................................................................................................21
3.11 Front side and operating elements ..................................................................................................22
3.12 EMC.................................................................................................................................................23
3.13 Environment ....................................................................................................................................24
3.14 Protective functions .........................................................................................................................25
3.15 Safety features ................................................................................................................................25
3.16 Dielectric strength............................................................................................................................26
3.17 Declaration of conformity and approvals .........................................................................................27
3.18 Dimensions and weight ...................................................................................................................28
4 Application notes.....................................................................................................................................29
4.1 Peak current capability ....................................................................................................................29
4.2 Output circuit breakers ....................................................................................................................30
4.3 Charging batteries ...........................................................................................................................31
4.4 Series connection ............................................................................................................................31
4.5 Parallel use to increase power ........................................................................................................31
4.6 Operation on two phases.................................................................................................................32
4.7 Use in a tightly sealed enclosure.....................................................................................................33
4.8 Installation positions ........................................................................................................................34
5 Appendix ..................................................................................................................................................36
5.1 Accessories .....................................................................................................................................36
5.2 Documentation issue status ............................................................................................................38
5.3 Support and Service ........................................................................................................................39

Table of contents
PS2031-2410-00004 Version: 1.0

Overview
PS2031-2410-0000 5Version: 1.0
1 Overview
PS2031-2410-0000 | Power supply 24V, 10A, 3-phase, Extra Power
• 3AC 380-480V wide-range input
• 2- or 3-phase operation possible
• Width only 62mm
• Efficiency up to 92.9% thanks to synchronous rectifier
• Excellent part-load efficiency
• 120% peak power, 288W
• Precise triggering of fuses through high overload / peak current
• Integrated input transient suppression circuit
• Minimum inrush current surge
• 3 integrated input fuses
• Current-sharing function for parallel use
• Full output between -25°C and +60°C
The PS2031-2410-0000 is a 3-phase 24V power supply unit with an output current of 10A and an output
power of 240W.
On the input side, the device features a wide-range input, harmonic correction (PFC) and inrush current
limitation.
The PS2031-2410-0000 features an Extra Power output with a continuous maximum output power of 120%
and is able to trigger fuses precisely with a short-term peak current.
The power supply unit is part of the PS2000 family and has a width of 62 mm. A DC OK LED monitors the
status of the output voltage
Overview of technical data *)
Overview of technical data PS2031-2410-0000
Output voltage DC 24V (nominal factory setting 24.1V)
Adjustment range 24 - 28V
Output current 12.0-10.3A (amb. below +45°C)
10.0-8.6A (amb. at +60°C)
7.5-6.5A (amb. at +70°C)
Linear load reduction between +45°C and +70°C
Input voltage AC 3AC 380-480V -15%/+20%
Mains frequency 50-60Hz ±6%
Input current AC 0.7 / 0.6A at 3x400 / 480Vac
Efficiency 92.8 / 92.9% at 3x400 / 480Vac
Temperature range -25°C to +70°C
Size (W x H x D) 62 x 124 x 117mm (without DIN rail)
Weight 750g
Approvals/markings CE
cULus
EAC
*) All values typical for 24V, 10A, 3x 400Vac, 50Hz, symmetrical mains voltages, 25°C ambient temperature and after a warm-up
time of five minutes, unless otherwise stated

Foreword
PS2031-2410-00006 Version: 1.0
2 Foreword
2.1 Notes on the documentation
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, EtherCAT®, EtherCATG®, EtherCATG10®, EtherCATP®, SafetyoverEtherCAT®,
TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation
GmbH. Other designations used in this publication may be trademarks whose use by third parties for their
own purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents: EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding
applications or registrations in various other countries.
Intended audience
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with the applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning these components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Foreword
PS2031-2410-0000 7Version: 1.0
2.2 Safety instructions
Description of instructions
In this documentation the following instructions are used.
These instructions must be read carefully and followed without fail!
DANGER
Serious risk of injury!
Failure to follow this safety instruction directly endangers the life and health of persons.
WARNING
Risk of injury!
Failure to follow this safety instruction endangers the life and health of persons.
CAUTION
Personal injuries!
Failure to follow this safety instruction can lead to injuries to persons.
NOTE
Damage to environment/equipment or data loss
Failure to follow this instruction can lead to environmental damage, equipment damage or data loss.
Tip or pointer
This symbol indicates information that contributes to better understanding.
Intended use
This device is designed for installation in a housing and is intended for general professional use, for example
in industrial control systems or office, communication and measuring equipment.
Do not use this power supply in installations where a malfunction could cause serious injury or danger to
human life.
Exclusion of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.
Personnel qualification
This description is only intended for trained specialists in control, automation and drive engineering who are
familiar with the applicable national standards.
Safety regulations
Please note the following safety instructions and explanations!
Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,
commissioning etc.

Foreword
PS2031-2410-00008 Version: 1.0
Safety instructions and installation requirements for PS2031-2410-0000 power supply unit
DANGER
Danger of electric shock, fire, injuries, injuries resulting in death!
• Do not use the power supply without proper earthing (protective conductor). Use the terminal at the input
terminal strip for the earth connection, not one of the screws on the housing.
• Switch off the power supply before working on the device. Provide protection against unintentional re-
connection.
• Ensure proper wiring by following all local and national regulations.
• Do not modify or attempt to repair the device.
• Do not open the device, as high voltages are present inside.
• Avoid foreign bodies entering the housing.
• Do not use the device in damp locations or in areas where moisture or condensation is likely to occur.
• Do not touch the device when it is switched on or immediately after it has been switched off. Hot sur-
faces can cause burns.

Foreword
PS2031-2410-0000 9Version: 1.0
Further notes on installation requirements
• This device contains no serviceable parts. In the event of damage or malfunction during installa-
tion or operation, switch off the device immediately and return it to the factory for inspection. Trig-
gering of an internal fuse indicates an internal defect.
• Install the device in a housing that provides protection against electrical, mechanical and fire
hazards.
• Install the device on a DIN rail according to EN 60715, with the input terminals at the bottom of
the device. Other mounting positions require a reduction of the output current.
• Make sure that the wiring is correct. Make sure that all individual wires of a strand enter the ter-
minal connection.
• Unused screw terminals should be tightened firmly.
• The device is designed for areas with contamination level 2 in controlled environments. No con-
densation or frost is allowed.
• The device housing offers IP20 protection.
• The device insulation is designed to withstand surge voltages of overvoltage category III accord-
ing to IEC 60664-1. For delta protective conductor systems, the overvoltage category is reduced
to level II.
• The device is designed to meet the requirements of protection class I according to IEC 61140.
• Do not use the device without a proper PE connection (protective earth).
• The device is suitable for supply from TN, TT and IT networks. The voltage between the L or N
terminal and the PE terminal must not exceed 500Vac continuously.
• An isolating device must be provided for the device input.
• This device is designed for convection cooling and does not require an external fan. Do not ob-
struct the air circulation.
• The device is designed for altitudes up to 6000m (19685ft). Above 2000m (6560ft) a reduction of
the output current and overvoltage category is required.
• Maintain the following installation distances: 40mm at the top, 20mm at the bottom and 5mm
on the left and right are recommended if the device continuously runs at more than 50% of the
rated output. Increase this distance to 15mm if the adjacent device is a heat source (e.g. an-
other power supply unit). If the device continuously runs at less than 50%, the 5mm distance
can be reduced to zero.
• The device is designed, tested and approved for branch-circuit currents up to 32A (IEC) and
30A (UL) without additional protection. If an external fuse is used, do not use circuit breakers
smaller than 6A (B or C characteristic) to avoid unwanted tripping of the circuit breaker.
• The maximum ambient air temperature is +70°C (+158°F). The operating temperature corre-
sponds to the ambient or ambient air temperature, per definition at 2 cm below the device.
• The device is designed for operation in the relative humidity range between 5% and 95%.

Foreword
PS2031-2410-000010 Version: 1.0
2.3 Terminology and abbreviations
PE and the earthing
symbol
PE is the abbreviation for "protective earth" and has the same meaning as the
earthing symbol
Earth, ground The terms earth and ground are synonymous and are used interchangeably in this
document.
T.b.d. Still to be defined, value or description will follow in due course.
AC 400V A value preceded by "AC" or "DC" represents a nominal voltage or a nominal
voltage range. The nominal voltage or the nominal voltage range may be provided
with tolerances. (e.g., AC380 - 480V ±15%). The calculated total range then
indicates the working range of the device.
Example:
DC 12V refers to a 12V battery, regardless of whether it is fully charged
(13.7Vdc) or discharged (10Vdc).
400Vac A value followed by the unit Vac or Vdc is an instantaneous value that does not
contain any additional tolerances.
50Hz vs. 60Hz Unless otherwise specified, AC 230V parameters are valid at a mains frequency of
50Hz.
may A keyword indicating a choice without implied preference.
shall A keyword indicating a mandatory requirement.
should A keyword indicating a choice with a clearly preferred method of implementation.

Technical data, mounting, wiring
PS2031-2410-0000 11Version: 1.0
3 Technical data, mounting, wiring
3.1 AC input
The device is suitable for being supplied with AC voltage from TN, TT and IT networks. Earthing of one
phase is permitted, except for UL508 applications.
The device can also be operated at only two phases of a three-phase system. For further information see
chapter Two-phase operation [}32].
AC input
AC input Nom. 3AC 380-480V Suitable for TN, TT and IT networks
AC input range Min. 3x 323-576Vac Continuous operation
Min. 3x 576-700Vac For up to 1000ms max.
Permissible voltage L or N to earth Max. 500Vac Continuous according to IEC 62477-1
Input frequency Nom. 50–60Hz ±6%
Turn-on voltage Typ. 3x 260Vac Static, see Fig. Input voltage range; switch-on behavior
definitions
Shut-down voltage Typ. 3x 185Vac Static, see Fig. Input voltage range; switch-on behavior
definitions
AC input 3AC 400V 3AC 480V
Input current Typ. 0.7A 0.6A At 24V, 10A per phase, see Fig. Input current over
output current; power factor over output current
Power factor*) Typ. 0.53 0.52 At 24V, 10A, see Fig. Input current over output cur-
rent; power factor over output current
Start-up delay Typ. 90ms 90ms See Fig. Input voltage range; switch-on behavior defini-
tions
Rise time Typ. 40ms 40ms At 24V, 10A constant current load, 0mF load capac-
ity, see Fig. Input voltage range; switch-on behavior
definitions
Typ. 85ms 85ms At 24V, 10A constant current load, 10mF load capac-
ity, see Fig. Input voltage range; switch-on behavior
definitions
Turn-on overshoot Max. 200mV 200mV See Fig. Input voltage range; switch-on behavior defini-
tions
*) The power factor is the ratio of real (or active) power to apparent power in an AC circuit.
Fig.1: Input voltage range; switch-on behavior definitions

Technical data, mounting, wiring
PS2031-2410-000012 Version: 1.0
Fig.2: Input current over output current; power factor over output current

Technical data, mounting, wiring
PS2031-2410-0000 13Version: 1.0
3.2 DC input
Do not use the power supply unit with DC input voltages!

Technical data, mounting, wiring
PS2031-2410-000014 Version: 1.0
3.3 Input inrush current
Active inrush current limitation limits the inrush current surge after the input voltage is switched on.
The charge current of the interference suppression capacitors during the first few microseconds after
switching on is not taken into account.
3AC 400V 3AC 480V
Input inrush
current
Max. 10Apeak 10Apeak temperature-independent
Typ. 4Apeak 4Apeak
Inrush energy Max. 0.5A²s 0.5A²s
Fig.3: Typical switch-on behavior at nominal load, 25°C ambient temperature

Technical data, mounting, wiring
PS2031-2410-0000 15Version: 1.0
3.4 Output
The output provides an SELV/PELV nominal voltage that is electrically isolated from the input voltage.
The device is designed to supply any type of load, including capacitive and inductive loads.
The output is electronically protected against overload, no-load and short circuit. In the event of a protection
event, audible noises may occur
Output voltage Nom. 24V
Adjustment range Min. 24-28V Guaranteed value
Max. 30.0V This is the maximum output voltage that can occur in the end position of the po-
tentiometer in clockwise direction due to tolerances. It is not a guaranteed
value that can be achieved.
Factory settings Typ. 24.1V ±0.2%, single use at full load (cold device)
±0.2%, parallel use at 10A (cold device)
(23.9V ±0.2% at 12A and 25.0V ±0.2% at zero load)
Line regulation Max. 10mV Between 3x 323 and 3x 576Vac
Load regulation Max. 100mV Between 0 and 10A, static value, single use
Typ. 1000mV Between 0 and 10A, static value, parallel use, see Fig. Output voltage over
output current (parallel use) typ.
Residual ripple and ripple
voltage
Max. 50mVSS Bandwidth 20Hz to 20MHz, 50Ohm
Output current Nom. 12A1) At 24V and ambient temperature below 45°C
Nom. 10A At 24V and 60°C ambient temperature
Nom. 7.5A At 24V and 70°C ambient temperature
Nom. 10.3A1) At 28V and ambient temperature below 45°C
Nom. 8.6A At 28V and 60°C ambient temperature
Nom. 6.5A At 28V and 70°C ambient temperature
Linear derating between +45°C and +70°C
Safety
switch-off current
Typ. 23A Up to 20ms once every five seconds, see Fig. Output voltage over output cur-
rent, typ.
The fuse output current is an increased transient current that contributes to the
tripping of fuses on faulty output branches. The output voltage remains above
20V.
Overload behavior Continuous cur-
rent
see Fig. Output voltage over output current, typ.
Short circuit current Max. 23A Continuous current, see Fig. Output voltage over output current, typ.
Output capacity Typ. 6500μF Included in the power supply
Load feedback Max. 35V The device is resistant to load feedback and will not indicate a malfunction if a
load is feeding voltage back into the power supply. It does not matter whether
the power supply is switched on or off. The absorbed energy can be deter-
mined by means of the built-in large-size output capacitor.
1) This current is also available for temperatures up to +70°C with a duty cycle of 10% and/or no more than 1
minute every 10 minutes.
Fig.4: Output voltage over output current (single use); output voltage over output current (parallel use).

Technical data, mounting, wiring
PS2031-2410-000016 Version: 1.0
3.5 Hold-up time
3AC 400V 3AC 480V
Power failure
Hold-up time
Typ. 34ms 54ms At 24V, 10A, see Fig. Hold-up time over
input voltage
Typ. 68ms 108ms At 24V, 5A, see Fig. Hold-up time over input
voltage
Min. 28ms 44ms At 24V, 10A, see Fig. Hold-up time over
input voltage
Min. 56ms 87ms At 24V, 5A, see Fig. Hold-up time over input
voltage
Fig.5: Hold-up time over input voltage; switch-off behavior, definitions

Technical data, mounting, wiring
PS2031-2410-0000 17Version: 1.0
3.6 Efficiency and losses
3AC 400V 3AC 480V
Efficiency Typ. 92.8% 92.9% At 24V, 10A, 3-phase operation
Typ. 92.4% 92.6% At 24V, 10A, 2 phase operation in a 3-phase system,
see chapter Two-phase operation [}32]
Average efficiency*) Typ. 92.2% 92.0% 25% at 2.5A, 25% at 5A,
25% at 7.5A, 25% at 10A, 3-phase operation
Losses Typ. 2.3W 2.6W At 24V, 0A, 3-phase operation
Typ. 11.8W 11.8W At 24V, 5A, 3-phase operation
Typ. 18.6W 18.3W At 24V, 10A, 3-phase operation
Typ. 23.5W 22.8W At 24V, 12A, 3-phase operation
*) The average efficiency is based on assumptions for a typical application with the power supply unit
operating at 25% of the nominal load during 25% of the time, 50% of the nominal load during 25% of the
time, 75% of the nominal load during 25% of the time and 100% of the nominal load during the remaining
time.
Fig.6: Efficiency over output current; losses over output current
Fig.7: Efficiency over input voltage; losses over input voltage

Technical data, mounting, wiring
PS2031-2410-000018 Version: 1.0
3.7 Lifetime expectancy
The lifetime expectancy shown in the table indicates the minimum number of operating hours (service life)
and is determined by the lifetime expectancy of the built-in electrolytic capacitors. The lifetime expectancy is
stated in operating hours and is calculated according to the specifications of the capacitor manufacturer. The
manufacturer of the electrolytic capacitors only guarantees a maximum life of up to 15 years (131,400h). Any
number exceeding this value represents a calculated theoretical lifetime which can be used to compare
devices.
3AC 400V 3AC 480V
Lifetime
expectancy
54,000h 62,000h At 24V, 10A and +40°C, 3-phase operation
133,000h 134,000h At 24V, 5A and +40°C, 3-phase operation
41,000h 47,000h At 24V, 12A and +40°C, 3-phase operation
151,000h 176,000h At 24V, 10A and +25°C, 3-phase operation
376,000h 379,000h At 24V, 5A and +25°C, 3-phase operation
116,000h 133,000h At 24V, 12A and +25°C, 3-phase operation
Lifetime
expectancy
48,000h 58,000h At 24V, 10A and +40°C, 2-phase operation
134,000h 145,000h At 24V, 5A and +40°C, 2-phase operation
36,000h 42,000h At 24V, 12A and +40°C, 2-phase operation
135,000h 164,000h At 24V, 10A and +25°C, 2-phase operation
379,000h 410,000h At 24V, 5A and +25°C, 2-phase operation
102,000h 119,000h At 24V, 12A and +25°C, 2-phase operation

Technical data, mounting, wiring
PS2031-2410-0000 19Version: 1.0
3.8 MTBF
MTBF stands for Mean Time Between Failure, which is calculated from the statistical failure rate of the
components and indicates the reliability of a device. It is a statistical representation of the probability of
equipment failure and does not necessarily represent the service life of a product.
The MTBF number is a statistical representation of the probability of equipment failure. An MTBF number of
1,000,000h, for example, means that statistically, if there are 10,000 devices in use, one device will fail every
100 hours. However, it is not possible to say whether the failed device has been in operation for 50,000
hours or only 100 hours.
For these device types the MTTF value (Mean Time To Failure) is identical to the MTBF value.
3AC 400V 3AC 480V
MTBF SN 29500,
IEC 61709
975,000h 985,000h At 24V, 10A and 40°C, 3-phase operation
1,706,000h 1,723,000h At 24V, 10A and 25°C, 3-phase operation
925,000h 939,000h At 24V, 10A and 40°C, 2-phase operation
1,633,000h 1,656,000h At 24V, 10A and 25°C, 2-phase operation
MTBF MIL HDBK
217F
444,000h 428,000h At 24V, 10A and 40°C, 3-phase operation, Ground Benign
GB40
584,000h 563,000h At 24V, 10A and 25°C, 3-phase operation, Ground Benign
GB25
100,000h 100,000h At 24V, 10A and 40°C, 3-phase operation, Ground Fixed GF40
132,000h 132,000h At 24V, 10A and 25°C, 3-phase operation, Ground Fixed GF25
436,000h 423,000h At 24V, 10A and 40°C, 2-phase operation, Ground Benign
GB40
555,000h 572,000h At 24V, 10A and 25°C, 2-phase operation, Ground Benign
GB25
98,000h 98,000h At 24V, 10A and 40°C, 2-phase operation, Ground Fixed GF40
129,000h 129,000h At 24V, 10A and 25°C, 2-phase operation, Ground Fixed GF25

Technical data, mounting, wiring
PS2031-2410-000020 Version: 1.0
3.9 Terminals and wiring
The terminals are designed to be finger-safe according to IP20 and are suitable for field or factory wiring.
Technical data Input Output
Connection cross-section e*: max. 6mm²
f*: max. 4mm²
a*: max. 4mm² (d<2.8mm)
e*: max. 6mm²
f*: max. 4mm²
a*: max 4mm² (d<2.8mm)
Connection cross section
(AWG)
e*: AWG 20-10
f*: AWG 20-10
a* AWG 20-10 (d<2.8mm)
e*: AWG 20-10
f*: AWG 20-10
a* AWG 20-10 (d<2.8mm)
Strip length 7mm / 0.28inch 7mm / 0.28inch
e* = solid single wire
f* = stranded wire
a* = with ferrule
Wiring instructions:
• Use suitable copper cables that are designed for at least the following operating temperatures: +60°C
for ambient temperatures up to +45°C, +75°C for ambient temperatures up to +60°C, and +90°C for
ambient temperatures up to +70°C.
• Observe the national installation rules and regulations!
• Make sure that all single wires of a strand are connected to the terminal!
• Unused terminals should be tightened firmly.
• Ferrules are permitted.
Series connection of power supply units:
Series connection (looping from one power supply output to the next) is permitted as long as the average
output current flowing through a connection pin does not exceed 25A. For higher currents please use a
separate distributor terminal strip as shown in Fig. Using distribution terminals.
Fig.8: Series connection of outputs; use of distribution terminals
