Bedkingdom JASPER User manual

PRODUCT SIZE : 920mm x 1930mm (Int Base Size)
Thank you for purchasing this product. Before starting assembly we suggest you spend a short time reading
through this leaflet, then follow the simple step by step guide.
Two persons are needed to assemble this product.
ASSEMBLY INSTRUCTIONS
MODEL : JASPER (#:FJASPBW)
120
* Approximately 2 Hours
* 2 People Required
IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
Tools Required For Assembly
Philips Screw Driver
DO NOT USE POWER TOOLS
TO ASSEMBLE THIS PRODUCT.
USE OF POWER TOOLS WILL
INVALIDATE ANY CLAIM AND
MAY DAMAGE THIS PRODUCT
MAKING IT UNSAFE.
DO NOT USE HAMMER
Tools Not Use
a) WARNING “High beds and the upper bed of bunk beds are not suitable for children under six years due to the risk of injuryfrom falls”;
b) WARNING “Bunk beds and high beds can present a serious risk of injury from strangulation if not used correctly. Never attach or
hang items to any part of the bunk bed that are not designed to be used with the bed,for example, but not limited to ropes, strings,
cords, hooks, belts and bags”
c) WARNING “Children can become trapped between the bed and the wall, a roof pitch, the ceiling, adjoining pieces of furniture
(e.g. cupboards) and the like. To avoid risk of serious injury the distance between the top safety barrier and the adjoining structure
shall not exceed 75 mm or shall be more than 230 mm”;
d) WARNING “Do not use the bunk bed/high bed if any structural part is broken or missing;
e) always follow the manufacturer’s instructions;
f)
g) Ventilation of the room is necessary in order to keep the humidity low and to prevent mauld in and around the bed;
h) all bunk beds and high beds intended to be assembled by other than the manufacturer or his/her representative shall include
assembly instructions including a list of the parts supplied and details of any tools required to assemble the bed;
i)
j)
k) This bunk bed conforms to BS EN 747-1 : 2012 + A1 : 2015
This bunk bed is suitable for a single mattress or foam bed 920mm x 1870mm.Thickness of mattress should not exceed 200mm.
Use ladder for entering and leaving upper bunk.
The bunk bed should be checked periodically by the owner to ensure that the guardrail, ladder and other components are
maintained in the correct position and state of repair and that all connectors are tight.
CK 6285

PARTS LIST
Pcs
Part Name
No.
Carton 1 of 4
2
20
FITTING LIST
Carton 2 of 4
Carton 3 of 4
Pcs
SIDE PANEL (LOWER)
01 2
SIDE PANEL (UPPER)
02 2
METAL SIDE RAIL
33 4
TOP PANEL (4TH LADDER STEP)
18 1
DOOR
22 1
DOOR
23 3
LVL SLATS BASE
35 16
LEFT AND RIGHT BASE (TRUNDLE)
30 2
CENTER BASE (TRUNDLE)
31 1
SUPPORT PANEL (TRUNDLE)
32 2
GUARDRAIL
34 2
Carton 4 of 4
FRONT PANEL (TRUNDLE)
26 1
RIGHT PANEL (TRUNDLE)
27 1
LEFT PANEL (TRUNDLE)
28 1
BACK PANEL (TRUNDLE)
29 1
LADDER BOTTOM PANEL
06 1
LEFT PANEL (1ST LADDER STEP)
08 1
TOP PANEL (1ST LADDER STEP)
09 1
RIGTH PANEL (1ST LADDER STEP)
07 1
LEFT PANEL (2ND LADDER STEP)
11 1
RIGHT PANEL (2ND LADDER STEP)
10 1
TOP PANEL (2ND LADDER STEP)
12 1
13 1
RIGHT PANEL (3RD LADDER STEP)
14 1
TOP PANEL (3RD LADDER STEP)
15 1
LEFT PANEL (3RD LADDER STEP)
RIGHT PANEL (4TH LADDER STEP)
16 1
17 1
LEFT PANEL (4TH LADDER STEP)
BACK PANEL (1ST LADDER STEP)
19 1
20 1
BACK PANEL (2ND LADDER STEP)
21 1
BACK PANEL (LADDER)
LVL SLATS BASE
35 16
RIGHT END PANEL
03
END PANEL
04
LADDER LEFT PANEL
05
1
1
1
CK 6285
JASPER (#:FJASPBW)

PARTS LIST 20
3
35 x16
34
02
03
01
02
34
01
04
30
31
30
32
29
28
27
23
22
19
20
07
09
10
12
15
18
21
05
x4
33
06
08
11
14
17
13
16
x3
x2
(2 set)
26
JASPER (#:FJASPBW)
CK 6285

FITTING LIST 20
4
USEFUL HINTS & TIPS
Two people will be required
to assemble this unit
Please keep this assembly
instruction for future reference
CAUTION
There are many small components used
in the construction of this unit. These
loose items should be kept away from
young children whilst assembling your
unit. As an extra precaution, screw
cover caps should be permanently
fixed in position. (Where applicable)
Fitting List
A60
Pcs
Part Name
No.
B
C
D
E
F
G
J
K
L
60
72
12
20
8set
M
N16
P
Cam Stud (5137)
Cam
M8 x 25mm Wood Dowel
22
H
8
38
Q
14mm Chipboard Screw
64
6
M6 x 15mm Allen Bolt
M6 x 13mm Baller
45mm Chipboard Screw
60
M6 x 45mm Allen Bolt
M6 x 30mm Allen Bolt
2
M6 x 50mm Allen Bolt
M6 JCN Nut
16
M6 Allen Wrech
M6 x 25mm Allen Bolt
40mm Plate Nylon Castes
Hinges Arm
CK 6285
JASPER (#:FJASPBW)

5
GUIDE TO ASSEMBLY 20
STEP 1
DD
L
Dx 32 L x 8
08
11
14
17
08
11
14
17
B x 12 C x 12A x 2
STEP 2
C
JASPER (#:FJASPBW)
CK 6285

6
GUIDE TO ASSEMBLY 20
STEP 3
07
10
13
16
WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORRECT
BEFORE YOU INSERT CONNECTING BOLT
TURN CLOCKWISE UNTIL SECURE
CORRECT WRONG
19
20
Turn Over
B x 20 C x 24A x 3
06
06
CK 6285
JASPER (#:FJASPBW)

7
GUIDE TO ASSEMBLY 20
STEP 4
STEP 5 STEP 6
15
12
09
18
C x 8A x 16
19 06
06
07
JASPER (#:FJASPBW)
CK 6285

8
GUIDE TO ASSEMBLY 20
STEP 7 STEP 8
STEP 9 STEP 10
STEP 11 STEP 12
A x 5
06
08 09
08
07
06
07
09
11
10
20
11
10
12
JASPER (#:FJASPBW)
CK 6285

9
GUIDE TO ASSEMBLY 20
STEP 13
STEP 15
STEP 14
STEP 16
A x 4
A x 2
15 15
12
14
13
JASPER (#:FJASPBW)
CK 6285

10
GUIDE TO ASSEMBLY 20
STEP 17
STEP 19
STEP 18
B x 6 C x 4A x 6
05
04
21
18
17
16
JASPER (#:FJASPBW)
CK 6285

11
GUIDE TO ASSEMBLY 20
STEP 20
STEP 21
E x 12
21
05
21
21
G x 4
P x 4
E
E
E
E
E
P
G
G
G
G
P
P
JASPER (#:FJASPBW)
CK 6285

12
GUIDE TO ASSEMBLY 20
STEP 22
02
N
N
x2
N
N
01
N
N
x2
N x 16
02
02
01
01
03
04
STEP 23
K x 16
K
K
K
K
K
K
K
JASPER (#:FJASPBW)
CK 6285

13
GUIDE TO ASSEMBLY 20
STEP 25
STEP 24
J x 20
P x 20
33 x4
P
P
P
J
J
J
J
J
J
JJ
J
J
JP
P
P
P
PP
P
P
P
J
G x 4
P x 4
21
P
P
P
P
G
G
G
G
04
03
JASPER (#:FJASPBW)
CK 6285

14
GUIDE TO ASSEMBLY 20
STEP 27
STEP 26
H x 32
35 x16
H
H
H
H
H x 32
H
35 x16
H
H
JASPER (#:FJASPBW)
CK 6285

15
GUIDE TO ASSEMBLY 20
STEP 28
STEP 30
P
34
G
34
G x 1
P x 1
STEP 29
F x 4
P x 4
F
P
P
F
G x 1
P x 1
34
P
G
JASPER (#:FJASPBW)
CK 6285

16
GUIDE TO ASSEMBLY 20
STEP 32
STEP 31
22
23 x3
D x 16
L x 8
D
D
L
23
23
23
22
STEP 33
34
F x 4
P x 4
P
P
F
F
JASPER (#:FJASPBW)
CK 6285

17
GUIDE TO ASSEMBLY 20
STEP 35
STEP 34
C x 24
B x 22A x 22
Turn Over
Turn Over
Turn Over
28
28
30 x2
31
29
29
27
27
26
JASPER (#:FJASPBW)
CK 6285

18
GUIDE TO ASSEMBLY 20
STEP 38
STEP 36 STEP 37
30
29
30
28
29
30
29 27
30
STEP 39
JASPER (#:FJASPBW)
CK 6285

19
GUIDE TO ASSEMBLY 20
STEP 42
STEP 40
31
STEP 43
STEP 41
26
G x 12 D x 12M x 6
32 x2
G
G
G
G
G
G
D
M
G
JASPER (#:FJASPBW)
CK 6285

20
GUIDE TO ASSEMBLY 20
STEP 44
JASPER (#:FJASPBW)
CK 6285
