Behringer Minimic Mic800 User manual

Technical Specifications
Version 1.0 October 2005
MINIMIC MIC800

2
MINIMIC MIC800
MIC800
MINIMIC
Ultra-Compact Microphone Modeling Preamp
VUltra-compact 9.5" microphone modeling preamp for studio and stage
applications
VHigh-end preamplifier for all microphone, instrument and line-level sources.
Perfectlycomplementsstudio-gradecondensermics
VUltra-flexiblePreampModelingallowsyoutoquickly optimize yourrecordings
VChoosebetween16 preampvoicings designedforelectricandacousticguitars,
keyboards, bass guitars, drums, vocals, etc.
VAuthenticVTCTubeModelingtechnologycreates thewarmth ofvacuumtubes
VEquippedwithBEHRINGER’s sophisticatedoutputlimiter—preventstheoutput
signalfrombeing distorted
VDedicatedLowCutfiltereliminatesunwantednoise,e.g.floorrumble
V+48 V phantom power and 20 dB Pad for utmost flexibility
VVintage-styleVUmeterforpreciselevelindication
VHigh-qualitypotentiometersandilluminatedswitchesforlong-term reliability
VUltralow-noiseaudiooperationalamplifiersofferoutstandingsoundperformance
VAll Mini Series components can be stacked on top of each other to create an
ultra-compactsignalprocessorsolution
VHigh-qualitycomponentsandexceptionallyruggedconstructionensurelong
life
VConceivedand designed byBEHRINGERGermany

3
MINIMIC MIC800
DEUTSCH
SPECIFICATIONS
MIC INPUT
Type XLR connector (balanced)
Impedance approx. 2.6 kΩ (balanced)
Max. input level -2 dBu, +18 dBu with pad
LINE INPUT
Type ¼" TRS connector (balanced)
Impedance approx. 20 kΩ (balanced)
Max. input level +19 dBu, +28 dBu with pad
OUTPUT
Type ¼" TS connector (unbalanced)
Impedance approx. 130 Ω
Max. output level +15 dBu
SYSTEM SPECIFICATIONS
Frequency response MIC: 10 Hz to 90 kHz, ±3 dB
LINE: 10 Hz to 67 kHz, ±3 dB
Dynamic range 100 dB, 20 Hz to 20 kHz
Distortion 0.016 % typ. @ -16 dBu input
Signal-to-noise ratio: 86 dBu @ +4 dBu, a-weighted
BUTTONS
PAD 20 dB
Ø (phase inversion) 180°
PHANTOM power +48 V
CONTROLS
INPUT GAIN +26 dB to +60 dB
LOW CUT 15 to 360 Hz
OUTPUT LEVEL -oo dB to +10 dB
POWER SUPPLY
Mains connection external power supply, 9 V~ / 750 mA
Mains voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption approx. 5 W
DIMENSIONS/WEIGHT
Dimensions (H x W x D) approx. 1.89" (48 mm) x 9.55" (243 mm) x 4.72" (120 mm)
Weight approx. 0.84 lbs. (0,380 kg)
BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made, if necessary, without prior
notice. The specifications and appearance of the equipment may therefore differ from those listed or illustrated.
